CoachComm X-System Getting Started Manual

Hide thumbs Also See for X-System:
1
2
3
4

Advertisement

Table of Contents

Getting Started
This Game Day Guide is a basic reference for setting up your X-System. For complete operation instructions, see the
X-System Operating Manual, which is available on CoachComm's website at: www.coachcomm.com/x-system.
CAUTION:
Allow only responsible, authorized individuals who have read all of the instructions and warnings to set up and
operate your X-System.

X2 Package Overview

Field Antennas
with Mounting
Hardware
Game Day Guide
Wired BeltPack
Accessory Case
Storage for the following:
• 15 ft. Duracat 5 Cable
• 50 ft. Duracat 5 Cable
• 100 ft. Cat 5 Cable
• 25 ft. Bundled Cat 5 Wired
BeltPack Cable
• Booth Coaches' Headsets
• Booth Antenna and Accessories
(if applicable)
Sideline Case
Storage for Batteries*,
Chargers, and Power Cords
(Sideline headset storage in bottom)
*Spare lithium batteries are not allowed in
checked airline baggage. Be sure to follow
all air travel rules and regulations when
traveling with your X-System.
Radio Pack

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X-System and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CoachComm X-System

Summary of Contents for CoachComm X-System

  • Page 1: Getting Started

    Game Day Guide Getting Started This Game Day Guide is a basic reference for setting up your X-System. For complete operation instructions, see the X-System Operating Manual, which is available on CoachComm’s website at: www.coachcomm.com/x-system. CAUTION: Allow only responsible, authorized individuals who have read all of the instructions and warnings to set up and operate your X-System.
  • Page 2 1c. Connect power to the Press Box Rack Unit, but do NOT turn on the Control Unit (CU) yet. The “Power” LED on the front of the Wired Interface should be lit green. Important: X-System requires a minimum of one dedicated 15 amp 120V circuit. (1c.) Power LED Mount and connect the Antenna.
  • Page 3 No RF transmission will occur until the Home/Away status is selected. Failure to set this status properly may result in RF interference if and when the opposing team is also using an X-System. It is important to coordinate with opponents to ensure optimal performance for both teams.
  • Page 4 While CoachComm makes every attempt to maintain the accuracy of the information contained in this document, this information is subject to change without notice. Please check our website for the latest system specifications and certifications. Copyright © 2018 CoachComm LLC. All rights reserved. The X-System logo is a...
