SpaceX
The Creamsource SpaceX is a 1200W, full colour (RGBWA) LED softlight fixture with continuous colour adjustment from 2200K up to 15000K,
including full control of Green/Magenta axis. Wireless DMX is built in using the LumenRadio system
Please take the time to read this manual before using your Creamsource Space X. This will give you a good understanding of the full
functionality and capabilities.
PART NUMBERS
The table below lists part numbers for the Creamsource Space X system
Part Number
Description
CSX-1200-C
Creamsource SpaceX Luminaire, 1200W with full colour
mixing. Power Supply is built into the unit
WARNINGS
High power LED light is emitted from this product. Do not stare directly into
the beam, permanent eye damage could result
Case can get hot during normal operation. Please take care when handling unit. Maximum Surface Temperature Tc = 70 deg C
Fixture has dangerous voltages inside. Do not open.
Falling hazard - make sure unit is properly secured and all three rigging chains are attached
If the external flexible cable of this luminaire is damaged, it must be replaced by an original cable from the manufacturer or
service agent.
COMPLIANCE NOTES
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
Please make sure discarded electrical waste is properly recycled to reduce environmental impact. Please use a separate collection facility or
contact the supplier from which this fixture was purchased
User Guide
N24018
Outsight Pty Ltd
6/888 Bourke St, Zetland, Sydney NSW 2017, AUSTRALIA
+61-2-9699 8688
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Creamsource SpaceX CSX-1200-C
Summary of Contents for Creamsource SpaceX CSX-1200-C
- Page 1 Green/Magenta axis. Wireless DMX is built in using the LumenRadio system Please take the time to read this manual before using your Creamsource Space X. This will give you a good understanding of the full functionality and capabilities.
- Page 2 CONTROLLING THE SPACE X There are four different ways of controlling the fixture, which are detailed below. On-board keypad and display Wired DMX Wireless DMX using inbuilt Lumen Radio system Wired remote dimmer control (sold separately) ON-BOARD KEYPAD AND DISPLAY All settings and configuration can be done using the on-board keypad and OLED display.
- Page 3 WIRED DMX CONTROL Standard 5 pin XLR connectors are located on the back of the unit. When a valid DMX signal is detected, the yellow DMX indicator LED will flash on the rear of the unit and the keypad controls for the light are disabled.
- Page 4 SILK SKIRT ATTACHEMENT Three spigots are provided for attachement a silk and/or black skirt to the underside of the unit. SPECIFICATIONS FOR FIXTURE Model Number CSX-1200-C Input 100-250V AC, 50-60Hz, Max 16A Maximum Ambient Temperature 40°C Cooling Variable Speed Low Noise Fans Weight 18kg Protection Class...
