ICP DAS USA I-8437-80 Getting Started

Hide thumbs Also See for I-8437-80:
Table of Contents

Advertisement

Quick Links

Download this manual
"I-8xx7" is the abbreviation of "I-8437-80/8837-80/8417/8817", and the I-8x37 is the Ethernet
PAC.
ICP DAS CO., LTD. would like to congratulate you own your purchase of our ISaGRAF PACs -
I-8437-80/8837-80/8437/8837/8417/8817.
power of the IEC 61131-3 ISaGRAF software program combine to make a powerful, yet
inexpensive industrial process control system.
ISaGRAF PAC Series of ICP DAS includes:
Please visit the website:
www.icpdas.com/en/product/guide+Software+Development__Tools+ISaGRAF
μPAC:
iPAC:
XPAC:

Legal Liability

ICP DAS CO., LTD. assumes no liability for any and all damages that may be incurred by the
user as a consequence of this product. ICP DAS CO., LTD. reserves the right to change this
manual at any time without notice.
ICP DAS CO., LTD. constantly strives to provide our customers with the most reliable and
accurate information possible regarding our products. However, ICP DAS CO., LTD. assumes
no responsibility for its use, or for any infringements of patents or other rights of third parties
resulting from its use.
Trademark & Copyright Notice
The names of products are used for identification purposes only, and are the registered
trademarks of their respective owners or companies. Copyright © April 2002, by ICP DAS CO.,
LTD. All Rights Reserved.

Technical Service

Please contact local agent or email problem-report to service@icpdas.com.
New information can be found at
ISaGRAF webpage:
https://www.icpdas.com/en/product/guide+Software+Development__Tools+ISaGRAF
ISaGRAF FAQ :
https://www.icpdas.com/en/faq/index.php?kind=280#751
ISaGRAF Download Center:
https://www.icpdas.com/en/download/index.php?nation=US&kind1=&model=&kw=isagraf
Written by Chun Tsai, Spike Huang & Janice Hong, R&D dept., ICP DAS
Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V4.0
Getting Started: I-8437-80/8837-80/
μPAC-7186EG, I-7188EG, I-7188XG Series
iP-8xx7 Series, I-8xx7 Series
XP-8xx7-CE6 Series
www.icpdas.com
8437/8837/8417/8817
The ease to integration of the PAC and the
1

Advertisement

Table of Contents
loading

Related Manuals for ICP DAS USA I-8437-80

Summary of Contents for ICP DAS USA I-8437-80

  • Page 1: Getting Started: I-8437-80/8837-80/ 8437/8837/8417/8817

    Getting Started: I-8437-80/8837-80/ 8437/8837/8417/8817 “I-8xx7” is the abbreviation of “I-8437-80/8837-80/8417/8817”, and the I-8x37 is the Ethernet PAC. ICP DAS CO., LTD. would like to congratulate you own your purchase of our ISaGRAF PACs - I-8437-80/8837-80/8437/8837/8417/8817. The ease to integration of the PAC and the power of the IEC 61131-3 ISaGRAF software program combine to make a powerful, yet inexpensive industrial process control system.

  • Page 2: Revision History

    This chapter provides revision history information to this document. The table below shows the revision history. Revision Date Description  Update URLs to the new website  Update some pictures V2.0 Jul. 2020  Remove FTP URLs and the path of CD-ROM Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V4.0...

  • Page 3: Table Of Contents

    Table of Contents Getting Started: I-8437-80/8837-80/ 8437/8837/8417/8817 ........1 Legal Liability ........................... 1 Trademark & Copyright Notice ....................1 Technical Service ........................1 Revision History ........................2 Table of Contents....................... 3 Reference Guide ......................6 I/O Modules Selection Guide ..................7 Specifications: I-8437-80/8837-80/I-8417/8817 ............
  • Page 4 How to change Modbus RTU Baud Rate & Setup COM3 as Modbus Slave Port ..52 Deleting an ISaGRAF Project from the PAC ..............53 Connecting PC to the I-8437-80/8837-80 Ethernet Port ..........54 Modbus Slave Connection to the I-8xx7 ............... 55 Setting I-8437-80/8837-80’s IP &...
  • Page 5 The Download Page for ISaGRAF Resource ............. 73 Using Modbus TCP/IP protocol to control ISaGRAF PACs with VB? ......75 B: 10-ch Thermocouple Input Module ..................76 I-7018Z ........................... 76 I-87018Z ..........................76 C: RU-87P1/2/4/8 ........................77 Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V4.0...

  • Page 6: Reference Guide

    (Hardware) Manual: https://www.icpdas.com/en/download/show.php?num=425 Related Products:  Industrial Ethernet Switch: http://www.icpdas.com/en/product/guide+Industrial__Communication+Ethernet__Communi cation+Ethernet__Switch  RS-232 to RS-422/485 Converter: http://www.icpdas.com/en/product/guide+Industrial__Communication+Serial__Communi cation+Converter  Power Supply : http://www.icpdas.com/en/product/guide+Accessories+Power__Supplies+Power__Supply  High Profile I-8K/87K Series I/O Modules http://www.icpdas.com/en/product/guide+Remote__I_O__Module__and__Unit+PAC__%EF %BC%86amp;__Local__I_O__Modules+I-8K_I-87K__Series__(High__Profile) ISaGRAF FAQ: https://www.icpdas.com/en/faq/index.php?kind=280#751 Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V4.0...

  • Page 7: I/O Modules Selection Guide

    I/O Modules Selection Guide The I-8xx7 series PAC supports the I-8K/I-87K I/O modules and RS-485 remote I/O modules modules. Please refer to ICP DAS website: www.icpdas.com http://www.icpdas.com/en/product/guide+Remote__I_O__Module__and__Unit+Software__ Support__+I-8K_I-87K__Software__Support Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V4.0...

  • Page 8: Specifications: I-8437-80/8837-80/I-8417/8817

    Specifications: I-8437-80/8837-80/I-8417/8817 Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V4.0...
  • Page 9 Note: I-8x37 has already been phased out; please select compatible I-8x37-80. ISaGRAF Download Center: Refer to Data Sheet http://www.icpdas.com/en/download/index.php?nation=US&kind1=&model=&kw=isagraf Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V4.0...

  • Page 10: Chapter 1 Typical Application

    - the advanced I-8xx7 ISaGRAF based iPAC. Features: • Support Dual Ethernet 10/100 Mbps • 768K memory for running program, 256K more than I-8437-80/8837-80 • Built-in 512K Battery backup SRAM • Support sending E-mail with an attached file (Max. 488 KB) •...

  • Page 11: Redundant Bus7000

    Redundant Bus7000 I-8437-80/8837-80: SMS: Short Message Service More at https://www.icpdas.com/en/faq/index.php?kind=280#751 > FAQ-111 Getting Started: I-8437-80/8837-80/8437/8837/8417/8817, Jul 2020 V2.0...

  • Page 12: Download & Monitoring Via Modem_Link

    One I-8091 can control 2-axis: X-Y plane, or 2 axes independent Two I-8091 can control 4-axis: X-Y plane + 2 axes independent or 4 axes independent I-8417/8817/ I-8091: 2 axes I-8090: 3 axes Encoder 8437-80/8837-80 Getting Started: I-8437-80/8837-80/8437/8837/8417/8817, Jul 2020 V2.0...

  • Page 13: Modbus Converter Of I-7000 & I-87K I/O

    Modbus Converter of I-7000 & I-87K I/O I-8417/8817 can be a Modbus RTU serial converter of I-7000 & I-87K series I/O modules. I-8437-80/8837-80 can be a Modbus RTU serial & TCP/IP converter of I-7000 & I-87K series I/O modules. Getting Started: I-8437-80/8837-80/8437/8837/8417/8817, Jul 2020 V2.0...

  • Page 14: Modbus Master

    Up to 2 COM Ports (COM1, COM3, COM4 and COM5 in multi serial port board) can support Modbus RTU Master or ASCII Master Protocol to connect to other Modbus Slave devices. NOTE: COM5 to COM20 is optional from the I-8112/8114/8142/8144/8142i expansion board. Getting Started: I-8437-80/8837-80/8437/8837/8417/8817, Jul 2020 V2.0...

  • Page 15: Data Exchange Through Ethernet & Rs-485

    Data Exchange through Ethernet & RS-485 PAC to PAC Data Exchange Ethernet: I-8437-80/8837-80 RS485: I-8xx7 1.10 Active Control Data and I/O Acquisition Data Reporting System More at https://www.icpdas.com/en/faq/index.php?kind=280#751 > FAQ-065 Getting Started: I-8437-80/8837-80/8437/8837/8417/8817, Jul 2020 V2.0...

  • Page 16: Zigbee Wireless Solution

    ZB-2000 series product has been phased out, users can choose ZT-2000 series product. ISaGRAF PAC plus ZB-2550P and ZB-2551P RS-232/RS-485 Converters can apply wireless communication, reduce the wiring cost, and achieve the mission of remote I/O control and data acquisition. More at https://www.icpdas.com/en/faq/index.php?kind=280#751 > FAQ-110 Getting Started: I-8437-80/8837-80/8437/8837/8417/8817, Jul 2020 V2.0...

  • Page 17: Chapter 2 Software Programming

    Since 2020, ICP DAS no longer provides ISaGRAF Workbench CD. Please download the software on ISaGRAF Download Center and extract the zip file. Then, double-click on the "ISaGRAF.exe" file to start the installation process. Select the language. Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V4.0...

  • Page 18: The Hardware Protection Device (Dongle & Usb Key-Pro)

    USB port first, then run “\Sentinel\SSD5411-32bit.exe” in the ISaGRAF installation folder after you have installed the ISaGRAF. Then please reset your PC. 2. To run ISaGRAF Ver. 3.5x, please always plug the USB protection-key in the PC’s USB port. Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V4.0...

  • Page 19: Important Notice For Window 2000 Users

    Locate the [WS001] header in the “isa.ini” initialization file (it should be at the top of the file). Anywhere within the [WS001] header portion of the “isa.ini” initialization file, add the entry shown below within the [WS001] header: [WS001] NT=1 Isa=C: \ISAWIN IsaExe=C: \ISAWIN\EXE Group=Samples IsaApl=c: \isawin\smp IsaTmp=C: \ISAWIN\TMP Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V4.0...

  • Page 20: Important Notice For Windows Vista Or Windows 7 (32-Bit) Users

    2. After clicking, it will show up the screen as below. Windows Vista: Uncheck the “Use User Account Control (UAC) to help you protect your computer” box and then click on “OK”. Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V4.0...
  • Page 21 Windows 7: Move the slider down to “Never Notify” and then click on “OK”. 3. Reboot your computer to apply the change. 4. After rebooting, please refer to section 2.1 Installing the ISaGRAF Software. Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V4.0...

  • Page 22: Important Notice For Windows (64-Bit) Users

    6. Install USB dongle driver on a virtual machine. More at https://www.icpdas.com/en/faq/index.php?kind=280#751 > FAQ-174 2.1.6 Important Setting for Using Variable Arrays Please add two more lines on the top of the c:\isawin\exe\isa.ini file to enable the usage of variable arrays. [DEBUG] Arrays=1 Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V4.0...

  • Page 23: Step 2 - Installing The Icp Das Utilities For Isagraf

    Note: Make sure that ISaGRAF Workbench has been installed, IF NOT, refer to Ch 2. 1 Step 1 before continuing. Execute setup.exe and follow the instructions of the InstallShield Wizard to install ISaGRAF Utilities. Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V4.0...

  • Page 24: Step 3 - Writing A Simple Isagraf Program

    Input Push button 1 Boolean Input Push button 2 Timer Internal Time period of blinking ST program – “ST1” outline: IF INIT THEN (* Do init steps here *) INIT:= False; T1:= T#1500ms; END_IF; Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V4.0...

  • Page 25: Open Isagraf-Project Management

    2.3.2 Creating an ISaGRAF User’s Group Click on the [Select Program Group] to open the Project Groups window. As the figure below, click [New Group] and enter a group name, then click on “OK”. Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V4.0...

  • Page 26: Creating A New Isagraf Project

    To start a new ISaGRAF project, click on the “Create New Project” button and then enter the name for the project, you can then enter additional information for the project by clicking on the [Edit] > [Set Comment Text] as illustrated below. Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V4.0...

  • Page 27: Declaring The Isagraf Project Variables

    4. As the figure below, enter a name in the Name field (e.g., "INIT"). 5. Add notes in the Comment field (e.g., "Flag to indicate first scan cycle or not". 6. Set the attribute for the "INIT" variable (e.g., "Internal"). Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V4.0...
  • Page 28 Enter in the output number that you will start within the “Numbering” from and “To” field (this example uses from 1 to 3). Enter the “Symbol” name for the output variables being declared. Lastly, set the attribute to “Output” and then press “OK”. Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V4.0...
  • Page 29 All three outputs will be immediately added to the “Global Boolean” window. Please click “Save” button to save them. Use the same method as former to create another 2 variables – “K1” & “K2” however with “input” attribution. Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V4.0...
  • Page 30 2. Enter the Name as "T1" and set the "Attributes" to "Internal". 3. Set the "Initial Value" to "T#8s", then click on the "Store" button. 4. Click the "Save" button and click on “X” to close the window. Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V4.0...

  • Page 31: Create And Edit The St - "St1" Program

    “Sequential” area, and last the “End” area. An ISaGRAF cycle run in the way as the below scheme. Scan all inputs Process ‘begin’ area ISaGRAF Cycle Process ‘Sequential’ area Process ‘End’ area Refresh all outputs Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V4.0...

  • Page 32: Create The Ld - "Ld1" Program

    Diagram” and make sure the “Style” is set to “End: Main Program”. Also, add any desired text in the “Comment” field. Now we have two programs inside this project. Double-click on the “LD1” to get into it. Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V4.0...

  • Page 33: Edit The "Ld1" Program

    We are going to write the first line of the LD1 program. Move the cursor to the first “contact” and then click on “cut” to delete it. Move the cursor to the first contact and then click on “cut” to delete it. Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V4.0...
  • Page 34 Select the “BLINK” type function block and press “OK”. To learn how the “BLINK” function operates you can click on the “Info” button for a detailed explanation of its functionality. Click on “Info” to get detailed explanation. Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V4.0...
  • Page 35 Now move your cursor to the left of the parameter “CYCLE” of the “BLINK” block. Double-click on it, select “Timer” and then double-click on variable name - “T1” Move your cursor to the “coil”. Double-click on it, select “Boolean” and then double-click on variable name – “OUT01”. Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V4.0...
  • Page 36 Click on “coil” button to create one another coil below the “OUT01”, and then assign a Boolean name – “OUT02” to it. Then we have the below window. To insert the second LD rung, move the cursor to be under the first rung, then click on “Edit” – “Insert rung”. Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V4.0...
  • Page 37 “P” and then set the type of OUT03 to “S”. By the same way to create the third rung as below. Note that K2 has type of “P”; OUT03 has type of “R”. Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V4.0...

  • Page 38: Connecting The I/O

    “push4key: 4 button on panel of 8xx7” to select the function. Slot 0 to 7 is used to connect I/O modules on the PAC, in this case, add the DI function on slot 8. Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V4.0...
  • Page 39 To map input variables “K1” & “K2” to the channel No. 1 & 2 of the “push4key”, double-click on the channel 1 and then click on “Connect”. Then click on “Connect” again to connect channel 2. Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V4.0...
  • Page 40 Only the Input and Output attributed variables will appear in the “I/O Connections” window. In this example we have only 3 Boolean output variables - OUT01, OUT02 & OUT03 and 2 Boolean input variables – K1 & K2. Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V4.0...

  • Page 41: Step 4 - Compiling & Simulating The Example Project

    When using “Variable Array” in the program, please DO NOT check the 2nd, 7th, 8th and 9th Optimizer options, or the value of the Variable array will be incorrect. Recommended to check only the 1st option – “Run two optimizer passes”. Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V4.0...

  • Page 42: Compiling The Ld Project

    “I/O Simulator” windows will be shown. If the names of I/O variables DO NOT appear in the I/O simulator window, just click “Options” on the menu bar, then click “Variable Names” to display variable names. Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V4.0...

  • Page 43: Running The Simulation Program

    "OUT2" is blinking every 1.5 seconds. Users can adjust the value of the "T1" variable during the simulation. In this case, change the setting to blink every 0.5 second. To accomplish this, click the "Dictionary" button. Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V4.0...
  • Page 44 Now we are going to simulate the “K1” & “K2” input. Right-click on the “K1” button will light up the “OUT03”. Also, try to click the “K2” button. Right-click on the “K1” button. To exit the simulation, please close the debugger window. Close the window to stop simulating. Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V4.0...

  • Page 45: Step 5 - Download & Debugging The Example Project

    (refer to Section 3.1) COM port of the PC. Click the Setup button to set communication parameters Using the same parameters with the PAC. The default setting is 19200, N, 8, 1, No flow control. Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V4.0...

  • Page 46: Downloading The Project

    If there is a project running on the PAC, you need to stop that project before downloading a new one. The way is to click the "Stop application" button in the "ISAGRAF Debugger" window. Then, the Example1 project can be downloaded to the PAC. Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V4.0...
  • Page 47 Click the Download button to download the project to the PAC. Then, a progress bar will appear in the “ISaGRAF Debugger” window to show the downloading progress. If the download is completed, you can see the window below. Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V4.0...

  • Page 48: Running The Example Program

    Though there are numerous steps involved in creating and downloading an ISaGRAF program, each step is quick and easy to accomplish. ISaGRAF provides a powerful and flexible software environment to develop the PAC control system. Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V4.0...

  • Page 49: Hardware System & Setting

    =5), set the DIP 1, 3 to ON. If Net-ID=FE = 254 =254), set the DIP 2 to 8 to ON. (16) (10) If Net-ID= FF = 255 =255), set the DIP 1 to 8 to ON. (16) (10) Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V2.0...

  • Page 50: Connecting Pc To The I-8Xx7'S Com1

    PC, wiring the RTS-CTS and DTR-DSR signals together as shown below. I-8xx7 9-Pin D-Sub COM1 RxD 2 TxD 2 TxD 3 RxD 3 GND 5 GND 5 DTR 4 DSR 6 RTS 7 CTS 8 Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V2.0...

  • Page 51: Connecting Pc To I-8417/8817'S Com2

    By default, the pull-high (JP1) and pull-low (JP2) resistor inside the PAC are set to “Disable” (i.e., Pin2-3). When using I-8417/8817 as a Modbus Master, you need to set both the JP1 and JP2 to “Enable” (i.e., Pin1-2). Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V2.0...

  • Page 52: How To Change Modbus Rtu Baud Rate & Setup Com3 As Modbus Slave Port

    1’. For the communication between PAC and PC works properly, if the baud rate setting of COM1 and COM2/3 on the PAC is changed, the settings of PC MUST be set to be the same. (Please refer to Section 2.5) Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V2.0...

  • Page 53: Deleting An Isagraf Project From The Pac

    You can see "dEL n" show in the LED readout, press the “Up” or “Dn” button until "dEL y" appears, then press the “OK” button. Cancel This will delete the currently installed ISaGRAF project from the PAC. After that press some “Cancel” to exit the setting. Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V2.0...

  • Page 54: Connecting Pc To The I-8437-80/8837-80 Ethernet Port

    Connecting PC to the I-8437-80/8837-80 Ethernet Port The I-8437-80/8837-80 PACs provides a single Ethernet port can be used to connect to the PC. The COM2 Port is replaced from an RS-485 to Ethernet. The user must set the Ethernet communication parameters correctly for successfully downloading the ISaGRAF project to the PAC over the network.

  • Page 55: Modbus Slave Connection To The I-8Xx7

    COM3 is “non-Modbus Slave Port”, also refer to Section 3.5 to change the setting. I-8437-80/8837-80 provides a single Ethernet port that supports Modbus TCP/IP Slave protocol. The user can set the IP address and TCP port number (fixed 502) for each PAC. One PAC can connect up to 4 PCs through the Ethernet port.

  • Page 56: Setting I-8437-80/8837-80'S Ip & Mask & Gateway

    Setting I-8437-80/8837-80’s IP & MASK & Gateway Download ISaGRAF driver for the PAC on the website and then extract the zip file: https://www.icpdas.com/en/download/show.php?num=368 1. Create a folder named “8000” in the hard drive (e.g., “c:\8000”). 2. Copy "7188xw.exe", "7188xw.ini", "7188xw.f4", "isa.exe", "autoexec.bat", and "8k050408.img"...

  • Page 57: Setting Com1 As Non-Modbus-Slave Port

    8. Remove the connection between “INIT” and “INIT COM” pins and restart the PAC. Note: Users can type “isa *f=0” command to set COM1 back to a Modbus RTU Slave. If the command is invalid, refer to the next section to update the PAC driver. Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V2.0...

  • Page 58: Update I-8Xx7'S Hardware Driver

    “I-8000>” will be shown on the screen. 6. Type “ver” to see the current OS version & date. 7. Type “isa *p=” to see the current version of driver and information about the PAC. Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V2.0...
  • Page 59 9. Type “dir” to make sure “autoexec. bat” and “isa. exe” are well burned. 10. Press ALT+X to exit “7188xw”, or COM1/COM2 of the PC will be occupied. 11. Remove the connection between “INIT” and “INIT COM” pins and restart the PAC. Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V2.0...

  • Page 60: Backup & Restore An Isagraf Project

    ISaGRAF project (e.g., ‘C:\SCOTT’). Also, check the Compress box if you want to reduce the size of the file. 3. In the Workbench section, choose the project you want to back up. 4. Click Backup to store the file to the specified location. Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V2.0...

  • Page 61: Pin Assignment Of The Fbus

    1. In the Archive section, choose the project you want to restore. 2. Click Restore to restore the file to the ISaGRAF Workbench. 3.13 Pin assignment of the Fbus For more details about Fbus, refer to Chapter 7 of the ISaGRAF user manual. http://www.icpdas.com/en/download/show.php?num=333 Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V2.0...

  • Page 62: Setting I-7000 And I-87K Remote I/O By Dcon Utility

    1. DIP-1= ON 2. Power on I-87Kn User Manual: http://www.icpdas.com/en/download/show.php?num=408 I-7000 User Manual: (Initialize I-7000) http://www.icpdas.com/en/download/show.php?num=1860   Init Power on Note: In INIT mode, the setting of I/O module will be initialized. Normal Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V2.0...
  • Page 63 Click the “COM Port” menu to select the COM Port and Baud Rate to search. You can select multiple Baud Rate, Protocol, or Checksum if you do not know the module’s setting, but it will spend more time searching the module. After selection, click “OK”. Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V2.0...
  • Page 64 “Start Search” button to begin search module. Click Step 4: Click Searched module ID and give the new configuration Click when it is searched and double-click module number to enter the setup screen. Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V2.0...
  • Page 65 After completing the settings, disconnect the INIT and the GND (or adjust the DIP switch to the ‘Normal’ position and reboot the module. Finally, you can search the module again and check the settings. Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V2.0...

  • Page 66: Linking I-7000 And I-87K Modules For Remote I/O

    PAC. For more information regarding setting up and programming an I-7000/I-87K remote module, refer to Section 3.14 or Chapter 6 of the ISaGRAF user manual - "Linking to I-7000 and I-87K Modules". Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V2.0...

  • Page 67: Creating A Modbus Link With The Pac

    Modbus device. Note that COM1 is a Modbus Slave port by default so the user can refer to section 3. 10 to change the setting. Also, connect the COM4 port of the PAC to an I-7520R (RS-232/RS-485 converter). In this way, one PAC can connect to several devices. Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V2.0...

  • Page 68: Linking To An Mmi Interface Device

    Touch Monitor: http://www.icpdas.com/en/product/guide+Panel__Products+Display+Touch__Monitor When using any of the Touch series of MMI devices (e.g., Touch506L/506S/510T, etc.) to connect to a PAC, you can only interface the devices to the COM1 port on the PAC. Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V2.0...

  • Page 69: Using N-Port Com

    "COMSTR_W", "COMWRITE" and "COMCLEAR". Visit to the website to download the ISaGRAF User’s Manual, and refer to Appendix A.4 for more details. https://www.icpdas.com/en/download/show.php?num=333 Pin assignment: Visit the website for more information about serial communication modules (Low Profile). Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V2.0...

  • Page 70: Pin Assignment Of Communication Ports

    3.19 Pin Assignment of Communication Ports Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V2.0...

  • Page 71: Dimension

    3.20 Dimension 8 Slots: Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V2.0...
  • Page 72 4 Slots: Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V2.0...

  • Page 73: Appendix

    FAQ on the ISaGRAF webpage. A.1 The Download Page for ISaGRAF Resource  Click the “Download Center” on the ISaGRAF webpage to go to ISaGRAF Download Center. http://www.icpdas.com/en/product/guide+Software+Development__Tools+ISaGRAF Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V2.0...
  • Page 74 Also, type the ICP DAS’s web address http://www.icpdas.com in the browser. 1. www.icpdas.com  Click the “SUPPORT” and “Download Center” to go to the webpage.  Type “ISaGRAF” in the Keywords field and click Search to search related files. Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V2.0...

  • Page 75: Using Modbus Tcp/Ip Protocol To Control Isagraf Pacs With Vb

    VB.net 2005 Demo program using Modbus TCP/IP protocol to control ISaGRAF PACs. Please refer to the website: http://www.icpdas.com/en/faq/index.php?kind=280#751 > FAQ-051 VB 6.0 Demo program using Modbus TCP/IP protocol to control ISaGRAF PACs. Please refer to the website: http://www.icpdas.com/en/faq/index.php?kind=280#751 > FAQ-052 Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V2.0...

  • Page 76: B: 10-Ch Thermocouple Input Module

    5. It features per-channel open wire detection for thermocouple and 4 ~ 20 mA inputs For more details, please visit the web site listed below: I-7018Z: http://www.icpdas.com/en/product/I-7018Z-G_S I-87018Z: http://www.icpdas.com/en/product/I-87018ZW-G_S Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V2.0...

  • Page 77: C: Ru-87P1/2/4/8

    CPU Power System Ready Power Auto Configuration Enable/Disable Address Rotary Switch Configuring DIP Switch Slots LED indicators Power /Data Connector Slot0 Slot1 Slot2 Slot3 Power Module CPU Module I-87K I/O Slot Fig. 1 : RU-87P4 Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V2.0...
  • Page 78  DCON Utility: for configuration  OPC Servers  EZ Data Logger  Support Variant Software Develop Toolkits Free DLL, ActiveX, Labview driver, Indusoft driver, DasyLab driver, Linux driver  ISaGRAF PACs can connect to the RU-87Pn directly Getting Started: I-8437-80/8837-80/8417/8817, Jul 2020 V2.0...

This manual is also suitable for:

I-8837-80I-8417-80I-8817-80
