5. Controls

5.6.14 Calibrate Sync

This is a special mode used for calibrating the light to an external sync source, such as the FlashBandit sync box. It is used to
make sure the camera shutter and Vortex8 are synchronised, to prevent the flash-banding effects when shooting on a CMOS
sensor camera or when using frame synchronised effects such as Flash Frames.
SETTING
SYNC PHASE
Ensure that you setup a camera sync signal that is connected to the Accessory port. See 7. Camera Sync for
a more detailed process of this setup.
Vortex8 User Manual
RANGE DESCRIPTION
0-360 Change the phase offset of the camera sync input. Adjust until the flashing light cannot be seen in the camera monitor.
Page 25 Version 1.2
