Summary of Contents for ZKTeco Green Label Elite Series

  • Page 1 Quick Start Guide Elite Series[TI] Version: 1.0 Date: May 2021...
  • Page 2 1 Overview Thermal Imaging Temperature Detection Module Flash Camera Near-Infrared flash 8" Touch Screen Tamper Switch Speaker Reset Button Wiegand IWD1 IWD0 RS232_RXD1 WD1-OUT Wiegand RS232 RS232_TXD1 WD0-OUT 485B Auxiliary RS485 485A Input 12V OUT Sensor Exit Button 12V IN Lock +12V Power...
  • Page 3: Installation Requirements

    Installation Requirements The installation requirements and indicators associated with the temperature detection is given below: Remark Specification Standard value The recommended operating Indoor, No wind, No direct light, Operating temperature is 25°C (77°F) 20°C to 35°C (68°F to 95°F) Environment Distance The recommended distance (between face...
  • Page 4: Device Installation

    3 Device Installation Installation on the wall ① Attach the mounting template sticker to the wall, and drill holes according to the mounting paper. ② Fix the back plate on the wall using the wall mounting screws. ③ Attach the device to the back plate. ④ Fasten the device to the back plate with a security screw.
  • Page 5 4 Device Installation Installation on the barrier gate ① Drill a hole on the barrier gate, insert the bracket into the hole and fix it with a nut. ② Adjust the angle of the device. ① ② Recommended: Gate’s Height (m) Tilt angle of the monitor (upward) 13°...
  • Page 6: Standalone Installation

    5 Standalone Installation Alarm Smoke Detector Exit Button Reader TCP/IP Door Sensor Lock...
  • Page 7: Lock Relay Connection

    6 Door Sensor, Exit Button & Alarm Connection WD1-OUT WD0-OUT Detector power Smoke detector Door Sensor Exit Button Alarm Alarm power 7 Lock Relay Connection The system supports both Normally Opened Lock and Normally Closed Lock. The NO Lock (Normally Opened when powered) is connected with 'NO' and 'COM' terminals, and the NC Lock (Normally Closed when powered) is connected with 'NC' and 'COM' terminals.
  • Page 8 8 Wiegand Reader Connection IWD1 IWD0 +12V RS232_RXD1 RS232_TXD1 485B 485A Wiegand Reader 12V OUT 12V IN WD1-OUT Access Controller WD0-OUT 9 Barrier Connection WD1-OUT WD0-OUT...
  • Page 9: Printer Connection

    10 RS485 Connection IWD1 IWD0 RS232_RXD1 RS232_TXD1 485- 485B 485+ 485A +12V 12V OUT 485 Reader 12V IN 11 Printer Connection IWD1 IWD0 RS232_RXD1 RS232_TXD1 RS232 Printer 485B 485A 12V OUT 12V IN...
  • Page 10: Power Connection

    12 Power Connection 12V 3A DC Recommended power supply: 12V - 3A To share the power with other devices, use a power supply with higher current ratings. 13 Ethernet Connection Connect the device and the system software over an Ethernet cable. An example is shown below: Default IP Address : 192.168.1.201 IP Address...
  • Page 11: User Registration

    14 User Registration When there s no Super Administrator set in the device, click enter the menu. Add a new user and set the User Role to Super Admin, then the system will request for Administrator’s veri cation before entering the menu. It is recommended to register a Super Administrator initially for security purposes. Method1: Registration on device Click >...
  • Page 12 Method 2: Registration on ZKBioSecurity MTD software Please set the IP Address and Cloud Service Server Address in the Comm. Menu on the device. 1. Click [Access] > [Access Device] > [Device] > [Search Device] to search the device on the software. When an appropriate server address and port is set on the device, the searched devices will be displayed automatically.
  • Page 13 Method 3: Register on Phone Once the ZKBioSecurity MTD software is installed, the users could enroll their face via a browser application on their own mobile phone. 1. Click [Personnel] > [Parameters], enter‘’http://Server address:Port’’ in the QR Code UGL bar. The software will automatically generate a QR code.
  • Page 14 15 Ethernet and Cloud Server Settings Click > [Comm.] > [Ethernet] to set the network parameters. If the TCP/IP communication of the device is successful, the icon will be displayed in the top right corner of the standby interface. Click >...
  • Page 15: Access Control Setting

    16 Access Control Setting to open the access control management interface and set the relevant Click > [Access Control] parameters of access control. Main Menu Access Control Options Access Control Gate Control Mode Access Control Options Door Lock Delay (s) User Mgt.
  • Page 16 18 Detection Management Settings Click > [ System ] > [ Detection Management ] to open the settings interface ❶ You can set the value of High temperature alarm threshold, and enable the Temperature over the range; access denied and the Trigger external alarm, the device will send an alarm prompt when the temperature of the user detected exceeds the set value, and the user will be forbidden to access.
  • Page 17 19 Precautions 1. The effective distance for temperature and face detection is within 0.3m to 1.2m and 0.3m to 2.5m respectively. 2. It is recommended for indoor use only. 3. The temperature detection data is for reference only, and not for medical use. 4.
  • Page 18 As shown in the following gure. Real-Time Monitoring Welcome, admin 2020-05-28 11:03:07 Real-Time Monitoring Temperature Real-Time Monitoring Total: Statistics Panel Abnormal Temperature Normal Records Temperature Raw Record Personnel Temperature Schedule Abnormal Temperature Name: Record Department: Test Departmental Body Temperature Daily Statistics 36.5 °C Temperature: Report...
  • Page 19 ZKTeco Industrial Park, No. 26, 188 Industrial Road, Tangxia Town, Dongguan, China. Phone : +86 769 - 82109991 : +86 755 - 89602394 www.zkteco.com Copyright©2021 ZKTeco CO., LTD. All rights reserved.
