- Page 1 Assembly Instructions max. 180 kg ~ 180 Min. 293 kg L 409 | W 107 | H 234 TFPTT0212.01.01 Art. No. TF-PTT0212 Taurus Studio Cross Over Pulley Combo A...
- Page 2 Cross Over Pulley...
-
Page 3: Table Of Contents
Content GENERAL INFORMATION Technical Data Personal Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Assembly STORAGE AND TRANSPORT General Instructions TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions Faults and Fault Diagnosis Maintenance and Inspection Calendar DISPOSAL RECOMMENDED ACCESSORIES ORDERING SPARE PARTS Serial Number and Model Name Parts List Exploded Drawing... - Page 4 Cross Over Pulley...
- Page 5 With Taurus® fitness equipment, the focus is on what sport is all about: maximum performance! Therefore, the equipment is developed in close consultation with athletes and sports scientists.
- Page 6 ABOUT THIS MANUAL Please carefully read the entire manual before installation and first use. The manual will help you to quickly set up the system and explains how to safely use it. Make sure that all persons exercising with the equipment (especially children and persons with physical, sensory, mental or motor disabilities) are informed about this manual and its contents in advance.
-
Page 7: General Information
GENERAL INFORMATION Technical Data Weight and Dimensions: Packaging dimensions (L x W x H) and weight approx.: Box 1: 230 cm x 56.5 cm x 83 cm 340 kg Box 2: 268 cm x 47 cm x 40.5 cm 30 kg Article weight (net, excl. -
Page 8: Personal Safety
Personal Safety ⚠ DANGER Before you start using the equipment, you should consult your physician that this type of exercise is suitable for you from a health perspective. Particularly affected are persons who: have a hereditary disposition to high blood pressure or heart disease, are over the age of 45, smoke, have high cholesterol values, are overweight and/or have not exercised regularly in the past year. -
Page 9: Set-Up Place
Set-Up Place ⚠ WARNING Do not place the equipment in main corridors or escape routes. CAUTION ⚠ Choose a location in which to place the equipment such that there is enough free space/ clearance to the front, the rear and to the sides of the equipment. The training room should be well ventilated during training and not be exposed to any draughts. -
Page 10: Assembly
ASSEMBLY General Instructions ⚠ DANGER Do not leave any tools, packaging materials such as foils or small parts lying around, as otherwise there is a danger of suffocation for children. Keep children away from the equipment during assembly. ⚠ WARNING Pay attention to the instructions attached to the equipment in order to reduce the risk of injuries. - Page 11 PTT0212D-PART LIST-1 QTY. ITEM NO. NAME. DESCRIPTION. OPERATER. Cbale Top weight palte Ground Connection Frame Guide rod Adjustment plate Main frame 2 2 0 0 9 9 1 1 . . 2 2 0 0 9 9 1 1 . . 2 2 0 0 9 9 1 1 .
-
Page 12: Assembly
Assembly Before assembly, take a close look at the individual assembly steps shown and carry out the assembly in the order given. NOTICE First loosely screw all parts together and check that they fit properly. Tighten the screws using the tool only when you are instructed to do so. Step 1: Assembly of the Main Frame and Ground Connection Frame Mount one main frame (1) to one ground connection frame (2) with four bolts (52), four snap... - Page 14 Step 2: Assembly of the Frame Tube Mount the frame tube (3) to the main frames (1) with four bolts (51), four snap rings (55) and four flat washers (58) on each of the main frames (1). Name Specification Qty. Main frame Ground connection frame Frame tube...
- Page 16 Step 3: Assembly of the Guide Rods and Weight Plates Place two supporting brackets (65) and two bumpers (16) on the two sockets of the bottom of the main frame (1). Insert two guide rods (26) into the sockets of the main frame (1). Carefully slide each of the 14 weight plates (21) onto the guide rods (26) one by one.
- Page 18 Step 4: Assembly of the Sliding Frame and Adjustment Plate Slide the sliding frame (4) onto the adjustment plate (9). Mount the lower part of the adjustment plate (9) onto the ground connection frame (2) with one bolt (50), two flat washers (57) and one nut (61). Mount the upper part of the adjustment plate (9) onto the upper part of the main frame (1) with one bolt (50), two flat washers (57) and one nut (61).
- Page 20 Step 5: Assembly of the Pulleys and Cable Routing ࣑ ATTENTION Always place the cables over or under the pulleys first and only then mount the pulleys. It can not be guaranteed that the cables can be passed through afterwards! Insert the end of the cable (8) into the opening of the sliding frame (4).
-
Page 22: Storage And Transport
Step 6: Arrangement of the Handles This equipment is delivered with a variety of workout accessories in order to enable a variable training. The multi gym provides storage solutions for the accessories on the outer side of the main frame. To attach an accessory onto the cable pull, open the snap hook on the cable pull and attach the accessory to it. -
Page 23: Troubleshooting, Care And Maintenance
TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions ⚠ WARNING Do not make any improper changes to the equipment. CAUTION ⚠ Damaged or worn components may affect your safety and the life of the equipment. Therefore, immediately replace damaged or worn components. In such a case, contact the contract partner. -
Page 24: Maintenance And Inspection Calendar
Maintenance and Inspection Calendar To avoid damage from body sweat, the equipment must be cleaned with a damp towel (no solvents!) after each training session. The following routine tasks must be performed at the specified intervals: Part Weekly Monthly Quarterly Cables Screw connections Pulleys and cable routing... -
Page 25: Recommended Accessories
RECOMMENDED ACCESSORIES To make your training experience even more efficient and pleasant, we recommend that you add suiting accessories to your fitness equipment. This could be a floor mat, for example, which makes your fitness equipment stand more securely and also protects the floor from falling sweat, but it could also be additional handrails on some treadmills or silicone spray to keep moving parts in good shape. -
Page 26: Ordering Spare Parts
The serial number of your equipment is unique. It's located on a white sticker. The exact position of this sticker is shown in the following illustration. Enter the serial number in the appropriate field. Serial number: Brand / Category: Taurus / multi-gym Model Name: Studio Cross Over Pulley Combo A Article Number: TF-PTT0212... -
Page 27: Parts List
Parts List Name Specification Qty. Main frame Ground Connection Frame Frame Tube Sliding frame Swing frame Top weight plate bracket Cable Adjustment plate Guide rod bushing Pulley Pulley Foot pad Bumper Pedal Guide sleeve Handle grip Handle grip 10LBS weight plate Knee strap Strap Handle... - Page 28 Snap clip Bumper Stopper Aluminium end cap Aluminium collar Aluminium collar Plastic collar Button head blind rivet 4*12 Button head Inner Hexagon Bolt M8*20 Socket Head Inner Hexagon Bolt M6*25 Socket Head Inner Hexagon Bolt M8*16 Socket Head Inner Hexagon Bolt M8*40 Socket Head Inner Hexagon Bolt M10*50...
- Page 29 Socket Head Inner Hexagon Bolt M12*90 Roller-bearing 6201 2Z collar Φ16*Φ12*7...
-
Page 30: Exploded Drawing
Exploded View Exploded Drawing Cross Over Pulley... -
Page 31: Warranty
WARRANTY Training equipment from Taurus® is subject to strict quality control. However, if a fitness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline. - Page 32 Warranty Conditions For the warranty to be valid, the following steps must be taken: Please contact our customer service by email or phone. If the product under warranty has to be sent in for repair, the seller bears costs. After expiry of the warranty, the buyer bears the costs of transport and insurance.
-
Page 33: Contact
CONTACT TECHNICAL SUPPORT TECHNICAL SUPPORT & SERVICE TECHNICAL SUPPORT & SERVICE �� �� �� +49 4621 4210-900 80 90 16 50 +33 (0) 172 770033 +49 4621 4210-945 +49 4621 4210-933 �� +49 4621 4210-698 �� �� info@fitshop.dk service-france@fitshop.fr �� technik@sport-tiedje.de ��... - Page 34 LIVE FITNESS WEBSHOP AND SOCIAL MEDIA Sport-Tiedje is Europe’s largest specialist store www.sport-tiedje.co.uk for home fitness equipment with currently over www.sport-tiedje.de/blog 70 stores and one of the world’s most renowned online mail order companies for fitness equipment. Private customers order via the 25 www.facebook.com/SportTiedje web shops in the respective national language or have their desired equpiment assembled on...
- Page 36 Taurus Studio Cross Over Pulley Combo A...
