7. Camera Sync
7.2 Setting up Camera Syncing with Sync/Genlock Input using the Flashbandit
Use the Flashbandit (CS-SYNC) to setup cameras that requires a sync generator.
Set correct frame rate and format on the Lockit box
1
frame rate and format you intend to shoot at.
2
Plug the BNC-T adapter
Connect the camera GENLOCK input
3
instructions for setting this up.
4
Plug Flashbandit adapter
5
Plug the Creamsource Accessory adaptor
Connect the Flashbandit to the Lockit Box using coaxial cable – a blue light on Flashbandit should flash
6
indicating valid signal.
Once sync is established, a green bar will be highlighted on the top of the status bar of the Vortex8 indicating
7
the device is synchronised. The frame rate will also be displayed beneath the status bar.
8
Calibrate using the Flashbandit (see 7.5 Calibrate Sync for details).
Vortex8 User Manual
1
(see user manual for device). This should match the
2
into the SYNC/WORDCLOCK output of the Lockit box.
3 2
to the Lockit box
4
into the Creamsource Accessory adaptor.
5 into Accessories input of the Vortex8.
with the coaxial cable. Follow the camera
5
6
