Directed Electronics PYTHON N426P Installation Manual

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

M M o o d d e e l l 4 4 6 6 0 0 H H P P

I I n n s s t t a a l l l l a a t t i i o o n n G G u u i i d d e e

NOTE:

This product is intended for installation by a professional installer only!

Any attempt to install this product by any person other than a trained professional

may result in severe damage to a vehicle's electrical system and components.

N426P 07-05

Table of Contents

Need help?

Do you have a question about the PYTHON N426P and is the answer not in the manual?

Questions and answers

Summary of Contents for Directed Electronics PYTHON N426P

Page 1 This product is intended for installation by a professional installer only! Any attempt to install this product by any person other than a trained professional may result in severe damage to a vehicle’s electrical system and components. © 2005 Directed Electronics, Inc. Vista, CA N426P 07-05...
Page 2: O O N N - - B B O O A A R R D D D D U U A A L L - - S S T T A A G G E E S S H H O O C C K K S S E E N N S S O O R
® Trademarks of Directed Electronics, Inc. w w w w w w . . d d i i r r e e c c t t e e c c h h s s . . c c o o m m D D i i r r e e c c t t F F a a x x 8 8 0 0 0 0 - - 9 9 9 9 9 9 - - 1 1 3 3 2 2 9 9 T T e e c c h h n n i i c c a a l l S S u u p p p p o o r r t t 8 8 0 0 0 0 - - 7 7 5 5 3 3 - - 0 0 8 8 0 0 0 0 These resources are for authorized Directed Dealer use only.
Page 3: Table Of Contents
W W i i r r i i n n g g Q Q u u i i c c k k R R e e f f e e r r e e n n c c e e G G u u i i d d e e ........................................2 2 9 9 2005 © Directed Electronics, Inc. all rights reserved...
Page 4: Primary Harness Wiring Diagram
NOTE: If using the H1/1 ORANGE wire to activate an add-on accessory such as window automation, pager or voice module a 1Amp diode must be installed to ensure proper operation. Insert the diode as shown in the following diagram. © 2005 Directed Electronics, Inc. all rights reserved...
Page 5 SPDT relay must be used on the H1/2 light flash output wire. IMPORTANT! DO NOT connect this wire to a negative vehicle light flash wire before changing the programming jumper to the negative polarity position or damage to vehicle light circuit may occur. 2005 © Directed Electronics, Inc. all rights reserved...
Page 6 IMPORTANT! This output is only intended to drive a relay. It cannot be connected directly to the domelight circuit, as the output cannot support the current draw of one or more bulbs. © 2005 Directed Electronics, Inc. all rights reserved...
Page 7 (+)12V when any door is opened. This wire will report Zone 3. NOTE: If using a door trigger wire that has a delay, Advanced Menu 2, feature 6 or the 998T Bitwriter can be used to turn Bypass Notification off. ® 2005 © Directed Electronics, Inc. all rights reserved...
Page 8 Connect this to the RED wire of the Revenger siren. Connect the BLACK wire of the siren to (-) ® chassis ground, preferably at the same point you connect the control module’s BLACK ground wire. © 2005 Directed Electronics, Inc. all rights reserved...
Page 9 IMPORTANT! Never use this wire to drive anything but a relay or a low-current input! The transistorized output can only supply 200 mA of current. Connecting directly to a solenoid, motor, or other high-current device will cause it to fail. 2005 © Directed Electronics, Inc. all rights reserved...
Page 10: Super Bright Led, 2-Pin White Plug
LED wires are not shorted to ground as the LED will be damaged. Multiple LED’s can be used, but they must be wired in series. The LED fits into a 9/32-inch mounting hole. Be sure to check for clearance prior to drilling the mounting hole. DIA-41 © 2005 Directed Electronics, Inc. all rights reserved...
Page 11: Valet/Program Switch, 2-Pin Blue Plug
After determining the best mounting location, follow these steps: 1. Clean the mounting area with a quality glass cleaner or alcohol to remove any dirt or residue. 2. Plug the receiver/antenna cable into the receiver/antenna. 2005 © Directed Electronics, Inc. all rights reserved...
Page 12 Note: When adjusting the sensor, it must be in the same mounting location that it will be after the installation is completed. Adjusting the sensor and then relocating the module requires readjustment. © 2005 Directed Electronics, Inc. all rights reserved...
Page 13: Light Flash Jumper
IMPORTANT! DO NOT connect the H1/2 light flash wire to a negative vehicle light flash wire before changing the programming jumper to the negative polarity position or damage to vehicle light circuit may occur. 2005 © Directed Electronics, Inc. all rights reserved...
Page 15 Once a feature is programmed: ➤ ➤ Other features can be programmed within the same menu. ➤ ➤ Another menu can be selected. ➤ ➤ The learn routine can be exited if programming is complete. 2005 © Directed Electronics, Inc. all rights reserved...
Page 16 To exit the learn routine do one of the following: ➤ ➤ Close the open door. ➤ ➤ Turn the ignition on. ➤ ➤ No activity for longer than 15 seconds. ➤ ➤ Press the Valet/Program switch too many times. © 2005 Directed Electronics, Inc. all rights reserved...
Page 17: Menu #1 - Basic Features
Channel 3: latched/latched, reset with ignition/30-second timed/ second unlock output* 2-11 Comfort Closure (On) (20 sec.) Comfort Closure (Off) *Second unlock is only available if Feature 2-8 is programmed to single pulse. 2005 © Directed Electronics, Inc. all rights reserved...
Page 18: Menu #1 - Basic Features
3.5 second pulses, will accommodate the door lock interface in these vehicles. The default setting is 0.8 second door lock pulses. For some vehicles a 0.4 second pulse duration is required to prevent the windows from moving. © 2005 Directed Electronics, Inc. all rights reserved...
Page 19 , the siren can be programmed to sound ® for any length of time ranging from 1 to 180 seconds. Using the SELECT button of the 998T Bitwriter will adjust the siren duration in one second increments. ® 2005 © Directed Electronics, Inc. all rights reserved...
Page 20 At the same time, the GREEN H2/A wire will supply two positive pulses instead of a single pulse. This makes it possible to directly interface with double pulse vehicles without any extra parts. © 2005 Directed Electronics, Inc. all rights reserved...
Page 22 This will erase any lost or stolen transmitters from the system's memory. It can also be used to start from scratch if the trans- mitter buttons were programmed incorrectly. © 2005 Directed Electronics, Inc. all rights reserved...
Page 23: Standard Configuration
An expanded configuration transmitter allows arming, disarming, and Panic Mode activation with separate buttons. When programmed for expanded configuration, the transmitter buttons are assigned to the following functions: 2005 © Directed Electronics, Inc. all rights reserved...
Page 24: Arm/Disarm Diagnostics
System Status Chirps Action Number of Chirps Description System armed 1 (3 second delay), 1 System armed with Bypass Notification Disarm System disarmed Disarm System disarmed with Tamper Alert Disarm System disarmed NPC active © 2005 Directed Electronics, Inc. all rights reserved...
Page 26 Rapid Resume Logic ensures that the when the system is powered up it will return to the same state it was in when power is disconnected. For a full description of Rapid Resume Logic refer to the owner's manual. © 2005 Directed Electronics, Inc. all rights reserved...
Page 27 ➤ programmed Valet pulse count. Status LED doesn’t work. Make sure that it is plugged in. (See Plug-In Harnesses section of this guide.) Is the LED ➤ plugged into the correct socket? 2005 © Directed Electronics, Inc. all rights reserved...
