ST CUE 1 TO G COMP & SUM TO MAIN BUS
This somewhat strangely named switch/feature allows the use of Stereo Cue 1 to create parallel mixes. A typical example is where
you want to use the bus compressor to act on a drum mix and this to then be summed in parallel to the main mix i.e. creating a
compressed drum mix, but with other elements left uncompressed. By creating the parallel drum mix on Stereo Cue 1 from the
console's channels, if you then press ST CUE 1 TO G COMP & SUM TO MAIN BUS the Stereo Cue 1 mix passes through the G
Series Bus Compressor and it is summed with the Main mix, while the Main mix bypasses the G-Series Bus Compressor. e.g.
Normal signal flow:
Channel OP
St Cue 1 OP
With ST CUE 1 TO G COMP & SUM TO MAIN BUS selected:
Channel OP
St Cue 1 OP
Main Mix Bus Block Diagram
MAIN
L R L R MIX BUS B AFL
L R L R
L
SUM IP
TO MAIN
R
EXT 1
FROM
EXT 1
EXT 2
FROM
EXT 2
18
Main Bus Main Insert
St Cue 1 Master
St Cue 1 Bus
(+Ext/Talk Sum)
Main Bus Main Insert
St Cue 1 Master
St Cue 1 Bus
(+Ext/Talk Sum)
SEND
+
-
SEND
+
-
G Bus Comp
St Cue 1 Output
SUM
G Bus Comp
BUS COMP to
∑ ST CUE 1
G SERIES BUS COMP
T/HOLD MAKE UP
AUTO
INSERT
RLS
RETURN
+
VCA
-
S/C
VCA
RETURN
+
VCA
-
S/C
VCA
FROM
ST CUE 1
MUTE
LEVEL
to +10dB
BUS B
TO MON
Main Fader
Main Fader
St Cue 1 Output
IN
USB
SEND
13/14
+
L
-
BUS B
OUT
+
R
-
BiG SiX User Guide
Main Output
Main Output
USB
SEND
15/16
+
L
-
MAIN
OUT
+
R
-
MAIN BUS
TO MON
