ILPM-AC Manual
Noted in the image below, you need to connect the RJ-45 extension cable from the RJ-
45 port on the unit to the RJ-45 sensor port on the sensorProbe+ or securityProbe+
base unit.
With the AC power disconnected, connect the AC power plug to the AC power source
using the "Power In" line on the ILPM. Then connect the AC power plug to the "Power
Out" line and then to the AC load or power strip. [[sentence is confusing, maybe just say
cConnect the AC power plug of the "Power In" to the AC power source, and the AC
:
power plug of the "Power Out" to the AC appliance or the power strip.]]
The following image shows an example how the ILPM has been installed in a 19" server
cabinet to monitor the other equipment that has been installed in the cabinet.
5
