  • Page 1 LS TRACTOR OHSAS 18001 OPERATOR'S MANUAL MT563 MT568 MT573 PO Box 70, Battleboro, NC 27809 Tel : 252-984-0700 Fax : 252-984-0701 www.lstractor.com P/NO 52121501/02 www.lstractorusa.com DATE 20160000...
  • Page 2 FEDERAL and CALIFORNIA EMISSION CONTROL SYSTEM WARRANTY STATEMENT YOUR WARRANTY RIGHTS AND OBLIGATIONS The California Air Resources Board (CARB), U.S. Environmental Protection Agency (EPA), and LS Mtron Ltd. (LS Mtron) are pleased to explain the emission control system warranty on your 2017-2018 model year engine.
  • Page 3 Any warranted part which is scheduled only for regular inspection in the written instructions shall be warranted for the warranty period defined above, provided that there has been no abuse, neglect or improper maintenance or usage of your engine. A statement in the written instructions to the effect of "repair or replace as necessary"...
  • Page 4 Limited Emission Control Systems Warranty, you should contact LS Mtron at the address below for assistance. If you need additional assistance or information concerning the Limited Emission Control System Warranty, contact: 1. LS Mtron Ltd. 2. LS Tractor USA LLC 886, Gwahak-Ro, Bongdong-Eup Ricky Mark Wanju-gun, Jeollabuk-Do, Korea...
  • Page 5 What is not covered by the Limited Emission Control System Warranty This warranty does not cover: 1. Malfunctions in any part caused by any of the following: misuse, abuse, improper adjustments, modifications, alteration, tampering, disconnection, improper or inadequate maintenance, or use of fuels not recommended for the engine as described in the Maintenance Manual.
  • Page 6 What is covered by the Limited Emission Control System Warranty The following is a list of systems and parts that are considered a part of the Emission Control System and are covered by the Limited Emission Control System Warranty for engines which were built to conform to CARB and EPA regulations: IMPORTANT! This may not include expendable maintenance items such as nozzle assemblies and rubber flanges.

  • Page 7: Table Of Contents

    Contents 1. General Notices for Safety 1-1. Before using the tractor · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 1-1 1-2.
  • Page 8 CONTENTS 3. Instruments and Controls 3-1. Instrument Panel and Front controls (1) Instrument panel · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 3-2 (2) Key switch ·...
  • Page 9 CONTENTS (5) Joystick lever (optional) · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 3-43 (6) Auto lift control (MHL, if fitted) ·...
  • Page 10 CONTENTS 5. Lubrication and Maintenance 5-1. Access for maintenance · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 5-1 5-2.
  • Page 11 CONTENTS 5-10. Every 1000hr or 1-year check (1) Replacing Air cleaner element (Dry type) · · · · · · · · · · · · · · · · · · · · · · 5-26 (2) Checking Nozzle injection pressure · · · · · · · · · · · · · · · · · · · · · · · · · · 5-26 (3) Adjusting Engine valve clearance ·...

  • Page 12: General Notices For Safety

    1. General Notices for Safety 1-1. Before using the tractor ※ Must read and understand this operator’s manual carefully and always refer to information and prescriptions outlined in this manual to prevent all potential health and safety risks. ◆ General information for intended use ...
  • Page 13  Never remove or modify or change the driver’s protection device or safety device arbitrary.  You must take the necessary precautions to always be aware of the possible presence of bystanders, certainly when maneuvering in confined areas. Keep people away from the tractor during work.
  • Page 14 ◆ Product Identification Your tractor has a exclusive chassis number and engine number marked with product serial number tag to identify the product. (See Fig.1-1) In case of requesting service or parts from your dealer, dealer will need chassis serial number, engine serial number, TM number and also running hours displayed on the instrument panel.

  • Page 15: Safety Precautions (Read This For Safety Before Using)

    1-2. Safety Precautions - read this for safety before using. (1) Notices before using the tractor  For Safety operation : Before using this tractor, read carefully and understand this operator's Read Operator’s manual and operator’s manual of the mounted Manual carefully.
  • Page 16 Tire air pressure, Wheel bolts, Toe-in, Electrical wirings, other items related to safety.  Genuine Parts : When replacing parts, you must use “Genuine Parts” of LS tractor. Contact your authorized local dealer. If not, it may cause a failure, reduction of product life or serious injury.
  • Page 17  Protective Structures : For the operator’s safety, various protective structures, i.e. Bonnet (Hood), Fan cover, PTO safety cover, PTO shaft protection cap, Roll-bar or another Roll-over Protective Structure, etc are attached on the tractor. If these structures are modified or removed by user arbitrarily, it may cause serious accident.

  • Page 18: Notices When Starting Engine

    (2) Notices when starting Engine  Check each part with reference of “5. Lubrication and Maintenance” in this manual. If necessary, repair or replace it immediately. Especially, check if safety protection structures or covers are attached originally and the bolts and nuts are tightened well.

  • Page 19: Notices While Operating/Using The Tractor

    (3) Notices while operating/using the tractor  Ventilation Warning ▶It is very dangerous to work in a closed area. The poisonous exhaust gas may cause serious damage to the human body. If you should work in this area, make sure to ventilate well and put on the protective mask.
  • Page 20  Obey the traffic rules while driving on public roads. Do not exceed the local legal speed limit. Use a beacon or slow moving vehicle (SMV) to indicate that the vehicle is slow moving.  If you can not drive the tractor due to a failure, move the tractor to a safe place and install troubled vehicle (safety tripod).
  • Page 21  Do not operate the product beyond its limits of terrain gradient and stability than outlined in this manual. Using the tractor beyond these limits may cause a serious accident or death.  The steering system of your tractor may be locked at steep slopes of more than 25 °downhill.

  • Page 22: Notices When Connecting Implement

    (4) Notices when connecting Implement  Attach or detach the implement on wide and level ground.  Do not use the tractor in combination with equipment arbitrary, without having consulted the specific operator’s manual provided with the equipment.  You have to stay clear from the three-point linkage when controlling it.

  • Page 23: Notices When Towing The Tractor

    (5) Notices when towing the tractor  If your tractor needs to be towed for a short distance, use the hitch (or drawbar) or front towing hook. Do not connect to other structures such as rear axle, ROPS, front axle, steering components for towing.

  • Page 24: Notices When Servicing The Tractor After Work

    (7) Notices when servicing the tractor after work  Check and maintenance must be performed after stopping the engine and cooling down the engine sufficiently.  DO NOT pour water into the radiator or engine when engine is hot. The engine or radiator may crack.

  • Page 25: Notices When Handling Diesel Fuel

     Do not attempt to remove or unfasten the air conditioning components arbitrary. There is a possible to be severely frostbitten or injured by escaping refrigerant. Contact your authorized local dealer to work air conditioning systems.  Before servicing the tractor, attach a “DO NOT OPERATE”...

  • Page 26: Notices When Leaving The Tractor

    (9) Notices when leaving the tractor  Stop the tractor on level ground.  Place the transmission gear in neutral and put PTO switch to “OFF” position.  Lower the mounted implements on the ground.  Apply the parking brake. ...

  • Page 27: Long-Term Storage

    1-3. Long-term storage (1) Preparation for storage ※ Wash the tractor cleanly and follow the procedure as below.  Apply grease or lubricant oil or spray paint to the non-painted metal to avoid corrosion. Keep the tractor in a covered, dry and well-ventilated place.

  • Page 28: Check & Maintenance During Storage

    ▶ When restarting engine at the end of long-term storage, follow the instructions of Warning the “Preparation for Reuse” as below. (2) Check & Maintenance during storage  Apply grease or lubricant oil regularly to the non-painted parts.  Check the leakage of fuel, oil and coolant. If necessary, repair the damaged part. ...

  • Page 29: Notices For "Use & Disposal" Related To The Environment

    1-4. Notices for ”Use & Disposal” related to the environment Soil, air and water are essential elements for human life. To contribute to environment preservation of the Earth, we are trying to minimize the environment pollution necessitated by general business activity such as product design, manufacturing, distribution, etc. Several substances and products derived from chemical and petrochemical products are major portion of environment pollution and must be disposed of according to environment laws or related regulations, and common sense.

  • Page 30: Symbols

    1-5. Symbols The followings show the symbols and its meaning used for the tractor. Refer to operator’s Gear Neutral Low speed Manual. Caution! Forward/Rearward High speed Engine speed Battery charging Forward control (throttle) Engine speed Fuel level Backward control (throttle) Turn signal Fuel filter 4WD connection...

  • Page 31: Safety Decals

    1-6. Safety Decals (1) Handling and Maintenance of Safety Decals  For intended use and personal safety of the operator, the safety decals (labels) are attached to the parts related with safety operation.  Before operating or maintenance of the tractor, check the position and read the instructions carefully. ...
  • Page 32 1. Location : On top of the Fuel tank - Only clean diesel fuel not contaminated (No gasoline, water, low quality diesel fuel, and foreign matters like dust. It could occur fatal damage to the fuel injection system. - Maximum of 7% Biodiesel (B7) - Part No.
  • Page 33 6. Location : On the right-hand door glass for cabin model. - If the DPF requires regeneration process, DPF Regen lamp shall be blinking. - If you need to be delayed or stopped because of an operation condition that may risk a fire hazard due to high exhaust temperature, push the DPF inhibit button and park your tractor.
  • Page 34 9. Location : On the left-hand pillar for Cabin model. ① CAUTION - PTO selector & lever must be in “OFF” position to start engine. - Do not operate on hard surfaces with 4WD engaged. ② WARNING - TO PREVENT SERIOUS INJURY OR DEATH; •...
  • Page 35 10. Location : On the right-hand side cover - TO PREVENT DEATH OR SERIOUS INJURY • During the DPF regeneration process, the exhaust stack and fixed hood area becomes extremely hot. • Park the tractor away from highly flammable material and person. - Part No.

  • Page 36: Instruction For Safe Operation

    2. Instruction for Safe Operation (1) The name of each part ① Cabin type Cabin Steering wheel Driver’s Seat Instrument panel Bonnet (Hood) Head lights Fender Sub step Fuel tank Front axle Front ballast weight (optional) 2 - 1...

  • Page 37: Boarding And Exiting The Tractor

    2-1. Boarding and Exiting the tractor (1) Boarding the tractor Grab handle ① Cabin type Whenever possible, use the left-hand side door for entering. Release the cabin door locked with the provided key and open the cabin door after pressing the Sub step push-button.

  • Page 38: Seat Adjustment

    (2) Seat adjustment ① Standard type Before operating the tractor, adjust the position of driver’s seat according to body size and length. 1) Seat F/R adjustment lever -.After sitting on driver’s seat, move the seat F/R adjustment lever up to release the lock. - Move the driver’s seat forward or backward depending on driver’s body length.
  • Page 39 ② Optional - continued 3) Weight adjustment lever - PUSH the lever downward for light weight. Weight - PULL the lever upward for heavy weight after adjustment lever turning key switch to “ON” position. 4) Backrest angle adjustment lever - Lift the lever upward to adjust the backrest angle. - After adjusting, release the lever and check the backrest locked in place.

  • Page 40: Seat Belt

    (3) Seat belt Always wear the seat belt before operating the Buckle tractor and adjust the belt to fit the operator. Seat belt 1. Insert the seat belt end into the buckle until a “click” indicates it is properly engaged. 2.

  • Page 41: Tilting Steering Wheel

    (4) Tilting steering wheel  Press the steering tilt pedal down to release the steering wheel and tilt the steering wheel to desired position. Steering tilt pedal  Release the tilt pedal to lock the steering wheel Lock in place, and make sure to check the steering column is locked firmly.

  • Page 42: Exiting The Tractor

    (6) Exiting the tractor ① Door (Left / Right) Door release lever Whenever possible, use the left-hand side door for entering/exiting. To open the left/right cabin door, push the door release lever downward, and use the grab handle to push the door outside. Grab handle RELEASE Lock the cabin doors before leaving the tractor.

  • Page 43: Safety Device

    2-2. Safety device (1) Hood (Bonnet) Hood (Bonnet) Hood is a protection device to prevent an unintended access to the rotating parts around engine; cooling fan, fan belt and rotating shaft and pulley. Do not remove and modify the hood. (2) Fender Fender is a protection device to prevent an unintended access to the rear tires and to...

  • Page 44: Roll-Over Protective Structure (Rops)

    (4) Roll-Over Protective Structure (ROPS) (optional) ① Cabin type The Protective Structure (Roll-bar or Cabin) and Cabin interconnecting components are a certified system. Any damage, fire, corrosion or modification will weaken the structure and reduce your protection. If this occurs, the Protective Structure MUST be replaced with a new one.

  • Page 45: Instruments And Controls

    3. Instruments and Controls 3-1. Instrument panel and Front controls Important to owner, read carefully Shuttle lever 540E PTO switch(if fitted) Beacon lamp switch(if fitted) Throttle pedal Clutch pedal Instrument panel Combination switch Key switch DPF switch Steering tilt pedal (See chapter 2) Grille work light switch...

  • Page 46: Instrument Panel

    (1) Instrument panel 16 LCD display panel Tachometer 17 Fuel level gauge Turn signal indicator (LH/RH) 18 Battery charging indicator Parking brake indicator 19 Low fuel level indicator High beam indicator 20 Cold start aid indicator Brake pedals not latched indicator (optional) 21 Engine oil pressure indicator Hydraulic oil filter pressure indicator 22 Fuel filter warning indicator...
  • Page 47 Tachometer  The tachometer shows the engine revolutions per minute (“30” means 3000rpm). Turn signal indicator (Left / Right)  When turning the turn signal light switch to the left/right direction, the front and rear turn signal lights are blinked. At this time, this indicator shall blink simultaneously.
  • Page 48 10 540E PTO operation indicator (optional)  When PTO gear lever is 750/540E rpm, and PTO switch and 540E PTO switch is “ON”, this indicator shall be ON, and the engine maximum speed shall be restricted in this mode. 11 PTO operation indicator ...
  • Page 49 16 LCD display panel ⓐ Hour meter & Engine diagnosis error code  If any error does not exist on tier-4 engine Battery voltage Hour meter control, in normal operation condition, accumulated operation hour shall be displayed  If the display shows “0019.1”, it means the tractor has been operated for 19.1hours so for (19 hours and 6 minutes).
  • Page 50    Changing Unit(km/h mph, mm inch): ESC main switch Press the upper side of the ESC main switch shortly(within one second). The unit change is only available before editing the tire rolling circumference.  Entering edit mode: Turn key switch to “ON” position with pressing the upper side of the ESC main switch.
  • Page 51 22 Fuel filter warning indicator  When there is a restriction or excess water in the fuel filter, this indicator shall be ON.  Remove water in the fuel filter. (See chapter 5-5-(1) in this manual) 23 DPF Regeneration indicator ...

  • Page 52: Key Switch

    (2) Key switch  OFF - power off (engine stop)  ON - power on & automatic glow Start  Start - engine start Key switch ▶ Because the safety switch for start is engaged, start the tractor after pressing clutch pedal.

  • Page 53: Clutch Pedal

    (4) Clutch pedal  This is used to engage or disengage the main transmission clutch for starting engine and shifting transmission gear.  Depress the clutch pedal quickly and fully and release it slowly.  When depressing the clutch pedal, If PTO mode switch is placed on ;...

  • Page 54: Shuttle Lever (Synchro-Shuttle)

    (6) Shuttle lever (Synchro shuttle)  This is used to select Forward or Reverse.  After depressing clutch pedal, Forward FORWARD : Push the lever forward. REVERSE : Pull the lever backward.  Before reversing the tractor, lower the engine speed and check the safety behind the tractor.

  • Page 55: Combination Switch

    Turning ON/OFF High beam  When pushing the switch downward from neutral position, the switch shall be locked and the high beam shall be ON. Neutral (Low beam)  To turn off the high beam, return the switch to neutral position. High beam Combination light switch ▶...

  • Page 56: Hazard Warning Light Switch

    (8) Hazard warning light switch  This is used to warn other vehicles in case of emergency status. If you press the upper side of the triangle switch, all turn signal lights (front/rear, left/right) shall be blinking. ▶ If using the hazard warning lights for a long time, it may Notice cause high electrical...

  • Page 57: Dpf Switch

    (10) DPF switch  This switch is used to select the Regeneration mode or the Inhibited regeneration mode. - Regeneration mode : If the soot is loaded over the designated level and the engine is warmed up enough, the DPF regeneration shall be processed automatically by ECU.
  • Page 58 If you have any questions in the operation of this emission system, please contact an authorized local LS tractor dealer. ▶Burn hazard ! During the Diesel Particulate Filter (DPF) regeneration process, the exhaust stack and fixed hood area becomes extremely hot.
  • Page 59 ④ Indicator illumination on instrument panel  The indicators related to the DPF regeneration have several illumination figures and its meanings as follows. Read carefully and keep in mind the instructions well. Symptom & Indicators figures Possible cause Remarks Actions 1.
  • Page 60 ⑤ Regeneration mode  In this mode, the operator does not have to take any actions, the system is activated automatically by the engine electronic controller. NOTE : The regeneration is the normal operating mode.  The regeneration shall be activated by ECU ; - When soot’s rate reaches 100% or more.
  • Page 61 ⑥ Inhibited regeneration mode NOTICE : Only use this mode when regeneration needs to be delayed or stopped because of an operation condition that may risk a fire hazard due to high exhaust temperatures during regeneration. NOTE : Even if the DPF regeneration indicator(1) is ON during the regeneration process, the inhibited regeneration mode can be set.

  • Page 62: Beacon Lamp Switch (If Fitted)

    (11) Beacon lamp switch (if fitted)  It is used to turn on/off the beacon lamp connected to beacon connectors. The beacon connectors are installed on the left and right-hand side under the cabin roof.  ON - press upper side of the switch. OFF - press lower side of the switch.

  • Page 63: Right-Hand Controls And Cabin Pillar

    3-2. Right-hand controls and Cabin pillar Important to owner, read carefully 4WD switch Electrical power outlet socket Wiper switch Work light switch Remote control Lever (Page 3-42) ECS switch Auto lift switch Differential lock (Page 3-44) switch PTO mode switch Joystick lever (Page 3-43) Throttle lever...

  • Page 64: Main Gear Shift Lever

    3-2. Right-hand controls and Cabin pillar Important to owner, read carefully Electrical power 4WD switch outlet socket Wiper switch Work light switch Remote control Lever (Page 3-42) ECS switch Differential lock switch Joystick lever PTO mode (Page 3-43) switch EHL control unit Throttle lever (Page 3-47)

  • Page 65: Work Light Switch

    (3) Work light switch ① Cabin type (Front, Rear) Front Rear work light work light  This is used to turn on the front/rear work lights. switch switch  ON - Press the upper side (symbol part) of the switch. ...

  • Page 66: Electrical Power Outlet Socket (Cabin Only)

    (5) Electrical power outlet socket (Cabin only)  This is used to withdraw the electric power for Power out socket charging of the cigarette lighter jack or cellular phone.  In case of using cigarette lighter jack (optional), If pushing the cigarette lighter jack into the socket, the heated coil can be used as an alternative of lighter.

  • Page 67: 4Wd Switch

    (8) 4WD switch  Press the upper side of switch for Four wheel 4WD switch drive.(4WD)  Press the switch lower side for 2WD.  Front wheel drive (4WD) is effective for the followings. -When traction is needed in plow ground. -When working on slippery ground.

  • Page 68: Pt0 Mode Switch (Optional)

     Push the lower side of the switch or press down the brake pedals once to release the differential Differential lock switch lock. If the traction of rear wheels is equalized, the lock is released automatically.  If the differential lock does not released, i.e. when turning to the right or left, the turning radius is larger than normal operation, depress the clutch pedal once and press one-side brake...

  • Page 69: Pto Switch

    (12) PTO switch  The engine starts only when PTO switch is placed in OFF position for safety.  After starting the engine, you must comply with the operation procedure of the PTO switch as follow. 1. Place the PTO gear lever to desired position. 2.

  • Page 70: Engine Speed Cruise Control (Esc) Switch

    (13) Engine Speed Cruise control (ESC) switch ① ESC main switch ESC main switch  This switch is used to enable Engine Speed Cruise control(ESC) function.  If pressing the ESC main switch from position 0 to position 1 (Off –> Ready), - ESC indicator on instrument panel shall be blinked.
  • Page 71 ② ESC speed up/down switch  This switch is used to adjust the engine speed ESC speed up/down switch for ESC when the ESC is working.  If pressing the upper/lower side of the switch, the engine speed shall be ; - Upper side : Increased.

  • Page 72: Left-Hand Controls

    3-3. Left-hand controls Important to owner, read carefully PTO gear Driver’s seat lever (if fitted) (See chapter 2) Range gear shift lever Down speed Control knob Creeper gear (chapter 3-5) lever (if fitted) (1) Range gear shift lever  Three speed gear selection is available. Range gear shift lever ...

  • Page 73: Creeper Gear Lever (If Fitted)

    (2) Creeper gear lever (if fitted)  If pulling this lever upward, the creeper gear is connected (ON), and if pushing it downward, the Creeper gear creeper gear is disengaged. (OFF) lever ▶As the driving force of the rear axle is very high when working Creeper range in creeper speed range, the machine may not stop even if...

  • Page 74: Power Shuttle System (Pss) (If Fitted)

    3-4. Power Shuttle System (PSS) (if fitted) (1) Power shuttle lever (PSS)  Your tractor has an advanced electro-hydraulic forward and reverse system which controls the Power shuttle lever movement (Forward/Reverse/Stop) of the tractor Forward by engaging or disengaging the multi-disk clutches.
  • Page 75  If the hydraulic pressure of the shuttle system goes lower than proper level during operation, corresponding error code (SPN, FMI code) shall be displayed on the instrument panel with continuous alarm. At this time, move the shuttle lever to neutral position first. DO NOT try to operate the tractor any more, because the clutch engagement under a lower pressure can cause damage to the clutch plate even for a few seconds.

  • Page 76: Clutch Pedal (Pss)

    (2) Clutch pedal (PSS)  This pedal is used to engage or disengage the engine power for engine start, transmission shift Clutch pedal and stopping tractor.  To disengage the clutch, depress the clutch pedal fully. If PTO select switch is placed on “AUTO”...

  • Page 77: Clutch On/Off Switch (Pss)

    (3) Clutch ON/OFF switch (PSS)  It is used to engage/disengage the main clutch before shifting the main gear shift lever instead of the clutch pedal.  If pressing/releasing this switch, the engine power shall be disengaged/engaged.  If pressing this switch for over 10 seconds, the Clutch on/off switch diagnostic code is displayed on LCD display and this switch is automatically released and the...

  • Page 78: Engaging Speed +/- Switch (Pss)

    (5) Engaging speed +/- switch (PSS)  It is used to adjust the engaging speed of the Engaging speed +/- switch power shuttle clutch when operating clutch pedal or power shuttle lever.  Engaging speed adjustment of the clutch pedal; 1.

  • Page 79: Error Diagnosis Code (Pss)

    (6) Error Diagnosis Code (PSS)  If a sensor or a valve related to the power shuttle system has failed, the corresponding error code, SPN code and FMI code shall be displayed on the instrument panel as shown in the figure. Refer to the next page for SPN code and FMI code.
  • Page 80 (6) Error Diagnosis Code (PSS) - continued Component Description Shuttle lever sensor Short to PWR source 100000 F/R Lever Shuttle lever sensor Short to Ground Shuttle lever sensor & Neutral Switch Error Clutch pedal sensor Short to PWR source 100100 Clutch Pedal Clutch pedal sensor Short to Ground 100200...

  • Page 81: Hydraulic System

    3-5. Hydraulic system (1) Safety precautions  Hydraulic oil leaking under pressure can penetrate the skin and cause infection or other injury. To prevent personal injury, comply with as below. -. Relieve all pressure before disconnecting hydraulic lines. -. Before applying pressure, make sure all connections are tight and components are in good condition.

  • Page 82: Steering System

    (2) Steering system  The hydraulic steering system controlled by fluid power provides you more convenience to operate the steering wheel.  Notices when using the steering system. 1. If there is too much of a load in front loader bucket, it could be difficult to operate the steering wheel. In this case, reduce the size of the load.

  • Page 83: Hydraulic Lift Control (Mhl)

    (3) Hydraulic lift Control (Mechanical Hydraulic Lift, MHL)  The hydraulic lift system is operated by the position control and draft control lever. Position control lever Draft control lever Down speed control valve ① Position control  To set the position (height) of the rear implement, Position control move the position control lever up/down during lever...
  • Page 84 ② Draft control  The working depth of the implement under the draft control is controlled automatically by the Upper link bracket draft load of the implement that detected from Draft sensing rod draft load sensor bracket and transmitted to the lift control valve.
  • Page 85 ④ Down speed control knob (MHL)  Turn the valve knob to the right to lower the implement slowly and to the left to rise speed faster. If turning right fully, the implement shall be fixed and even if lowering down the position control lever, the implement does not let down.

  • Page 86: Remote Control Lever And Quick Coupler (Optional)

    (4) Remote control lever and Quick coupler (optional)  These levers are used to operate the hydraulic cylinder and/or motor of the implement attached to the tractor.  Push the remote control lever forward, and the hydraulic pressure can be delivered to the left-hand coupler of the related lever and right-hand coupler shall be connected to the drain.

  • Page 87: Joystick Lever (Optional)

    (5) Joystick lever (optional)  Remote joystick lever helps to operate front loader comfortably.  Joystick can be operated at 4 directions as shown in the right figure.  If you move joystick diagonally, loader and bucket shall be operated at the same time. Then, small loads move first.

  • Page 88: Auto Lift Control (Mhl, If Fitted)

    (6) Auto lift control (MHL, if fitted) ※ It is used to lift the implement up to the highest position quickly and lower it down to the position Auto lift set by position control lever without using up switch position control lever. ...

  • Page 89: Hydraulic System Diagram

    (7) Hydraulic System Diagram Mechanical Hydraulic Lift (MHL) 1. Hydraulic oil filter 8. Steering unit 14. Hydraulic lift housing 2. Hydraulic lift pump 9. Steering cylinder 15. Hydraulic lift control valve 3. Steering pump 10. Oil cooler valve 16. Down speed control valve 4.
  • Page 90 Electro-Hydraulic Lift (EHL) 1. Hydraulic oil filter 8. Steering unit 14. In-line pressure filter (optional) 2. Hydraulic lift pump 9. Steering cylinder 15. Leveling control valve 3. Steering pump 10. Oil cooler valve (optional) 4. Sequence valve 11. Oil cooler 16.

  • Page 91: Electro-Hydraulic Lift (Ehl) (If Fitted) (1) Configuration & Description Of The Ehl Controller

    3-6. Electro-Hydraulic Lift (EHL) (if fitted) (1) Configuration & Description of the EHL Controller Draft/Depth control Upper limit Down speed Slope setting setting dial setting dial setting dial dial (if fitted) Lower limit setting knob Sensitivity switch (if fitted) Manual up/down switch (if fitted) Auto lift Leveling mode...
  • Page 92 Draft/Depth control Upper limit Down speed Slope setting setting dial setting dial setting dial dial (if fitted) Lower limit setting knob Sensitivity switch (if fitted) Manual up/down switch (if fitted) Auto lift Leveling mode Work mode Position control mode switch switch (if fitted) setting switch lever...

  • Page 93: Operating Electro-Hydraulic Lift (Ehl)

    (2) Operating Electro-Hydraulic Lift (EHL)  If the engine starts, and the position control lever does not synchronized to the 3-point linkage, the EHL display shows symbols in the right figure. In this case, you have to synchronize the position control lever to 3-point linkage before using the Electro-Hydraulic Lift.
  • Page 94 ② Draft control  This mode maintains the draft load from the implement consistently by detecting the load and transmitting it to the hydraulic valve to lift up or down the implement. Generally, this is useful for Light Heavy the implements such as plow. 1.
  • Page 95 ▶ If the draft control mode is set in the state that depth control cable is not attached, Notice this mode is not available, and continuous beep sounds. ④ Upper limit setting dial  This is used to set the upper limit of one touch lift and auto lift function.
  • Page 96 ⑦ Auto lift mode switch  This is used to select the auto lift mode. Instrument panel Control unit 1. When the engine starts at first, the auto lift mode is “OFF”. If you press the auto lift mode switch Turn-up repeatedly, the mode shall be changed with the LED light as below.
  • Page 97 ⑨ Automatic PTO ON/OFF adjustment (EHL)  The position that PTO shaft is stopped can be Position control lever adjusted by operator depending on the works.  The adjustment height is restricted within 25% ~75% of the maximum lift stroke. If the set-up is over the designated range, the set-up is modified to 25% or 75% automatically.
  • Page 98 ⑩ Auto-Leveling Control (EHL, optional) Slope Manual  Auto-Leveling Control is a automatic control setting dial up/down device which keep the tilt of the rear implement switch horizontal electro-hydraulically when the tractor Sensitivity switch is tilted by uneven ground.  When turning the key switch ON, Leveling mode switch shall be set for Manual model(M).

  • Page 99: External Up/Down Switch (Ehl)

    (3) External up/down switch (EHL) ① External lift up/down switch (EHL)  This switch is attached on the rear mudguard.  This is used to attach or detach the implement to the 3-point linkage. 1. If pressing and holding the switch up/down, the implement will lift up/down with beep sounds.
  • Page 100 ② External leveling cylinder up/down switch (EHL, if fitted)  This switch is attached on the rear mudguards.  This is used to lift/lower the auto-leveling cylinder for: 1) attaching or detaching the implement to the 3- point linkage. 2) leveling the implement horizontally. Leveling cylinder Up ...

  • Page 101: Error Diagnosis Code (Ehl)

    (4) Error Diagnosis Code (EHL)  If the EHL sensor or valve has failed, the error code shall be displayed on the Instrument panel as shown in the figure.  In case of several errors, the errors shall be displayed repeatedly every 1 second. In this case, record all error codes.
  • Page 102 Component Description (ENG) Up valve short to ground 220100 Lift Up Valve Up valve short to power Up Valve Stick Down valve short to ground 220200 Lift DN Valve Down valve short to power AL Up valve short to ground 220300 AL Up Valve AL Up valve stick...

  • Page 103: Operation And Work

    4. Operation and Work 4-1. Engine start and stop ▶Check each part before starting engine. ▶Check if there is some other people Caution around the tractor before starting. ▶Place the lever and switch in NEUTRAL or OFF position. (1) Engine start 1.

  • Page 104: Start In Cold Weather

    Warning ▶Only start engine outdoors or in a well ventilated place, as the engine exhaust fumes may cause sickness or death. ▶To avoid an explosion, never use starting fluid to start engine. ▶Start the engine ONLY from the driver’s seat with depressing clutch pedal fully. ▶DO NOT start the engine by shorting across the terminals of start motor.

  • Page 105: Engine Stop

    (3) Engine stop  Pull the throttle lever backward to reduce the engine speed and turn the key switch to “OFF” Throttle lever position. The engine shall be stopped.  Remove the ignition key after stopping engine. ▶ To stop the engine after finishing heavy work, run engine for 5 minutes in low idle Notice rpm.

  • Page 106: How To Drive And Stop

    4-2. How to drive and stop (1) How to drive ① Synchro-shuttle model 1. Lift up all the implements Main gear (front/middle/rear) from the ground shift lever after starting engine. Throttle lever Position control lever 2. Pull throttle lever to low speed position.
  • Page 107 1. Lift up all the implements Main gear (front/middle/rear) from the ground shift lever after starting engine. Throttle lever Position control 2. Pull throttle lever to low speed lever position. Parking brake lever 3. Place power-shuttle lever in neutral position. 4.

  • Page 108: Changing Speed

    (2) Changing speed Shuttle lever  Depress the clutch pedal fully and operate all the Throttle pedal shift levers correctly.  Before shifting F/R Shuttle lever, Range gear lever, Creeper gear (if fitted), HAVE TO STOP the tractor completely. (3) Emergency Stop 1.

  • Page 109: Driving Tractor On The Road

    (5) Driving tractor on the road  When facing downhill, DO NOT place the gear lever in Neutral position.  When driving the tractor on a unpaved road by attaching a implement to 3-point linkage, place the gear lever to low speed and DO NOT lift the implement up to the highest position. When driving in the highest position, it may cause the vibration of implement and the failure of hydraulic system.

  • Page 110: Parking

    (6) Parking  Stop the tractor on a level surface, not on a slope.  Disengage PTO and place all the transmission shift lever in NEUTRAL position.  Lower the mounted implements on the ground.  Apply the parking brake. ...

  • Page 111: How To Handle New Tractor

    4-3. How to handle new tractor (1) Check points ※ For new tractor, the following must be checked once again even though there was sufficient quality management, inspection, regulating of each part in the factory.  Appearance check - Is there any damage while transporting? ...

  • Page 112: 3-Point Linkage

    4-4. Attaching Equipment (1) 3-point linkage ⑦ ④ ⑥ ⑤ 1. Lift rod (RH) ① 2. Stabilizer ② 3. Lower link ③ 4. Lift rod (LH) 5. Upper link 6. Lift rod pin 7. Top link pin  When attaching the implement, comply with the followings. 1.
  • Page 113 ① Adjustment of Lift rod and Upper link  Do not adjust the lift rod and upper link over the Lift rod (LH) described range as below. Upper link  Lift rod (RH) - Lift up the lift rod handle and turn left or right to adjust the length.
  • Page 114 ③ Reference of implement installation part (Max.) (Min.) (Max.) (Min.) 19.3 44.5 22.4 CAT.1 (0.74) (0.75) (1.73) (2.99) (2.71) (1.75) (0.86) (0.88) (1.53) (1.53) (0.47) (26.8) 25.4 25.7 28.7 CAT.2 (1.00) (1.01) (2.00) (3.66) (3.38) (2.04) (1.10) (1.12) (1.77) (1.92) (0.47) (32.4) Unit : mm...
  • Page 115 ④ Handling of the 3-point linkage ⑦ ④ ⑥ ⑤ 1. Lift rod (RH) ① 2. Stabilizer ② 3. Lower link ③ 4. Lift rod (LH) 5. Upper link 6. Lift rod pin 7. Top link pin  When driving without attaching implement, comply with the followings. 1.

  • Page 116: Power Take-Off (Pto) Shaft

    (2) Power take-off (PTO) shaft ① Safety precautions  When PTO shaft is rotating, NEVER APPROACH the shaft.  Check if PTO shield is attached correctly. If the shield is removed or damaged, replace it with a new one.  Suitable Clothes & Protect Entanglement : When checking or attaching implement to the PTO shaft, wear tight fitting clothes and safety equipment instead of loose or long clothes.
  • Page 117 ③ Attaching PTO drive shaft  When connecting PTO drive shaft to the PTO shaft and implement, make sure to check the fixing status of the locking pins.  When attaching implements with power take-off drive shafts, refer to the drawings as below. ...

  • Page 118: Hitch And Drawbar (Optional)

    (3) Hitch and Drawbar (optional)  When attaching towing equipments, use the hitch or drawbar. DO NOT use the 3-point linkage or other parts. If so, the tractor could turnover.  Insert the hitch pin and snap pin correctly after Drawbar attaching/detaching equipment.

  • Page 119: 7-Pole Connector (Optional)

    (4) 7-Pole connector (optional)  The one of the standard 7-pole trailer connectors is provided and is mounted at the rear of the tractor. The connections of the 7-pole connector (viewed from the rear of the tractor) are as follows; ...

  • Page 120: Technically Maximum Permissible Mass

    (5) Technically maximum permissible mass  When working with front loader or rear heavy loaded attachments installed to the 3-point linkage, install ballast weights on the counter-part axle to maintain the front and rear weight balance of the tractor. If not, front or rear axle can be strained by the overloaded weight. ...

  • Page 121: Tires And Load Capacity

    (6) Tires and Load capacity Axle No. Standard tire air pressure Load capacity (x2) Maximum mass(es) Tires (kg/cm2) (kg) (kg) 11.2-24 8PR 2.4 (240 KPa, 34 psi) 1940 (4277 lb) 5240(11552 lb) 16.9-30 8PR 1.6 (160 KPa, 23 psi) 3300 (7275 lb) 9.5-24 6PR 2.2 (220 KPa, 32 psi) 1500 (3307 lb)

  • Page 122: Adjusting Wheel Tracks And Tire Replacement

    (7) Adjusting wheel track and tire replacement  If the front wheel track is adjusted, check the FENDER clearance between tires and tractor body case by case. If necessary, the steering angle must be adjusted. (refer to the chapter 4-4-(9) “Adjusting steering angle”...
  • Page 123 ① Front wheel track – 9.5-24 6PR with rim & disk (W8x24) Unit : mm (inch) 1639(64.5in) 1493(58.8in) 1693(66.7in) (Standard track) 1549(61.0in) 1749(68.9in) 1603(63.1in) 1803(71.0in) 4 - 21...
  • Page 124 ② Front wheel track – 11.2-24 8PR with rim & disk (W10x24) Unit : mm (inch) 1665(65.6in) 1667(65.6in) 1774(69.8in) 1777(70.0in) 1577(62.1in) (Standard track) 4 - 22...
  • Page 125 ③ Rear wheel track – 14.9-30 8PR with rim & disk(W12x30) Unit : mm (inch) 1518(59.8in) 1624(63.9in) 1630(64.2in) 1736(68.3in) 1452(57.2in) (Standard track) 4 - 23...
  • Page 126 ④ Rear wheel track – 16.9-30 8PR with rim & disk(W15x30) Unit : mm (inch) 1526(60.1in) 1646(64.8in) 1726(68.0in) 1446(56.9in) 1846(72.7in) (Standard track) 4 - 24...

  • Page 127: Using Front-End Loader (Optional)

    (8) Using Front-end loader (if fitted) ① Safety precautions  If attaching a non-approved front-end loader or heavy front-mounted implement, engine block or front axle can be damaged or broken. Contact your authorized local dealer.  DO NOT attach any non-approved front- mounted implement by manufacturer.
  • Page 128 PRE-OPERATION CHECK, REAR BALLAST ! ▶ For tractor stability and operator’s safety, rear ballast should be added to the rear Caution of the tractor in the form of implements as counter weight like Back Hoe, Rotary Tiller, etc. The amount of rear ballast will be depend on the application. ②...
  • Page 129 ③ Attaching points for Front-end loader  When attaching the front-end loader, refer to the drawings as below. (Unit : mm) 4 - 27...

  • Page 130: Adjusting Steering Angle

    (9) Adjusting Steering Angle  If the front wheel track is adjusted or front tires are replaced with new tires having bigger diameter or width, or one of the front equipment is attached, the steering angle must be adjusted as below. 1) Loosen the locking nut on both sides.

  • Page 131: Recommended Maximum Specification Of Implements

    (10) Recommended maximum Specification of Implements  When attaching implements to the tractor, refer to the followings recommended as maximum specification of each implement. DO NOT attach bigger implements than this specification. For other implements, contact your authorized local dealer. MT563 MT568 MT573...

  • Page 132: Ballast Weights (Optional)

    (11) Ballast Weights (optional)  It is used to balance the front/rear weight of the tractor.  To remove the front ballast weights, unscrew the locking nut of the front ballast weights and disassemble the weight plate one by one. Locking nut Front ballast weight (kg) : 40kg x 4ea = 160kg or 40kg x 6ea = 240kg...

  • Page 133: Working In Hazardous Area

    4-5. Working in hazardous area  Level of protection against hazardous substances For cabin model, it provides protection against hazardous substances according to EN15695-1:2009 (Category 2). But it can provide only dust protection level by pressurizing air in the cabin with air filters. Do not use the tractor with crop sprayers in hazardous area.

  • Page 134: Driving Speed

    4-6. Driving speed  The driving speed of tractor or the revolution speed of PTO depends on the work and ground condition. For safety, operate the tractor at suitable speed.  Driving speed (unit: Km/h → Mile/h) - Standard ① Synchro-shuttle models (Global market) ...
  • Page 135  Driving speed (unit : Km/h -> Mile/h) ② Power shuttle models (optional, Global market)  Standard transmission (F12xR12) Main gear Range gear 1.83 2.46 3.30 4.26 4.99 6.72 9.01 11.63 13.83 18.61 24.96 32.21 (1.14) (1.53) (2.05) (2.65) (3.10) (4.18) (5.60) (7.23)

  • Page 136: Lubrication And Maintenance

    5. Lubrication and Maintenance 5-1. Access for maintenance ① Opening Hood  For safety, the hood must be closed and correctly latched before operating the tractor.  The hood is hinged at the rear and a gas cylinder is attached to provide easy access to the engine for check and maintenance.

  • Page 137: Maintenance Chart

    5-2. Maintenance chart  Periodic maintenance not only extends the service life of the tractor but also serves to ensure safe operation. The maintenance chart shows the standard service intervals. If you notice any abnormal symptoms, make sure to carry out the inspection and maintenance work, regardless of recommended service intervals in this maintenance chart.
  • Page 138 Check period (hr) Checking Parts Page No. 1000 1500 Daily 3000 or 1-yr or 2-yr ▲ ■ Fuel tank 5-8, 5-21 ■ ● Fuel filter 5-6, 5-24 ▲ ★ ● Engine oil 5-5, 5-7, 5-17 ★ ● Engine oil filter 5-5, 5-17 ▲...

  • Page 139: Lubricants And Capacity

    5-3. Lubricants and Capacity INTERNATIONAL RECOMMENDED LUBRICANTS CAPACITY STANDARD ITEMS 10 ℓ Engine coolant Soft water (50%)+ ASTM D5216 Anti-freeze (50%) (Radiator) (2.6U.S.gals) 100 ℓ Ultra low sulfur Fuel ASTM D975 No.2 (26.4U.S.gals) diesel fuel Engine oil 7.0 ℓ KIXX DL API CJ-4, ACEA E3 (Maker : GS Caltex) (1.8U.S.gals)

  • Page 140: First 50 Hour Check

    5-4. First 50 hour check  After using first 50 hours, contact your authorized dealer for maintenance if possible. - Replace engine oil & engine oil filter. (⇒ Refer to Every 300 hour check. See page 5-17) - Replace hydraulic oil filter. (⇒ Refer to Every 300 hour check. See page 5-18) - Replace power shuttle oil filter.

  • Page 141: When The Warning Indicator Lights

    5-5. When the warning indicator lights (1) Drain water from Fuel filter 1. Loosen the drain plug and drain water inside of Fuel pre-filter the filter. (Approx. 150cc(9.1 in³)) 2. Tighten the drain plug and bleed the air from the fuel filter.

  • Page 142: Check Before Starting (Daily Check)

    5-6. Check before starting (Daily check)  Before starting engine, check the followings carefully to avoid any failure or damage. Wheel bolts and Damage of Headlights, Engine coolant Transmission Brake, Clutch tightening of Turn signal lights, level pedal operation oil level each part Horn etc.

  • Page 143: Fuel Tank

    (2) Fuel tank ① Using Diesel fuel  Use Ultra low sulfur diesel, below 15 ppm. - ASTM D975-08a Grade 2 - EN590 : 2009 Diesel fuel Drum - BS2869 : 2006 Class A2 Impurities - You can use the Bio diesel fuel up to 7% (EN590 2009, ASTM D975) ...

  • Page 144: Engine Coolant

    (4) Turn signal lights, Lights, Horn  Check the operation status of light, turn signal lights, horn etc.  If the light is OFF despite of operation of switch of head light or indicating light, 1. Check the corresponding fuse in the fuse box. 2.

  • Page 145: Air Cleaner (Dry Type)

    (6) Air cleaner (Dry type) ① Cleaning filter element Filter element  If the air-cleaner service indicator in the instrument panel is turned on, make sure to check and/or clean the filter element regardless of recommended service intervals in this maintenance chart.

  • Page 146: Cleaning Of Radiator And Radiator Screen

    (7) Cleaning of Radiator and Radiator screen  Remove dust or dry grass stuck to the radiator or radiator screen on a daily basis.  To easy access, unscrew the knob on the right- hand side cover of the radiator and pull the radiator screen to the outside.

  • Page 147: Adjustment Of Clutch Pedal Play

    (9) Tightening state of bolts and nuts of each part  Check if the bolts or nuts of each part are loosened. If necessary, tighten it again as referring to the following table.  Especially, check the bolts and nuts of the tires before starting engine, if necessary, tighten them. ※...

  • Page 148: Adjustment Of Brake Pedal Play

     If you need more adjustment for clutch pedal play, check the oil level and bleed air from the clutch pedal oil line. (See page 5-32) ② Power shuttle (PSS)  In case of power shuttle models, an electric sensor to control the power shuttle clutch pack is attached and tuned specially on the clutch pedal linkage system.

  • Page 149: Every 50 Hour Check

    5-7. Every 50 hour check (1) Lubricating grease nipple  Steering cylinder pins (LH/RH)  Front axle holder & Steering arm (LH/RH)  3-point linkage Grease nipples Grease nipple (Both side) Grease nipple Grease nipple Grease nipple (2) Cleaning Radiator and Radiator screen ...

  • Page 150: Checking Transmission Oil

    (3) Checking Transmission oil  Stop the tractor on level surface and apply the parking brake and lower implements to the ground. Oil filling inlet  Clean around oil filling inlet and pull the gauge straight out.  Check If the oil level is between MIN and MAX Oil gauge mark of oil gauge.

  • Page 151: Battery Check

    (5) Battery check  Refer to “Batter handling and Notices” (See page 5-36) (6) Air cleaner (Dry type)  (See page 5-10 ) (7) Hydraulic hoses and Leakage  Stop the engine and place all the transmission gears in neutral and lower down the implement to the ground.

  • Page 152: Every 300 Hour Check

    5-8. Every 300 hour check (1) Replacing Engine oil and Filter ① Drain Engine oil  Run engine for a few minutes to warm oil.  Park the tractor on a level surface.  Remove both LH and RH drain plugs of oil pan Oil filling inlet and drain the oil completely.

  • Page 153: Replacing Hydraulic Oil Filter

    (2) Replacing Hydraulic Oil Filter  Park tractor on level surface and apply parking brake and lower implements and stop the engine.  Carefully clean around the filter and set a clean container under the filter.  Coat clean hydraulic oil on the packing of new filter and check the packing is placed well in the groove.

  • Page 154: Checking Brake Oil

    (4) Checking Brake oil  Open the Bonnet and check the brake oil level. If the oil level is between “MAX” and “MIN”, it means “Proper amount”. If necessary, add the brake oil.  Make sure to check the specification, before adding oil.

  • Page 155: Tension Adjustment Of Fan Belt

    (5) Tension adjustment of Fan belt  If the tension of fan belt exceeds the normal Adjusting plate Cooling water value, loosen the bolts and adjust the tension. pump pulley - Belt tension : crank shaft pulley ~ alternator pulley - Normal : approx.

  • Page 156: Cleaning Fuel Tank

    (8) Cleaning fuel tank  The contaminants like dusts, water and sediments in fuel tank shall cause to malfunction of the fuel injection system.  Clean fuel tank periodically.  The fuel tank is very heavy. Cooperate with other people to lift up/down the fuel tank after loosening nuts in the right figure.

  • Page 157: Every 500 Hour Check

    5-9. Every 500 hour check (1) Changing Front axle oil Air-breather Oil filling inlet & check port ① Center housing  Stop the tractor on a level surface and apply parking brake.  Clean air-breather and the surrounding area.  Set a container under the drain plug. ...

  • Page 158: Changing Transmission Oil

    (2) Changing Transmission oil  Stop tractor on a level surface and apply parking brake. Run engine for several minutes to warm Copper washer oil and lower implements and stop the engine.  Set container under drain plugs and remove the drain plugs under the transmission and drain oil completely.

  • Page 159: Replacing Fuel Filter Cartridge

    (3) Replacing Fuel filter cartridge ① Fuel pre-fuel filter  Loosen the drain plug and drain fuel in the filter. Body  Disconnect electric wire of the fuel filter sensor.  Remove element from the body.  Remove fuel filter sensor from the element and Element assemble it to the new element.

  • Page 160: Replacing Cabin Air Filters

    (4) Replacing Cabin air filters  Before servicing the filters, switch off the blower and close all cabin doors and windows.  Unscrew the bolts under the roof and remove Cabin the cover and filter element as shown in the right air filters figure.

  • Page 161: Every 1000Hr Or 1-Year Check

    5-10. Every 1000hr or 1-year check (1) Replacing Air cleaner element (Dry type)  If the air-cleaner service indicator in the Primary instrument panel is turned on, make sure to element check and/or replace the filter element regardless of recommended service intervals in this maintenance chart.

  • Page 162: Every 1500Hr Or 2-Year Check

    5-11. Every 1500hr or 2-year check (1) Replacing radiator coolant  After cooling down the engine enough, open the radiator cap slowly. Radiator cap  Set a clean container under radiator drainage cock. Warning ▶When opening the radiator cap, be careful of the escaping hot water or steam.

  • Page 163: Cleaning Emission Related Parts

    ※ Anti-freeze  The amount of anti-freeze in the coolant must be determined on the ambient temperature. If the amount of anti-freeze in the coolant is low, the coolant can be frozen and the engine and radiator may be damaged. ...

  • Page 164: Every 3000Hr Check

    5-12. Every 3000hr check (1) Cleaning Emission related parts  The following items are major engine emission DOC&DPF assembly related parts. These items are checked and cleaned periodically. But it is performed by special engine service experts. Contact your authorized local dealer for check. -.

  • Page 165: General Maintenance (When Required)

    5-13. General maintenance (When required) (1) Air-bleeding from Fuel system  The air in the fuel system may cause weak injection or the failure of engine start or stop. To prevent such failure, bleed the air from fuel system. Manual feed pump Fuel injection pipe Common Rail Fuel injection nozzle...
  • Page 166 ▶ If the foreign materials are stuck to the air bleed plug, it may prevent the air- Notice bleeding. In this case, unscrew the air bleed plug and remove foreign materials by blowing. ▶ Cover the bleeding fuel with a rag so that it does not flow to other components. ▶Do not throw the exhausted waste fuel to any place.

  • Page 167: Air-Bleeding From Brake Lines

    (2) Air-bleeding from brake lines 1. As the brake system of this tractor is separated into left and right brake, the air bleeding must be carried out separately. 2. Stop engine and apply parking brake. Open the bonnet and fill the brake oil tank with new oil sufficiently.

  • Page 168: Fuse & Main Fuse

    (4) Fuse & Main fuse ① Cabin fuse box Cabin fuse  Cabin fuse box is installed on the right cabin box cover filler.  How to replace the fuse 1. Remove the cover of fuse box. 2. Check each fuse and remove the damaged fuse. 3.
  • Page 169 ② Chassis fuse box  Chassis fuse box is installed under the front console cover.  How to replace the fuse Chassis fuse box cover 1. Remove the cover of fuse box. 2. Check each fuse and remove the damaged fuse. 3.
  • Page 170 ③ Main fuse  Main fuse is attached inside start motor cover in Cover the left side of the engine for protection the electrical circuit and components.  Disassemble the start motor cover.  Remove the fuse box cover, If necessary, replace it with a genuine part.

  • Page 171: Battery Handling And Notices

    ▶ Charge the battery in an area with good ventilation and DO NOT charge a frozen battery. ▶ Replace it with LS tractor genuine products or the battery with the same capacity. 5 - 36...
  • Page 172 ▶Replaced old battery must be disposed of in a suitable manner, according to the national legislation or local regulations. Contact your authorized dealer. ▶ Replace it with LS tractor genuine products or the battery with the same capacity. 5 - 37...
  • Page 173 ③ Notices in charging the battery using separate charger  As the battery fluid makes poisonous gas which can explode during the charging, comply with the following instructions. 1. Detach battery from the tractor. 2. Wait until the battery is warmed to room temperature.
  • Page 174 ④ How to use jumper cables ※ If the battery which is attached to the tractor is discharged and needs to connect a auxiliary battery, follow the instructions as below. ⓐ Connecting Jumper cables  Check followings before connecting the cables. Red cable - Is the spring of clamp normal? - Is the cable and clamp cut-off?

  • Page 175: Troubleshooting

    5-14. Troubleshooting ▶ To avoid injury due to sudden start, apply parking brake and place the Warning transmission gear in NEUTRAL position before checking and repairing. System Faults Possible causes Solutions ▲ Start safety switch is not ▲ Depress the clutch pedal contacted fully ▲...
  • Page 176 System Faults Possible causes Solutions ▲ Lack of engine coolant ▲ Supplement ▲ Bad fan belt tension or broken ▲ Adjust belt tension or Engine overheat replace ▲ Dirt attached to the radiator ▲ Clean ▲ Air cleaner clogged ▲ Wash element The color of exhausted ▲...
  • Page 177 System Faults Possible causes Solutions ▲ Wrong brake pedal play ▲ Adjust ▲ Lining worn or broken ▲ Replace Brake does not work or only one side works. ▲ Left/right pedal play is different ▲ Adjust ▲ Air in brake line ▲...
  • Page 178 System Faults Possible causes Solutions ▲ Repair or replace ▲ Pump worn or part damaged ▲ Repair or replace ▲ Steering unit damaged or worn Hydraulic steering ▲ Repair ▲ Oil leakage by steering system does not work. cylinder piston seal damaged or worn ▲...
  • Page 179 System Faults Possible causes Solutions ▲ Abnormal wiring ▲ Check the tightening state of terminal and ground ▲ Alternator failure ▲ Repair or replace Battery is not charge ▲ Lack of fan belt tension or ▲ Adjust fan belt tension or broken replace ▲...

  • Page 180: Air Conditioning System (Cabin Type)

    6. Air Conditioning System (Cabin type) 6-1. The name of each part of cooling and heating system Heater evaporator unit Heater hose Cut-off valve Cooler hose Condenser w/receiver drier Compressor ▶ Maintenance of the air conditioning system components (Compressor, Receiver drier, Condenser, Heater evaporator unit and connection parts) must be performed Caution in the designated dealer.

  • Page 181: How To Use Air Conditioner And Heater

    6-2. How to use Air conditioner and Heater (1) How to operate air conditioner and heater  Blower control switch - It is used to operate the air conditioner. If you turn the blower control switch to 1~4 position, the operation lamp shall be ON and the air conditioner begins to work.

  • Page 182: Every 6 Month Check

    6-3. Every 6 month check (1) Checking refrigerant amount  Check the refrigerant amount periodically. Have to contact your authorized local dealer for it. Refrigerant : R-134a, 850 ~ 900 g (30.0 ~ 31.7 oz)  The components of the air conditioning system have to be handled by authorized service expert. (2) Cleaning Condenser and Radiator screen ...

  • Page 183: Cleaning And Replacing Cabin Air Filters

    (5) Cleaning and replacing cabin air filters  Check, clean and replace the cabin air filters periodically after referring to the chapter 5 in this manual. Cabin air filters  See chapter 5-7, “Every 50 hour check”  See chapter 5-9, “Every 500 hour check” Filter cover Bolt...

  • Page 184: Using Cut-Off Valve (If Necessary)

    6-5. Using Cut-off valve (if necessary)  When disassembling the air-conditioner hose ① line, comply with the following instruction; ① Turn the plastic cap counter-clockwise and remove it. ② Turn the high-pressure line valve (lower side) clockwise and tighten it. ③...

  • Page 185: Troubleshooting

    6-6. Troubleshooting Failures Cause Actions Fan motor does not turn. Fuse blown. Check and replace. Wiring cut off and poor Repair the wiring or connection. connect right. Failure of fan motor. Replace. Resistor, relay and switch Replace. cut off. Fan motor is normal but the air Evaporator or heater core Remove the obstacles volume is small.
  • Page 186 Failures Cause Actions The compressor does not turn or Belt loosened. Adjust the belt tension. it is hard to revolve. Temperature switch or Check refrigerant pressure switch is “ON”. amount. Coil of magnet clutch was Contact the dealer. shorted or cut off. Compressor failure.

  • Page 187: System Diagram

    6-7. System diagram Heater evaporator Fan motor Expansion valve Evaporator core Heater core Control panel Engine Compressor Cut-off valve Radiator Condenser w/receiver drier Heater hose Cooler hose Electric line 6 - 8...
  • Page 188 7. Dimension and Specification ① Cabin type (Unit : mm) * When applying front tires: 11.2-24 8PR, rear tires: 16.9-30 8PR 7 - 1...
  • Page 189 MT563 MT568 MT573 Frame Type Cabin Type 2913kg (6422 lb) 2913kg (6422 lb) 2997kg (6607 lb) Bumper 42kg (92.6 lb) (optional) Front weight 40kg (88.2 lb) x 6 (optional) Model L4C25-T3A L4C25-T2A L4C25-T1A Type In-line vertical, Water cooled 4-cycle diesel, CRDI No.
  • Page 190 MT563 MT568 MT573 Type Independent rear PTO No. of speed 3 speed gears (optional) 1st : 540 rpm / 2237 rpm PTO / Engine 2nd : 750 rpm / 2471 rpm 3rd : 1000 rpm / 2318 rpm 3 Point linkage CAT.
  • Page 191 MT563 MT568 MT573 Rated output 12V, 70A Voltage control Built-in (IC type) Voltage Capacity 100Ah Output power 12V, 2.0kW Operation Solenoid Headlights 12V 55W / 60W (Lower / Upper) Turn signal lights / 12V 16W / LED Side lights(front) Turn signal lights 12V 21W (rear) Stop light / Taillight...
  • Page 192 Lubricants and Capacity INTERNATIONAL RECOMMENDED LUBRICANTS CAPACITY STANDARD ITEMS 10 ℓ Engine coolant Soft water (50%)+ ASTM D5216 Anti-freeze (50%) (Radiator) (2.6U.S.gals) 100 ℓ Ultra low sulfur Fuel ASTM D975 No.2 (26.4U.S.gals) diesel fuel Engine oil 7.0 ℓ KIXX DL API CJ-4, ACEA E3 (Maker : GS Caltex) (1.8U.S.gals)

This manual is also suitable for:

Mt563Mt568Mt573

Table of Contents

Save PDF
