Technical Bulletin #1
Objective: This document provides best-practice recommendations for using your X-System.
If you have any questions after reviewing this document, please consult the additional product documentation available at
www.coachcomm.com/x-system
Charging Your Cart Battery
Power up your sideline cart and check your battery bank status before needing to use your system.
Check your AC power switch.
•
door) must be in the RESET (ON) position for the cart battery bank to charge.
IMPORTANT:
CoachComm recommends leaving this switch in the ON position at all times.
•
Plug in your cart every week to charge.
being too low to power on or to charge with the onboard system.
»
If the cart has been stored with the breaker (located in the belly compartment)
in the ON position without connection to AC power during that time, the batteries
may be too low to power your system. Contact CoachComm Customer Support at
1.800.749.2761 for assistance if this occurs with your cart.
•
Turn breaker OFF when traveling.
battery circuit from damage resulting from an overload or short. The breaker should
be turned OFF when transporting the cart to away games and also if the cart is
stored for more than one week without use. Allow enough space to access the belly
compartment when storing or transporting so you can turn on the breaker and activate
the drive system to unload the cart.
Unlocking Your Roll-Up Door
For carts shipped in 2017 (those with a black rooftop),
the lock of the roll-up door before opening it
to break off in the lock. Improvements to this area of the cart will be implemented at a
later date.
C o a c h C o m m
or call Customer Support at 1.800.749.2761.
The cart's AC power distribution unit's switch (located on the front rack, behind the acrylic
AC Power Distribution Unit Switch
This prevents the cart battery bank from
The battery bank breaker protects the cart's
always remove your key from
. Failure to do so may cause the key
2017 Bulletin #1
Battery Breaker (On Position)
Roll-Up Door Keys
T e c h n i c a l B u l l e t i n
1
