W i d e Fo r mat Pr inte r
Te r i o s t a r LP-20 6 0 S e r i e s
Multifunction Model
LP-2060-MF
Printer Model
LP-2060
User's Manual
U10000138300 December, 2017 Rev. 2
for Basic Printer Operation
Chapter
1
Chapter
2
Chapter
3
Chapter
4
Chapter
5
Chapter
6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LP-2060-MF and is the answer not in the manual?

Questions and answers

Related Manuals for Oki LP-2060-MF

Summary of Contents for Oki LP-2060-MF

  • Page 1 Chapter W i d e Fo r mat Pr inte r Te r i o s t a r LP-20 6 0 S e r i e s Multifunction Model LP-2060-MF Chapter Printer Model LP-2060 Chapter User's Manual for Basic Printer Operation Chapter U10000138300 December, 2017 Rev.
  • Page 2 U10000138300 December, 2017 Rev. 2 Copyright© 2016 OKI Data Infotech Corporation. All rights reserved. The contents of this manual may be changed without prior notice. This product supports TCP/IP (IPv4/IPv6). This product displays fonts created by TypeBank Co., Ltd. and ARPHIC TECHNOLOGY.
  • Page 3 To handle the Printer safely and correctly, be sure to read the Safety Precautions carefully before use. Keep this manual in a place where you can easily read it when required. The LP-2060 printer model may not be sold in some countries or regions. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 4: Safety Precautions

    This symbol indicates a prohibited action. The example on the left means Do not disassemble. This symbol indicates required actions or instructions. The example on the left means Disconnect the power plug from the outlet. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 5 120V and a rated current of 16A or more, or to a power socket with a rated voltage of 230V and a rated current of 9A or more. To prevent a fire or electric shock, avoid the sharing of power with other equipment. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 6 Install the Printer close to a power outlet. Make sure the outlet is easy to reach in case the power plug needs to be disconnected in an emergency. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 7 Before moving the Printer from its current installation location to another location, contact your service representative. In addition to the items above, observe the warnings and precautions in each section of the manual. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 8: Warning Labels

    Make sure you understand the information on the warning labels before handling the Printer. (2) Instruction label to remove jams (1) HIGH TEMPERATURE caution label (1) HIGH TEMPERATURE caution label (1) HIGH TEMPERATURE caution label (3) Caution label to prevent hands from being stuck LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 9 (3) Caution label to prevent hands from being stuck This label raises your caution to prevent your hands from being stuck between the Printer and the scanner. On closing the scanner, do not place your hands near this label. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 10: Reading The Manual

    Printer and the users of the Printer. Chapter 6 describes the action to solve a Printer problem. Take appropriate action by following the instructions in this chapter. Appendix contains the Printer's basic specifications, command lists, and menu structure. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 11: Notations

    ‹ D-SCAN format Note that the following related to D-SCAN is applied only for the customers in Japan. - All descriptions in the documents for LP-2060/LP-2060-MF. - All messages appearing on the operation panel. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 12: Supplied Items

    To the 200V system printers, two types of the power cords are attached. Power cord To the 120V system printers, no power cord is attached as it is already mounted and fixed to the printers. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 13: Consumables

    For high-speed PDF print operation using TerioStation PDF Print LP-874 TerioStation. ActiveActive Directory To perform individual authentication using LP-868 authenticationDirectory Active Directory. Smart card authentication To perform individual authentication using smart cards. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 14 LP-819 Carrier Sheet Set LP-874 TerioStation PDF Print LP-868 Active Directory authentication LP-854 STACKER STD LP-863 Catch Basket LP-859 Bucket (W) LP-858 Original Stacking tray Smart Card Authentication Kit LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 15: Table Of Contents

    Environment Requirements ....................26 Ensure Good Ventilation.......................27 Installation/Maintenance Space ..................28 Supported paper ........................29 Part Names and Functions.................32 Front Side ............................32 Left Side and Rear Side ......................33 Inside ..............................34 Operation Panel ........................35 Mode Screen ....................39 LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 16 Handling Print Jobs ......................... 74 Web Functions .....................75 Functions ............................75 Cleaning the Exterior ..................77 Using Paper from a New Size Standard ..........78 Using Paper from a User Defined Series ..........80 Restricting the Available Rolls ..............82 LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 17 Setting Parameter Table in PDL Setting Menu .............118 PDL Parameter Priority Mode..................119 Paper Parameters........................120 Drawing Parameters ......................126 Scale Parameters ........................129 Format Parameters (only with HP-GL and D-SCAN) .........136 Pen Parameters (only with HP-GL and D-SCAN) ..........142 LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 18 Submission Destination Setting Menu ..........157 Adjustment Menu ..................161 Smart card settings Menu ...............162 Import/Export Menu ................163 Export Operation ........................167 Import Operation ........................168 Date and Time Settings Menu ..............169 Delete HDD Data Menu ................170 LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 19 Print Job Box Settings Menu ..............173 Print Job Box Operation ................175 Using Smart Cards with the Print Job Box Function ......178 Preparation ..........................178 Smart Card Registration Procedure ................178 Print Procedure Using a Smart Card ................182 LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 20 One-time Password Authentication ................218 AD-related Attributes Location ..................221 Smart Card Registration Procedure ............222 Preparation 1 ..........................222 Preparation 2 ..........................222 Registration of Smart Cards by Users with the Printer ........223 LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 21 Procedure to Check the Error Log ................236 Error Log List ..........................236 Ethernet Troubleshooting ..............247 Image Quality Defects ................249 Unusual Sound ..................250 When you have set the wrong language ..........251 LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 22 List of HP RTL Printing Commands ................278 List of D-SCAN Format Commands ................280 TIFF Tags ............................286 CALS Format Record ......................287 Commands Supported by lpd ..................289 xpt (socket I/F) ......................... 289 LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 23: Chapter Before Use

    Chapter 1 describes the information required for using the Printer. Be sure to understand the basic information described in this chapter before moving to the next chapters. Chapter Chapter Contents Features ....................24 Operation Requirements ..............26 Part Names and Functions ..............32 Chapter Mode Screen ....................39 Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 24: Features

    Features Chapter This manual explains the operation for LP-2060-MF/LP-2060 Wide Format Printer, that is: - A monochrome raster printer with electro photographic technology, to receive and Print the graphic data created on a workstation or personal computer Chapter (referred to as “computer” in this manual).
  • Page 25 75 g (2.11oz)/m ), and film are available in roll paper supported format. Select the paper type depending on your purpose. An original is scanned and copied at 600 dpi resolution. High resolution scanner unction LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 26: Operation Requirements

    In such a case, to solve them you are recommended to increase the room temperature to be within the range 20˚C to 30˚C (68 to 86˚F). LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 27: Ensure Good Ventilation

    Also, chemical substances may be emitted during printing operations. Ensure enough ventilation and air circulation for safe use of the Printer. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 28: Installation/Maintenance Space

    (23.62) (39.37) (39.37) (11.81) (Printer front) (Printer front) Chapter 2100 (82.68) 3200 (125.98) Unit: mm (inches) Chapter 2000 mm (78.74 inches) in height Note Before relocating the Printer, contact your service representative. ‹ LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 29: Supported Paper

    Use the OKI Data Infotech-specified roll paper listed below. Note Chapter If the installed paper is not OKI Data Infotech-specified, the image quality is ‹ not guaranteed and the Printer malfunction may occur. Store the paper carefully, following the instructions below.
  • Page 30 (17 inches) (11 inches) 431.8 mm 279.4 mm B standard size (17 inches) (11 inches) 11 inches (279.4 mm) 279.4 mm 215.9 mm A standard size (11 inches) (8.5 inches) „ 30×42 Series LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 31 (19.69 inches) (19.69 inches) 500.0 mm 353.0 mm B3 standard size (19.69 inches) (13.90 inches) „ User-defined Series Chapter With user-defined series, standard-size printing is not available. All printing is performed at actual length. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 32: Part Names And Functions

    (5) Toner door/document table Open to replace the toner cartridge. ( & page 55) (6) Scanner cover Open to clear an original jam. ( & page 233) Roll 4 Roll 3 U001XXXXXXXX U001XXXXXXXX LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 33: Left Side And Rear Side

    Open when replacing a waste toner bottle. ( & page 60) (6) Outlet slot Outputs paper. (7) Original output guide Guides the scanned original to the proper position. (8) Output tray Stores output paper sized A3 or smaller. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 34: Inside

    (7) Ethernet interface connector The interface connector for 1000BASE-T, 100BASE-TX, and 10BASE-T. (8) USB port Used to connect a smart card reader or a USB drive. (9) Power cord Insert into a power outlet. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 35: Operation Panel

    The layout for the keys, lamps, and touchpanel screen on the operation panel is shown in the following figures. Chapter „ Multifunction Model Chapter Chapter ( & page 39) „ Printer Model Chapter Chapter ( & page 39) LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 36 Red: Error lamps Red (lights up): Indicates that an error has occurred for the corresponding mode. REMOTE lamp Green (lights up): Indicates data transmission with connected computers or access from Web functions. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 37 Changes, enters, or cancels the setting values. +/- button Uses to enter the values. Enter button Confirms the setting values. Cancel button Cancels the input operation or the last scanned document when copies are stored. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 38 Chapter Starts scanning the original or stops scanning in progress. STOP FEED button Stops the scanning of the original. Chapter START button Starts the scanning of the original. Chapter Chapter Chapter Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 39: Mode Screen

    Shows the Printer's status and a computer connected to the settings. network. For the structure of the Setup For more details, see the menu, see the following page. separate User's Manual for Multifunction Printer Operation. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 40 Port 1_CALS Paper Parameters (& page 120) Drawing Parameters (& page 126) Scale Parameters (& page 129) Port 20_CALS Raster Parameters (& page 146) PDC Parameters (& page 147) Stamp Parameters (& page 150) LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 41 Replacing the Process Cartridge ............66 Job Operation ..................73 Web Functions..................75 Chapter Cleaning the Exterior ................77 Using Paper from a New Size Standard ..........78 Using Paper from a User Defined Series ..........80 Restricting the Available Rolls .............82 LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 42: Turning The Power On/Off

    POWER on the operation panel. Note Do not turn off the main power switch while data is being processed. The ‹ system may crash. Chapter Operation panel POWER button Chapter Heater switch Chapter Chapter Main power switch LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 43: Powering On

    POWER on the Chapter Printer's operation panel. The first time the power is turned on after purchasing the Printer, guidance is displayed for initial settings such as the panel language. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 44 Select No to keep the waiting print jobs. In this case, the waiting print jobs are printed when the Printer starts. After about 10 seconds, No is automatically selected and the message disappears. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 45: Powering Off

    Always turn off the power using the POWER button on the operation panel. ‹ Directly turning off the main switch may damage the data stored inside the Printer. Do not turn off the power when the REMOTE lamp is flashing. ‹ LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 46: Replacing The Roll Paper

    ‘ When the prompt message to supply paper appears, press Alternative Printing to print with: - a paper size bigger than the requested paper; or - a paper type different from the requested paper. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 47: Replacement Precautions

    Be careful not to drop the roll paper onto the flange guide. The flange guide ‹ may be damaged. The flange guide will be damaged if you drop the roll paper when the paper ‹ flanges are installed. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 48: Removing The Roll Paper

    The risk of trapping your hand will increase. Chapter Note Use the OKI Data Infotech-specified roll paper. If your paper is not OKI Data ‹ Infotech-specified, the image quality is not guaranteed. Store paper in a cool, dark, and dry place ‹...

  • Page 49: Installing The Roll Paper

    CLOSE direction. Knob Note If a paper flange knob is too loose, the roll paper will move from side to side. ‹ There will be a negative effect on printing. Fasten the knobs tightly. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 50 A2 or less. When installing a roll paper size of A1 or larger, get the help of another person to carry the roll paper. Installing the paper by yourself may injure your back. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 51 Dispose of the cut paper. Chapter Cutter Note After cutting the paper, move the cutter to the arrowed position in the right or ‹ left. Caution Be careful not to injure yourself on the cutter. ‹ LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 52 ‘ When you set a roll paper of a different type or series, press Paper on the supply paper error screen. Set the type and the series of the new paper roll on the paper setting popup screen which appears. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 53: Replacing The Toner Cartridge

    To avoid this, replace the toner as soon as possible when the toner level runs low. The Supply Toner screen may not disappear if you replace only one toner ‹ cartridge after the toner has run out. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 54: Handling Precautions

    After installing a new toner cartridge, try to use it all within 6 months. If a ‹ long period of time elapses after installing a cartridge, the printing quality will deteriorate. Store toner cartridges in a cool and dark place. ‹ Use genuine toner cartridges. ‹ LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 55: Toner Replacement Procedure

    Do not replace the toner cartridge twice consecutively. ‹ Chapter With your both hands, open the toner door (or document table Chapter Warning Never refill an empty toner cartridge with toner. A malfunction may ‹ result. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 56 Shake up and down, and left to right, 10 times in each direction. Chapter Set the toner cartridge into the Printer. Insert the toner cartridge by aligning the tabs on the cartridge with the guide rails on the Printer. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 57 Chapter With your both hands, Close the toner door (or document table The toner mixing takes about 1 minute. Chapter ‘ Dispose of the used toner cartridge according to the local regulations. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 58: Replacing The Waste Toner Bottle

    Chapter Chapter ‘ An instruction label to replace waste toner bottle is affixed to the side of the waste toner bottle. Refer to this when replacing the waste toner bottle. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 59: Replacement Precautions

    Do not reuse the waste toner bottle or the toner inside the waste toner ‹ bottle. Chapter ‹ Waste Toner Bottle Replacement Procedure Remove the new waste toner bottle from its box. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 60 Chapter Chapter Remove the waste toner bottle from the Printer. ① (1) Lift up the waste toner bottle. (2) Pull out the bottle towards you from the bottom. ② LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 61 (2) Lower the bottle to the floor of the Printer, and stabilize it. ② Chapter Close the waste toner door. Chapter ‘ Dispose of the waste toner bottle according to the local regulations. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 62: Replacing The Charger Unit

    Put the document table in the vertical position. Chapter Press the latch button, and open the fuser unit drawer. Chapter Chapter By rotating the right and left outer- side knobs counterclockwise, release the process cartridge drawer's lock. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 63: T Replacing The Charger Unit

    At the step 3, rotate the outer-side knobs. Inner-side knob Chapter U00120305200 Outer-side knob Pull out the process cartridge to your Chapter side by holding its green-indicated parts. Chapter Chapter Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 64 Remove a new charger unit from its Chapter box. Chapter Install the new charger unit by aligning its | mark with the process Chapter cartridge’s | mark. The charger unit does not have right and left sides. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 65 Close the process cartridge drawer. Chapter Chapter By rotating the outer-side knobs, fix the process cartridge. Chapter Close the fuser unit drawer. Chapter By pressing the POWER button on the operation panel, turn on the printer. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 66: Replacing The Process Cartridge

    Printer. So it does not affect the print quality. To prevent the waste toner from being spilled, be careful not to expose the ‹ process cartridge to strong shaking, tilting, or impacts. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 67: Process Cartridge Replacement Procedure

    Chapter Chapter ‘ Note that the knobs are classified into two: inner-side ones and outerside ones. At the step 4, rotate the outer-side knobs. Inner-side knob U00120305200 Outer-side knob LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 68 Chapter Chapter ‘ To the used process cartridge, attach the protective case removed from a new process cartridge at the step 8. Then dispose of it according to the local regulations. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 69 With the protective case still attached, install the process cartridge in the Printer so that both of green arrow labels on the protective case and Chapter Printer are aligned. Chapter Remove the protective case of the Chapter process cartridge. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 70 Chapter Rotate the knob at the center to remove it, and then dispose of it. Chapter Chapter Close the process cartridge drawer. Chapter By rotating the outer-side knobs, fix the process cartridge. Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 71 (1) Turn the knob and remove the cover. (2) Replace the filter inside. Chapter (3) Reinstall the cover. (4) Replace the small filter on the other side following the same procedure. Chapter Chapter Chapter Close the fuser unit drawer. Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 72 ‘ Install the filter cover in any direction. Chapter Chapter Chapter ‘ Dispose of the two removed filters according to the local regulations. By pressing the POWER button on the operation panel, turn the Printer on. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 73: Job Operation

    ‘ To be able to display and manipulate completed jobs, Save/Delete Complete Job in the system settings must be set to Save. This parameter is set to Delete by default. & page 108 for more details. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 74: Printing Pause And Cancellation

    Press Job on the print mode top screen to display the print job screen. Chapter The following operations can be performed from the print job screen. - Changing printing order and cancelling waiting jobs - Cancelling processing jobs - Deleting completed jobs Chapter Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 75: Web Functions

    PDC submission destinations as well. (7) Image browsing, acquisition, and deletion in the submission box Enables the browsing, acquisition, and deletion of image data stored in the submission box of the Printer. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 76: T Web Functions

    (1) Install a Web browser on the host computer. Microsoft Internet Explorer Ver. 6.0 or higher Chapter (2) Open the Web browser. (3) Enter "http://(IP address set on the Printer)/" in the address field, and press ENTER. Chapter Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 77: Cleaning The Exterior

    If the Printer exterior becomes dirty, soak a soft cloth in water or a neutral detergent diluted with water. Wring the cloth thoroughly, and then wipe the Printer. Chapter Warning Never use volatile solvents such as thinner, benzene, or alcohol. ‹ Chapter Chapter Chapter Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 78: Using Paper From A New Size Standard

    105). You are recommended to set all unrequired roll widths to Off. Note It is not possible to set all the paper size standards in the same size standard ‹ to Off When the Paper Size Standards setting is changed, the Printer restarts. ‹ LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 79 Chapter Supplied Paper to ANSI series ( & page 120). (6) Unexpected operation If the set series does not operate as expected, check the settings again from (1) to (5). Chapter Chapter Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 80: Using Paper From A User Defined Series

    Off. Note It is not possible to set all the user defined series rolls to Off. ‹ When this setting is changed, the Printer restarts. ‹ LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 81 Also, when performing user defined operations with the printer driver, set Printer Drive to User Defined ( & page 137). (7) Unexpected operation Chapter If the user defined series does not operate as expected, Again check the settings (1) to (6). Chapter Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 82: Restricting The Available Rolls

    On in Paper Size Standards. are available. When the roll that will produce the least wasted paper is not set in the Printer, a message prompting paper setting is displayed on the operation panel. Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 83 Function Menu ..................153 Options Settings Menu................156 Chapter Submission Destination Setting Menu ..........157 Adjustment Menu .................161 Smart card settings Menu ..............162 Import/Export Menu ................163 Date and Time Settings Menu ............169 Delete HDD Data Menu ...............170 LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 84: Menu Mode Screen

    The following procedures are displayed on the screen. (7) Function Menu • Replace the Toner Cartridge • Replace the Waste Toner Bottle ( & page 153) • Load Roll Paper • Clear Paper Jams • Clear Original Jams LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 85 ( & page 162) (21) Delete HDD Data Menu This menu is displayed only when the smart card option is enabled. ( & page 170) Chapter (18) Import/Export Menu ( & page 163) LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 86: Confirming Printer Restart

    Chapter top screen is exited. Chapter Chapter To continue configuration, press No. When configuration is complete, press Yes to restart printer. Setting changes are not applied until the printer is restarted. Chapter Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 87: Paper Menu

    When you intend to install the rolls of a specif ic size standard, you are recommended to specify the size standard rather than Auto. A series A0 (841 mm (33.11 inches)), A1 (594.5 mm (33.11 inches)), A2 (420.5 mm (16.56 inches)), A3 (297.3 mm (11.70 inches)) LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 88 30x42 series User Defined series ARCH series MAP series Note Chapter As options, the Printer displays only the paper size standard set to On in ‹ Available Size Standards in the System menu. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 89: Printer Engine Menu

    Sets the data waiting time after which the end of the roll paper is cut automatically. This is performed when data is received for printing after the data waiting status has continued for a while. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 90: Top Cut At Door Open

    ‘ With this function, the top of the roll paper is cut with the printer's cutter. Set for a clean cut on the top of the paper of the output page. Chapter <Parameter by selecting options> : Default value Does not cut the paper. Cuts the paper. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 91: Print Density

    : Default value Power saving is low, but warm-up time is short. Medium Power saving is fairly high, but warm-up time is fairly long. High Power saving is high, but warm-up time is long. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 92: Output Report To Tray

    Prints with other large paper roll. Print is not performed with a different paper and an error Chapter specifying that there is no more paper is displayed. Load an A3 paper roll to print the report. Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 93: Communication Parameters

    Sets the IP address (Internet address) of the Printer. This parameter is the same as the parameter that is set in the installation operation. <Parameter by entering numbers> 0.0.0.0 to 255.255.255.255 Default value: 192.168.100.100 LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 94: T System Menu

    0 to 15 characters Chapter Connection Speed Sets the communication speed. <Parameter by selecting options> : Default value Auto Automatically recognizes 1000BASE-T, 100BASE-TX, or 10BASE-T. 1000 Sets to 1000BASE-T. Sets to 100BASE-TX. Sets to 10BASE-T. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 95 The default name is public. Chapter Up to 63 characters can be used for this setting. SNMP Version Sets the version of the SNMP to use. <Parameter by selecting options> : Default value Version 1 Version 2 LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 96 <Parameter by entering characters in IPv4/IPv6 format> Chapter 0 to 63 characters Prefix Length Sets the prefix length when IPv6 Address Manual Setting is On. <Parameter by entering numbers> Chapter 0 to 128 Default value: 64 LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 97 0.0.0.0 (not set) Network Address 01 to 10 Chapter Sets the network address. <Parameter by entering numbers> 0.0.0.0 to 255.255.255.255 Default value: 0.0.0.0 (not set) The network address set to 0.0.0.0 specifies the default routing LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 98 TRAP 1 to 5 Agent Computer Sets the IP address of the agent computer to return a trap. This setting is not required when, at the submission function, the destination is specified with an IP address. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 99 TRAP Agent Computer. Note that when this setting is 0.0.0.0, a trap is sent for all the received jobs. <Parameter by entering numbers> 0.0.0.0 to 255.255.255.255 Default value: 0.0.0.0 LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 100 Specifies whether or not the user logs in Active Directory. In principle, this setting should not be changed. <Parameter by selecting options> : Default value Logged In Logs in Active Directory. Not Logged In Does not log in Active Directory. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 101 Sets the user name and the password for the SMTP server when With SMTP Authentication is set to On. Maximum E-mail Data Size Sets the maximum size of the attached file. <Parameter by selecting options> : Default value 1 to 4096 Default value: 25 Unit: MB LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 102 The time zone of Japan is + 09 00. Left box <Parameter by selecting options> : Default value Chapter Middle box <Parameter by selecting options> 00 to 14 Default value: 09 Right box <Parameter by selecting options> : Default value LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 103 When the set time elapses, the TWAIN mode is exited. <Parameter by selecting options> : Default value 30 minutes Performs timeout after 30 minutes. 60 minutes Performs timeout after 60 minutes. Chapter 90 minutes Performs timeout after 90 minutes. Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 104: Available Size Standards

    - Size Standard in the Paper menu - Size of Automatically Supplied Paper in PDL Setting - Original size standard at copy setting - Original size standard at submission setting LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 105: Paper Size Standards

    It is not possible to set all the items in the same series to Off at the same ‹ time. Chapter In a same size standard, it is not possible to set all the sizes to Off at the ‹ same time. Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 106: User Defined Size

    Printer restarts. This setting is available when User Defined series is set to ON in Available ‹ Size Standards. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 107: Printer Settings

    : Default value English Italiano Русский 日本語 Français Dutch (NL) Español 简体中文 繁體中文 Deutsch Português Unit of Length Changes the unit of length between mm and inches. <Parameter by selecting options> : Default value Inch LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 108 When this parameter is set to something other than Delete w/o Overwriting, ‹ it may be more difficult for the Printer to enter power save mode or it may take time before the Printer stops during shutdown. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 109 Default value: 3 days Unit: day Time to Start Scanning Specifies the time from feeding original document to starting scanning. <Parameter by selecting numbers> 0 to 10 Default value: One second Unit: second LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 110 FTP Reception Enables or disables the FTP reception function. <Parameter by selecting options> : Default value Available The FTP reception function can be used. Not Available The FTP reception function cannot be used. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 111 Enables or disables the E-mail scan data function. <Parameter by selecting options> : Default value Available The E-mail scan data function can be used. Not Available The E-mail scan data function cannot be used. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 112 The Submission job box function cannot be used. Scan Enables or disables the Scan function. <Parameter by selecting options> : Default value Available The Scan function can be used. Not Available The Scan function cannot be used. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 113: Ports Settings Menu

    A total of 20 ports is available, including XPT, LPD, and FTP. ‹ ‹ Common Settings Connection Timeout Select a wait time to close the TCP port. The Printer starts counting the time when the Printer is not receiving data during the data transmission. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 114: Port 1 To 20

    : Default value Chapter Not set FTP Protocol LPD Protocol XPT Protocol HPGL <Parameter by selecting options> : Default value The port does not accept HP-GL format command. The port accepts HP-GL format command. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 115 Default value: LPxx xx: Port number The available characters are A to Z, 0 to 9, - (hyphen), and _ (underscore). Case is not distinguished. Do not use the same Printer name in multiple ports. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 116 Chapter ASCII/UTF-8 File names are displayed. File names sent from the host computer are encoded in ASCII/UTF-8. ShiftJIS File names are displayed. File names sent from the host computer are encoded in ShiftJIS. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 117: Setup Items In Pdl Settings Menu

    Chapter The data formats shown in the following table can be used with this Printer. Panel Display Data Formats This is OKI Data Infotech's original D-SCAN format. D-SCAN raster D-SCAN Chapter data is also supported. This data format is compatible with HP-GL, HP-GL/2, and HP RTL HP-GL from HP.

  • Page 118: Setting Parameter Table In Pdl Setting Menu

    Port n_TIFF in TIFF format are performed with this parameter. Sets the parameter for the PDL table of Ethernet port n. Settings for printing in Port n_CALS CALS format are performed with this parameter. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 119: Pdl Parameter Priority Mode

    - At the HP-GL PDL setting with a printer driver, the printer driver setting was deactivated by setting the printer driver option to invalid. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 120: Paper Parameters

    The Printer prints on the roll 2 paper. Roll 3 The Printer prints on the roll 3 paper. Roll 4 The Printer prints on the roll 4 paper. Note The default value varies depending on the Printer initialization category. ‹ LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 121 Longer Side Shorter Side B1 size 1000.0 mm (39.37 inches) 707.0 mm (27.83 inches) B2 size 707.0 mm (27.83 inches) 500.0 mm (19.69 inches) B3 size 500.0 mm (19.69 inches) 353.0 mm (13.90 inches) LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 122 <Parameter by selecting options> : Default value The printed image is not centered. The printed image is centered. The image is not centered when the data size is larger than the spool memory LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 123 However, note that the part of the image exceeding the used paper size is not printed, as the actual print area is not affected by the excess size tolerance. <Parameter by entering numbers> 0 to 30 Default value = 2, Unit in mm LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 124 The printer prints the image with setting its shorter edge toward the roll paper's lead edge. Long Edge First The printer prints the image with setting its longer edge toward the roll paper's lead edge. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 125 Only A4 drawings can be printed in landscape orientation. In principle, the default setting should be used. <Parameter by selecting options> : Default value Short Edge Firs Prints in portrait orientation. Long Edge First Prints in landscape orientation. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 126: Drawing Parameters

    Note that the parameter is valid only when the offset mode is set to Same Drawing Size with Top and Bottom Blank. <Parameter by entering numbers> 0 to 100 Default value = 0, Unit in mm LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 127 The parameter specifies the overwriting mode when the images overlap. Note that, with HP-GL data, the writing mode specified with data is prioritized over the setting with touchpanel. <Parameter by selecting options> : Default value Overwrite Overwrites. Delete and Write Deletes and writes. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 128 Adds and prints an error memo on the side of the page if a PDL error occurs during data processing. However, the Printer does not print the error memo for the command errors (only with HP-GL). LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 129: Scale Parameters

    - X scale - Y scale - Standard-size scale Auto Scale The parameter selects the image to be scaled automatically so that the whole image larger than the paper is printed on the paper. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 130 - Line widths - Inter-dot distance - Dash-dot distance The parameter applies the scaling to: - Line widths - Inter-dot distance - Dash-dot distance However, note that the maximum line width is 16 mm. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 131 The Printer prints the D standard size image in the ANSI series, auto scaled from a standard size original image. The Printer prints the E standard size image in the ANSI series, auto scaled from a standard size original image. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 132 A0 Width The Printer prints the image reduced to A0 roll width size. A1 Width The Printer prints the image reduced to A1 roll width size. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 133 The Printer prints the image reduced to D roll width size. C Width The Printer prints the image reduced to C roll width size. B Width The Printer prints the image reduced to B roll width size. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 134 2 roll width size. User Defined 3 Width The Printer prints the image enlarged to user defined 3 roll width size. User Defined 4 Width The Printer prints the image with the original size. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 135 User Defined 3 Width The Printer prints the image reduced to user defined 3 roll width size. User Defined 4 Width The Printer prints the image reduced to user defined 4 roll width size. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 136: Format Parameters (Only With Hp-Gl And D-Scan)

    User Defined. However, in spite of selecting User Defined, the user-defined roll width with touchpanel Chapter setting is valid when the Printer receives data from the other printer drivers. Chapter Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 137 However, when the Printer receives data from the other Chapter printer driver, the PDL settings with the operation panel is prioritized. Note The default value varies depending on the Printer initialization category. ‹ LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 138 *1: Paper size is enabled but series specification is disabled. *2: Vectors are specified on the operation panel. *3: The printer driver's Draw figure area item cannot be specified with the operation panel. However, the printout depends on the panel settings. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 139 0 is taken as a terminator. Chapter <Parameter by selecting options> : Default value Does not set the command as a terminator (EOF). Sets the command as a terminator (EOF). LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 140 <Parameter by selecting options> : Default value Disables the paper number in the information block. Paper Position Identifies the paper number as the paper position. Paper Type Identifies the paper number as the paper type. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 141 Prints with film. 4 or higher Supplies paper with identifying the Paper Supply Mode as Roll 4. Chapter Note The settings are valid only with the application compatible with the paper ‹ numbers above. Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 142: Pen Parameters (Only With Hp-Gl And D-Scan)

    Line Join parameter. Performs rounding for all micro-vectors. With the Printer, micro-vector is defined as follows: - The line width and line length are 1 mm or less. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 143 0.92 to 0.95 mm (0.0362 to 0.0374 inches) 0.45 to 0.48 mm (0.0177 to 0.0189 inches) 0.96 to 0.99 mm (0.0378 to 0.0390 inches) 0.49 to 0.52 mm (0.0193 to 0.0205 inches) 1.00 to 1.03 mm (0.0394 to 0.0406 inches) LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 144 The printing may take time when the parameter settings are NOT as follows. Line End to Round; and Line Join to Round The Line End parameter may not be valid for the outermost line on a drawing. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 145 The Line Join parameter is not valid when a line attribute below is changed: - Line color - Line width - Line type Chapter The Line Join parameter may not be valid for the outermost line on a drawing. Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 146: Raster Parameters

    Standard Uniformity processing is not performed. Better uniformity Uniformity processing is performed. (Print quality is less than with Standard.) High uniformity Uniformity processing is performed. (Print quality is less than with Better uniformity.) LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 147: Pdc (Print Data Converter) Parameters

    WEB functions or TerioStation2 (exclusive application). DestFolder for Submission Save to a folder defined as a destination folder for submission preset on the computer. Note For presetting of submission destinations, see & page 157. ‹ LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 148 The page number is added at the end of the file name. When a file contains several drawings, the page number appears as _1, _2, _3, etc. Not Specified cannot be set for the file naming rule 1. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 149 When the file save destination is set to Number of Dest Folder for Sub, specifies the folder using the number of the destination folder. <Parameter by entering numbers> 1 to 100 Default value = 1 Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 150: Stamp Parameters

    Chapter Top Left Stamp Direction This parameter specifies the direction of the character string. <Parameter by selecting options> : Default value Left to right Right to left Bottom to top Top to bottom LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 151 December 23, 2010, at 12:34:56 p.m. from a computer with user logged in, the following stamp is printed. us er CO NFID EN T IAL 2010/12 /23 12: 3 4: 56 Stamped item 1 Stamped item 2 Stamped item 3 LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 152 This parameter sets the user specified character string. <Parameter by entering characters> 0 to 16 characters Default value: 0 The available characters are A to Z, 0 to 9, - (hyphen), and _ (underscore). Chapter Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 153: Function Menu

    Chapter Prints the system settings. ‹ Print Print Settings Chapter Prints the Print settings. Chapter ‹ Print Copy Settings Prints the copy function settings. ‹ Print Submission Settings Prints the submission function settings. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 154: Print All Settings

    ‹ Print for Fax Transmission Prints the accounting information based on the customer's maintenance contract Chapter so that the customer can send it to OKI Data Infotech by fax. ‹ Print Error Log Chapter Prints five A4 size pages of error logs starting from the most recent.

  • Page 155: Print Port Accounting Information

    - Output tray of USB Drive Submission (default and 10 presets) Chapter - Output Report to Tray in the Printer Engine menu ‹ PDL Setting Print (Port 1 to 20) Prints PDL settings for each port. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 156: Options Settings Menu

    After entering the code, press the Enter button. Chapter Check that the option corresponding to the code you have entered is set to On. * The Printer restarts when you exit the menu after entering an option code. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 157: Submission Destination Setting Menu

    ‘ Files stored in the hard disk drive of the Printer can be accessed using the WEB functions or TerioStation2 (exclusive application). Chapter Chapter Select the submission destination number to be preset, and then press Add/Edit. Configure the following settings. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 158 0 to 15 characters FQDN When FQDN has been selected for Shared server name selection, enter the fully qualified domain name (FQDN) of the host computer. <Parameter by entering characters> 0 to 255 characters LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 159 When the protocol is set to FTP, specify the path of a folder at the submission destination. <Parameter by entering characters> 0 to 128 characters ‘ Multiple languages entry is performed with Web functions. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 160 Specify whether to call a preset from memory for each submission destination automatically. <Parameter by selecting options> : Default value Chapter If Yes is selected for Call Settings Preset, specify the preset to be called. <Parameter by selecting numbers> 1 to 10 Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 161: Adjustment Menu

    In such a case, calibrate the touchpanel coordinates by operating the calibration screen following the instruction on the screen. Panel Brightness Adjustment Chapter Adjusts the panel brightness. <Parameter by selecting options> : Default value Bright Slightly Bright Normal Slightly Dark Dark Chapter Chapter Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 162: Smart Card Settings Menu

    Chapter restarts when you exit the menu screen. Note Use the default values for all the smart card settings. ‹ The function may malfunction if the settings are modified. Chapter Chapter Chapter Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 163: Import/Export Menu

    When exporting and importing settings, make sure the latest firmware ‹ version is installed on both the printer from which the settings are exported and the printer to which the settings are imported. Chapter Chapter Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 164 Settings for E-mail Scan Data >> Presets 1 to 10 Settings for E-mail Scan Data >> Default USB drive submission settings >> Presets 1 to 10 USB drive submission settings >> Default Print Job Box Settings LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 165 Settings for E-mail Scan Data >> Default >> Paper >> Output Tray USB drive submission settings >> Presets 1 to 10 >> Paper >> Output Tray USB drive submission settings >> Default >> Paper >> Output Tray LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 166 When transferring settings from a model with 10 ports to this printer (which has 20 ports), the settings for the ports that do not exist are set to the default values. Chapter Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 167: Export Operation

    Press the Export Destination button to display the selection screen for the export folder on the USB drive. Select the export folder and then press the OK button. Chapter Chapter An export file is created in the folder specified on the USB drive. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 168: Import Operation

    Press the File to Import button to display the content of the folder on the USB drive. Select the export file and then press the OK button. Chapter Chapter After the import process is finished, the Printer will restart when you exit the menu screen. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 169: Date And Time Settings Menu

    This menu configures the date (year, month, day) and the time (hours, minutes, seconds) of the Printer. Enter the time in the 24-hour clock system. These settings are used when printing menus, and when saving error logs and job Chapter logs. Chapter Chapter Chapter Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 170: Delete Hdd Data Menu

    Several hours are necessary for this operation. Chapter Chapter Chapter Deletion Method Select the deletion method. <Parameter by selecting options> : Default value Overwrite Once & Delete Chapter Overwrite Thrice & Delete Deletion is even more effective. Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 171: Print Job Box Function

    Chapter Contents Chapter Overview of the Print Job Box Function ..........172 Print Job Box Settings Menu ..............173 Print Job Box Operation ..............175 Using Smart Cards with the Print Job Box Function ......178 Chapter Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 172: Overview Of The Print Job Box Function

    Moreover, using this function becomes even simpler when it is operated together with smart cards. Chapter Note This function cannot be used together with the print authentication ‹ function. Chapter Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 173: Print Job Box Settings Menu

    The print job is deleted if the set time passes after the print job has been received, and if it has not been printed. <Parameter by selecting numbers> Chapter 1 to 199 Default value: 3 Unit: hours LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 174 The Print All button is not displayed. ‘ When the optional IC card authentication function is used, the jobs in the print job box can be easily printed using the IC card. Chapter Chapter Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 175: Print Job Box Operation

    (2) Press the Print Job Box button. Press the Print Job Box button on the Ready screen or the Print Mode top screen. Chapter Chapter Ready screen Chapter Chapter Print Mode top screen LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 176 You may also press a Select and Print button to select the jobs you want to print. Print All buttons are not displayed when the Display Print All Button parameter is set to No. Chapter Print All buttons Chapter Chapter Select and Print buttons Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 177 With LPR connection, which does not use the printer driver connection, ‹ Host character encoding must be set to either ASCII/UTF-8 or ShiftJIS (see & page 116). Chapter Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 178: Using Smart Cards With The Print Job Box Function

    (1) Register the smart card. Print from the printer driver and press the Print Job Box button. On the user selection screen that is displayed, press the Register button at the top right corner. Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 179 The user names are the login names used when logged in to the computer used to print with the printer driver. Chapter Chapter (3) Confirm the user. Chapter Press OK if the user is correct. Chapter Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 180 In such a case, operation is performed as with The print job list is displayed after the smart card is read. Chapter Chapter (5) Read the smart card with the reader. When the screen below is displayed, read the smart card with the reader. Chapter Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 181 The screen below is displayed when the smart card registration is complete. Press OK. Chapter Chapter (7) Confirm the smart card registration. A smart card icon is displayed as shown below for users who have registered a Chapter smart card. Chapter Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 182 Chapter Chapter Ready screen Chapter Chapter Print Mode top screen Chapter On the screen below, jobs in the print job box can be printed by reading the smart card with the card reader. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 183 Chapter read your smart card with the card reader. Then, you can select jobs to print or delete them. Chapter Chapter Chapter Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 184 Chapter Chapter Chapter Chapter Chapter Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 185 Authentication Function Chapter Chapter 5 describe the authentication function for the Printer. Chapter Contents Chapter Authentication Function Overview ..........186 Printer Administration .................189 User Authentication ................198 Smart Card Registration Procedure ..........222 Chapter Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 186: Authentication Function Overview

    - To initialize the Printer; and - To acquire log information, Chapter which are not allowed to non-administrators with the function. Supervisor Standard user Chapter Registration User administrator Change settings Chapter Management of jobs and logs Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 187 - The users enter directly a PIN code on the operation panel to authenticate themselves. - The users use smart cards to authenticate themselves. Chapter PIN code authentication Chapter Enter a PIN code Password authentication Enter a login name and password Smart card (option) Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 188 With the one-time password specified, the Printer does not print data it receives until the password is entered from the operation panel. Chapter Print data with one-time password Password entry Print Chapter Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 189 Up to three supervisors can be registered. 1. Changing the Printer settings 2. Acquiring logs 3. Special job operations User administrator Up to five user administrators can the registered Copying, submitting, scanning, and printing Standard user LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 190: T Printer Administration

    *2: When Edit submission destination/memory is set to Allow edit, changes can be made without printer administration privileges. *3: For actual login, authentication is required using a login name and password. *4: Displayed only when the smart card option is enabled. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 191 Acquire user name from LPR file name Printer Engine Maintenance Scanner Maintenance Import/Export All Settings *1: This mode is available when Submission destination / Preset editing is set to Permit in Printer Administration. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 192 The first time you register a supervisor, login Chapter using the default login name and password. Login name: supervisor Password: (blank) After login, the menu top screen is displayed again. Press Register Supervisor in Administrator Settings. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 193 ‹ ‹ Registering User Administrators Chapter To register an user administrator, you will have to login as a supervisor even if Printer Administration is set to Off Press MENU. Chapter Press Administrator Login. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 194 OK. Chapter Chapter Note Chapter Do not forget the login name and password of the user administrator. If you ‹ forget this information, you will have to log in with supervisor privileges. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 195 If Printer Administration is set to On, later changes in settings must be ‹ performed by a supervisor or user administrator. To change Printer Administration from On to Off, you will have to login as a ‹ supervisor. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 196: T User Authentication

    „ Enabling remote maintenance When requested to do so by our maintenance staff, set the remote maintenance function setting to On. Chapter Chapter This setting must be changed by a user administrator with printer administration privileges. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 197 Administration is set to Yes. Enter a supervisor or user administrator Chapter login name and password and then press Login. If the Printer display returns to the standby screen after logging in, the user is logged out. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 198 PIN code authentication or password authentication. ‘ When using user authentication, you are recommended to set Printer Administration to On. When Printer Administration is On, only users with printer administration privileges can register Printer’s users. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 199 However, if a host environment other than our software is present, like in personal computers or work stations, the Printer can be set to print the data sent from a specified computer without authentication. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 200 - Job operation screen (for print, copy, submit and scan); - Submission box screen; and Chapter - PDC box screen. So your job cannot be monitored nor operated by other users. Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 201 Specify the modes (copy, submit, scan, and print) in which the user is authenticated. Chapter After this setting is completed, only authorized users can operate the Printer in the specified modes requiring user authentication. Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 202 Press MENU. Chapter Press User Authentication Settings. Chapter Note When Printer Administration is On, user administration settings are ‹ operated only by user administrators with printer administration privileges. Chapter Press User Registration. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 203 (proxy user) other than yourself to print your print jobs. Register a PIN code or a login name for the proxy user. Up to five proxy users can be registered. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 204 A LPR identification name must be set when using LPR Data for User ‹ Chapter Identification. Specify a unique string of characters for the LPR identification name for each user. Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 205 Chapter Activate user authentication function at each of copy, submission, scan, and print modes with On. Specify Print Job Authentication Time. Chapter Then check the box for Print all confidential documents. Press >>. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 206 ‘ When Use PC Login Name is set for User Verification for Print Auth., set the same login name (PIN code) when registering the user as the Chapter login name used to log in the computer. The default setting is Use PC Login Name. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 207 Chapter If the user authentication setting is changed, the Printer restarts when leaving the menu mode. Chapter To use smart card authentication, you need to configure the Smart card settings. Chapter Chapter Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 208 IC cards. Chapter Press MENU. Press User Authentication Settings. Chapter Chapter Press Allow User Info Edit. Chapter Set to allow or disallow IC card registration. Set to allow or disallow password modification. Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 209 You can configure the settings so that user authentication is not used only for print jobs sent from specified host computers. The computers are specified with their IP addresses. Chapter You can specify up to three computer IP addresses. Press MENU. Press User Authentication Settings. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 210 Chapter have specified the IP address will be printed immediately without being stored in the Printer. & page 212 for the printer operation when you select Store in the Printer. Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 211 If you select Print immediately, the print data received from the corresponding port will be printed immediately without being stored in the Printer. & page 212 for the printer operation when you select Store in the Printer. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 212 ASCII/UTF-8 or ShiftJIS (see & page 116). The print jobs stored in the Printer are deleted automatically after the time ‹ set in Print Job Auth. Time (see & page 205) has elapsed. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 213 The screen of the desired mode appears. Perform copy, submission, or scanning operations. When operation is complete, press Log Out at the bottom of the top screen to logout. The standby screen appears. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 214 Ready screen when they read their smart card with the card reader. After successful authentication, the Authenticated Printing screen in is displayed. Press PRINT. The Print mode top screen appears. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 215 ‘ You can read your smart card with the card reader to authenticate while the PIN code input screen in step 4 or the login name/password input Chapter screen is displayed. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 216 Chapter & page 202 for how to register proxy users. After all printing is complete, press Log Out at the Print top screen to logout. Chapter Chapter Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 217 On the job screen, only the jobs of authenticated users are displayed. Chapter After logging in, the user can operate the Printer under the specified restrictions. To logout, click Log Out at the top of the Web browser window. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 218 Set a unique one-time password so that it does not match another user’s ‹ one-time password. Be aware that all the print data with that password will be printed if multiple users coincidentally set the same password. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 219 „ Setting procedure with the printer driver When you are printing from the printer driver, specify one-time passwords with the authentication sheet. For details, see the help section of the printer driver. Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 220 The checkbox's default status is set to On or Off at the User Authentication Chapter Setting. For more details, see & page 205. On the authenticated printing screen, select a job to print it. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 221 E-mail Address When an e-mail address is registered in Active Directory, set the name of the attribute where the e-mail address is registered. Note It is not necessary to modify the other ‹ settings. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 222 After this step, the smart card has not been registered yet. (3) Configure User Authentication. See User Authentication Setting Procedure on & page 205 for more details. After this step, PIN code authentication or password authentication can be used. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 223 Press the Smart card Registration button on the Edit User Information screen. Chapter Chapter (3) Authenticate the user. On the User authentication screen, enter your login name and password, or your PIN code, and press the Authentication button. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 224: T Smart Card Registration Procedure

    Check that your account information is displayed, and then read your smart card with the card reader. Chapter Chapter (5) Complete the smart card registration. Chapter The screen below is displayed when the smart card registration is completed successfully. Press the OK button. Chapter Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 225 When the Error Screen Appears ............227 Chapter Error Log Reference ................236 Ethernet Troubleshooting ..............247 Image Quality Defects ................ 249 Unusual Sound ..................250 Chapter When you have set the wrong language .........251 LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 226: Initial Checks

    ( & page 236). With PDL errors, the error message can be printed on a part of the printout. ‹ ( & page 128). LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 227: When The Error Screen Appears

    The touchpanel also shows the paper jam location. Remove the paper jam by following the procedures described next. The method for removing the paper jam can also be viewed in the Help of the error screen. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 228 After removing the jammed paper, go to Chapter Warning Be careful not to touch the fuser unit. ‹ Note that the fuser unit is very hot. To avoid burning yourself, remove the jammed paper carefully. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 229 Note Close the fuser unit drawer by holding it near the right and left latch ‹ buttons. The fuser unit drawer cannot be closed if the latch buttons are pressed. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 230 Chapter Chapter Chapter Remove the jammed paper, and then close the front door. When the front door is closed, the Printer restarts the print from the page at which the paper jam occurred. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 231 „ Removing a Paper Jam from the Roll Paper Drawer and the Front Door Chapter Chapter Press the latch button, and open the fuser unit drawer. Chapter Chapter Open the front door. Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 232 When the Error Screen Appears Chapter Open the roll paper drawer. Chapter Rewind the roll paper. Chapter Chapter Cut the paper. Chapter Remove the roll paper. Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 233 Close the front door. Chapter Close the fuser unit drawer. Chapter Chapter „ Original Jam When an original jam occurs, the following messages appear on the screen. Chapter Chapter Open the scanner cover. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 234 Close the scanner cover. Be closing the scanner cover, then the Printer Chapter becomes ready. Warning Be careful not to catch your hand in the scanner cover. ‹ Otherwise, you may injure yourself. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 235 ‹ Door is Open The following messages are displayed on the screen when a door or drawer is open. Chapter Following the message, close the indicated door or drawer. Chapter Chapter Chapter Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 236: Error Log Reference

    ‹ Error Log List Solve the problem by identifying the error with referring to the Error Log List shown below. If the problem persists after the corresponding troubleshooting, contact your dealer or nearest service representative. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 237 Module start error (upgrade library) 1031 Initialize TIMER Module start error (timer task) 1032 Initialize OPERATION Module start error (operation task) 1033 Initialize PANEL Module start error (panel task) (1) Type (2) Character string (3) Error number LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 238 MYKselect returned an error when sending a Chapter message 4300 Receive message error MYKrcvInterface returned an error 4310 Send message error MYKsndInterface returned an error C000 Internal information error (1) Type (2) Character string (3) Error number LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 239 MYKsndInterface returned an error when sending a jobEvent message jobevent LN 1100 alloc memory xx Insufficient internal memory Restart the Printer. xx: Internal code (01 to 04) (1) Type (2) Character string (3) Error number LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 240 Communication timeout (application level) Check the status of the data (Communication with the host broke during transmission host. data transmission) PPP: Protocol name (FTP/LPD/XPT) xx: Internal code (1) Type (2) Character string (3) Error number LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 241 Supported character string xx: Internal code LN 8260 PPP bind(nnnn) xx Communication connection related: bind error PPP: Protocol name (FTP/LPD/XPT) nnnn: Supported character string xx: Internal code (1) Type (2) Character string (3) Error number LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 242 CC or DATA process) & CC or DATA ML 8737 server protocol Check CC & SMTP server protocol error (CC permission and DATA process) DATA (1) Type (2) Character string (3) Error number LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 243 NPRINT OM 4740 Receive message error from MYKrcvInterface returned an error when receiving a message from a CIFS task CIFS (1) Type (2) Character string (3) Error number LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 244 Data was disregarded because there was no Check on the computer side whether valid print data on the paper. valid print data is being transmitted. (1) Type (2) Character string (3) Error number LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 245 MIB information access error SN C020 Internal communication error A000 Cannot Parse PJL PJL analysis failed Check the print data. * Details may be divided into multiple items (1) Type (2) Character string (3) Error number LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 246 TW 83FF Twain : others (net) • Check the other network settings. Network errors other than above If the error persists, replace the ARC substrate. Chapter (1) Type (2) Character string (3) Error number LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 247 Contact and check with the system Contact the system administrator. DNS server, the DNS administrator. server is not set up, or the IP address setting of the DNS server on the Printer is incorrect. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 248: T Ethernet Troubleshooting

    (However, with some host devices, bin is not issued even after setting the bin specification. In such a case, set the setting on the device side to bin fixed.) Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 249: Image Quality Defects

    Printer does not print for the Chapter prescribed time or more between the current printing and the next printing. ( & page 89, Top Cut Timer (Roll 1 to 4)) Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 250: Unusual Sound

    Unusual Sound Chapter If the Printer issues an unusual sound, contact your dealer or nearest service representative. Chapter Chapter Chapter Chapter Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

  • Page 251: When You Have Set The Wrong Language

    The Printer starts normally and the standby screen appears. Press the following buttons consecutively. Chapter Cancel --> . --> Enter --> Cancel The language selection screen appears. Select a language. Chapter Chapter Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 252 Chapter Chapter Chapter Chapter Chapter Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 253 Chapter The Appendix contains information such as the Printer's basic specifications, components, menu structure, and command lists. Chapter Chapter Contents Basic Specifications ................254 Menu Structure ..................256 Chapter Command Lists ..................274 Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 254 - 5 mm on rear end - 5 mm on both sides Chapter Data format D-SCAN, HP-GL, HP-GL/2, HPRTL, TIFF, CALS 500 GB Interface Ethernet (10Base-T/100Base-Tx/1000Base-T) Network protocol TCP/IP (ftp, lpr, xpt (socket)) LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 255 2100 mm (82.68 inches) (W) × 2740 mm (107.87 inches) (D) × Installation space 2000 mm (78.74 inches) (H) Chapter 3200 mm (125.98 inches) (W) × 3540 mm (139.37 inches) (D) × Maintenance space 2000 mm (78.74 inches) (H) LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 256 ‘ The menu structure in this section was created based on the Printer's factory default settings. Chapter Chapter Chapter & page 93 & page 89 Chapter Chapter & page 113 & page 117 & page 173 & page 162 LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 257 Slightly Low Normal Slightly High High Chapter Humidity for Tracing Paper Normal High Humidity Power Saving in Standby Medium High Output Report to Tray A3 Tray Print Reports with Other Paper : Default value LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 258 SNMP SNMP Community 0 to 32 characters Chapter SNMP Version Version 1 Version 2 IPv6 Connection IPv6 Address Manual Setting IPv6 Address 0 to 63 characters Prefix Length 0 to 63 characters DHCPv6 LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 259 With SMTP Authentication SMTP User Name SMTP Password Maximum E-mail Data Size 1 to 4096 Sender's E-mail Address Same as Receiver's Custom Custom Sender's 0 to 127 characters E-mail Address Subject 0 to 40 characters LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 260 (standard, user defined, US1, US2, ARCH Series US3). ANSI Series Chapter 30×42 Series Map Series Chapter DIN Series User Defined Paper Size A Series A0 Roll Standard A1 Roll A2 Roll A3 Roll LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 261 15 in. Roll MAP Series B1 Map Roll Chapter B2 Map Roll DIN Series B1 DIN Roll B2 DIN Roll User Defined A1 User Defined Roll User Defined A2 Roll User Defined A3 Roll LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 262 Русский Chapter Dutch (NL) 繁體中文 Unit of Length Inch Save/Delete Delete Complete Job Save Optional Folder Not Enabled Enabled PDtF box retention 1 to 199 (hours) period Job Display Order Chronological Reverse Chronological LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 263 Submit to USB Drive Available Chapter Not Available Submit from Thumbnail Available Not Available Submit Print Job Available Not Available Submission Job Box Available Not Available Scan Available Not Available Russian language Available Not Available LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 264 XPT Port 0 to 65535 Printer Name 3 to 15 characters User Name 3 to 15 characters FTP password 3 to 15 characters Host character encoding Not Specified ASCII/UTF-8 ShiftJIS : Default value LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 265 Plain Tracing Film Excess Size Tolerance 0 to 30 (mm) Output Tray Output Tray Print from End Print direction Short Edge First Long Edge First : Default value *1: HP-GL, TIFF, CALS only. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 266 : Default value *2: D-SCAN only. *3: HP-GL, D-SCAN only. Partial *4: TIFF, CALS only. *5: HP-GL only. Scale Parameters Scale Settings Scale Mode Manual Scale Auto Scale X Scale 0.01 to 1000.00 (%) LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 267 C Width / B Width E Width / D Width / E Width C Width / B Width Same Width / E Width / Width Exceeding E D Width / C Width / B Width LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 268 User Defined 3 Width User Defined 2 Width User Defined 1 Width Chapter Format Parameters Printer Driver Not Enabled Enabled User Defined Language Auto HP-GL HP-GL/2 Terminator PG1; Terminator NR; : Default value *5: HP-GL only. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 269 Pen N Width 0.00 to 16.00 (mm) Density 0 to 100 (%) Line End Round Butt Line Join Rounded : Default value Mitered *5: HP-GL only. *6: D-SCAN only. *7: HP-GL, D-SCAN only. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 270 Date and Time Created File Name User Name Host Name File naming rules 4 Not Specified Date and Time Created : Default value File Name *8: HP-GL, D-SCAN, User Name TIFF only. Host Name LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 271 Stamped items 1 to 3 Not Specified Reception Date and Time Chapter User Specified User name Date and time YYMMDDhhmmss received format YYYYMMDD YYMMDD hhmmss User-specified 0 to 16 characters character string : Default value LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 272 ‹ Print Job Box Settings Menu Print Job Box Settings Activate Print Job Box Chapter Print Jobs Storing Time 1 to 199 (hours) Display Print All Button : Default value Chapter Chapter Chapter Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 273 Common Settings Card reader type General keyboard I/F PR-700UDM Chapter PR-450UDM Smart card read information Specified sector Keyboard I/F settings Timeout 50 to 300msec. Chapter Termination character CR+LF : Default value Chapter Chapter Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 274 ) The fonts of the font numbers specified with the AD and SD commands are printed with the fonts of the font numbers indicated in the CS command table below. ) Recognized as EOF. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 275 Relative coordinates 3-point arc printing command Arc resolution mode selection command Graduation length setting command X axis graduation printing command Y axis graduation printing command Encryption printing command Absolute coordinates Bezier printing command Relative coordinates Bezier printing command LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 276 Bitmap font setting command Character string printing command Character string storage command Stored character string printing command Character Number of characters movement command Commands Symbol mode setting command User character registration command User character printing command LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 277 Font No. Font No. Font No. Font No. Font No. Font No. 1611 (Kanji) 101 (Kanji) 1643 (Kanji) 101 (Kanji) (Note 1) (Note 1) Character set 531 is handled as user defined characters. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 278 Sets the RGB value of the specified index Foreground Color ESC * v # s|S number as the lower limit for raster printing. Specifies the algorithm for expressing neutral Render Algorithm ESC * t # j|J Partially ( color data. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 279 ) The only parameter value enabled for ESC*t#J is 0. ) ESC*l#O is enabled only in some logical calculations for monochrome binary raster. Chapter Commands not included in the table result in command errors or are disregarded. Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 280 40 to 7F Writes a symbol. PLOT 80 to FF Prints a line segment or moves a coordinate. PTN SET 0001 Registers a fill pattern. PATRN 0002 Fills the inside of closed polygons. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 281 Specifies the output bin number for the sorter. STOCK Specifies the stock of the sorter. PAPER Specifies the paper type number. Partially * USERN Specifies the user name (EBCDIC). * On hold. Not supported yet. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 282 Specifies the output bin number for the sorter. Chapter STOCK Specifies the stock of the sorter. PAPER Specifies the paper type number. Partially * USERN Specifies the user name (EBCDIC). * On hold. Not supported yet. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 283 * The maximum values of the 4 parameters (0 to 255) indicating the proportion of yellow, magenta, cyan, and black are used to determine the gradation in 16 levels. This is expressed as the density of black. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 284 DIRECT RASTER 2 1195 Sets the information for direct raster (2). Chapter PACKING RASTER 2 1196 Sets the information for packing raster (2). PIXEL 2 1197 Pixels 2 * On hold. Not supported yet. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 285 Pixel data Chapter CONTINUATION 12FF Data continued from the previous block. DATA * Even yellow, magenta, and cyan pattern arrays are registered as black pattern arrays. The registered dots are all expressed in black. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 286 Specifies the option information for T4 compression. Partially Specifies the physical unit of resolution units in the X ResolutionUnit 0128 Resolution and Y Resolution tags. Color Map 0140 Specifies the palette color table (RGB). LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 287 Specifies the rotation direction for the page. Specifies the number of dots in 1 line and the rpelcnt number of lines. Chapter rdensty Specifies the number of dots in each inch. Chapter Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 288 Logs in to the Printer's ftp server. After executing the user user (user name) — command, enter the user name and password. ‘ Up to 10 users can be connected in 3 protocols: ftp (for data transfer), lpr (lpq, lprm), and xpt. LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 289 With LP-2060 xpt, data from up to 20 users can be transferred. Chapter ‘ Up to 20 users can be connected in 3 protocols: ftp (for data transfer), lpr (lpq, lprm), and xpt. Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...
  • Page 290 Command Lists Chapter Chapter Chapter Chapter Chapter Chapter LP-2060/LP-2060-MF User's Manual for Basic Printer Operation...

This manual is also suitable for:

Teriostar lp-2060 seriesLp-2060

Table of Contents
