AIRPRO [L]
Installation Manual
Issued March 2020
ANIM19AI Rev. A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AIRPRO L and is the answer not in the manual?

Questions and answers

Summary of Contents for ANEMOI AIRPRO L

  • Page 1 AIRPRO [L] Installation Manual Issued March 2020 ANIM19AI Rev. A...
  • Page 2 AIRPRO [L] UPDATES DATE UPDATE DESCRIPTION 05/03/2020 First Edition Technical documents are regularly updated. Anemoi reserves the right to modify the contents of this manual, in full or in part, without warning.
  • Page 3: Table Of Contents

    AIRPRO [L] TABLE OF CONTENTS SAFETY .................................. 4 INTRODUCTION ............................5 TECHNICAL CHARACTERISTICS ....................... 6 DIMENSIONS ..............................7 DELIVERY ..............................8 Package Dimensions & Weights ......................8 Packing List ............................8 Fan diagram ............................10 MECHANICAL INSTALLATION ........................11 Clearances ............................12 Installation Tools ..........................
  • Page 4: Safety

    AIRPRO [L] SAFETY Thank you for purchasing our products! Please read this manual carefully before use, use the product accordingly and keep the manual in safe place. Installation work and electrical wiring must be done by qualified person(s) in accordance with all applicable codes and standards.
  • Page 5: Introduction

    1 INTRODUCTION The AIRPRO L series is the most powerful motor in the series and has been specially designed to be easily installed in high ceilings. This fan combines IP55 to operate in the harshest ambient conditions and design. This fan is built- in seven blades and the drives are provided in an external box to reduce maintenance and installation costs.
  • Page 6: Technical Characteristics

    AIRPRO [L] 2 TECHNICAL CHARACTERISTICS AIRPRO 400 L AIRPRO 500 L AIRPRO 550 L AIRPRO 600 L AIRPRO 700 L GENERAL CHARACTERISTICS Diameter 5.5 m 6.1 m 7.3 m Blades number 7 aluminium blades Standard colour Black matte colour and aluminium blades MOTOR CHARACTERISTICS Motor power 1,000W...
  • Page 7: Dimensions

    3 DIMENSIONS The Anemoi Airpro [L] has five different diameters. The height of the fan can also be varied by changing the length of the extension rod. The next figure shows the fan dimensions with an extension drop of 643 mm:...
  • Page 8: Delivery

    AIRPRO [L] 4 DELIVERY The Anemoi Airpro [L] fan is delivered in two wood boxes, one including the motor parts and the other the blades. Handle the fan boxes carefully and with proper lifting equipment to avoid any damage. CAUTION! Use proper lifting equipment to handle the motor and blade boxes.
  • Page 9 AIRPRO [L] Drive Box 1 pc Extension Tube Shield 2 pc Blade Guides 7 pc Small Equipment box, included at motor box: Component name Safety Cable 1 pc Wire Rope Clamp 20 pcs End Caps 7 pcs Turnbuckle 4 pcs Beam clamp set 4 pcs Earth Wire...
  • Page 10: Fan Diagram

    AIRPRO [L] 4.3 Fan diagram A - Safety Cable H - Extension tube clamp B - I-Beam clamp I - Wire rope clamp C - I-Beam shim J - Blades Retainer D - Mounting Base K - Main Fan Unit (motor) E - Mounting bracket L - Blade guides F - Extension tube...
  • Page 11: Mechanical Installation

    The Anemoi Airpro [L] fan is designed for ceiling installation. Ensure that the ceiling area chosen can hold the weight of the fan and that there are no obstacles in its operating range. The maximum weight of the fan is about 120 kg and the maximum torque is about 42Nm.
  • Page 12: Clearances

    5.1 Clearances In order to ensure the maximum coverage of the Anemoi Airpro [L], all obstacles that may be encountered within the radius of the fan and between the horizontal height of the fan's static position and the ceiling should be considered before installation, ensuring that the fan has an appropriate clearance in all directions when running.
  • Page 13: Installation Tools

    AIRPRO [L] 5.2 Installation Tools To install the fan, ensure having the following required tools: Name Quantity Standard wrench set Standard socket set with ratchet Standard Allen wrench set Phillips screwdriver Hydraulic cutter Torque wrench (5-45 Nm) Flat head screwdriver Multimeter Pair of #14 to #24 AWG strippers Electronic level...
  • Page 14: Pre-Installation Checklist

    Ensure the minimum requirements are met. Failure to do so may result in equipment damage. 5.5 Blade guide The Anemoi Airpro [L] comes with seven blade guides for install the blades easily 1. Install the 7 blade guides on the motor, this step can be completed on ground.
  • Page 15: Ceiling Mount Bracket

    5.6 Ceiling Mount Bracket The Anemoi Airpro [L] comes with mounting brackets (Mounting Base) to anchor the fan to the ceiling. As standard, all tooling is provided so that the fan can be mounted in I beams or concrete beams. The fan is prepared to be installed in inclined roofs.
  • Page 16: Safety Cable Installation

    AIRPRO [L] 5.7 Safety Cable Installation The motor box contains a safety cable that must be installed to prevent the engine from failing after assembly. To do so, please use four Wire Rope Clamp and the Safety Cable. If the fan is mounted on a steel or concrete beam, wrap the beam with the safety cable in a closed loop as shown below: 4-1.
  • Page 17: Extension Tube Shield Installation

    AIRPRO [L] 5.8 Extension Tube Shield Installation The extension tube shield is provided in order to protect the safety cable and wiring. To do so, please use four bolts of the Extension tube shield bolt kit that is provided in the motor box, as shown below: 5-1 Connect three-phase terminals (U, V, W) to drive box.
  • Page 18: Guy Wires Fixation (Optional)

    AIRPRO [L] 5.9 Guy Wires Fixation (optional) If oscillations are detected, winds must be installed as part of the assembly process. The use of winds is recommended for extensions greater than the standard extension.do so, there is an auxiliary hardware with Turnbuckle, Wire Rope Clamp and Beam Clamp set.
  • Page 19 AIRPRO [L] 9-1. Based on step 9, tighten the guy wire with turnbuckle and wire rope clamp as picture shows. 9-2 Adjust the turnbuckle to balance the ceiling fan. Recommended Tightening Torque: 12Nm. Use 8 x Wire Rope Clamp and 4 x Turnbuckle.
  • Page 20: Blades Assembly

    AIRPRO [L] 5.10 Blades Assembly To assemble the blades, it is necessary to screw the plastic end caps, and introduce and fix them to the motor guides. Use the M6 bolts to fix the plastic end caps before lifting the blade to the motor. 10.
  • Page 21: Drive Box Installation

    Drive Box Installation The Anemoi Airpro [L] drive is provided in an external box to reduce maintenance and installation costs. The drive box is prepared to be screwed to a wall. Before drilling the wall, present the box to the wall and mark the screws.
  • Page 22: Electrical Installation

    You may use shielded or unshielded cables. Please root the cables along the ceiling beams using the shortest possible path. The Anemoi Airpro [L] fan needs an external control to work. The external control is connected directly to the fan control board using shielded cable type Modbus cable RS485 2x2x0.50 mm² POSCY.
  • Page 23 AIRPRO [L] The external Drive Box of the Anemoi Airpro has the next Port defined: No Connection (Modbus Version) MODBUS No Connection (Modbus Version) Power Switch Circuit Breaker Incoming Power Plug Motor Wire Plug Motor Drive Earth Terminal Interface Power Switch...
  • Page 24 AIRPRO [L] Electrical and data connections are shown below: A circuit breaker (CB) must be installed for each fan, it is recommended an 20mA Circuit Breaker. In other to avoid motor damages. In order to avoid motor damages, GND must be connected in Earth Terminal at the Drive Box and to the Extension Tube (PE) by using the Earth Wire included in the Main Box.
  • Page 25: Multi Fans Installation

    AIRPRO [L] 6.1.1 Multi Fans Installation In installations with multiple fans, it is possible to control the fans using a single controller. In this case, the controller is connected to the different by using control connections. The connection must be made in series. The next figure shows the correct connections: WARNING! Never mix electrical and control wiring.
  • Page 26: Recommendations

    AIRPRO [L] 6.1.2 Recommendations To ensure correct installation and functioning of the Modbus control fan, please keep in mind following recommendations: 1- Please strip the wire 5cm as a maximum as shown below: 2- Communication cables cannot be wound. If it were done, they could act as an antenna. Communication cables that are not used have to be cut and left inside the shielded tube as shown below.
  • Page 27: Maintenance

    AIRPRO [L] 7 MAINTENANCE WARNING! Do NOT repair or clean the fan while it is in operation or connected to the power supply. Doing so may result in serious or fatal electrical shock. Please maintain the fan as follows: Every three months: •...
  • Page 28: Troubleshooting

    AIRPRO [L] 8 TROUBLESHOOTING WARNING! Do NOT make any inspection of the fan while it is in operation or connected to the power supply. Doing so may result in serious or fatal electrical shock. In case of failure, refer to the following table for quick solutions: Observation Probable cause Inspection method...
  • Page 29 www.anemoifans.com...
