Appendix A
Main Bus Outputs
1/4" TRS Jack Socket
Pin Description
Tip Signal +ve (Hot)
Ring Signal -ve (Cold)
Sleeve 0 V Chassis
Main Monitor Outputs
1/4" TRS Jack Socket
Pin Description
Tip Signal +ve (Hot)
Ring Signal -ve (Cold)
Sleeve 0 V Chassis

Insert Sends/Returns

1/4" TRS Jack Socket
Pin Description
Tip Signal +ve (Hot)
Ring Signal -ve (Cold)
Sleeve 0 V Chassis

DC Power Inlet

4-pin DIN Male
Pin Description
1,4 +15 V, 3.3 A
2,3 0 V Common
Shell Chassis
40
Bus B Outputs
1/4" TRS Jack Socket
Pin Description
Tip Signal +ve (Hot)
Ring Signal -ve (Cold)
Sleeve 0 V Chassis
Alternate Monitor Outputs
1/4" TRS Jack Socket
Pin Description
Tip Signal +ve (Hot)
Ring Signal -ve (Cold)
Sleeve 0 V Chassis
