- Page 1 Version 1.0 Hamilton Bookcase 5 Shelf fantasticfurniture.com.au...
- Page 2 We’re thrilled you’ve chosen Fantastic Furniture to help create a home you’ll love! Love it? Share it! Fantastic buy! Share how it looks at home on Instagram for your chance to win a $250 Fantastic Furniture Gift Card! @fantasticfurniture Page 2 fantasticfurniture.com.au...
-
Page 3: Assembly Checklist
Assembly Checklist Read through the instructions carefully Make sure you have all the required tools. before you begin. Never use power tools unless instructed. Unless instructed, do not fully tighten Identify and lay out all of the screws until the item is fully assembled. components before you begin assembly. -
Page 4: What You Need
What you need Top Panel to assemble the product Rail (P1) (P7) 5 x Back Right Side Panels Panel (P3) DO NOT USE (P6) Shelf Panel (P4) Other tools you need: Phillips head screwdriver; Shelf Panel (P4) Left Side Panel (P2) Shelf Panel (P4) Parts list... - Page 5 Step 1 You will need 4 x Cam Bolts Phillips Head (H3) Screwdriver (P1) Attach 4 x Cam Bolts (H3) to Top Panel (P1) by tightening with the Phillips Head Screwdriver. Step 2 You will need (P2) 24 x Cam Bolts Phillips Head (H3) Screwdriver...
- Page 6 Step 3 You will need (P7) 2 x Long Phillips Head Screws (H2) Screwdriver (P5) Secure Rail (P7) to Bottom Panel (P5) with 2 x Long Screws (H2) by tightening with the Phillips Head Screwdriver. Step 4 (P7) You will need (P4) (P4) 10 x Dowels...
- Page 7 Step 5 (P6) (P6) (P6) (P4) (P6) (P4) (P4) (P4) (P5) Slide Back Panels (P6x4) into the grooves of Shelf Panels & Bottom Panel (P4x4 & P5) as shown. Step 6 (P3) You will need 10 x Dowels 12 x Cam Nuts (P7) (H1) (H4)
- Page 8 (P6) Step 7 (P3) (P2) Gently stand the unit upright. Slide Back Panel (P6) into the grooves of the Left & Right Side Panels (P2 & P3). Step 8 (P1) (P3) You will need (P7) 2 x Long 4 x Cam Nuts (P2) (P7) Screws (H2)
- Page 9 Step 9 (P1) You will need (P6) 8 x Wedges 8 x Wedge (H5) Screws (H6) 1 x Safety 1 x Safety Strap Strap (H7) Screw (H8) 1 x Washer Phillips Head (P6) (H9) Screwdriver Secure Back Panels (P6 x 2) in place as shown with 8 x Wedges (H5) using 8 x Wedge Screws (H6) by tightening with the Phillips Head Screwdriver.
-
Page 10: Job Complete
Job Complete! In the interest of our environment please dispose of all packaging thoughtfully. fantasticfurniture.com.au Page 10...
