Item # 1001 868 881
Model # FLS80132A
USE AND CARE GUIDE
BELLEVILLE PADDED SLING CHAISE
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
ve placed in Hampton Bay through the purchase of this chaise. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HAMPTON BAY BELLEVILLE FLS80132A
Summary of Contents for HAMPTON BAY BELLEVILLE FLS80132A
- Page 1 THANK YOU ve placed in Hampton Bay through the purchase of this chaise. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
- Page 2 Table of Contents Table of Contents ............2 Pre-Assembly ..............3 Safety Information ............2 Planning Assembly ..............3 Hardware Included ..............3 Product Caution ..............2 Safety Warnings ..............2 Package Contents ..............4 Assembly ............... 5 Warranty ................
- Page 3 Pre-Assembly PLANNING ASSEMBLY Read all instructions before assembly. To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard. NOTE: More than one person may be required to complete the assembly of this product. HARWARE INCLUDED NOTE: Hardware not shown to actual size.
- Page 4 Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Right arm Left arm Chaise back Chaise seat Support bar Back bar...
- Page 5 Assembly Connecting the support bar and the back bar to the chaise arm Attach the support bar (E) to the left arm (B) using M6x15 combination bolts (AA). Attach the back bar (F) to the left arm (B) using M6x40 combination bolts (DD) and plastic spacers (FF). Repeat for the right arm (A).
- Page 6 Assembly (continued) Connecting the chaise seat to the chaise arm Attach the chaise seat (D) to the left arm (B) using M6x30 combination bolts (CC) and M6 plastic washers (EE). Repeat for the right arm (A). NOTE: Loosely tighten the M6x30 combination bolts (CC) using the wrench (HH).
- Page 7 Assembly (continued) Connecting the chaise back to the chaise arm Attach the chaise back (C) to the right arm (A) and left arm (B) using M6x20 combination bolts (BB) and M6 plastic washers (EE). Tighten all of the bolts using the hex wrench (GG) and the wrench (HH). Ensure all connections are secure before use.
- Page 8 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-HD-HAMP N HAMPTONBAY.COM Retain this manual for future use.
