5. Controls

5.1 Controlling the Vortex8

There are several different ways of controlling the fixture, which are detailed below.
1
On-board keypad
and display

5.2 On-board Keypad and Display

Vortex8 User Manual
2 3
Wired DMX
LCD display Navigation
with CreamOS buttons
Quick select Level shortcut
dock buttons button
4
Wireless DMX using inbuilt
Lumen Radio system
Ambient DMX quick Encoder nav
light sensor Access button wheel
EXT
Flash Button Power Button
(trigger effects) Turns the LED panel On and Off,
but leaves fixture powered on
Page 15
5
Wired remote dimmer sACN over ethernet
control (sold separately) connection
MENU takes you to the home screen and
back a screen while in a function
SELECT enters into the
active function
DMX and Wireless Quick Access Button
(HOLD to unlink Lumen Radio)
Version 1.2
