4x M.2 SSD to 3.5in SATA HDD Adapter
35S24M2NGFF
*actual product may vary from photos
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 01/09/2015
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for StarTech.com 35S24M2NGFF
Summary of Contents for StarTech.com 35S24M2NGFF
- Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 01/09/2015...
- Page 2 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...
-
Page 3: Table Of Contents
Table of Contents Product Diagram ..................1 Front View ..............................1 Top View ............................... 1 Introduction ....................2 Packaging Contents ..........................2 System Requirements ..........................2 M.2 NGFF SSD Installation ..............2 System Installation ................7 Technical Support ..................8 Warranty Information ................8 Instruction Manual... -
Page 4: Product Diagram
Product Diagram Front View Top View 1. M.2 NGFF connectors 2. SSD Mounting holes 3. SSD standoff 4. SATA Power Port 5. SATA Data Port Instruction Manual... -
Page 5: Introduction
Introduction Packaging Contents • 1x 4x M.2 SSD to 3.5in SATA HDD Adapter (35S24M2NGFF) • 4x SATA data cables • 1x SATA power extension cable • 4x M.2 SSD Installation screws • 4x Bracket Mounting Screws. System Requirements • 4x M.2 NGFF SATA SSD Drive •... - Page 6 2. (Only required if any of the drive installation screws and standoffs requires relocating) Using a Philip’s head screw driver, remove the three board mounting screws pictured below. Instruction Manual...
- Page 7 3. (Only required if any of the drive installation screws and standoffs requires relocating) Remove the screw holding the SSD standoff you wish to move, from the reverse side using a small Phillip’s head screw driver (not included). 4. (Only required if the drive installation screw and standoff requires relocating) Remove the SSD installation standoff, and reseat it into the drive installation hole that matches your SSD.
- Page 8 5. Place the board back on the enclosure, lining up the mounting holes where the screws were earlier removed, and screw the board back into place, using a Philip’s head screw driver. 6. Slide the M.2 connector on the SSD into the M.2 receprical connector on the 35S24M2NGFF. Instruction Manual...
- Page 9 Note: The connector on your M.2 SSD is keyed so the drive will only fit one way. 7. Press the drive down toward the SSD standoff, and drive the removed screw through the mounting hole on your SSD drive and into the SSD standoff using the a Philips head screw driver.
-
Page 10: System Installation
1. Open your computer case (refer to the computer case user manual for details), and place the 35S24M2NGFF with installed M.2 NGFF SSDs into an available 3.5in bay. 2. Using four of the included computer case screws and a Phillip’s head screw driver. -
Page 11: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 12 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
