LS LOADER
LS BACK-HOE
OPERATOR MANUAL
LB3100
TRACTOR Model
• U43/47, 55
• K5047/K5055-2WD/K5055-4WD
• XU5055/5055C, XU5065/5065C
• XU5057/5062/5067
INNOVATIVE
TECHNOLOGY
PARTNER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LB3100 and is the answer not in the manual?

Questions and answers

Jerry Toms
February 23, 2025

Connecting to tractor and how to get remotes secure to keep flow to backhoe. R4019H owned since new with 3100

0

Subscribe to Our Youtube Channel

Related Manuals for LS tractor LB3100

Summary of Contents for LS tractor LB3100

  • Page 1 INNOVATIVE TECHNOLOGY PARTNER LS LOADER LS BACK-HOE OPERATOR MANUAL LB3100 TRACTOR Model • U43/47, 55 • K5047/K5055-2WD/K5055-4WD • XU5055/5055C, XU5065/5065C • XU5057/5062/5067 PO Box 70, Battleboro, NC 27809 Tel : 252-984-0700 Fax : 252-984-0701 www.lstractor.com www.lstractorusa.com BT024-ME000-06 P/NO...
  • Page 2 WARRANTY CONDITIONS Warranty Coverage : LS Mtron Tractor Division, herein referred to as LS Mtron, undertakes to replace or repair any part of a LS Mtron Backhoe where damage has been proven to be caused by defects in material or workmanship.
  • Page 3 PLEASE NOTE : Make sure all potential operators of the this equipment review this manual and all safety messages contained within. This safety symbol indicates important safety messages in this manual. When you see this symbol, carefully read the message that follows and be alert to the possibility of personal injury or death.

  • Page 4: Table Of Contents

    Table of Contents Safety Precautions Safety Decals Backhoe Specifications Introduction Tractor Preparation Backhoe Operation Backhoe Removal Backhoe Mounting Lubrication and Maintenance Trouble Shooting Hydraulic System Schematic Torque Tightening Chart Parts IIlustrations General Information Subframe Assembly - U43/47, U55 - K5047/K5055-2WD, K5055-4WD - XU5055/XU5055C, XU5065/XU5065C - XU6158/XU6163/XU6168 - XR4000 series...

  • Page 5: Safety Precautions

    SAFETY PRECAUTIONS Understand that your safety and the safety of Read this manual completely and thoroughly. other persons is measured by how you service Make sure you understand all controls. All and operate this backhoe. Know the position equipment has a limit. Make sure you are aware and operations of all controls before you of the stability and load characteristics of this begin operation.
  • Page 6 SAFETY PRECAUTIONS Contact with overhead power lines can cause Make sure all parked backhoe on stands are on severe electrical burn death from a hard level surface with all safety devices electrocution. engaged to prevent backhoe from falling and Make sure there is enough clearance between being damaged or injuring someone.

  • Page 7: Safety Decals

    SAFETY DECALS Safety Decal Loacations Important: Warning decals are visible when getting on backhoe. Refer to the left and right hands used in this manual, It's the position of the operator when seated in the operating position of Backhoe Care of Safety Decals. 1.
  • Page 8 SAFETY DECALS Caution 3102E-00009 Location : Main valve cover Warning 3102E-00008 Location : Main valve cover Warning 3103E-00004 Location :Right side valve lever Warning 3103E-00003 Location : Left side valve lever Warning 3103E-00006 Location : Side of right inner lever Warning 3103E-00005 Location : Side of left inner lever Warning 3103E-00008...
  • Page 9 SAFETY DECALS Loader Series 3101E-00112 Location : Boom side Name Plate 3104E-00010 Location : Both side of Valve Room - 8 -...

  • Page 10: Backhoe Specifications

    BACKHOE SPECIFICATIONS Specifications and design are subject to change without prior Backhoe Model : LB3100 Tractor Model : U43/47, U55, K5047/K5055-2WD, K5055-4WD, XU5055/XU5055C, XU5065/XU5065C, XU6158/XU6163/XU6168, XR4000 series, XR4100 series A. Digging Depth (two foot flat bottom) 2,400 mm 94.4 "...

  • Page 11: Introduction

    INTRODUCTION The purpose of this manual is to assist you in Important: maintaining and operating your backhoe. Read Illustrations used in this manual may not show carefully, furnishes information all safety equipment that is recommended to instructions that will help you achieve years of ensure safe operation of tractor and backhoe.

  • Page 12: Tractor Preparation

    TRACTOR PREPARATION CAUTION: Tractor Hydraulic System Do not exceed the manufacturer's rating Tractor operation in a backhoe application for maximum gross vehicle weight. Refer significantly increase demands on the tractor to Operator's Manual or ROPS serial Hydraulic System. Check the tractor Hydraulic plate provided with tractor.

  • Page 13: Backhoe Operation

    BACKHOE OPERATION Position vehicle so that the backhoe is as near CAUTION: The tractor/backhoe should only be operated to the pile as possible and in such a direction as with all safety equipment properly installed. to minimize the amount of tractor turning Keep assistants or bystanders a safe distance required to dump.
  • Page 14 BACKHOE OPERATION Initial Backhoe Operation Always keep cylinders in a retracted position Before operating the backhoe, fully raise and when the backhoe is not in use to guard against lower the boom, dipperstick(arm), swing and rust contamination which cause stabilizers two or three times. Then raise the damage to the cylinder rods or hydraulic system.
  • Page 15 BACKHOE OPERATION Push the right hand inner control lever, right stabilizer lowers. And pull up the lever, right stabilizer raises. Do not dig near the stabilizers to avoid possible accident. Do not lift the tractor rear wheels by stabilizers. Also, be sure the stabilizers are seated on hard ground to support.
  • Page 16 BACKHOE OPERATION Swing Lock and Boom Lock When transporting or dismounting backhoe, you must lock the backhoe's swing and boom. Position boom straight back and push the boom lock lever in boom. Swing backhoe to position in the middle of swing and drop pin through holes in swing frame. When not in use, pull back boom lock lever and store pin in hole provided on swing frame.

  • Page 17: Backhoe Removal

    BACKHOE REMOVAL CAUTION: Move the backhoe to flat, firm and wide place to remove the equipment. CAUTION: Do not allow to be removed without bucket and stabilizers. Also, Dump the remaining material from the bucket to empty. WARNING: Use other lifting equipment to remove when the backhoe has damage. STEP 1.

  • Page 18: Backhoe Mounting

    BACKHOE MOUNTING CAUTION: Backhoe should be mounted on the proper subframe assembly. CAUTION: Never store backhoe without bucket attached to the backhoe. STEP 1. Attach the loader midmount and mounting bracket to the tractor by fit the bolts and nuts. STEP 2.
  • Page 19 BACKHOE MOUNTING STEP 5. Set the parking brake of the tractor, Make sure the PTO switch is in the off position MODEL: U43/47, U55 MODEL: K5047/K5055-2WD, K5055-4WD Backhoe Frame MODEL: XU5055/XU5055C, XU5065/XU5065C MODEL: XU6158/XU6163/XU6168 MODEL: XR4000 series MODEL: XR4100 series Mounting Bracket Subframe Crosser Subframe...

  • Page 20: Lubrication And Maintenance

    LUBRICATION AND MAINTERNANCE Bucket, Dipperstick Cylinder Grease Boom, Dipperstick Cylinder Grease Stabilizer Cylinder Grease Backhoe Bucket Grease Swing Cylinder Mainframe Grease Grease ITEM SERVICE SERVICE INTERVAL As specified in Tractor Hydraulic System Oil Level Replace Operator's Manual Hydraulic System Oil Level Check Daily/10 hours As specified in Tractor...
  • Page 21 LUBRICATION AND MAINTERNANCE CAUTION: Do not perform service or maintenance Operations with backhoe raised off the ground. For additional access to tractor components remove backhoe. Important: Lower the backhoe to the ground and relieve pressure in backhoe hydraulic lines prior to performing any service or maintenance operations on the tractor or backhoe.

  • Page 22: Trouble Shooting

    TROUBLE SHOOTING This Trouble Shooting Chart is provided for reference to possible backhoe operational problems. Determine the problem that best describes the operational problem being experienced and eliminate the possible causes as listed by following the correction procedures. PROBLEM POSSIBLE CAUSE CORRECTION Low hydraulic fluid level.
  • Page 23 TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE CORRECTION Low hydraulic fluid level. Check and replenish hydraulic fluid. Allow hydraulic system to warm up to operating Cold hydraulic fluid. temperature. Engine R.P.M. too Increase engine speed to obtain satisfactory slow(hydraulic pump backhoe operation. R.P.M.
  • Page 24 TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE CORRECTION Hydraulic Oil viscosity Check oil number and viscosity, Refill correct too heavy or Incorrect oil hydraulic oil. Excessive load in bucket. Weight exceeds specified Reduce load. backhoe capacity. System relief valve squeals. Relief valve setting below Check and reset valve setting as needed.
  • Page 25 TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE CORRECTION Allow hydraulic fluid to warm up to operating Cold hydraulic fluid. temperature. Engine R.P.M. too slow. Increase engine R.P.M. Low hydraulic fluid Refer to Tractor Operator's Manual for service Hydraulic pump capacity supply. recommendations. inadequate.

  • Page 26: Hydraulic System Schematic

    HYDRAULIC SYSTEM SCHEMATIC - 25 -...

  • Page 27: Torque Tightening Chart

    TORQUE TIGHTENING CHART MINIMUM HARDWARE TIGHTENING TORQUES IN FOOT POUNDS (NEWTON-METERS) FOR NORMAL ASSEMBLY APPLICATIONS Always tighten hardware to these values unless a different torque value or tightening procedure is listed for a specific application. Fasteners must always be replaced with the same grade as specified in the manual parts list. Always use the proper tool for tightening hardware : SAE or SAE hardware and Metric for metric hardware.

  • Page 28: Parts Iilustrations

    PART ILLUSTRATIONS GENERAL INFORMATION Illustrations The individual parts in their normal relationship to each other. Reference numbers are used in the illustrations. These numbers correspond to those in the "Number" column and are followed by the quantity required and description. Directional Reference "Right hand"...

  • Page 29: Subframe Assembly -U43/47, U55

    SUBFRAME ASSEMBLY -U43/47, U55 REF.NO LS PART.NO PART.NO DESCRIPTION SERIAL OR DATE 40261827 FTS74-00100 CROSS BAR W.A.. 40261828 FTS74-00200 MAIN RAIL W.A.. 40261829 FTS74-00300 MOUNTING BRACKET W.A.. 40261488 14132-20146 40261825 FTS38-50101 BRACE 40228656 14021-10000 RING-PIN,∅10 40261826 FTS74-00001 BRACKET-WORKING LAMP 40228623 10191-M1406-60 HEX.BOLT-HT,M14-2.0P 60L 40228643...

  • Page 30: -K5047/K5055-2Wd,K5055-4Wd

    SUBFRAME ASSEMBLY -K5047/K5055-2WD,K5055-4WD REF.NO LS PART.NO PART.NO DESCRIPTION SERIAL OR DATE 40288717 FTS80-00000 SUBFRAME ASS'Y 40288718 FTS80-11100 CROSS BAR W.A. 40288719 FTS80-11200 RAIL W.A. 40288720 FTS80-11300 BRACKET_MID W.A. 40261825 FTS38-50101 BRACE 40230905 14132-20120 40228656 14021-10000 RING-PIN,∅10 40228623 10191-M1406-60 HEX.BOLT-HT,M14-2.0P 60L 40230894 10191-M2007-70 HEX.BOLT-HT,M20-2.5P 70L...

  • Page 31: Xu5055/Xu5055C, Xu5065/Xu5065C

    SUBFRAME ASSEMBLY -XU5055/XU5055C, XU5065/XU5065C REF.NO LS PART.NO PART.NO DESCRIPTION SERIAL OR DATE 40308215 FTS83-00100 CROSS BAR W.A. 40308216 FTS83-00200 MAIN RAIL W.A. 40261829 FTS74-00300 MOUNTING BRACKET W.A. 40261488 14132-20146 40308214 FTS38-50101-01 BRACE 40228656 14021-10000 RING-PIN,∅10 40261826 FTS74-00001 BRACKET-WORKING LAMP 40228623 10191-M1406-60 HEX.BOLT-HT,M14-2.0P 60L 40228643...

  • Page 32: Xu6158/Xu6163/Xu6168

    SUBFRAME ASSEMBLY -XU6158/XU6163/XU6168 REF.NO LS PART.NO PART.NO DESCRIPTION SERIAL OR DATE 40321691 FTS84-00100 CROSS BAR W.A. 40321692 FTS84-00200 MAIN RAIL W.A. 40261829 FTS74-00300 MOUNTING BRACKET W.A. 40261488 14132-20146 40308214 FTS38-50101-01 BRACE 40228656 14021-10000 RING-PIN,∅10 40261826 FTS74-00001 BRACKET-WORKING LAMP 40228623 10191-M1406-60 HEX.BOLT-HT,M14-2.0P 60L 40228643 10316-M1400...

  • Page 33: Xr4000 Series Xr4100 Series

    SUBFRAME ASSEMBLY -XR4000 series -XR4100 series REF.NO LS PART.NO PART.NO DESCRIPTION SERIAL OR DATE 40324625 FTS85-00000 SUBFRAME ASS'Y 40324626 FTS85-11100 CROSS BAR W.A. 40286941 FTS79-11200 RAIL W.A. 40231133 FTS72-10300 BRACKET_MID W.A. 40231116 DK05-0101-02 BRACE 40230905 14132-20120 40230904 14021-10000 RING PIN 40228623 10191-M1406-60 HEX.BOLT-HT,M14-2.0P 60L...

  • Page 34: K5047/K5055-2Wd, K5055-4Wd

    HOSE KIT -K5047/K5055-2WD,K5055-4WD REF.NO LS PART.NO PART.NO DESCRIPTION SERIAL OR DATE 40288715 FTS80-HK000 HOSE KIT 40228715 802L2-T46F9-40 NIPPLE,PT3/8×3/4-16UNF,HOSE 90˚ 40230959 802L2-T46F9-4S NIPPLE,PT3/8×3/4-16NUF,SWIVEL 90° 40228721 80420-T3360 QUICK COUPLER,PT3/8" FEMALE 40228720 80410-T3360 QUICK COUPLER,PT3/8" MALE 40288716 80620-02019 HOSE ASS'Y,4(3/4-16UNF)-1(PT1/2) 1500(3/8) 40230968 80420-T1130 QUICK COUPLER,PT1/2 FEMALE 40230970 8043W-01100...

  • Page 35: Hose Kit

    HOSE KIT XR4000 series -XR4100 series REF.NO LS PART.NO PART.NO DESCRIPTION SERIAL OR DATE 40286936 103C0-M0200 WASHER-COPPER,M20 40286939 802N2-T63M3-41 NIPPLE,M20-1.5P,COPPER×PT1/2 40230968 80420-T1130 QUICK COUPLER,PT1/2 FEMALE 40230969 8043K-01100 DUST-PLUG,1/2" BLACK MALE - 34 -...

  • Page 36: Bucket, Dipperstick Assembly

    BUCKET, DIPPERSTICK ASSEMBLY - 35 -...
  • Page 37 BUCKET, DIPPERSTICK ASSEMBLY REF.NO LS PART.NO PART.NO DESCRIPTION SERIAL OR DATE 40261812 BT665-23100-01 BUCKET ASS'Y(9) 40261813 BT665-23200-01 BUCKET ASS'Y(12) 40261814 BT665-23300-01 BUCKET ASS'Y(16) 40261815 BT665-23400-01 BUCKET ASS'Y(18) 40261816 BT665-23500-01 BUCKET ASS'Y(24) 40261817 BT665-23600-01 BUCKET ASS'Y(36) 40261497 BT400-22100 DIPPERSTICK ASS'Y 40261820 BT665-25100 LINK ASS'Y 40261819...

  • Page 38: Boom Assembly

    BOOM ASSEMBLY REF.NO LS PART.NO PART.NO DESCRIPTION SERIAL OR DATE 40261496 BT400-21100 BOOM ASS'Y 40231095 BT664-71700 PIN,∅30-176.5L 40231096 BT664-71900-01 PIN,∅40-185.5L 40231093 BT664-71500-01 PIN,∅40-185.5L 40261480 10121-M080C-60 HEX.BOLT,M8-1.25P 60L 40261481 10121-M080C-70 HEX.BOLT,M8-1.25P 70L 40230896 1021N-M0803 NUT-SELFLOCK,M8-1.25P 40228707 802G0-T1900 NIPPLE,GREASE,1/8" 40230979 83040-4440D BUSHING,404440 - 37 -...

  • Page 39: Swing Frame Assembly

    SWING FRAME ASSEMBLY REF.NO LS PART.NO PART.NO DESCRIPTION SERIAL OR DATE 40261804 BT664-31000-01 SWING FRAME ASS'Y 40231106 BT664-74100 SWING CYL.PIN,∅25×118L 40231098 BT664-72100-03 PIN,∅40-117L 40261809 BT664-72200-01 LOCK 40231101 BT664-72400 PIN, ∅22-190L 40231100 BT664-72300 HANDLE SET 40231031 BC04-5100 PLASTIC BALL 40231102 BT664-72500 LOCK 40230946 6002-0122...

  • Page 40: Mainframe Assembly

    MAINFRAME ASSEMBLY - 39 -...
  • Page 41 MAINFRAME ASSEMBLY REF.NO LS PART.NO PART.NO DESCRIPTION SERIAL OR DATE 40261803 BT664-11000-01 MAIN FRAME ASS'Y 40231065 BT651-52100-01 CROSS BAR 40231088 BT664-62100-02 STABILIZER ASS'Y-RH 40231086 BT664-61100-02 STABILIZER ASS'Y-LH 40231087 BT664-61200 FOOT PLATE 40231064 BT651-31600 BRACKET-CUSHION 40230876 1002-B004 CUSHION 40261802 BT651-75110 BUSHING 40231089 BT664-71100 PIN,∅25-171L...

  • Page 42: Seat, Control Assembly(Hanil)

    SEAT, CONTROL ASSEMBLY(HANIL) - 41 -...
  • Page 43 SEAT, CONTROL ASSEMBLY(HANIL) REF.NO LS PART.NO PART.NO DESCRIPTION SERIAL OR DATE 40231070 BT664-12000H VALVE ROOM W.A. 40231059 BT651-12210-03 FRONT COVER 40231085 BT664-54101H TOP COVER 40231062 BT651-12240 FOOT PLATE - CENTER 40231061 BT651-12230-01 FOOT PLATE - RH 40231060 BT651-12220-01 FOOT PLATE - LH 40231081 BT664-41110-01 SUPPORT SEAT...

  • Page 44: Seat, Control Assembly(Walvoil)

    SEAT, CONTROL ASSEMBLY(WALVOIL) - 43 -...
  • Page 45 SEAT, CONTROL ASSEMBLY(WALVOIL) REF.NO LS PART.NO PART.NO DESCRIPTION SERIAL OR DATE 40294001 BTV02-20200 VALVE ROOM W.A. 40294002 BTV02-20301 COVER, FRONT 40294003 BTV02-40102-01 TOP COVER 40231062 BT651-12240 FOOT PLATE - CENTER 40231061 BT651-12230-01 FOOT PLATE - RH 40231060 BT651-12220-01 FOOT PLATE - LH 40294004 BTV02-70001P GUIDE BAR...

  • Page 46: Hose Fitting Assembly(Hanil)

    HOSE FITTING ASSEMBLY b-b , B-B c-c , d-d f-f , F-F e-e , E-E f'-f' , F'-F' a-a , A-A - 45 -...
  • Page 47 HOSE FITTING ASSEMBLY REF.NO LS PART.NO PART.NO DESCRIPTION SERIAL OR DATE 40228612 1012S-M0803-35 BOLT-SEM'S,M8-1.25P 35L 40261476 227102 BUCKET CYLINDER ASSEMBLY 40261475 227101 DIPPERSTICK CYLINDER ASSEMBLY 40261477 227103 BOOM CYLINDER ASSEMBLY 40230918 225806 SWING CYLINDER ASSEMBLY 40230910 224304 STABILIZER CYLINDER ASSEMBLY-LH 40230913 224305 STABILIZER CYLINDER ASSEMBLY-RH...

  • Page 48: Hose Fitting Assembly(Walvoil)

    HOSE FITTING ASSEMBLY(WALVOIL) b-b , B-B c-c , d-d f-f , F-F e-e , E-E f'-f' , F'-F' a-a , A-A - 47 -...
  • Page 49 HOSE FITTING ASSEMBLY(WALVOIL) REF.NO LS PART.NO PART.NO DESCRIPTION SERIAL OR DATE 40294009 8WKEXP2124 VALVE,WALVOIL SD6/6 40261476 227102 BUCKET CYLINDER ASSEMBLY 40261475 227101 DIPPERSTICK CYLINDER ASSEMBLY 40261477 227103 BOOM CYLINDER ASSEMBLY 40230918 225806 SWING CYLINDER ASSEMBLY 40230910 224304 STABILIZER CYLINDER ASSEMBLY-LH 40230913 224305 STABILIZER CYLINDER ASSEMBLY-RH...

  • Page 50: Bucket Cylinder Assembly

    BUCKET CYLINDER ASSEMBLY REF.NO LS PART.NO PART.NO DESCRIPTION SERIAL OR DATE 40261476 227102 BUCKET CYLINDER ASSEMBLY 40261491 227102-R ROD ASS'Y 40228867 OC60-7037 CAP OUTER,∅60-70-37L 40228827 IC60-3555 COVER INNER,∅60×35×55L 40228766 DSSD-R035 DUST,SDR,35×43×5/6.5 40228884 UPSK-Y035 PACKING U, SKY,35-45-6 40228880 UPIS-I035 PACKING U, ISI,35-45-6 40228872 OR1B-G055 O-RING,1BG55...

  • Page 51: Dipperstick Cylinder Assembly

    DIPPERSTICK CYLINDER ASSEMBLY REF.NO LS PART.NO PART.NO DESCRIPTION SERIAL OR DATE 40261475 227101 DIPPERSTICK CYLINDER ASSEMBLY 40261489 227101-R ROD ASS'Y 40230859 OC70-8037 CAP, OUTER,∅70-80-37L 40230766 IC70-4055 COVER, INNER,∅70-40-55L 40230710 DSSD-R040 DUST, SDR,40-48-5/6.5 40230872 UPSK-Y040 PACKING, U, SKY,40-50-6 40230869 UPIS-I040 PACKING, U, ISI,G55 40230861 OR1B-G065 O-RING, 1BG65,1BG65...

  • Page 52: Boom Cylinder Assembly

    BOOM CYLINDER ASSEMBLY REF.NO LS PART.NO PART.NO DESCRIPTION SERIAL OR DATE 40261477 227103 BOOM CYLINDER ASSEMBLY 40261493 227103-R ROD ASS'Y 40230859 OC70-8037 CAP, OUTER,∅70-80-37L 40230766 IC70-4055 COVER, INNER,∅70-40-55L 40230710 DSSD-R040 DUST, SDR,40-48-5/6.5 40230872 UPSK-Y040 PACKING, U, SKY,40-50-6 40230869 UPIS-I040 PACKING, U, ISI,G55 40230861 OR1B-G065 O-RING, 1BG65,1BG65...

  • Page 53: Swing Cylinder Assembly

    SWING CYLINDER ASSEMBLY REF.NO LS PART.NO PART.NO DESCRIPTION SERIAL OR DATE 40230918 225806 SWING CYLINDER ASSEMBLY 40230919 225806-R ROD ASS'Y 40231033 BC60-3555 HEAD,∅60-35-55L 40228766 DSSD-R035 DUST,SDR,35×43×5/6.5 40228884 UPSK-Y035 PACKING U, SKY,35-45-6 40228880 UPIS-I035 PACKING U, ISI,35-45-6 40231137 TRBR-G055 BACKUP RING,G55 40231135 OR00-G060 O-RING, G60,G60...

  • Page 54: Stabilizer Cylinder Assembly-Lh

    STABILIZER CYLINDER ASSEMBLY-LH REF.NO LS PART.NO PART.NO DESCRIPTION SERIAL OR DATE 40230910 224304 STABILIZER CYLINDER ASSEMBLY-LH 40230911 224304-R ROD ASS'Y 40228867 OC60-7037 CAP OUTER,∅60-70-37L 40228827 IC60-3555 COVER INNER,∅60×35×55L 40228766 DSSD-R035 DUST,SDR,35×43×5/6.5 40228884 UPSK-Y035 PACKING U, SKY,35-45-6 40228880 UPIS-I035 PACKING U, ISI,35-45-6 40228872 OR1B-G055 O-RING,1BG55...

  • Page 55: Stabilizer Cylinder Assembly-Rh

    STABILIZER CYLINDER ASSEMBLY-RH REF.NO LS PART.NO PART.NO DESCRIPTION SERIAL OR DATE 40230913 224305 STABILIZER CYLINDER ASSEMBLY-RH 40230914 224305-R ROD ASS'Y 40228867 OC60-7037 CAP OUTER,∅60-70-37L 40228827 IC60-3555 COVER INNER,∅60×35×55L 40228766 DSSD-R035 DUST,SDR,35×43×5/6.5 40228884 UPSK-Y035 PACKING U, SKY,35-45-6 40228880 UPIS-I035 PACKING U, ISI,35-45-6 40228872 OR1B-G055 O-RING,1BG55...

  • Page 56: Control Valve Assembly-Hanil Av 80/6

    CONTROL VALVE ASSEMBLY-HANIL AV 80/6 - 55 -...
  • Page 57 CONTROL VALVE ASSEMBLY-HANIL AV 80/6 REF.NO LS PART.NO PART.NO DESCRIPTION SERIAL OR DATE 40230982 BC04-0000-P CONTROL VALVE ASS'Y 40230983 BC04-0100 BLOCK-BA TYPE(INLET) 40230984 BC04-0200 BLOCK-HB TYPE(BOOM) 40230985 BC04-0300 BLOCK-HA TYPE 40230986 BC04-0400 BLOCK-EA TYPE 40230987 BC04-0500 BLOCK-GB TYPE (OUTLET) 40230988 BC04-0600 O-RING 40230989...

  • Page 58: Control Valve Assembly-Walvoil Sd6/6

    CONTROL VALVE ASSEMBLY-WALVOL SD 6/6 - 57 -...
  • Page 59 CONTROL VALVE ASSEMBLY-WALVOL SD 6/6 REF.NO LS PART.NO PART.NO DESCRIPTION QTY I.C SERIAL OR DATE 40308224 YTAP623282-H PLUG SV/VMP5 * Order code for spare parts 40308222 XTAP524280 PLUG P3T/SD6 * Order code for spare parts 40308217 KEXPE0000033 VALVE KIT U(G3)/SD6 * Order code for spare parts 40308213 5KIT306113-W...

  • Page 60: Decals

    DECALS CAUTION : Read and refer to the Tractor Operation Manual or Decals on the Tractor. and Backhoe Decals on as shown. ⑧ ① ② ⑨ ⑦ ③ ④ ⑨ ⑪ ⑤ ⑫ ⑥ ⑬ ⑭ ⑦ ⑬ Refer to category "Safety decals" - 59 -...
  • Page 61 DECALS REF.NO LS PART.NO PART.NO DESCRIPTION SERIAL OR DATE 40231049 BH35-0110 DECAL-WARNING 40231046 BH35-0107 DECAL-WARNING 40231047 BH35-0108 DECAL-WARNING 40231048 BH35-0109 DECAL-WARNING 40231051 BH35-0112 DECAL-WARNING 40231041 BH35-0101 DECAL-WARNING 40231042 BH35-0102 DECAL-WARNING 40230647 3101E-00112 DECAL-LS 40231045 BH35-0105 DECAL-WARNING 40230653 3104E-00010 NAME PLATE 40231044 BH35-0104 DECAL-DANGER...
