Summary of Contents for Taurus TF-PTT0224
- Page 1 Assembly Instructions max. 250 kg ~ 60 Min. 71 kg L 160 | W 94 | H 108 TFPTT0224.01.01 Art. No. TF-PTT0224 Taurus Studio Adj Roman Chair...
- Page 2 Adjustable Roman Chair...
-
Page 3: Table Of Contents
Content GENERAL INFORMATION Technical Data Personal Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Assembly STORAGE AND TRANSPORT General Instructions TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions Faults and Fault Diagnosis Maintenance and Inspection Calendar DISPOSAL RECOMMENDED ACCESSORIES ORDERING SPARE PARTS Serial Number and Model Name Parts List Exploded Drawing... - Page 4 Adjustable Roman Chair...
- Page 5 With Taurus® fitness equipment, the focus is on what sport is all about: maximum performance! Therefore, the equipment is developed in close consultation with athletes and sports scientists.
- Page 6 ABOUT THIS MANUAL Please carefully read the entire manual before installation and first use. The manual will help you to quickly set up the system and explains how to safely use it. Make sure that all persons exercising with the equipment (especially children and persons with physical, sensory, mental or motor disabilities) are informed about this manual and its contents in advance.
-
Page 7: General Information
GENERAL INFORMATION Technical Data Weight and Dimensions: Packaging dimensions (L x W x H) and weight approx.: Box 1: 127 cm x 67 cm x 38.5 cm 65 kg Box 2: 60 cm x 20 cm x 48 cm 13 kg Article weight (net, excl. -
Page 8: Personal Safety
Personal Safety ⚠ DANGER Before you start using the equipment, you should consult your physician that this type of exercise is suitable for you from a health perspective. Particularly affected are persons who: have a hereditary disposition to high blood pressure or heart disease, are over the age of 45, smoke, have high cholesterol values, are overweight and/or have not exercised regularly in the past year. -
Page 9: Set-Up Place
Set-Up Place ⚠ WARNING Do not place the equipment in main corridors or escape routes. CAUTION ⚠ Choose a location in which to place the equipment such that there is enough free space/ clearance to the front, the rear and to the sides of the equipment. The training room should be well ventilated during training and not be exposed to any draughts. -
Page 10: Assembly
ASSEMBLY General Instructions ⚠ DANGER Do not leave any tools, packaging materials such as foils or small parts lying around, as otherwise there is a danger of suffocation for children. Keep children away from the equipment during assembly. ⚠ WARNING Pay attention to the instructions attached to the equipment in order to reduce the risk of injuries. -
Page 11: Scope Of Delivery
Scope of Delivery The scope of delivery consist of the following parts. At the beginning, check whether all parts and tools belonging to the device are included in the scope of delivery and whether damage has occurred. In the event of complaints, the contractual partner must be contacted directly. ⚠... -
Page 12: Assembly
Assembly Before assembly, take a close look at the individual assembly steps shown and carry out the assembly in the order given. NOTICE First loosely screw all parts together and check that they fit properly. Tighten the screws using the tool only when you are instructed to do so. Step 1: Assembly of the Support Frames Place the right support frame (2) and left support frame (3) on the outer sides of the intermediate... - Page 13 Step 2: Assembly of the Main Frame Slide the main frame (6) in between the right support frame (2) and left support frame (3). Make sure that the holes of the right and left support frames (2 & 3) align with the hole of the main frame (6).
- Page 14 Step 3: Assembly of the Foot Frame Mount the foot frame (12) onto the main frame (6) with two screws (42), four plain washers (46) and two nuts (51). Name Specification Qty. Main frame Foot frame Hex socket head cap screw M10*80 Plain washer Φ20*Φ10.5*2...
- Page 15 Step 4: Assembly of the Arc Adjusting Plate Mount the arc adjusting plate (8) onto the main frame (6) with two screws (41), four plain washers (46) and two nuts (51). Mount the limiting rubber (25) onto the two outer holes of the arc adjusting plate (8) with one screw (39), one spring washer (48) and one plain washer (45) each.
- Page 16 Step 5: Assembly of the Gas Spring Mount the gas spring (19) onto the main frame (6) with one nut (50) and one plain washer (45). Mount the gas spring (19) onto the right support frame (2) with one nut (50) and one plain washer (45).
- Page 17 Step 6: Assembly of the Adjusting Tube Pull out the rotary knob (31) a bit. Insert the adjusting tube (9) into the opening of the main frame (6). Let go of the rotary knob (31) and ensure that it engages with one of the holes of the adjusting tube (9).
- Page 18 Step 7: Assembly of the Cushion Frame Mount the cushion frame (5) onto the adjusting tube (9) with two screws (2), four plain washers (46) and two nuts (51). Name Specification Qty. Cushion frame Adjusting tube Hex socket head cap screw M10*90 Plain washer Φ20*Φ10.5*2...
- Page 19 Step 8: Assembly of the Back Pad Mount the back pads (13) onto the cushion frame (5) with two screws (40), two spring washers (48) and two plain washers (45) each. Name Specification Qty. Cushion frame Back pad Hexagon socket button head M8*30 screw Plain washer...
- Page 20 Step 9: Assembly of the Pedal Frame Remove one end cap (26) of the pedal frame (4) by loosening the screw (38). Slide the pedal frame (4) through the opening of the main frame (6). Mount the pedal frame (4) onto the main frame (6) with one screw (39), one spring washer (48) and one plain washer (45).
- Page 21 Step 10: Assembly of the Leg Pads Remove the other end cap (26) of the pedal frame (4) by loosening the screw (38). Remove the end caps (26) of the foot frame (12) by loosening the screws (38). Slide one leg pad (14) on either side of the pedal frame (4). Slide one leg pad (14) on either side of the foot frame (12).
-
Page 22: Storage And Transport
STORAGE AND TRANSPORT General Instructions ⚠ WARNING The storage location should be chosen so that improper use by third parties or children can be prevented. If your equipment does not have transportation wheels, the equipment must be disassembled before transportation. ࣑... -
Page 23: Troubleshooting, Care And Maintenance
TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions ⚠ WARNING Do not make any improper changes to the equipment. CAUTION ⚠ Damaged or worn components may affect your safety and the life of the equipment. Therefore, immediately replace damaged or worn components. In such a case, contact the contract partner. -
Page 24: Maintenance And Inspection Calendar
Maintenance and Inspection Calendar To avoid damage from body sweat, the equipment must be cleaned with a damp towel (no solvents!) after each training session. The following routine tasks must be performed at the specified intervals: Part Weekly Monthly Quarterly Screw connections Cushions Legend: C = clean;... -
Page 25: Recommended Accessories
RECOMMENDED ACCESSORIES To make your training experience even more efficient and pleasant, we recommend that you add suiting accessories to your fitness equipment. This could be a floor mat, for example, which makes your fitness equipment stand more securely and also protects the floor from falling sweat, but it could also be additional handrails on some treadmills or silicone spray to keep moving parts in good shape. -
Page 26: Ordering Spare Parts
The serial number of your equipment is unique. It's located on a white sticker. The exact position of this sticker is shown in the following illustration. Enter the serial number in the appropriate field. Serial number: Brand / Category: Taurus / Abs machine / Back machine Model Name: Studio Adjustable Roman Chair Article Number: TF-PT0224... -
Page 27: Parts List
Parts List Name Specification Qty. Intermediate support frame Right support frame Left support frame Pedal frame Cushion frame Mainframe Leg pad fixing frame φ25*124 Arc adjusting plate Adjusting tube Adjusting column Semi-sliding sleeve Foot frame Back pad Leg pad Steps rolling bearing φ52*φ25*18 Spring Φ1.4*Φ12.5*30... - Page 28 Countersunk riveted nut M8*16.5 Countersunk hex socket screws M6*10 Countersunk hex socket screws M8*25 Hexagon socket button head screw M8*20 Hexagon socket button head screw M8*30 Hex socket head cap screw M10*30 Hex socket head cap screw M10*80 Hex socket head cap screw M10*90 Hex socket head cap screw M12*140...
-
Page 29: Exploded Drawing
Exploded View Exploded Drawing... -
Page 30: Warranty
WARRANTY Training equipment from Taurus® is subject to strict quality control. However, if a fitness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline. - Page 31 Warranty Conditions For the warranty to be valid, the following steps must be taken: Please contact our customer service by email or phone. If the product under warranty has to be sent in for repair, the seller bears costs. After expiry of the warranty, the buyer bears the costs of transport and insurance.
-
Page 32: Contact
CONTACT TECHNICAL SUPPORT TECHNICAL SUPPORT & SERVICE TECHNICAL SUPPORT & SERVICE �� �� �� +49 4621 4210-900 80 90 16 50 +33 (0) 172 770033 +49 4621 4210-945 +49 4621 4210-933 �� +49 4621 4210-698 �� �� info@fitshop.dk service-france@fitshop.fr �� technik@sport-tiedje.de ��... - Page 33 LIVE FITNESS WEBSHOP AND SOCIAL MEDIA Sport-Tiedje is Europe’s largest specialist store www.sport-tiedje.co.uk for home fitness equipment with currently over www.sport-tiedje.de/blog 70 stores and one of the world’s most renowned online mail order companies for fitness equipment. Private customers order via the 25 www.facebook.com/SportTiedje web shops in the respective national language or have their desired equpiment assembled on...
- Page 34 Notes Adjustable Roman Chair...
- Page 36 Taurus Studio Adj Roman Chair...
