Controls
Hold to flatten
bed for CPR
Head section
Bed height
Lockout switches
Control Buttons
Located at foot end of bed. Controls include individual lockout
functions as well as master lockout switch.
Locking out specific or all functions will disable affected functions
on both hand and foot control.
Expanding/Retracting Bed Deck
Lift handle to unlock while
pulling out or pushing in section
Battery Backup
This bed is equipped with an emergency battery backup that will
charge when plugged into an AC outlet.
Cardiac Chair
Foot section
Trend/ Reverse
Illuminated buttons
Expand/retract all sections on
both sides for 39"/42" and
48" widths
position
Trend
Master lockout
switch
