Tally Dascom DL-830
GateWay – User defined. If Static Address Method is selected, type in the gateway address of the
network.
WiFi Port – Default value = 9100
Specification:
Item
Wireless Standard
Frequency Range
Receiver Sensitivity
Data Rate
Modulation
Transmit Power
Antenna Interface
Parameters
IEEE802.11b/g/n
2.412~2.484 GHz
802.11b: -82 dBm @ 11Mbps （typical）
802.11g: -68 dBm @ 54Mbps（typical）
802.11b: 1,2,5.5,11 Mbps
802.11g: 6,9,12,18,24,36,48,54 Mbps
DSSS, OFDM, DBPSK, DQPSK, CCK, QAM16/64
802.11b: 16±2 dBm（typical）
802.11g: 13±2 dBm（typical）
IPX/microstrip antenna
55
User Guide V1.0
