Tally Dascom DL-830

6.3 Parallel

Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19~30
31
32
33
34~35
36
Remarks: H - signal source from host; P - signal source from printer.
1284-B Connector:
Source
H
STROBE*
H
Data0 (LSB)
H
Data1
H Data2
H Data3
H
Data4
H
Data5
H
Data6
H Data7 (MSB)
P
ACK*
P BUSY
P
PError
Not Connected
－
Not Connected
－
Not Connected
－
Logic Ground
Chassis Ground
5V/500mA driver
－
Logic Ground
INIT*
－
P FAULT*
Logic Ground
Not Connected
－
Not Connected
Signal Name
53
User Guide V1.0
