5. Controls

5.6.9 Strobe

Strobe effect with control over frequency, brightness & duty cycle.
SETTING
FREQUENCY
DUTY CYCLE

5.6.10 Random

Create a random pattern of flashes with control over frequency, length & variation.
SETTING
FREQUENCY
LENGTH
VARIATION

5.6.11 Dual Level

Set two different light levels and instantly switch between then using Flash button, DMX or external trigger signal.
SETTING
FLASH LEVEL
Vortex8 User Manual
RANGE DESCRIPTION
0.1-50Hz Frequency of strobe effect
0-100% The ratio between light OFF and ON times
RANGE DESCRIPTION
0.05-5.0Hz Frequency of random effect
2-200ms Maximum length of any flash
0-100% The amount of variation allowed from the effect
RANGE DESCRIPTION
0-100% Light output when FLASH button pressed on the control panel
