9. Power

9.2 Setting a Power Limit

Power draw of the fixture can be limited by setting a limit, in Watts. This can be set from 100W to 650W, in steps of 10W. The
brightness level of the unit will be limited to keep within the power limit set. Note the limit only applies when a DC input is
detected, and will apply even if AC source is also plugged in. Set the limit under MENU > Fixture Settings > Battery Power Limit.
This icon indicates the unit is being powered via a
battery source, and the power limit has been set
but not yet reached.
The icon will turn yellow if the power limit has
been exceeded. The unit will dim to keep within
the set power limit.
The table below shows power requirements when running at maximum brightness.
Battery Amp-Hour ratings should be chosen accordingly.
Part Number
CSV-8 Vortex8
Vortex8 User Manual
Wattage Current Draw @ 48V
650W 13.5A
Page 46 Version 1.2
