- Page 1 INNOVATIVE TECHNOLOGY PARTNER LS LOADER LS BACK-HOE OPERATOR MANUAL LB1100 SERIES TRACTOR Model • LB1101 : S3010 • LB1102 : G3033/G3033H, G3038/G3038H PO Box 70, Battleboro, NC 27809 Tel : 252-984-0700 Fax : 252-984-0701 www.lstractor.com www.lstractorusa.com BT013-ME000-11 P/NO...
- Page 2 WARRANTY CONDITIONS Warranty Coverage : LS Mtron Tractor Division, herein referred to as LS Mtron, undertakes to replace or repair any part of a LS Mtron Backhoe where damage has been proven to be caused by defects in material or workmanship.
- Page 3 PLEASE NOTE : Make sure all potential operators of the this equipment review this manual and all safety messages contained within. This safety symbol indicates important safety messages in this manual. When you see this symbol, carefully read the message that follows and be alert to the possibility of personal injury or death.
-
Page 4: Table Of Contents
Table of Contents Safety Precautions Safety Decals Backhoe Specifications Introduction Tractor Preparation Backhoe Operation Backhoe Removal Backhoe Mounting Lubrication and Maintenance Trouble Shooting Hydraulic System Schematic Torque Tightening Chart Parts IIlustrations General Information Hose Kit - G3033/G3033H, G3038/G30380H - S3010 - XG3025 - XG3032/XG3032H, XG3037/XG3037H Subframe Assembly... -
Page 5: Safety Precautions
SAFETY Understand that your safety and the safety of Read this manual completely and thoroughly other persons is measured by how you service and make sure you understand all controls. All and operate this backhoe. Know the position equipment has a limit. Make sure you are aware and operations of all controls before you they of the stability and load characteristics of this to operate. - Page 6 SAFETY Contact with overhead power lines can cause Make sure all parked backhoe on stands are on severe electrical burn death from a hard level surface with all safety devices electrocution. engaged to prevent backhoe from falling and Make sure there is enough clearance between being damaged or injuring someone.
-
Page 7: Safety Decals
SAFETY DECALS Safety Decal Loacations Important: Warning decals are visible when getting on backhoe. Refer to the left and right hands used in this manual, It's the position of the operator when seated in the operating position of Backhoe Care of Safety Decals. 1. - Page 8 SAFETY DECALS Caution BH35-0117 Location : Main valve cover Warning BH35-0105 Location : Main valve cover Warning BH35-0108 Location :Right side valve lever Warning BH35-0107 Location : Left side valve lever Warning BH35-0110 Location : Side of right inner lever Warning BH35-0109 Location : Side of left inner lever Warning BH35-0112...
- Page 9 SAFETY DECALS Loader Series 3101E-00112 Location : Boom side Name Plate 3104E-00010 Location : Both side of Valve Room - 8 -...
-
Page 10: Backhoe Specifications
BACKHOE SPECIFICATIONS Specifications and design are subject to change without prior Backhoe Model : LB1100 Tractor Model : S3010, G3033/G3033H, G3038/G3038H, XG3000series, XG3100series, XG3025 A. Digging Deth (two foot flat bottom) 1,940 mm 76.3 " B. Reach from center line of Swing Pivot 2,875 mm 113.1 "... -
Page 11: Introduction
INTRODUCTION The purpose of this manual is to assist you in Important: maintaining and operating your backhoe. Read Illustrations used in this manual may not show carefully, furnishes information all safety equipment that is recommended to instructions that will help you achieve years of ensure safe operation of tractor and backhoe. -
Page 12: Tractor Preparation
TRACTOR PREPARATION CAUTION: Tractor Hydraulic System Do not exceed the manufacturer's rating Tractor operation in a backhoe application for maximum gross vehicle weight. Refer significantly increase demands on the tractor to Operator's Manual or ROPS serial Hydraulic System. Check the tractor Hydraulic plate provided with tractor. -
Page 13: Backhoe Operation
BACKHOE OPERATION Position vehicle so that the backhoe is as near CAUTION: The tractor/backhoe should only be operated to the pile as possible and in such a direction as with all safety equipment properly installed. to minimize the amount of tractor turning Keep assistants or bystanders a safe distance required to dump. - Page 14 BACKHOE OPERATION Initial Backhoe Operation Always keep cylinders in a retracted position Before operating the backhoe, fully raise and when the backhoe is not in use to guard against lower the boom, arm, swing and stabilizers rust contamination which cause two or three times.
- Page 15 BACKHOE OPERATION Push the right hand inner control lever, right stabilizer lowers. And pull up the lever, right stabilizer raises. Do not dig near the stabilizers to avoid possible accident. Do not lift the tractor rear wheels by stabilizers. Also, be sure the stabilizers are seated on hard ground to support.
- Page 16 BACKHOE OPERATION Swing Lock and Boom Lock When transporting or dismounting backhoe, you must lock the backhoe's swing and boom. Position boom straight back and drop pin through holes in swing frame and boom. When not in use, store pin in hole provided on swing frame and boom. Observe the following safety warnings when working with your new backhoe/tractor.
-
Page 17: Backhoe Removal
BACKHOE REMOVAL CAUTION: Move the backhoe to flat, firm and wide place to remove the equipment. CAUTION: Do not allow to be removed without bucket and stabilizers. Also, Dump the remaining material from the bucket to empty. WARNING: Use other lifting equipment to remove when the backhoe has damage. STEP 1. -
Page 18: Backhoe Mounting
BACKHOE MOUNTING CAUTION: Backhoe should be mounted on the proper subframe assembly. CAUTION: Never store backhoe without bucket attached to the backhoe. STEP 1. Attach the loader midmount and mounting bracket to the tractor by fit the bolts and nuts. STEP 2. - Page 19 BACKHOE MOUNTING MODEL: G3033/G3033H, G3038/G3038H Backhoe Frame XG3000series, XG3100series, XG3025 Bracket Mid. Subframe Subframe Cross Bar CAUTION: This is the Backhoe's Operator's manual for Safety Precautions and Tractor Preparations. STEP 5. Move the tractor to put the subframe front side into the loader midmount slowly. Set the subframe crosser parallel to the mounting bracket by using the backhoe control levers to lower the stabilizers and boom to raise the subframe.
-
Page 20: Lubrication And Maintenance
LUBRICATION AND MAINTERNANCE Bucket, Dipperstick Cylinder Grease Boom, Dipperstick Cylinder Grease Stabilizer Cylinder Grease Backhoe Bucket Grease Swing Cylinder Mainframe Grease Grease ITEM SERVICE SERVICE INTERVAL As specified in Tractor Hydraulic System Oil Level Replace Operator's Manual Hydraulic System Oil Level Check Daily/10 hours As specified in Tractor... - Page 21 LUBRICATION AND MAINTERNANCE CAUTION: Do not perform service or maintenance Operations with backhoe raised off the ground. For additional access to tractor components remove backhoe. Important: Lower the backhoe to the ground and relieve pressure in backhoe hydraulic lines prior to performing any service or maintenance operations on the tractor or backhoe.
-
Page 22: Trouble Shooting
TROUBLE SHOOTING This Trouble Shooting Chart is provided for reference to possible backhoe operational problems. Determine the problem that best describes the operational problem being experienced and eliminate the possible causes as listed by following the correction procedures. PROBLEM POSSIBLE CAUSE CORRECTION Low hydraulic fluid level. - Page 23 TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE CORRECTION Low hydraulic fluid level. Check and replenish hydraulic fluid. Allow hydraulic system to warm up to operating Cold hydraulic fluid. temperature. Engine R.P.M. too Increase engine speed to obtain satisfactory slow(hydraulic pump backhoe operation. R.P.M.
- Page 24 TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE CORRECTION Hydraulic Oil viscosity Check oil number and viscosity, Refill correct too heavy or Incorrect oil hydraulic oil. Excessive load in bucket. Weight exceeds specified Reduce load. backhoe capacity. System relief valve squeals. Relief valve setting below Check and reset valve setting as needed.
- Page 25 TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE CORRECTION Allow hydraulic fluid to warm up to operating Cold hydraulic fluid. temperature. Engine R.P.M. too slow. Increase engine R.P.M. Low hydraulic fluid Refer to Tractor Operator's Manual for service Hydraulic pump capacity supply. recommendations. inadequate.
-
Page 26: Hydraulic System Schematic
HYDRAULIC SYSTEM SCHEMATIC - 25 -... -
Page 27: Torque Tightening Chart
TORQUE TIGHTENING CHART MINIMUM HARDWARE TIGHTENING TORQUES IN FOOT POUNDS (NEWTON-METERS) FOR NORMAL ASSEMBLY APPLICATIONS Always tighten hardware to these values unless a different torque value or tightening procedure is listed for a specific application. Fasteners must always be replaced with the same grade as specified in the manual parts list. Always use the proper tool for tightening hardware : SAE or SAE hardware and Metric for metric hardware. -
Page 28: Parts Iilustrations
PART ILLUSTRATIONS GENERAL INFORMATION Illustrations The individual parts in their normal relationship to each other. Reference numbers are used in the illustrations. These numbers correspond to those in the "Number" column and are followed by the quantity required and description. Directional Reference "Right hand"... -
Page 29: Hose Kit
HOSE KIT -G3033/G3033H, G3038/G3038H BLOCK REF. LS PART NO PART NO DESCRIPTION QTY I.C REMARK 40230959 802L2-T46F9-4S NIPPLE, PT3/8×3/4-16NUF, SWIVEL 90° 40228721 80420-T3360 QUICK COUPLER, PT3/8" FEMALE 40230676 8043W-03300 DUST-CAPS, 3/8" WHITE MALE 40228729 8044W-03300 DUST-CAP, 3/8" WHITE FEMALE 40228720 80410-T3360 QUICK COUPLER, PT3/8"... -
Page 30: S3010
HOSE KIT -S3010 BLOCK REF. LS PART NO PART NO DESCRIPTION QTY I.C REMARK 40230965 802N2-T46F9-40 NIPPLE, PT3/8×3/4-16UNF, HOSE 40228721 80420-T3360 QUICK COUPLER, PT3/8" FEMALE 40230676 8043W-03300 DUST-CAPS, 3/8" WHITE MALE 40228729 8044W-03300 DUST-CAP, 3/8" WHITE FEMALE 40228720 80410-T3360 QUICK COUPLER, PT3/8" MALE 40230964 802N2-P46F9-4M NIPPLE, PF3/8,COPPER×3/4-16UNF (69L) 40228652... -
Page 31: Xg3025
HOSE KIT -XG3025 REF. LS PART PART NO DESCRIPTION REMARK 40228720 80410-T3360 QUICK COUPLER, PT3/8" MALE 40230959 802L2-T46F9-4S NIPPLE, PT3/8×3/4-16NUF, SWIVEL 90° 40228718 802N2-P63F9-42 NIPPLE, PF1/2, O-RING×3/4-16UNF, HOSE 40228757 81301-BP018 O-RING, 1BP18 40228729 8044W-03300 DUST-CAP, 3/8" WHITE FEMALE 40230676 8043W-03300 DUST-PLUG, 3/8"... -
Page 32: Xg3032/Xg3032H, Xg3037/Xg3037H
HOSE KIT -XG3000series, XG3100series ＊When hydraulic auxiliary is installed on tractor ※REF 3,4 are interchangeable with kit from the tractor which the hydraulic auxiliary are not installed. REF.NO LS PART.NO PART.NO DESCRIPTION SERIAL OR DATE 40286936 103C0-M0200 WASHER-COPPER,M20 40286939 802N2-T63M3-41 NIPPLE,M20-1.5P,COPPER×PT1/2 40230968 80420-T1130... - Page 33 HOSE KIT -XG3000series, XG3100series ＊When hydraulic auxiliary is not installed on tractor Port.2 Carry over line Port.1 Port.1 Port.2 ＊After removal of the carry over line connect each ports as shown in figure. - 32 -...
- Page 34 HOSE KIT -XG3000series, XG3100series REF.NO LS PART.NO PART.NO DESCRIPTION SERIAL OR DATE 40230968 80420-T1130 QUICK COUPLER, PT1/2" FEMALE 40230969 8043K-01100 DUST PLUG,1/2 BLACK MALE 40230971 8044K-01100 DUST CAP, 1/2 BLACK FEMALE 40230967 80410-T1130 QUICK COUPLER, PT1/2" MALE HOSE ASS'Y, 904(3/4-16UNF)x1(PT1/2) 40326738 80620-07018 800L (3/8)
- Page 35 SUBFRAME ASSEMBLY -G3033/G3033H,G3038/G3038H REF. LS PART NO PART NO DESCRIPTION QTY I.C REMARK 40256025 FTS75-00000 FRAME ASS'Y-SUB 40320336 FTS75-00000-04 FRAME ASS'Y-SUB 2014.12.15~ 40256023 FTS75-10100 BAR-CROSS W.A. 40320337 FTS75-10100-01 BAR-CROSS W.A. 2014.12.15~ 40256024 FTS71-10200-01 RAIL W.A. 40286940 FTS78-11200 RAIL W.A. 2014.12.15~ 40256022 FTS71-10400 BRACKET_MID W.A.
-
Page 36: S3010
SUBFRAME ASSEMBLY -S3010 TRACTOR REF. LS PART NO PART NO DESCRIPTION QTY I.C REMARK 40231122 FTS70-00000 SUBFRAME ASS'Y 40231123 FTS70-10100 CROSS BAR W.A. 40231124 FTS70-10200 RAIL W.A. 40231125 FTS70-10300 BRACKET_MID W.A. 40256021 FTS70-10300-01 BRACKET_MID W.A. 2010.06.25~ 40231116 DK05-0101-02 BRACE 40230905 14132-20120 40230904 14021-1000... -
Page 37: Xg3000Series, Xg3100Series
SUBFRAME ASSEMBLY -XG3000series, XG3100series REF. LS PART NO PART NO DESCRIPTION QTY I.C REMARK 40324621 FTS87-00000 FRAME ASS'Y-SUB 40342995 FTS87-00000-03 FRAME ASS'Y-SUB 2016.03.15~ 40324622 FTS87-11100 BAR-CROSS W.A. 40286940 FTS78-11200 RAIL W.A. 40256022 FTS71-10400 BRACKET_MID W.A. 40286935 LDS04-2131A-03 BRACE 40342997 FTS88-41000 BRACE 2016.03.15~ 40230905... -
Page 38: Xg3025
SUBFRAME ASSEMBLY -XG3000series, XG3100series, XG3025 REF. LS PART NO PART NO DESCRIPTION QTY I.C REMARK 40342996 FTS88-00000-01 FRAME ASS'Y-SUB 40324622 FTS87-11100 BAR-CROSS W.A. 40286940 FTS78-11200 RAIL W.A. 40256022 FTS71-10400 BRACKET_MID W.A. 40342997 FTS88-41000 BRACE 40230905 14132-20120 40228656 14021-10000 RING-PIN, ∅10 40228623 10191-M1406-60 HEX.BOLT-HT, M14-2.0P 60L 40230601... -
Page 39: Bucket, Dipperstick Assembly
BUCKET, DIPPERSTICK ASSEMBLY - 38 -... - Page 40 BUCKET, DIPPERSTICK ASSEMBLY REF. LS PART NO PART NO DESCRIPTION QTY I.C REMARK 40231071 BT664-23100-01 BUCKET ASS'Y, 9 40231072 BT664-23200-01 BUCKET ASS'Y, 12 40231074 BT664-23400-02 BUCKET ASS'Y, 18 40231075 BT664-23500-02 BUCKET ASS'Y, 24 40231076 BT664-23600-02 BUCKET ASS'Y, 36 40231056 BT200-22100 DIPPERSTICK ASS'Y 40231079 BT664-25100...
-
Page 41: Boom Assembly
BOOM ASSEMBLY REF. LS PART NO PART NO DESCRIPTION QTY I.C REMARK 40231114 BT673-21100 BOOM ASS'Y 40231095 BT664-71700 PIN, ∅30-176.5L 40231096 BT664-71900-01 PIN, ∅40-185.5L 40231093 BT664-71500-01 PIN, ∅40-185.5L 40230880 10121-M0803-60 HEX.BOLT, M8-1.25P 60L 40230881 10121-M0803-70 HEX.BOLT, M8-1.25P 70L 40230896 1021N-M0803 NUT-SELFLOCK, M8-1.25P 40228707 802G0-T1900... -
Page 42: Swing Frame Assembly
SWING FRAME ASSEMBLY REF. LS PART NO PART NO DESCRIPTION QTY I.C REMARK 40231080 BT664-31000-03 SWING FRAME ASS'Y 40231106 BT664-74100 SWING CYL.PIN, ∅25×118L 40231098 BT664-72100-03 PIN, ∅40-117L 40231099 BT664-72200-02 LOCK 40343506 BTS08-20100 LOCK 2016.03.15~ PIN, ∅22-190L 40231101 BT664-72400 40231100 BT664-72300 HANDLE SET 40343507 BTS08-30100... -
Page 43: Mainframe Assembly
MAINFRAME ASSEMBLY - 42 -... - Page 44 MAINFRAME ASSEMBLY REF. LS PART NO PART NO DESCRIPTION QTY I.C REMARK 40231069 BT664-11000-05 MAIN FRAME ASS'Y 40231065 BT651-52100-01 CROSS BAR 40231088 BT664-62100-02 STABILIZER ASS'Y-RH 40231086 BT664-61100-02 STABILIZER ASS'Y-LH 40231087 BT664-61200 FOOT PLATE 40231064 BT651-31600 BRACKET-CUSHION 40230876 1002-B004 CUSHION 40231066 BT651-75110-03 BUSHING, 405030 40231089 BT664-71100...
-
Page 45: Seat, Control Assembly(Hanil)
SEAT, CONTROL ASSEMBLY(HANIL) - 44 -... - Page 46 SEAT, CONTROL ASSEMBLY(HANIL) REF. LS PART NO PART NO DESCRIPTION QTY I.C REMARK 40231070 BT664-12000H VALVE ROOM W.A. 40231059 BT651-12210-03 FRONT COVER 40231085 BT664-54101H TOP COVER 40231062 BT651-12240 FOOT PLATE - CENTER 40231061 BT651-12230-01 FOOT PLATE - RH 40231060 BT651-12220-01 FOOT PLATE - LH 40231081 BT664-41110-01 SUPPORT SEAT 40231138...
-
Page 47: Seat, Control Assembly(Walvoil)
SEAT, CONTROL ASSEMBLY(WALVOIL) - 46 -... - Page 48 SEAT, CONTROL ASSEMBLY(WALVOIL) REF. LS PART NO PART NO DESCRIPTION QTY I.C REMARK 40294001 BTV02-20200 VALVE ROOM W.A. 40343508 BTV08-20200 VALVE ROOM W.A. 2016.03.15~ 40294002 BTV02-20301 COVER, FRONT 40294003 BTV02-40102-01 TOP COVER 40231062 BT651-12240 FOOT PLATE - CENTER 40231061 BT651-12230-01 FOOT PLATE - RH 40231060 BT651-12220-01 FOOT PLATE - LH 40294004...
-
Page 49: Hose Fitting Assembly(Hanil)
HOSE FITTING ASSEMBLY(HANIL) b-b , B-B c-c , d-d f-f , F-F e-e , E-E f'-f' , F'-F' a-a , A-A F' f' - 48 -... - Page 50 HOSE FITTING ASSEMBLY(HANIL) REF. LS PART NO PART NO DESCRIPTION QTY I.C REMARK 40230891 1012S-M0803-50 BOLT-SEM'S, M8-1.25P 50L 40230928 226702 BUCKET CYLINDER ASSEMBLY 40230925 226701 DIPPERSTICK CYLINDER ASSEMBLY 40230931 226703 BOOM CYLINDER ASSEMBLY 40230918 225806 SWING CYLINDER ASSEMBLY 40230910 224304 STABILIZER CYLINDER ASSEMBLY-LH 40230913 224305...
-
Page 51: Hose Fitting Assembly(Walvoil)
HOSE FITTING ASSEMBLY(WALVOIL) b-b , B-B c-c , d-d f-f , F-F e-e , E-E f'-f' , F'-F' a-a , A-A - 50 -... - Page 52 HOSE FITTING ASSEMBLY(WALVOIL) REF. LS PART NO PART NO DESCRIPTION QTY I.C REMARK 40294009 8WKEXP2124 VALVE, WALVOIL SD6/6 40230928 226702 BUCKET CYLINDER ASSEMBLY 40230925 226701 DIPPERSTICK CYLINDER ASSEMBLY 40340572 22L101 DIPPERSTICK CYLINDER ASSEMBLY 2016.03.15~ 40230931 226703 BOOM CYLINDER ASSEMBLY 40230918 225806 SWING CYLINDER ASSEMBLY 40230910...
-
Page 53: Bucket Cylinder Assembly
BUCKET CYLINDER ASSEMBLY REF. LS PART NO PART NO DESCRIPTION QTY I.C REMARK 40230928 226702 BUCKET CYLINDER ASSEMBLY 40230929 226702-R ROD ASS'Y 40228867 OC60-7037 CAP OUTER, ∅60-70-37L COVER INNER, ∅60×35×55L 40228827 IC60-3555 40228766 DSSD-R035 DUST,SDR, 35×43×5/6.5 40228884 UPSK-Y035 PACKING U, SKY, SKY 35-45-6 40228880 UPIS-I035 PACKING U, ISI, 35-45-6... -
Page 54: Dipperstick Cylinder Assembly
DIPPERSTICK CYLINDER ASSEMBLY REF. LS PART NO PART NO DESCRIPTION QTY I.C REMARK 40340572 22L101 DIPPERSTICK CYLINDER ASSEMBLY 40340573 22L101-R ROD ASS'Y 40340574 3AE-0006 CAP OUTER ∅60x∅75x37L 40340575 22L101-RC COVER INNER ASS'Y COVER INNER ∅65x∅35x55L 40340576 3CN-065-002 40340577 9DT-SDR-035 Dust Seal SDR 35x43x5/6.5 40340578 9ST-SKY-035 U-Packing SKY 35x45x6... -
Page 55: Boom Cylinder Assembly
BOOM CYLINDER ASSEMBLY REF. LS PART NO PART NO DESCRIPTION QTY I.C REMARK 40230931 226703 BOOM CYLINDER ASSEMBLY 40230932 226703-R ROD ASS'Y 40230859 OC70-8037 CAP, OUTER, ∅70-80-37L COVER, INNER, ∅70-40-55L 40230766 IC70-4055 40230710 DSSD-R040 DUST, SDR, 40-48-5/6.5 40230872 UPSK-Y040 PACKING, U, SKY, 40-50-6 40230869 UPIS-I040 PACKING, U, ISI, G55... -
Page 56: Swing Cylinder Assembly
SWING CYLINDER ASSEMBLY REF. LS PART NO PART NO DESCRIPTION QTY I.C REMARK 40230918 225806 SWING CYLINDER ASSEMBLY 40230919 225806-R ROD ASS'Y 40231033 BC60-3555 HEAD, ∅60-35-55L 40228766 DSSD-R035 DUST,SDR, 35×43×5/6.5 40228884 UPSK-Y035 PACKING U, SKY, SKY 35-45-6 40228880 UPIS-I035 PACKING U, ISI, 35-45-6 40231137 TRBR-G055 BACKUP RING, G55... -
Page 57: Stabilizer Cylinder Assembly-Lh
STABILIZER CYLINDER ASSEMBLY-LH REF. LS PART NO PART NO DESCRIPTION QTY I.C REMARK 40230910 224304 STABILIZER CYLINDER ASSEMBLY-LH 40230911 224304-R ROD ASS'Y 40228867 OC60-7037 CAP OUTER, ∅60-70-37L COVER INNER, ∅60×35×55L 40228827 IC60-3555 40228766 DSSD-R035 DUST,SDR, 35×43×5/6.5 40228884 UPSK-Y035 PACKING U, SKY, SKY 35-45-6 40228880 UPIS-I035 PACKING U, ISI, 35-45-6... -
Page 58: Stabilizer Cylinder Assembly-Rh
STABILIZER CYLINDER ASSEMBLY-RH REF. LS PART NO PART NO DESCRIPTION QTY I.C REMARK 40230913 224305 STABILIZER CYLINDER ASSEMBLY-RH 40230914 224305-R ROD ASS'Y 40228867 OC60-7037 CAP OUTER, ∅60-70-37L COVER INNER, ∅60×35×55L 40228827 IC60-3555 40228766 DSSD-R035 DUST,SDR, 35×43×5/6.5 40228884 UPSK-Y035 PACKING U, SKY, SKY 35-45-6 40228880 UPIS-I035 PACKING U, ISI, 35-45-6... -
Page 59: Control Valve Assembly-Hanil Av 80/6
CONTROL VALVE ASSEMBLY-HANIL AV 80/6 - 58 -... - Page 60 CONTROL VALVE ASSEMBLY-HANIL AV 80/6 REF. LS PART NO PART NO DESCRIPTION QTY I.C REMARK 40230982 BC04-0000-P CONTROL VALVE ASS'Y 40230983 BC04-0100 BLOCK-BA TYPE(INLET) 40230984 BC04-0200 BLOCK-HB TYPE(BOOM) 40230985 BC04-0300 BLOCK-HA TYPE 40230986 BC04-0400 BLOCK-EA TYPE 40230987 BC04-0500 BLOCK-GB TYPE (OUTLET) 40230988 BC04-0600 O-RING...
-
Page 61: Control Valve Assembly-Walvoil Sd6/6
CONTROL VALVE ASSEMBLY-WALVOL SD 6/6 - 60 -... - Page 62 CONTROL VALVE ASSEMBLY-WALVOL SD 6/6 REF.NO LS PART.NO PART.NO DESCRIPTION QTY I.C SERIAL OR DATE 40308224 YTAP623282-H PLUG SV/VMP5 * Order code for spare parts 40308222 XTAP524280 PLUG P3T/SD6 * Order code for spare parts 40308217 KEXPE0000033 VALVE KIT U(G3)/SD6 * Order code for spare parts 40308213 5KIT306113-W...
-
Page 63: Decals
DECALS CAUTION : Read and refer to the Tractor Operation Manual or Decals on the Tractor. and Backhoe Decals on as shown. ⑧ ⑨ ① ② ⑦ ③ ④ ⑩ ⑪ ⑤ ⑫ ⑥ ⑬ ⑭ ⑦ ⑬ Refer to category "Safety decals" - 62 -... - Page 64 DECALS REF. LS PART NO PART NO DESCRIPTION QTY I.C REMARK 40231049 BH35-0110 DECAL-WARNING 40231046 BH35-0107 DECAL-WARNING 40231047 BH35-0108 DECAL-WARNING 40231048 BH35-0109 DECAL-WARNING 40231051 BH35-0112 DECAL-WARNING 40231041 BH35-0101 DECAL-WARNING 40231042 BH35-0102 DECAL-WARNING 40230647 3101E-00112 DECAL-LS 40231045 BH35-0105 DECAL-WARNING 40230653 3104E-00010 NAME PLATE 40231044 BH35-0104...
