Super Io Configuration; Power Management Setup - AMD 785G User Manual

Onboard PCIE Lan
Use this item to enable or disable Onboard PCIE Lan
HD Audio Azalia Device
This item allows you to decide to enable/disable the chipset family to support HD
Audio. The optional settings are: Auto; Enabled and Disabled.
USB Configuration
Press Enter to set values for sub-items as: Legacy USB Support, USB 2.0 Controller
Mode BIOS EHCI Hand-OFF and so on.
3-7-3

Super IO Configuration

CMOS Setup Utility-Copyright(C)1985-2005 American Megatrends. Inc.
Configure F71863 Super IO Chipset
Power On By Keyboard
Power On By Mouse
Onboard Floppy Controller
Serial Port 1 Address
Serial Port 2 Address
Serial Port 2 Mode
IR Duplex Mode
IRTX pin Select
IRRX Select
IR TX to RX Delay Select
IR RX to TX Delay Select
PWRON After PWR-Fail
↑↓ : Move
Enter: Select
F5: Discard Charges
Serial Port1 /2 Address
Use this item to select serial port address for serial port one.
Serial Port2 Mode
Allows BIOS to Select mode for Serial Port2.
IR Duplex Mode
This item allows BIOS to select full or half duplex for serial port 2 (IR Mode). The
optional settings are: Full Duplex; Half Duplex.
IrTX Pin Select
The optional settings are: Normal and Inverse.
This item allows BIOS to select transmit pin in a normal condition or inverse the
IRTX(IR Mode).
IrRX Pin Select
The optional settings are: Normal and Inverse.
This item allows BIOS to select receiver pin in normal condition or inverse the
IRRX(IR mode).
IRTX to RX Delay Select
The optional settings are: No Delay and Reception Delay.
This item allows BIOS to select IR from TX to RX 4 characters time delay for serial
port2(IR mode)
IRRX to TX Delay Select
The optional settings are: No Delay and Transmission Delay.
Super IO Configuration
Disabled
Disabled
Enabled
3F8/IRQ4
2F8/IRQ3
IrDA (1.6 US)
Half Deplex
Normal
Normal
No Delay
No Delay
Always OFF
+/-/: Value F10: Save
F6: Standard Defaults
27
Help Item
Allows BIOS to Enable or Disable
Floppy Controller
ESC: Exit F1: General Help
F7: Optimized Defaults
