Zip-Tex Spray Gun
(Consult your material supplier for Warnings and Application Requirements)
Model 249458
125 psi (0.86 MPa, 8.6bar) Maximum Working Pressure
Non-bleeder gun for use with Zip-Tex 1500 Texture Sprayer.
For sprayer operation and warning information,
refer to your sprayer or compressor operation manual.
Important Safety Instructions
Read all warnings and instructions in this manual.
Save these instructions.
For water-based materials only
-
311159A
-
ti3966a
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ASM 249458
Summary of Contents for ASM 249458
- Page 1 Zip-Tex Spray Gun 311159A For water-based materials only (Consult your material supplier for Warnings and Application Requirements) Model 249458 125 psi (0.86 MPa, 8.6bar) Maximum Working Pressure Non-bleeder gun for use with Zip-Tex 1500 Texture Sprayer. For sprayer operation and warning information, refer to your sprayer or compressor operation manual.
- Page 2 Check equipment daily. Repair or replace worn or damaged parts immediately. • Do not alter or modify equipment. • Use equipment only for its intended purpose. Call your ASM distributor for information. • Route hoses and cables away from traffic areas, sharp edges, moving parts, and hot surfaces. •...
-
Page 3: Component Identification
Component Identification Component Identification Air Valve Trigger Trigger Lock Nozzle Air Fitting Material Inlet Air Shutoff Needle Pressure Relief Procedure IMPORTANT To reduce the risk of injury, follow this Pressure Relief Procedure whenever you: • Are instructed to relieve pressure •... -
Page 4: Installation
Setup Setup Grounding To reduce risk of electrical shock, proper electric grounding is essential. See your sprayer instruction manual and consult your local electrical codes for detailed grounding instructions. Installation ti4003a 1 Relieve Pressure, page 3. 2 Connect air and material hoses 3 Install nozzle (4a) on front of 4 Refer to system operation man- to gun. -
Page 5: Nozzle Selection
Spray Techniques Nozzle Selection ti4000a Standard nozzles (4A) are • For smaller droplet sizes, • For larger droplets, increase numbered 3, 4, 6, 8, 10 and 12, reduce nozzle (4A) size and nozzle (4A) and reduce gun designating orifice size in increase gun atomizing air by atomizing air by closing air millimeters. - Page 6 Spray Techniques ti4338a 4 To select correct nozzle for When adjusting flow adjustment Check material consistency your applications, consider nut (B), release trigger (C), then often. Material may thicken as it size of aggregate in material adjust. sits and slow down production or and coarseness of spray pat- affect spray pattern.
- Page 7 Cleanup Cleanup WATER ti4290a ti4334a WASTE 1 Pump remaining material into 2 Fill hopper with clean water. 3 Pump water through system 4 Remove nozzle (4A) from gun bucket until most of texture and out of gun. and allow water to flow material is out of hopper.
- Page 8 1 Remove retaining ring (11), 2 Use a hook-shaped object to 3 Using your finger or a 1/2-in. 5 ASM recommends you nozzle (28), and needle carefully pull up-cup retainer diameter rod, push new seal replace the entire fluid needle assembly (9) through front of and u-cup out of gun.
-
Page 9: Troubleshooting
Troubleshooting Troubleshooting Problem Cause Solution Material will not flow out of gun Material too thick Thin material. Increase pressure at pump. Not enough air Open gun air valve (A) more (counter-clockwise) Trigger adjustment set too low Rotate trigger nut clockwise to increase (adjust) trigger travel Nozzle too small Increase nozzle size... - Page 10 Parts Parts ti3968a 311159A...
- Page 11 Parts Parts Item Part No. Description 103147 PLUG, pipe 15D125 SEAL, u-cup,.375 dia. shaft 15D126 SEAL, u-cup,.156 dia. shaft 118592 SPRING, compression 156454 PACKING, o-ring 15C894 GUIDE, needle, fluid 15B163 NUT, needle 246972 NEEDLE, fluid, assbly 119343 RING, retaining 15B042 RING, retaining, nozzle 15C882 TRIGGER, gun 15D120 LOCK, trigger 118717 PIN, clevis w groove...
-
Page 12: Technical Data
Technical Data Technical Data Maximum air working pressure 125 psi (8.6 bar) Air requirements 30 scfm (0.84m /min) Maximum Fluid inlet sizes 1 in. NPT (25.4 mm) Wetted parts Anodized Aluminum, Stainless Steel, Buna-N, UHMW Poly- ethylene, Brass, Steel Viton, Delrin Sound data Sound pressure level 96 dB(A)*... - Page 13 Notes Notes 311159A...
-
Page 14: Warranty
ASM distributor to the original purchaser for use. With the exception of any special, extended, or limited warranty published by ASM, ASM will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by ASM to be defective.
