- Page 1 AIRSLIM [M] Installation Manual Issued January 2020 ANIM10FI Rev. F...
- Page 2 Update Technical Characteristics 02 / 09 / 2019 Wiring installation recommendations 29 / 01 / 2020 Update Technical Characteristics Technical documents are regularly updated. Anemoi reserves the right to modify the contents of this manual, in full or in part, without warning.
-
Page 3: Table Of Contents
AIRSLIM [M] TABLE OF CONTENTS SAFETY .................................. 4 INTRODUCTION ............................5 TECHNICAL CHARACTERISTICS ....................... 6 DIMENSIONS ..............................7 DELIVERY ..............................8 Package Dimensions & Weights ......................8 Packing List ............................8 MECHANICAL INSTALLATION ........................10 Clearances ............................10 Installation Tools ..........................12 Ceiling Fixation ............................ -
Page 4: Safety
AIRSLIM [M] SAFETY Before the installation, read the following warning and caution instructions: WARNING! Do NOT install, repair or clean the fan while it is in operation or connected to the power supply. Failure to do so may result in serious injury or death. Do NOT install, handle, repair or clean the fan with wet hands. -
Page 5: Introduction
AIRSLIM [M] 1 INTRODUCTION The Anemoi AIRSLIM [M] fans have been designed to generate a huge volume of air from the ceiling in industrial and commercial installations with roofs around 7m high. This low consumption fan is used to increase comfort in summer by generating a smooth breeze and also in winter using the heat located in the top coats of the building. -
Page 6: Technical Characteristics
AIRSLIM [M] 2 TECHNICAL CHARACTERISTICS AIRSLIM 300M AIRSLIM 350M AIRSLIM 400M GENERAL CHARACTERISTICS Diameter 3.6m 4.3m Blades number 5 aluminium blades Standard colour Black matte colour and aluminium blades MOTOR CHARACTERISTICS Motor power 240W 240W 240W Supply voltage 110VAC – 240VAC single phase, 50/60 Hz... -
Page 7: Dimensions
3 DIMENSIONS The Anemoi AIRSLIM [M] comes in four different diameters. The height of the fan can also be adjusted by modifying the length of the extension bar. The following figure shows the dimensions of the fan with a standard extension of... -
Page 8: Delivery
AIRSLIM [M] 4 DELIVERY The Anemoi AIRSLIM [M] fan is delivered in two wood boxes, one including the motor parts and the other the blades. Handle the fan boxes carefully and with proper lifting equipment to avoid any damage. CAUTION! Use proper lifting equipment to handle the motor and blade boxes. - Page 9 AIRSLIM [M] The motor box also includes the following screws: Screw standard Screw M10x70 Nut M10x70 Ring clamb for for the safety cable “U-shaped” clamps for the control plate Screw M6 for the “U” for cla p Screw M6x25 Nut M6 Washer M6 Blades Box: Component name...
-
Page 10: Mechanical Installation
The Anemoi AIRSLIM [M] fan is designed for ceiling installation. Ensure that the ceiling area chosen can hold the weight of the fan and that there are no obstacles in its operating range. The maximum weight of the fan is about 30 kg. - Page 11 AIRSLIM [M] If the fan is installed in an inclined roof, ensure that these minimum distances are achieved and add a higher extension rod if necessary, to allow the fan take enough air and provide the maximum performance. CAUTION! Ensure that the minimum distances are achieved. Otherwise, the fan could be damaged. It is recommended to protect the fan if there is the possibility to receive impacts.
-
Page 12: Installation Tools
Phillips screwdriver Level ruler 300mm Cutting pliers Small Screwdriver Wire stripper Insulating tape 5.3 Ceiling Fixation The Anemoi AIRSLIM [M] comes with mounting brackets to anchor the fan to the ceiling. The fan is prepared to be installed in inclined roofs. -
Page 13: Extension Rod Assembly
AIRSLIM [M] 5.4 Extension Rod Assembly CAUTION! Ensure that power cables, control cables and safety cable pass through the ceiling bracket and through the extension rod. Otherwise, the fan will be installed incorrectly. Ensure to place the rectangular hole of the extension bar on the bottom. Otherwise, the fan will be installed incorrectly. - Page 14 AIRSLIM [M] CAUTION! Ensure that the M10 motor/extension bolts are correctly fastened. Failure to do so may result in equipment damag. Once the extension rod has been fixed to the roof fixing, the screws must be tightened to avoid the swinging of the extension.
- Page 15 AIRSLIM [M] The length of the extension rod can be customized according to the installation requirements between 500, 800, 1000, 1500 y 2000 mm. The variation of the extension rod length allows adjusting installation height of fan. f the extension rod exceeds one meter, winds must be installed to avoid oscillations. The variation of the extension rod allows adjusting the height at which the fan is installed.
-
Page 16: The Cover
AIRSLIM [M] 5.5 The cover The mounting bracket of the ceiling of the fan Anemoi AIRSLIM [M] should be covered with a cover. To fix the cover, turn counterclockwise and tighten the two fixing screws as shown in the following figure:... -
Page 17: Motor Assemby
AIRSLIM [M] 5.6 Motor Assemby CAUTION! Ensure that the cables which pass through the top of the motor are on the same side as the rectangular window of the extension rod. Failure to do so may result in equipment damage. Do not lift the motor weight alone. -
Page 18: Safety Cable Installation
AIRSLIM [M] 5.7 Safety Cable Installation The motor box contains a steel safety cable that must be installed to protect the motor from falling once it is installed. Place the safety cable in a fixed element of the ceiling. • If the fan is installed in a concrete ceiling, drill the ceiling and insert a ring that supports the weight of the fan at the fan’s ceiling fra e. -
Page 19: Controller Installation
AIRSLIM [M] 5.8 Controller Installation The fan motor is connected to a control board that is installed on the extension rod, just above the motor. The control board carries a hole to pass the power and communications cables that come out through the hole of the extension tube. -
Page 20: Blades Assembly
AIRSLIM [M] 5.9 Blades Assembly The Anemoi AIRSLIM [M] fan has five blades. To assemble the blades, it is necessary to introduce and fix them to the motor guides. Use the M6x25 screws, M6 nuts and M6 washer provided by applying a tightening torque of 37Nm as shown in... -
Page 21: Cover Fixation
AIRSLIM [M] 5.10 Cover Fixation The fan includes a special cover to hide the screws. Use the screws provided to cover the bottom of the motor as shown in picture:... -
Page 22: Guy Wires Fixation (Optional)
AIRSLIM [M] 5.11 Guy Wires Fixation (Optional) When the extensión rod esceeds one meter, it is needed guy wires fixation to secure the fan, in order to avoid oscillations. The extension rod must be ordered specially prepared with four perforations to connect the four safety cables. -
Page 23: Electrical Installation
Follow the instructions and recommendations contained in this section. Failure to do so may result in serious injury or death. The Anemoi AIRSLIM [M] fan motor is controlled by a control plate located above the motor. To ensure the operation of the fan, the user must connect power and control cables. -
Page 24: Connectors And Switches Location
AIRSLIM [M] 6.1 Connectors and Switches Location The Anemoi AIRSLIM [M] fan has all the connectors on the control board that is installed on the motor. This board also has several switches that allow you to configure communications. The following image shows the location of the connectors and switches: Nº... -
Page 25: Power Connections
6.2 Power Connections The Anemoi AIRSLIM fan motor has three connectors that must be connected to the control board. In the figure of section 6.1 you can see where to connect the cables directly to connectors 5, 6 and 7. -
Page 26: Control Connections
AIRSLIM [M] 6.3 Control Connections The Anemoi AIRSLIM [M] fan needs an external control to work. The external control is connected directly to the fan control board using shielded cable type modbus cable RS485 2x2x0.50 mm² POSCY. The control connections of the fan are located in connector 2 of the figure in section 6.1. -
Page 27: Multi Fans Installation
AIRSLIM [M] 6.4 Multi Fans Installation In installations with multiple fans, it is possible to control the fans using a single controller. In this case, the controller is connected to the different by using control connections described in section 6.3. The connection must be made in series. - Page 28 AIRSLIM [M] The fans connected in a network can be operated individually with a customized Modbus address in each of them. There are two options to customize the Modbus address: • Connecting a computer and writing the value in address 29 as long as Pin8 of switch 2 is in the ON position.
-
Page 29: Wiring Installation Recommendations
AIRSLIM [M] 6.5 Wiring installation recommendations To ensure correct installation and functioning of the Modbus control fan, please keep in mind following recommendations: 1- Please strip the wire 5cm as a maximum as shown below: 2- Communication cables cannot be wound. If it were done, they could act as an antenna. Communication cables that are not used have to be cut and left inside the shielded tube as shown below. - Page 30 AIRSLIM [M] 3- Please keep always a distance of at least 20cm between the power and the data cable. If both cables must cross at some point, please ensure that they do so at a 90º angle to prevent interference. DRIVE 4- The data cable should follow the shortest path and he should avoid areas of power drive, as shown below: Communications cable must...
-
Page 31: Mantenaince
AIRSLIM [M] 7 MANTENAINCE WARNING! Do NOT repair or clean the fan while it is in operation or connected to the power supply. Doing so may result in serious or fatal electrical shock. Please maintain the fan as follows: Every three months: •... - Page 32 www.anemoifans.com...
