Item # 1001 868 827
1001 868 812
Model # FLA70310A
FLA70310A-W
USE AND CARE GUIDE
STATESVILLE ALUMINUM CHAISE
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this chaise. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Related Manuals for HAMPTON BAY STATESVILLE FLA70310A
Summary of Contents for HAMPTON BAY STATESVILLE FLA70310A
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this chaise. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
-
Page 2: Table Of Contents
Table of Contents Table of Contents ............2 Pre-Assembly ..............3 Safety Information ............2 Planning Assembly ..............3 Hardware Included ..............3 Product Caution ..............2 Safety Warnings ..............2 ents ..............4 Warranty ................ 2 Assembly ............... -
Page 3: Pre-Assembly
Pre-Assembly PLANNING ASSEMBLY Read all instructions before assembly. To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard. NOTE: More than one person may be required to assemble this product. HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity... -
Page 4: P C A A K E G O C T N Ents
Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Seat Left arm Right arm Backrest... -
Page 5: Assembly
Assembly Connecting the seat to the right arm Place the right arm (C) on a soft surface. Attach the seat (A) to the right arm (C) using M6x15 combination bolts (BB). NOTE : Loosely tighten all bolts using the hex wrench (DD). HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance. - Page 6 Assembly (continued) Connecting the seat to the left arm Place the left arm (B) on a soft surface. Attach the seat (A) to the left arm (B) using M6x15 combination bolts (BB). NOTE : Loosely tighten all bolts using the hex wrench (DD).
- Page 7 Assembly (continued) Connecting the backrest to the left arm and the seat to the right arm Attach the backrest (D) to the left arm (B) using one M6x30 combination bolt (AA). Attach the seat (A) to the right arm (C) using one M6x60 combination bolt (CC). NOTE : Loosely tighten all bolts using the hex wrench (DD).
- Page 8 Assembly (continued) Connecting the backrest to the right arm and the seat to the left arm Attach the backrest (D) to the right arm (C) using one M6x30 combination bolt (AA). Attach the seat (A) to the left arm (B) using one M6x60 bolt combination bolt (CC). NOTE : Loosely tighten all bolts using the hex wrench (DD).
-
Page 9: Care And Cleaning
Assembly (continued) Tightening all bolts Once all bolts are in place, fully tighten all bolts. Turn the chaise right side up. Ensure all connections are secure before use. Care and Cleaning For best results, clean the chaise with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt particles that may accumulate. - Page 10 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturda 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use.
