Getting Started

Use this Quick Start Guide as a basic reference to set up your Tempo

complete operation instructions, refer to the Tempo Go Operating Manual at

www.coachcomm.com/product/tempo-go/summary/.

CAUTION :

Allow only responsible individuals who have been properly trained to set up,

modify, and/or operate your system. Deploy your Tempo Go system on even

ground and beware of potential tipping hazards. Avoid deploying the system

when wind speed exceeds 20 mph. Failure to heed these recommendations

may result in system damage and personal injury.

Assemble the tripods.

Fully extend the two tripods. (Full extension is when the sliding plastic collar contacts the bolt near the bottom of the center tube.)

Then, place the tripods side by side, aligning the holes in each tripod's Leg 1. Secure with the provided pin as shown in Figure 2.

Figure 1: Leg 1 of Each Tripod

P r a c t i c e

H a r d w a r e Q u i c k S t a r t G u i d e

Go system. For

igure 2: Pinned Tripod Legs

S m a r t .

For setup and operation assistance, contact

CoachComm Customer Support.

CoachComm, LLC

Voice: 800.749.2761 or 334.321.2300

Fax: 866.793.SERV (7378) or 334.821.0397

customer.service@coachcomm.com

Table of Contents

Do you have a question about the TEMPO GO and is the answer not in the manual?

Page 1 Allow only responsible individuals who have been properly trained to set up, Fax: 866.793.SERV (7378) or 334.821.0397 modify, and/or operate your system. Deploy your Tempo Go system on even customer.service@coachcomm.com ground and beware of potential tipping hazards. Avoid deploying the system when wind speed exceeds 20 mph.
Page 2 Attach the mounting bracket. Insert the mounting bracket’s two posts into the tops of the tripods. Use two of the provided pins to secure the posts in place as shown in Figure 3. Figure 3: Mounting Bracket Secured to Tripods Mount the Control Unit and speakers.
Page 3 Note: If you are using an optional Tempest FX system with Tempo Go, CoachComm recommends that you power on your FX system before powering on your Tempo Go Control Unit and speakers. See Step 8 on the following page for more information about FX setup.
Page 4 FX (optional). ® You must have the most recent Tempest firmware before using Tempest FX with your Tempo Go system. A CoachComm technician will assist in upgrading your existing Tempest FX system. To connect the Tempest FX BaseStation to Tempo Go: 8a.
