Page 13: About This Manual
Describes the panel details, how to operate, performance test, maintenance, and troubleshooting of the module to be installed on the MP1900A. MU196020A PAM4 PPG MU196040A PAM4 ED MU196040B PAM4 ED Operation Manual Describes the panel details, performance test, maintenance, and troubleshooting of the MU196020A, MU196040A, and MU196040B.
Page 14 Configuration of Signal Quality Analyzer-R Series Operation Manuals (Cont’d) indicates this document. MX190000A Signal Quality Analyzer-R Control Software Operation Manual Describes the operation of the software that controls the Signal Quality Analyzer-R Series. Extended Application Operation Manual Describes the operation of the extended application for the Signal Quality Analyzer-R Series.
Page 15: Table Of Contents
Table of Contents About This Manual..........I Chapter 1 Overview ........... 1-1 Product Overview ............1-2 Product Configuration ........... 1-4 Specifications .............. 1-10 Chapter 2 Before Use ........2-1 Installation to MP1900A ..........2-2 How to Operate Application .......... 2-2 Preventing Damage ............
Page 16 Chapter 7 Troubleshooting ....... 7-1 Problems That Occur When Replacing Modules ..7-2 Problems That Occur During Output Waveform Observation ..............7-3 Problems That Occur During Error Rate Measurement 7-4 Synchronization Failures ..........7-5 Appendix A Pseudo-Random Pattern ..... A-1 Appendix B List of Default Settings ....
Page 17 Overview This chapter describes the overview of the following modules. ● MU196020A PAM4 PPG (hereafter, MU196020A) ● MU196040A PAM4 ED (hereafter, MU196040A) ● MU196040B PAM4 ED (hereafter, MU196040B) Product Overview............1-2 Product Configuration ..........1-4 1.2.1 Standard configuration ........1-4 1.2.2 Options ............
Page 18: Chapter 1 Overview
Chapter 1 Overview 1.1 Product Overview The MU196020A, MU196040A, and MU196040B (hereinafter “MP1900A modules”) are plug-in modules that can be built into the MP1900A Signal Quality Analyzer-R. MP1900A supports error measurement with PRBS patterns, DATA patterns and various PAM4 test patterns at the following bit rates or baud rates: •...
Page 19 Product Overview • Long user-programmable patterns (256 Mbits, 256 Msymbol) • Capable of evaluating serial communication by selecting MU196040A- 001 that has one data input channel each for NRZ (32.1 Gbit/s) and PAM4 (32.1 Gbaud). • Having the input sensitivity (typical values) of NRZ 23 mV (32.1 Gbit/s, Eye Height) and PAM4 23 mV (32.1 Gbaud, Eye Height, per eye) and optimal for signal evaluation.
Page 20: Product Configuration
Chapter 1 Overview 1.2 Product Configuration 1.2.1 Standard configuration Table 1.2.1-1 and Table 1.2.1-2 below show the standard configurations of the three MP1900A modules respectively. Table 1.2.1-1 Standard Configuration of MU196020A Item Model Name Product Name Q'ty Remarks Mainframe MU196020A PAM4 PPG Accessories J1632A...
Page 21 Product Configuration Table 1.2.1-3 Standard Configuration of MU196040B Item Model Name Product Name Q'ty Remarks Mainframe MU196040B PAM4 ED Accessories V210 Terminator Data Input × 2 J1341A Open Ext Clock Input, AUX Input J1359A Coaxial Adaptor (K-P.K-J, SMA) Ext Clock Input J1632A Terminator Aux Output ×...
Page 22 This value is recognized by the MP1900A. Anritsu management number. This value is not recognized by the mainframe. 0: Factory-installed option 1: Retrofit option. (Must be returned to Anritsu (Japan) when installing.) 2: Retrofit option. (Must be returned to Anritsu Service and Sales office when installing.) 3: Software option.
Page 23 Product Configuration *4: It can be retrofitted when the Option 002 or y12 is installed. *5: x = 0, 1, or 2 *6: z = 0, 1, 2, or 3 *7: It can be retrofitted when the Option x11 is installed. *8: Options 040, 142, 140, 142, 240, and 242 work with version 3.01.07 and later of the MX190000A.
Page 24 Chapter 1 Overview *7: One of MU196040B-x21 and MU196040B-x22 can be installed. *8: MU196040B-002 or MU196040B-y12 must be installed. MU196040B-x21 or MU196040B-x22 must be installed. *9: MU196040B-x21 must be installed. *10: z = 0, 1, 2, or 3 *11: w = 0 or 3 1.2.3 Optional accessories Table 1.2.3-1 shows the optional accessories for the MP1900A modules.
Page 25 Product Configuration Table 1.2.3-1 Optional Accessories (Cont’d) Model Product Name Remarks Name J1748A Power Splitter (1.5G-18GHz) J1758A ISI Board J1789A Electrical Length Specified Coaxial Cable (0.4m, V connector) J1790A Electrical Length Specified Coaxial Cable (0.8m, V connector) J1792A Skew match pair semirigid cable For connecting to the Data (V-K connector, Data Input1) Input1 connector of MU195050A...
Page 26: Specifications
Chapter 1 Overview 1.3 Specifications 1.3.1 Specifications for MU196020A Table 1.3.1-1 Operating Baud/Bit Rate Item Specifications Operating Baud/Bit Rate When the Option 001 is installed. PAM4: 2.4 to 32.1 Gbaud NRZ: 2.4 to 32.1 Gbit/s When the Option 002 or y12 is installed. PAM4: 2.4 to 58.2 Gbaud NRZ: 2.4 to 58.2 Gbit/s When the Option 003, y13, or y23 is installed.
Page 27 Specifications Table 1.3.1-1 Operating Baud/Bit Rate (Cont'd) Item Specifications When linking with MU181500B and using external clock Clock Output Rate Full Relationship Rate Input Clock Between Baud Baud Rate Setting Range Frequency Rate and Input Clock Frequency 2.4 to 15.0 Gbaud* 2.4 to 15.0 GHz 1/1 Clock Input 15.0 to 30.0 Gbaud* 7.5 to 15.0 GHz 1/2 Clock Input...
Page 28 Chapter 1 Overview Table 1.3.1-1 Operating Baud/Bit Rate (Cont'd) Item Specifications External Clock When the Output Clock Relationship Rate is set to Full Rate Input Clock Between Baud Baud Rate Setting Range Frequency Rate and Input Clock Frequency 2.4 to 16.05 Gbaud* 2.4 to 16.05 GHz 1/1 Clock Input 16.05 to 32.1 Gbaud* 8.025 to 16.05 GHz 1/2 Clock Input...
Page 29 Specifications Table 1.3.1-2 Jitter Setting Range Item Specifications* SJ1 Setting Range When SJ2 switch is the built-in SJ2, the settable Jitter Amplitude is halved. SJ1 Clock Output Rate 30 < Baud rate ≤ 32.1 Gbaud, 15 < Baud rate ≤ 17 Gbaud At Full Rate 10000 1000...
Page 30 Chapter 1 Overview Table 1.3.1-2 Jitter Setting Range (Cont’d) Item Specifications* SJ1 Clock Output Rate 8.5 < Baud rate ≤ 15 Gbaud At Full Rate (Cont'd) 10000 1000 10k 100k 10M 100M1000M Modulation Frequency [Hz] Modulation Frequency (Hz) Jitter Amplitude (UIp-p) 10 to 100k 0 to 1000 100.1k to 1M...
Page 31 Specifications Table 1.3.1-2 Jitter Setting Range (Cont’d) Item Specifications* SJ1 Clock Output Rate 2.4 ≤ Baud rate ≤ 4 Gbaud At Full Rate (Cont'd) 10000 1000 100k 10M 100M 1000M Modulation Frequency [Hz] Modulation Frequency (Hz) Jitter Amplitude (UIp-p) 10 to 100k 0 to 500 100.1k to 1M 0 to 50...
Page 32 Chapter 1 Overview Table 1.3.1-2 Jitter Setting Range (Cont’d) Item Specifications* SJ1 Clock Output Rate 60 < Baud rate ≤ 64.2 Gbaud, At Half Rate, Quarter 30 < Baud rate ≤ 34 Gbaud, Rate 8 < Baud rate ≤ 17 Gbaud 10000 1000 100k...
Page 33 Specifications • Relationship between Baud Rate and Input Clock Frequency is set to 1/8 Clock Input with Clock Output Rate Half Rate and Quarter Rate in Table 1.3.1-1. Table 1.3.1-2 Jitter Setting Range (Cont’d) Item Specifications* SJ1 Clock Output Rate 2.4 <...
Page 34 Chapter 1 Overview Table 1.3.1-2 Jitter Setting Range (Cont’d) Item Specifications* SJ2 Setting Range The SJ2 via MU181000 Clock and the Built-in SJ2 can be set exclusively. SJ2 via MU181000 15.000 001 ≤ Baud rate ≤ 32.1 Gbaud Clock Output Rate At Full Rate 10k 100k 10M 100M1000M...
Page 35 Specifications Table 1.3.1-2 Jitter Setting Range (Cont’d) Item Specifications* SJ2 via MU181000 3.200 001 ≤ Baud rate ≤ 6.25 Gbaud Clock Output Rate At Full Rate (Cont'd) 10k 100k 10M 100M1000M Modulation Frequency [Hz] Modulation Frequency (Hz) Jitter Amplitude (UIp-p) 10 to 1M 0 to 20 1.001M to 10M...
Page 36 Chapter 1 Overview Table 1.3.1-2 Jitter Setting Range (Cont’d) Item Specifications* SJ2 via MU181000 60.000 001 ≤ Baud rate ≤ 64.2 Gbaud Clock Output Rate At Half Rate, Quarter Rate 100k 10M 100M 1000M Modulation Frequency [Hz] Modulation Frequency (Hz) Jitter Amplitude (UIp-p) 10 to 1M 0 to 50...
Page 37 Specifications Table 1.3.1-2 Jitter Setting Range (Cont’d) Item Specifications* SJ2 via MU181000 12.800001 ≤ Baud rate ≤ 30.0 Gbaud Clock Output Rate At Half Rate, Quarter Rate (Cont'd) 10k 100k 10M 100M 1000M Modulation Frequency [Hz] Modulation Frequency (Hz) Jitter Amplitude (UIp-p) 10 to 1M 0 to 50 1.001M to 10M...
Page 38 Chapter 1 Overview Table 1.3.1-2 Jitter Setting Range (Cont’d) Item Specifications* SJ2 via MU181000 3.600001 ≤ Baud rate ≤ 6.25 Gbaud Clock Output Rate At Half Rate, Quarter Rate (Cont'd) 10k 100k 10M 100M 1000M Modulation Frequency [Hz] Modulation Frequency (Hz) Jitter Amplitude (UIp-p) 10 to 1M 0 to 25...
Page 39 Specifications Table 1.3.1-2 Jitter Setting Range (Cont’d) Item Specifications* SJ2 via MU181000 2.4 ≤ Baud rate ≤ 3.125 Gbaud Clock Output Rate At Half Rate, Quarter Rate (Cont'd) 100k 10M 100M 1000M Modulation Frequency [Hz] Modulation Frequency (Hz) Jitter Amplitude (UIp-p) 10 to 1M 0 to 12.4 1.001M to 10M...
Page 40 Chapter 1 Overview Table 1.3.1-2 Jitter Setting Range (Cont’d) Item Specifications* Built-in SJ2 Clock 15 < Baud rate ≤ 32.1 Gbaud Output Rate Modulation Frequency (Hz) Jitter Amplitude (UIp-p) At Full Rate 0 to 1000 0 to 0.5 100M 0 to 0.5 210M 0 to 0.2 4 <...
Page 41 Specifications Table 1.3.1-3 External Clock Input Item Specifications Number of Inputs 1 (Single-Ended) Input frequency range 1.2 to 16.05 GHz Input amplitude 0.3 to 1.0 Vp-p (–6.5 to +4.0 dBm) Termination 50 Ω, AC Coupling Connector SMA connector (f.) Table 1.3.1-4 Aux Input Item Specifications Number of Inputs...
Page 42 Chapter 1 Overview Table 1.3.1-6 Gating Output Item Specifications Number of Outputs 1 (Single-Ended) Output control ON/OFF switching Variation Burst, Repeat Burst Burst Output Burst Trigger Delay 0 to (Burst Cycle – 256) bits, 8 bits step Enable Pulse Width 16 to (Burst Cycle –...
Page 43 Specifications Table 1.3.1-7 Generated Pattern (Cont’d) Item Specifications Zero-Substitution This is available in NRZ mode only. Additional bit 0 bit, 1 bit Pattern Length (n = 7, 9, 10, 11, 15, 20, 23) –1 (n = 7, 9, 10, 11, 15, 20, 23) Start position Bit after the longest run of zero bits Length of Consecutive...
Page 44 Chapter 1 Overview Table 1.3.1-8 Pattern Sequence Item Specifications Sequence Repeat, Burst Repeat Continuous Pattern Burst This is available only when Coding is NRZ. Source Internal, External-Trigger (Aux Input), External-Enable (Aux Input) Data Sequence Restart, Consecutive, Continuous Enable period Internal: 12 800 to 2 147 483 136 bits, 256 bits step External-Trigger, External-Enable: 12 800 to 2 147 483 648 bits, 256 bits step...
Page 45 Specifications Table 1.3.1-10 Error Addition (Cont’d) Item Specifications RS-FEC Symbol Error This is available whether Coding is NRZ or PAM4.* When Coding is PAM4, an error is inserted to make the PAM4 signal change by one level only. NRZ: An error is inserted every 10 bits. PAM4: An error is inserted every 10 or 20 PAM4 symbols.
Page 46 Chapter 1 Overview Table 1.3.1-10 Error Addition (Cont’d) Item Specifications RS-FEC Symbol Error (Cont’d) Error Addition Method Type1: Level 0 Level 1, Level 1 Level 2, Level 2 Level 3, Level 3 Level 2 Type2: Level 0 Level 1, Level 1 Level 2, Level 2 Level 1, Level 3...
Page 47 Specifications Table 1.3.1-10 Error Addition (Cont’d) Item Specifications Error on MSB Adds the specified symbol error. This is available only when Coding is PAM4. The set error is added to MSB only. Source Internal, External-Trigger (Rise edge trigger), External-Disable (L: Disable) Error Variation Repeat, Single (Cannot be selected when Source is External-Trigger.) Symbol Error Rate...
Page 48 Chapter 1 Overview Table 1.3.1-10 Error Addition (Cont’d) Item Specifications Error on LSB&MSB Adds the specified symbol error. This is available only when Coding is PAM4. An error is inserted to make the PAM4 signal change by one level only. Source Internal, External-Trigger (Rise edge trigger), External-Disable (L: Disable)
Page 49 Specifications Table 1.3.1-11 Data Output Item Specifications* Number of Outputs 2 (Data, XData) Cannot be varied independently Waveform NRZ, PAM4 NRZ Eye Amplitude Setting Range NRZ: 70 to 800 mVp-p, 2 mV step (Single-Ended) Accuracy When using the J1789A: ±35 mV ±12% (Single-Ended)* When using the J1790A: ±35 mV ±12% (Single-Ended)* PAM4 Eye Amplitude PAM4 (0/3 Level)
Page 50 Chapter 1 Overview *4: Setting Range ≤ 600 mVp-p (≤ 58.2 Gbit/s, when the Options 002, y12, 003, y13 and y23 are installed *5: Setting Range ≤ 550 mVp-p (≤ 64.2 Gbit/s, when the Options 003, y13 and y23 are installed) *6: When PAM4 output signal is directly input to the ED, the lower limit for the error-free amplitude depends on the performance of the ED used.
Page 51 Specifications Table 1.3.1-11 Data Output (Cont'd) Item Specifications* Half Period Jitter Setting Range –20.0 to +20.0, 0.1 step Accuracy Typ. ±0.04 UI* Jitter Measurement NRZ, conditions Bit rate 32.1 Gbit/s (When the Option 001 is installed), 58.2 Gbit/s (When the Options 002 and y12 are installed), 64.2 Gbit/s (When the Options 003, y13 and y23 are installed) Eye Amplitude 0.5 Vp-p (Single-Ended) At a constant temperature between 20 and 30°C, measure with a 70-...
Page 52 Chapter 1 Overview installed), 1.0 Vp-p (Differential), refer to the IEEE P802.3bs for equation to calculate. *18: PAM4, 26.5625 Gbaud (When the Option 001 is installed), 53.125 Gbaud (When the Options 002, y12, 003, y13 and y23 are installed), 1.0 Vp-p (Differential), refer to the IEEE P802.3cd for equation to calculate.
Page 53 Specifications Table 1.3.1-11 Data Output (Cont'd) Item Specifications* Channel Emulator* Normal: Outputs the PPG Data signal whose waveform emulates the connected transmission line with the loaded S parameter. Inverse: Outputs the PPG Data signal whose inverse characteristics emulate the transmission line with the loaded S parameter. Response Normal, Inverse S-Parameter file...
Page 54 Chapter 1 Overview *22: It is assumed to use for the purpose of compensating the loss of the transmission line. The following graph shows typical limits for adjustable insertion loss. However, it does not mean that all the responses emulated from the S-Parameter file are compensated as the graph shows.
Page 55 Specifications Table 1.3.1-12 Clock Output Item Specifications* Frequency Full Rate Operation Baud Rate = Clock Output Frequency 2.4 to 32.1 GHz (Option 001) Half Rate Operation Baud Rate = (Clock Output Frequency) × 2 1.2 to 16.05 GHz (Option 001) 1.2 to 29.1 GHz (When the Options 002 and y12 are installed) 1.2 to 32.1 GHz (When the Options 003, y13 and y23 are installed) Quarter Rate...
Page 56 Chapter 1 Overview Table 1.3.1-14 Jitter Tolerance Item Specifications Jitter tolerance For NRZ output, Bit rate: 32.1 Gbit/s (Option 001) 58.2 Gbit/s (When the Options 002 and y12 are installed) 64.2 Gbit/s (When the Options 003, y13 and y23 are installed) Pattern: PRBS2...
Page 57 Specifications Table 1.3.1-14 Jitter Tolerance (Cont’d) Item Specifications Jitter tolerance 58.2 Gbit/s, 64.2 Gbit/s (Cont’d) 10000 Max. modulation amplitude Specification 1000 100k 100M 1000M Modulation Frequency [Hz] Modulation Max. modulation Specification frequency [Hz] amplitude [UIp-p] [UIp-p] 2 000 1 000 7 500 2 000 1 000...
Page 58 Chapter 1 Overview Table 1.3.1-15 Multichannel Operation* Item Specifications Multi-Module A function to synchronize timing of generating patterns among Synchronization multiple modules *2, *3, *4, *5, *6 Baud Rate ≤ 32.1 Gbaud: Capable of synchronizing bit generation timing with an accuracy of less than 1 UI Baud Rate >...
Page 59 Specifications Table 1.3.1-15 Multichannel Operation* (Cont’d) Item Specifications Output Only the items to be changed when Multi-Module Synchronization is set are described. Phase setting range –64 000 to +64 000 mUI* Phase setting resolution 2 mUI* Pattern Data length When CH Combination is set: 4 to 536,870,912 bits, 2 bits step When CH Synchronization is set: same as Sync OFF...
Page 60 Chapter 1 Overview Table 1.3.1-16 General Item Specifications Dimensions 21 mm (H), 234 mm (W), 175 mm (D) Excluding protrusions Mass 2.5 kg max. Operating Temperature 15 to 30°C MP1900A’s ambient temperature. MU196020A shall operate when installed. Storage Temperature –20 to 60°C MU196020A installed to MP1900A shall comply with MIL-T-28800E Class 5.
Page 61 Specifications 1.3.2 Specifications for MU196040A Table 1.3.2-1 Operating Baud Rate Item Specifications Operating Baud Rate When the Option 001 is installed. PAM4 input: 2.4 to 32.1 Gbaud NRZ input: 2.4 to 32.1 Gbit/s Table 1.3.2-2 System Clock Item Specifications System Clock External, Recovered Clock (When the Option 022 is installed) External: Clock input from the Ext Clock Input connector...
Page 62 Chapter 1 Overview Table 1.3.2-3 Data Input Item Specifications Number of inputs 2 (Data, XData) (Differential) Input Condition Single-Ended, Differential 50 Ohm, Differential 100 Ohm When set to Differential 50 Ohm or Differential 100 Ohm: Independent, Tracking, Alternate* When set to Alternate: Data-XData, XData-Data* When set to Single-Ended: Data, XData*...
Page 63 Specifications Table 1.3.2-3 Data Input (Cont’d) Item Specifications Sensitivity Single-Ended , Mark Ratio1/2, when connecting directly to the MU196020A with J1789A. When the Option-001 is installed, 34VKF50 shall be included. At a constant temperature between 20 and 30°C Eye Amplitude NRZ, PRBS31 Typ.
Page 64 Chapter 1 Overview Table 1.3.2-3 Data Input (Cont’d) Item Specifications Stressed Margin* Stressed Eye Height PAM4 0/1 1/2 2/3 Level, QPRBS13-CEI, Eye Height where BER is 1E– 06, when using External Clock ≥ 32 mV* Stressed Eye Width PAM4 0/1 1/2 2/3 Level, QPRBS13-CEI, Eye Width where BER is 1E–06, when using External Clock ≥...
Page 65 Specifications Table 1.3.2-4 Clock Input Item Specifications External Clock Input Operation Baud Rate = Clock Input Frequency (When the Option 001 is installed) Number of inputs 1 (Single-Ended) Frequency range When the Option 001 is installed: 2.4 to 32.1 GHz Amplitude 0.3 to 1.0 Vp-p (–6.5 to +4.0 dBm) (Input Frequency ≤...
Page 66 Chapter 1 Overview Table 1.3.2-7 Pattern Detection Item Specifications PRBS Pattern length –1 (n = 7, 9, 10, 11, 13, 15, 20, 23, 31) Mark ratio 1/2, 1/2inv PRBS generator n=7: 1 + X polynomial n=9: 1 + X n=10: 1 + X n=11: 1 + X...
Page 67 Specifications Table 1.3.2-8 Pattern Sequence Item Specifications Sequence Repeat, Burst Repeat Continuous Pattern Burst This is available only when Coding is NRZ. Source Internal, External-Enable (Aux Input), External-Trigger (Aux Input) Delay Internal: 0 to 2 147 483 640 bits, 8 bits step External-Trigger, External-Enable: 0 to 2 147 483 520 bits, 8 bits step Adjust Method:...
Page 68 Chapter 1 Overview Table 1.3.2-9 Measurement Item Specifications Counter Error Rate (ER) Total: 0.000 1E–18 to 1.000 0E00 Error Count (EC) Total: 0 to 9 999 999, 1.000 0E07 to 9.999 9E17 Error Interval: 0 to 9 999 999, 1.000 0E07 to 9.999 9E17 %Error Free Interval: 0.000 0 to 100.000 0 Error Rate (ER) Insertion (INS):...
Page 69 Specifications Table 1.3.2-9 Measurement (Cont’d) Item Specifications Counter (Cont’d) The following are available when the Option x41 SER Measurement is installed. The following are available only for PAM4 (Diagnostics Mode OFF) measurement. Symbol Error Rate (SER): 0.000 1E–18 to 1.000 0E00 Symbol Error Count (SEC): 0 to 9 999 999, 1.000 0E07 to 9.999 9E17 Symbol Error Interval: 0 to 9 999 999, 1.000 0E07 to 9.999 9E17...
Page 70 Chapter 1 Overview Table 1.3.2-9 Measurement (Cont’d) Item Specifications Counter (Cont’d) Level 2 3 EC: 0 to 9 999 999, 1.000 0E07 to 9.999 9E17 Level 2 1 EC: 0 to 9 999 999, 1.000 0E07 to 9.999 9E17 Level 2 0 EC: 0 to 9 999 999, 1.000 0E07 to 9.999 9E17 Level 2...
Page 71 Specifications Table 1.3.2-10 Error Analysis Item Specifications Block Window Excludes the specified data pattern from measurement. Setting resolution Pattern length (bits) Step (bits) 2 to 2 097 152 2 097 153 to 4 194 304 4 194 305 to 8 388 608 8 388 609 to 16 777 216 16 777 217 to 33 554 432 33 554 433 to 67 108 864...
Page 72 Chapter 1 Overview Table 1.3.2-13 Jitter Tolerance Item Specifications Jitter tolerance For NRZ output Bit rate: 32.1 Gbit/s Pattern: PRBS2 –1 With MU181500B, SSC with frequency of 33 kHz and deviation of 5300 ppm can be applied simultaneously with RJ with amplitude of 0.3 UI. These specifications are defined assuming the following conditions: Loopback connection to the MU196020A, at a constant temperature between 20 and 30°C.
Page 73 Specifications Table 1.3.2-14 Clock Recovery Item Specifications* Operating bit rate NRZ: 25.5 to 32.1 Gbit/s PAM4: 25.5 to 32.1 Gbaud Setting range 25.500 000 to 32.100 000 Gbaud, 0.000 001 Gbaud step Supported standard For NRZ mode and baud rate Standard Bit Rate [Gbit/s] Remarks...
Page 74 Chapter 1 Overview Table 1.3.2-14 Clock Recovery (Cont’d) Item Specifications Jitter Tolerance At the bit rate of 28.05 Gbaud, conforming to Jitter Tolerance Mask defined by the “32G FC standard”. The following masks are taken as Clock Recovery* typical values: 0.01 10k 100k 1M 10M 100M1000M...
Page 75 Specifications *5: Typical value, specified at a constant temperature between 20 and 30°C. Table 1.3.2-15 Mechanical Performance Item Specifications Dimensions 21 mm (H), 234 mm (W), 175 mm (D), Excluding protrusions Mass 2.5 kg max. Operating temperature 15 to 30°C MP1900A’s ambient temperature.
Page 76 Chapter 1 Overview 1.3.3 Specifications for MU196040B Table 1.3.3-1 Operating Baud Rate Item Specifications Operating Baud Rate When the Option 001 is installed. PAM4 input: 2.4 to 32.1 Gbaud NRZ input: 2.4 to 32.1 Gbit/s When the Option 002 or y12 is installed. PAM4 input: 2.4 to 58.2 Gbaud NRZ input: 2.4 to 64.2 Gbit/s Table 1.3.3-2 System Clock...
Page 77 Specifications Table 1.3.3-3 Data Input Item Specifications Number of inputs 2 (Data, XData) (Differential) Input Condition Single-Ended, Differential 50 Ohm, Differential 100 Ohm When set to Differential 50 Ohm or Differential 100 Ohm: Independent, Tracking, Alternate* When set to Alternate: Data-XData, XData-Data* When set to Single-Ended: Data, XData*...
Page 78 Chapter 1 Overview *6: Bit rate >32.1 Gbit/s *7: 0/3 Level, PRBS31, Mark Ratio1/2, with connected to the MU196020A using an attenuator, with Emphasis adjusted so that the Eye Height meets the specification MP1900A Data Output MU196020A Data Input MU196040B Example of waveform input to MU196040B when baud rate is 32.1 Gbaud 0.3 to 1.0 Vp-p...
Page 79 Specifications Table 1.3.3-3 Data Input (Cont’d) Item Specifications Sensitivity Single-Ended , Mark Ratio1/2, PRBS31, when connecting directly to the MU196020A using J1789A and an attenuator, Emphasis ON, unused connectors on the MU196020A and MU196040B are terminated, At a constant temperature between 20 and 30°C Eye Amplitude Typ.
Page 80 Chapter 1 Overview Table 1.3.3-3 Data Input (Cont’d) Item Specifications Stressed Margin Stressed Eye Height PAM4 0/1 1/2 2/3 Level, QPRBS13-CEI, Eye Height where BER is 1E– 06, when using External Clock ≥ 32 mV* ≥ 37 mV* Stressed Eye Width PAM4 0/1 1/2 2/3 Level, QPRBS13-CEI, Eye Width where BER is 1E–06, when using External Clock ≥...
Page 81 Specifications MP1900A Data Output J1789A 40 cm V Cable MU196020A Data Input J1800A MU196040B ISI Board J1789A 40 cm V Cable At a constant temperature between 20 and 30°C, measure with a 70- GHz bandwidth sampling oscilloscope with residual jitter of less than 200 fs (RMS).
Page 82 Chapter 1 Overview *19: When the Option x11 is installed. *20: 53.125 Gbaud, Calculated from the following three: ● The BER result obtained when DFE is OFF under the condition of *18. ● The BER result obtained when DFE is OFF under the condition of *18 and 1.8 dB additional loss.
Page 83 Specifications Table 1.3.3-7 Pattern Detection Item Specifications PRBS Pattern length –1 (n = 7, 9, 10, 11, 13, 15, 20, 23, 31) Mark ratio 1/2, 1/2inv PRBS generator n=7: 1 + X polynomial n=9: 1 + X n=10: 1 + X n=11: 1 + X n=13:...
Page 84 Chapter 1 Overview Table 1.3.3-7 Pattern Detection (Cont’d) Item Specifications Coding NRZ, PAM4 Normal, Invert PAM4 Gray Coding ON, OFF* PAM4 Precoding ON, OFF* (1/(1 + D) mod 4)* PAM4 Inverse Gray Coder ON, OFF* PAM4 Pre Code ON, OFF* Remover* Input Signal Decoder ON, OFF...
Page 85 Specifications Table 1.3.3-7 Pattern Detection (Cont’d) Item Specifications PAM4 Standard Pattern Standard-compliant PAM4-mode patterns QPRBS13-CEI, QPRBS31-CEI IEEE IEEE802.3bs/cd: PRBS13Q, PRBS31Q, SSPRQ, Square Wave IEEE802.3bj: QPRBS13, JP03A, JP03B, Transmitter Linearity InfiniBand PRBS13Q (InfiniBand), PRBS23Q, PRBS31Q (InfiniBand) Fibre Channel PRBS31Q (Fibre Channel) RS-FEC RS-FEC Scrambled Idle 50G 1Lane* RS FEC Scrambled Idle 100G 1Lane*...
Page 86 Chapter 1 Overview Table 1.3.3-9 Measurement Item Specifications Counter Error Rate (ER) Total: 0.000 1E–18 to 1.000 0E00 Error Count (EC) Total: 0 to 9 999 999, 1.000 0E07 to 9.999 9E17 Error Interval: 0 to 9 999 999, 1.000 0E07 to 9.999 9E17 %Error Free Interval: 0.000 0 to 100.000 0 Error Rate (ER) Insertion (INS):...
Page 87 Specifications Table 1.3.3-9 Measurement (Cont’d) Item Specifications Counter (Cont’d) MSB Error Rate (ER) Total: 0.000 1E–18 to 1.000 0E00 MSB Error Count (EC) Total: 0 to 9 999 999, 1.000 0E07 to 9.999 9E17 MSB Error Interval* 0 to 9 999 999, 1.000 0E07 to 9.999 9E17 MSB %Error Free Interval* : 0.000 0 to 100.000 0 MSB Error Rate (ER) Insertion (INS):...
Page 88 Chapter 1 Overview Table 1.3.3-9 Measurement (Cont’d) Item Specifications Counter (Cont’d) The following are available when the Option z41 SER Measurement is installed. The following are available only for PAM4 (Diagnostics Mode OFF) measurement. Symbol Error Rate (SER): 0.000 1E–18 to 1.000 0E00 Symbol Error Count (SEC): 0 to 9 999 999, 1.000 0E07 to 9.999 9E17 Symbol Error Interval: 0 to 9 999 999, 1.000 0E07 to 9.999 9E17...
Page 89 Specifications Table 1.3.3-9 Measurement (Cont’d) Item Specifications Counter (Cont’d) Level 2 3 EC: 0 to 9 999 999, 1.000 0E07 to 9.999 9E17 Level 2 1 EC: 0 to 9 999 999, 1.000 0E07 to 9.999 9E17 Level 2 0 EC: 0 to 9 999 999, 1.000 0E07 to 9.999 9E17 Level 2 EC Total: 0 to 9 999 999, 1.000 0E07 to 9.999 9E17...
Page 90 Chapter 1 Overview Table 1.3.3-9 Measurement (Cont’d) Item Specifications Counter (Cont’d) The following items are available only when the Option w42 FEC Analysis is installed. Uncorrectable Codeword Error Rate (UCWER): 0.000 1E–18 to 1.000 0E00 Uncorrectable Codeword Error Count (UCWEC): 0 to 9 999 999, 1.000 0E07 to 9.999 9E17 Uncorrectable Codeword Error Interval: 0 to 9 999 999, 1.000 0E07 to 9.999 9E17...
Page 91 Specifications Table 1.3.3-9 Measurement (Cont’d) Item Specifications Input Signal Decoder Displays the coding status during PAM4 mode error measurement. Indicator Raw Signal: Displays error measurement results of input data without decoding it. Decoded Signal: Displays error measurement results of decoded input data.
Page 92 Chapter 1 Overview Table 1.3.3-10 Error Analysis Item Specifications Bit Mask (Block Window) Excludes the specified data pattern from measurement.* Setting resolution The resolution is set depending on the pattern length as follows: Pattern length (bits) Setting resolution (bits) 2 to 2 097 152 2 097 153 to 4 194 304 4 194 305 to 8 388 608 8 388 609 to 16 777 216...
Page 93 Specifications Table 1.3.3-10 Error Analysis (Cont’d) Item Specifications Capture (Cont’d) Auto Launch Select the result screen you want to display automatically when data is captured. ● Capture Data Displays the captured pattern data numerically or by a string (Bin, Hex, Symbol). ●...
Page 94 Chapter 1 Overview Table 1.3.3-10 Error Analysis (Cont’d) Item Specifications Capture (Cont’d) FEC Symbol Capture Setting Preset For NRZ: Variable,RS-FEC 25G 1Lane, RS-FEC 50G 2Lanes RS(544, 514), RS-FEC 100G 4Lanes, RS-FEC 100G 4Lanes RS(544, 514) For PAM4: Variable, RS-FEC 50G 1Lane, RS-FEC 100G 1Lane, RS-FEC-Int 100G 1Lane, RS-FEC 100G 2Lanes, RS-FEC 200G 2Lanes, RS-FEC 200G 4Lanes, RS-FEC 400G 4Lanes, RS-FEC 400G 8Lanes...
Page 95 Specifications Table 1.3.3-10 Error Analysis (Cont’d) Item Specifications Capture (Cont’d) Capture Result Capture Data Displays captured results by bit or symbol sequence in NRZ or PAM4 mode. When Capture Mode is Sync Mode Capture or FEC Symbol Capture, error bits and symbols are displayed with background color. Viewer Mode Sets the view mode of the captured result pattern.
Page 96 Chapter 1 Overview Table 1.3.3-10 Error Analysis (Cont’d) Item Specifications Capture (Cont’d) File Save Saves the captured results and pattern to a file. NRZ: BIN/HEX Text: Captured result file (It can be opened in the Capture Data screen.) BIN/HEX Text(export): Pattern file including error information (It can be opened in Pattern Editor.) PAM4: Symbol Text:...
Page 97 Specifications Table 1.3.3-11 Auto Measurement Item Specifications Bath-Tub NRZ/PAM4: Available* Eye Contour NRZ/PAM4: Available* Auto Adjust NRZ: Vth direction only* PAM4: MSB Vth direction only* Auto Search NRZ: Available* PAM4 (LSB/MSB Diagnostics OFF/ON): Available* Advanced Search Supports adjustment of PRBS Inv, Logic (MSB, LSB), Gray Coder, Inverse Gray Coder, Eye Threshold (Middle, Upper, Lower), Delay, DFE and LFEQ.* NRZ:...
Page 98 Chapter 1 Overview Table 1.3.3-12 Variable Clock Delay Item Specifications Phase variable range –1000 to +1000 mUI, 2 mUI step Accuracy ±50 mUIp-p* (Baud rate ≤32.1 Gbaud) ±100 mUIp-p* (Baud rate >32.1 Gbaud) mUI – ps switching Available (internally converted into ps) Calibration Available (when jitter modulation is off) Calibration indicator...
Page 99 Specifications Table 1.3.3-13 Jitter Tolerance Item Specifications For NRZ input Bit rate: 32.1 Gbit/s, 64.2 Gbit/s* Pattern: PRBS2 –1 32.1 Gbits: With MU181500B, SSC with frequency of 33 kHz and deviation of 5300 ppm can be applied simultaneously with RJ with amplitude of 0.3 UI. 64.2 Gbits: With MU181500B, SSC with frequency of 33 kHz and deviation of 3300 ppm can be applied simultaneously...
Page 100 Chapter 1 Overview Table 1.3.3-13 Jitter Tolerance (Cont’d) Item Specifications For NRZ input (Cont’d) 64.2 Gbit/s 10000 Max. modulation amplitude Specification 1000 100k 100M 1000M Modulation Frequency [Hz] Modulation Max. modulation Specification frequency [Hz] amplitude [UIp-p] [UIp-p] 2 000 1 000 7 500 2 000 1 000...
Page 101 Specifications Table 1.3.3-13 Jitter Tolerance (Cont’d) Item Specifications For PAM4 input Baud rate: 32.1 Gbaud* , 58.2 Gbaud* Pattern: PRBS31Q 32.1 Gbaud: With MU181500B, SSC with frequency of 33 kHz and deviation of 5300 ppm can be applied simultaneously with RJ with amplitude of 0.3 UI. 58.2 Gbaud: With MU181500B, SSC with frequency of 33 kHz and deviation of 3300 ppm can be applied simultaneously...
Page 102 Chapter 1 Overview Table 1.3.3-13 Jitter Tolerance (Cont’d) Item Specifications For PAM4 input (Cont’d) 58.2 Gbaud 10000 Max. modulation amplitude Specification 1000 100k 100M 1000M Modulation Frequency [Hz] Modulation Max. modulation Specification frequency [Hz] amplitude [UIp-p] [UIp-p] 2 000 1 000 7 500 2 000 1 000...
Page 103 Specifications Table 1.3.3-14 Clock Recovery Item Specifications* Operating Baud rate When the Option x21 is installed. NRZ: 2.4 to 29.0 Gbit/s PAM4: 2.4 to 29.0 Gbaud When the Option x22, or x21 + y24 is installed. NRZ: 2.4 to 32.1 Gbit/s PAM4: 2.4 to 32.1 Gbaud When the Option x23 is installed.
Page 104 Chapter 1 Overview Table 1.3.3-14 Clock Recovery (Cont’d) Item Specifications* Supported standard and For NRZ mode baud rate Standard Bit Rate [Gbit/s] Remarks CEI-56G 56.000 000 * 100G ULH 32.100 000 * 32G FC 28.050 000 * CEI-28G 28.000 000 * 100G OTU4 27.952 496 * 100GAUI-4...
Page 105 Specifications Table 1.3.3-14 Clock Recovery (Cont’d) Item Specifications* Supported standard and For PAM4 mode baud rate (Cont’d) Standard Baud Rate [Gbaud] Remarks CEI 112G 56.000 000 * 400GAUI-4 (400GbE (53.1 × 4)) 53.125 000 * 200GAUI-2 53.125 000 * 100GAUI-1 53.125 000 * 64G FC 28.900 000 *...
Page 106 Chapter 1 Overview Table 1.3.3-14 Clock Recovery (Cont’d) Item Specifications* Target loop band When the Option x21, x22, or x21 + y24 is installed. 25.5 to 32.1 G* Baud rate / 1667 Baud rate / 2578 Baud rate / 6640 Jitter Tolerance 2.4 to 25.499 999 G Baud rate / 1667...
Page 107 Specifications Table 1.3.3-14 Clock Recovery (Cont’d) Item Specifications Jitter Tolerance NRZ input* At the bit rate of 58.0 Gbit/s, conforming to Jitter Tolerance Mask defined by the “CEI 56G Jitter Tolerance Mask”. The following masks are taken as nominal values: 0.01 10k 100k 1M 10M 100M1000M Modulation Frequency [Hz]...
Page 108 Chapter 1 Overview Table 1.3.3-14 Clock Recovery (Cont’d) Item Specifications Jitter Tolerance (Cont’d) PAM4 input* At the bit rate of 53.125 Gbaud, conforming to Jitter Tolerance Mask defined by the “CEI-112G-VSR Jitter Tolerance Mask”. The following masks are taken as nominal values: 0.01 10k 100k 1M 10M 100M1000M Modulation Frequency [Hz]...
Page 109 Specifications Table 1.3.3-15 Mechanical Performance Item Specifications Dimensions 21 mm (H), 234 mm (W), 175 mm (D), Excluding protrusions Mass 2.5 kg max. Operating temperature 15 to 30°C MP1900A’s ambient temperature. MU196040B shall operate when installed. Storage temperature –20 to 60°C MU196040B installed to MP1900A shall comply with MIL-T-28800E Class 5.
Page 110 Chapter 1 Overview 1-94.
Page 111: Chapter 2 Before Use
Before Use This chapter describes preparations required before using the MP1900A modules. Installation to MP1900A ..........2-2 How to Operate Application ......... 2-2 Preventing Damage ............ 2-3...
Page 112: Installation To Mp1900A
Chapter 2 Before Use 2.1 Installation to MP1900A For information on how to install the MP1900A modules to the MP1900A and how to turn on the power, refer to Chapter 3 “Preparation before MP1900A Signal Quality Analyzer-R Operation Manual Use” in the 2.2 How to Operate Application The modules connected to the MP1900A are controlled by operating the MX190000A Signal Quality Analyzer-R Control Software (hereinafter,...
Page 113: Preventing Damage
Preventing Damage 2.3 Preventing Damage Always observe the ratings when connecting to the input and output connectors of the MP1900A modules. If an out-of-range signal is input, the MP1900A modules may be damaged. CAUTION • When signals are input to the MP1900A modules, avoid excessive voltage beyond the rating.
Page 114 Chapter 2 Before Use CAUTION • To protect the MP1900A modules from electrostatic discharge failure, a conductive sheet should be placed onto the workbench, and the operator should wear an electrostatic discharge wrist strap. Always ground the wrist strap to the workbench antistatic mat or the frame ground of the MP1900A modules.
Page 115 Preventing Damage Set output ON/OFF after power completing connections. 50 Ω To protect DUT and PPG MP1900A MU196020A Coaxial cable Coaxial cable Bias-T Do not connect/disconnect while DC voltage impressed. Figure 2.3-1 Bias-T Connection Example...
Page 116 Chapter 2 Before Use 2-6.
Page 117: Chapter 3 Panel Layout And Connectors
Chapter 3 Panel Layout and Connectors This chapter describes the panel and connectors of the MP1900A modules. Panel Layout ............... 3-2 3.1.1 MU196020A ............ 3-2 3.1.2 MU196040A ............ 3-3 3.1.3 MU196040B ............ 3-4 Inter-Module Connection ..........3-5 3.2.1 Measuring errors ..........3-7 3.2.2 Measuring errors with noise added ....
Page 118: Panel Layout
Inputs clock signals from these units: MU181000A 12.5GHz Synthesizer MU181000B 12.5GHz 4 Port Synthesizer MU181500B Jitter Modulation Source External Synthesizer* We recommend using the MG3690C series as an external synthesizer. For details about the MG3690C series, contact Anritsu or our sales representative.
Page 119: Mu196040A
Panel Layout 3.1.2 MU196040A Figure 3.1.2-1 Panel Layout (MU196040A) Table 3.1.2-1 Connectors on Panel Name Description Data Input, Input Data, Data data signals. Data Input Support both differential and single-ended input signals. AUX In Inputs auxiliary signals. Variation: External Mask, Burst AUX Out, Outputs auxiliary signals.
Page 120: Mu196040B
Chapter 3 Panel Layout and Connectors 3.1.3 MU196040B Figure 3.1.3-1 Panel Layout (MU196040B) Table 3.1.3-1 Connectors on Panel Name Description Data Input, Input Data, Data data signals. Data Input Support both differential and single-ended input signals. Be sure to terminate the unused connector with the coaxial terminator (V210).
Page 121: Inter-Module Connection
Inter-Module Connection 3.2 Inter-Module Connection Avoid static electricity when handling the devices. WARNING • When signals are input to this MP1900A modules, avoid excessive voltage beyond the rating. Otherwise, the circuit may be damaged. • As a countermeasure against static electricity, ground other devices to be connected (including experimental circuits) with ground wires before connecting the I/O connector.
Page 122 Chapter 3 Panel Layout and Connectors CAUTION The maximum data input level of MU196040A/B is 1.00 Vp- When connecting Data Output connector MU195020A/MU183020A directly Data Input connector of MU196040A/B to verify operation, make sure that data output level MU195020A/MU183020A is 1.00 Vp-p or under. Avoid inputting the signal exceeding the maximum input level to the Data Input connector of MU196040A/B.
Page 123: Inter-Module Connection
Inter-Module Connection 3.2.1 Measuring errors This section describes a connection example of MU196020A, MU181000B 12.5GHz 4 ports synthesizer (hereafter MU181000B), and MU196040A/B that are installed to an MP1900A. MU181000B MU196020A MU196040A/B Figure 3.2.1-1 Inter-Module Connection Example Using a coaxial cable, connect the Clock Output connector of the MU181000B and the Ext Clock Input connector of the MU196020A.
Page 124: Measuring Errors With Noise Added
Chapter 3 Panel Layout and Connectors 3.2.2 Measuring errors with noise added This section describes a connection example of MU196020A, MU181000B, MU181500B Jitter Modulation Source (hereafter MU181500B), MU195050A, and MU196040A/B that are installed to an MP1900A. To connect MU196020A and the Data1 connector of MU195050A, use J1792A (optional accessory).
Page 125 Inter-Module Connection connector of the MU195050A and the Data Input connector of the DUT. Using a coaxial cable, connect the Data Output connector of the DUT and the Data Input connector of the MU196040A/B. Also, using a coaxial cable, connect the Data Output connector of the DUT and the Data Input connector of the MU196040A/B.
Page 126: Adding Jitter To Output Signal
Chapter 3 Panel Layout and Connectors 3.2.3 Adding jitter to output signal To add jitter to signals output from PAM4 PPG, use MU181000B and MU181500B. Figure 3.2.3-1 shows a connection example of MU181000B, MU181500B, MU196020A, and MU196040A/B. MU196040A/B-001 supports up to 32.1 Gbit/s and 32.1 Gbaud.
Page 127: Synchronizing Multiple Channels Of Ppg
Inter-Module Connection 3.2.4 Synchronizing multiple channels of PPG To synchronize multiple MU196020As installed to MP1900A, use MU181000A/B or external clock. The following figure shows a connection example when synchronizing two units of MU196020A using MU181000B. MU196020A MU181000B Figure 3.2.4-1 Connection Example When Synchronizing Two Units of PPGs Connect two Clock Output connectors on MU181000B to the Ext Clock In connector on each MU196020A with two coaxial cables.
Page 128 Chapter 3 Panel Layout and Connectors The following figure shows a connection example when synchronizing four units of MU196020A using MU181000B and MU181500B. J1748A MU196020A MU181500B MU181000B Figure 3.2.4-2 Connection Example When Synchronizing Four Units of PPGs Connect the Clock Output connector of MU181000B and the Ext Clock Input connector of MU181500B with a coaxial cable.
Page 129: Chapter 4 Usage Examples
Usage Examples This chapter describes usage examples of measurement using the MP1900A modules. Evaluating Optical Components in 400GbE Transceiver ........... 4-2 Evaluating Devices for 400GbE Transceiver ....4-5...
Page 130: Evaluating Optical Components In 400Gbe Transceiver
Chapter 4 Usage Examples 4.1 Evaluating Optical Components in 400GbE Transceiver This section explains how to evaluate optical components used in a 400GbE optical transceiver by using MU196020A and MU196040A. The optical components are as follows: • TOSA (transmitter optical subassembly) consisting of a laser diode, driver amp, EML and other parts •...
Page 131 Evaluating Optical Components in 400GbE Transceiver Measurement Connect the MP1900A and DUT to GND. Use a coaxial connector to connect the Clock Output connector of the MU181000B and the Ext. Clock In connector of the MU196020A. Use a coaxial connector to connect the Clock Out connector of the ��...
Page 132 Chapter 4 Usage Examples Test method Connect the power cord of the MP1900A. Turn on the MP1900A. Turn OFF data output. Match MU196020A data output interface to DUT's input by adjusting the amplitude and offset on the Output tab. On the Pattern tab of the MU196020A and MP196040A, set the pattern by selecting a test pattern.
Page 133: Evaluating Devices For 400Gbe Transceiver
Evaluating Devices for 400GbE Transceiver 4.2 Evaluating Devices for 400GbE Transceiver In the evaluation of SERDES for 400GbE transceiver, the jitter tolerance of the CDR (Clock Data Recovery) is measured. This test requires the emphasis settings to be configured in order to compensate the frequency characteristics of the transmission channel and devices.
Page 134 Chapter 4 Usage Examples �� Use coaxial cables to connect the Data Input connector and Data Input connector of the MU196040A to the Data Output connectors of the DUT (two connections). To input the reference clock to the DUT, connect the Sub-rate Clock Output connector of MU181500B and the Clock Input connector of the DUT with a coaxial cable.
Page 135 Evaluating Devices for 400GbE Transceiver On the Output tab of the MU196020A, set Data Output to ON, and then touch the Output button on the top of the screen to turn it from grey to green ( Adjust the threshold voltage of the MU196040A. Touch the Auto Search module function button.
Page 136 Chapter 4 Usage Examples 4-8.
Page 137: Chapter 5 Performance Test
Chapter 5 Performance Test This chapter describes the performance testing of the MP1900A modules. Timing of Performance Tests ........5-2 Devices Required for Performance Tests ....5-3 Performance Test Items ..........5-5 5.3.1 Operating frequency range ......5-5 5.3.2 Waveform evaluation test ........ 5-7 5.3.3 Input level .............
Page 138: Timing Of Performance Tests
Chapter 5 Performance Test 5.1 Timing of Performance Tests Performance test is conducted to check that the major performance of the MP1900A modules meets the required specifications. Conduct performance tests at acceptance inspection, operation check after repair, and periodic testing (once every six months).
Page 139: Devices Required For Performance Tests
Devices Required for Performance Tests 5.2 Devices Required for Performance Tests Before starting performance test, warm up the MP1900A and the measuring instruments for at least 30 minutes. Table 5.2-1 shows the required devices for performance test. Table 5.2-1 Devices Required for Performance Tests Device Name Model Required Performance...
Page 140 Chapter 5 Performance Test conditions: ● Measurement is performed at room temperature. ● Fluctuations of AC power supply voltage are small. ● Noise, vibration, dust, and humidity are insignificant.
Page 141: Performance Test Items
Performance Test Items 5.3 Performance Test Items This section describes the following test items. ● Operating frequency range ● Waveform evaluation test ● Input level ● Pattern ● Error detection 5.3.1 Operating frequency range (1) Specifications Table 5.3.1-1 Specifications Option Specifications MU196020A-001 2.4 to 32.1 Gbit/s (Gbaud)
Page 142 Chapter 5 Performance Test (3) Procedure Mount the MU196020A onto the MP1900A, and turn on the MP1900A with the cables unconnected. Set the modulation mode of MU196020A and MU196040A/B to NRZ. On the Output tab of the MU196020A, set Amplitude to 0.500 Vp-p, and Offset to 0.000 V and Vth.
Page 143 Performance Test Items 5.3.2 Waveform evaluation test (1) Specifications Table 5.3.2-1 Specifications for MU196020A Item Conditions Specification Amplitude 0.07 to 0.70 Vp-p* ±35 mV ±12% of amplitude 0.07 to 0.60 Vp-p* 0.07 to 0.55 Vp-p* −2.0 − +3.3 − Offset (Vth) ±65 mV ±10% of offset (Vth) ±(Eye Amplitude Accuracy / 2)* Cross point*...
Page 144 Chapter 5 Performance Test (2) Device connection MU181000B MU196020A J1789A or J1790A Sampling oscilloscope Trigger Input Input Figure 5.3.2-1 Connection Diagram for Waveform Test When using the MU181000A instead of MU181000B, attach the 6 dB Coaxial Attenuator to the Clock Output connector. For waveform test, use a sampling oscilloscope that has a 70 GHz band and that has a residual jitter of less than 200 fs (RMS).
Page 145 Performance Test Items Ext ATT Factor 0.000 Amplitude 0.070 Offset AC OFF, 0.000, Vth Half Period Jitter Delay In the Cable for Data Output box, select the model name of the cable used for connection to the sampling oscilloscope. On the Output tab of the MU196020A, set the Data output amplitude, offset, and cross point to be tested.
Page 146 Chapter 5 Performance Test 16. On the Output tab of the MU196020A, set Amplitude to 0.070 and Offset to 3.265. 17. Measure the middle level of the eye with the sampling oscilloscope, and record it. 18. On the Output tab of the MU190020A, set Amplitude to 0.500 and Offset to 0.000.
Page 147: Input Level
Performance Test Items 5.3.3 Input level (1) Specifications Table 5.3.3-1 Specifications Option Specifications MU196040A-001 NRZ Input amplitude: 0.05 to 1.0 Vp-p PAM4 Input amplitude: 0.3 to 1.0 Vp-p Threshold voltage: −3.5 to +3.3 V MU196040B-001 NRZ Input amplitude: 0.05 to 1.0 Vp-p PAM4 Input amplitude: 0.3 to 1.0 Vp-p Threshold voltage:...
Page 148 Chapter 5 Performance Test Touch Auto Search. In the Mode list, select Fine, and then touch Start. Check that the threshold voltage and phase are adjusted to optimum values and that no error occurs. Set the modulation mode of MU196020A and MU196040A/B to PAM4.
Page 149 Performance Test Items Amplitude: 0.5 Vp-p Offset: +3.05 V *3: In the Mode list, select Fine (NRZ), and then start Auto Search to adjust the threshold voltage and phase to optimum values. Table 5.3.3-3 PAM4 Input Level Test Settings (MU196040A/B) MU196020A MU196040A/B No.
Page 150: Pattern
Chapter 5 Performance Test 5.3.4 Pattern (1) Specifications ● PRBS pattern (NRZ, PAM4) ● Zero Substitution pattern (NRZ) ● SSPRQ pattern (PAM4) (2) Connection Refer to Figure 5.3.3-1 for the device connection. (3) Procedure Configure the settings in the same manner as shown in steps 1 to 5 in Section 5.3.1.
Page 151: Error Detection
Performance Test Items 10. Set the modulation mode of MU196020A and MU196040A/B to PAM4. 11. Change the test patterns of both MU196040A/B and MU196020A to SSPRQ, and check that no error occurs. 5.3.5 Error detection (1) Specifications Error rate: 0.0000 × 10 to 1.0000 –16 Error count:...
Page 152 Chapter 5 Performance Test 10. Touch the Start button of the MU196040A/B. While the measurement is running for 10 seconds, touch Single once on the Error Addition tab of the MU196020A. When the measurement has finished, check that the measurement results are as follows. Error rate (ER): 5.0000E−12 Error count (EC):...
Page 153 Maintenance This chapter describes maintenance of the MP1900A modules. Daily Maintenance ............6-2 Cautions on Storage ........... 6-2 Transportation............. 6-3 Calibration ..............6-3...
Page 154: Chapter 6 Maintenance
Chapter 6 Maintenance 6.1 Daily Maintenance • Wipe off any external stains with a cloth damped with diluted mild detergent. • Vacuum away any accumulated dust or dirt with a vacuum cleaner. • Tighten any loose parts fixed with screws, using the specified tools. 6.2 Cautions on Storage Wipe off any dust, soil, or stain on the MP1900A modules prior to storage.
Page 155: Transportation
The recommended calibration cycle after delivery of the Signal Quality Analyzer Series is twelve months. If you require support after delivery, contact an Anritsu Service and Sales office. Contact information can be found on the last page of the printed version of this manual, and is available in a separate file on the PDF version.
Page 156 Chapter 6 Maintenance 6-4.
Page 157 Troubleshooting This chapter describes how to determine if a failure has occurred when a problem occurs during the MP1900A module operation. Problems That Occur When Replacing Modules ..7-2 Problems That Occur During Output Waveform Observation ..............7-3 Problems That Occur During Error Rate Measurement ..........
Page 158: Problems That Occur When Replacing Modules
Anritsu web site (https://www.anritsu.com). If the appropriate modulus are not recognized, it may have failed. Contact an Anritsu Service and Sales office. Contact information can be found on the last page of the printed version of this manual, and...
Page 159: Problems That Occur During Output Waveform Observation
Problems That Occur During Output Waveform Observation 7.2 Problems That Occur During Output Waveform Observation Table 7.2-1 Remedies for Problems That Occur During Waveform Observation Symptom Check Item Remedy Output waveform Is the Data or Clock on the On the Output tab, set Data or Clock to be output cannot be Output tab set to ON? to ON.
Page 160: Problems That Occur During Error Rate Measurement
Chapter 7 Troubleshooting 7.3 Problems That Occur During Error Rate Measurement Table 7.3-1 Remedies for Problems That Occur During Error Rate Measurement Symptom Check Item Remedy An error occurs. Is the connection interface Check that the data rate, level, offset and with the DUT correct? termination conditions match those of the DUT.
Page 161: Synchronization Failures
Synchronization Failures 7.4 Synchronization Failures Table 7.4-1 Remedies for Synchronization Failures Item Check Item Remedy Input conditions Do the quality, status and Replace the cables with appropriate ones in the length of the connection cables following cases: comply with the specifications? •...
Page 162 Chapter 7 Troubleshooting Table 7.4-1 Remedies for Synchronization Failures (Cont’d) Item Check Item Remedy PAM4 symbol Has symbol synchronization In Diagnostics Mode, check that MSB/LSB Diff is synchronization been established between 0. If it is 0, symbol synchronization has been conditions PAM4 MSB and LSB? established.
Page 163 Appendix A Pseudo-Random Pattern Pseudo-Random Pattern ..........A-2 Zero-Substitution Pattern ........... A-3...
Page 164 Appendix A Pseudo-Random Pattern A.1 Pseudo-Random Pattern Table A.1-1 shows the principle of pseudo-random pattern generation. A pseudo-random pattern is expressed in an N-th degree generating polynomial, with one cycle of 2 –1. For a PRBS pattern with a cycle of –1, a pattern of successive “1s”...
Page 165 Zero-Substitution Pattern A.2 Zero-Substitution Pattern A string of successive “0s” for the number of set bits is made by substituting “0” for the pattern that follows the longest bit string of successive 0s in a PRBS pattern. In this event, if the bit immediately after the bit substituted to “0”...
Page 166 Appendix A Pseudo-Random Pattern A-4．...
Page 167 Appendix B List of Default Settings Appendix B lists the factory default settings for MU196020A, MU196040A, and MU196040B. To initialize all settings, select Menu → Initialize. MU196020A ............... B-2 B.1.1 PAM4 ............. B-2 B.1.2 NRZ ............... B-7 MU196040A ............. B-11 B.2.1 PAM4 ............
Page 168: Mu196020A
Appendix B List of Default Settings B.1 MU196020A B.1.1 PAM4 Table B.1.1-1 Output Tab Main Item Secondary Item Tertiary Item Default Baud Rate Variable Baud Rate 12.500 000 Gbaud Output Data Clock Level Guard Level Guard Setup Total Amplitude 0.800 V Offset Max(Voh) 3.300 V Offset Min(Vol)
Page 169 MU196020A Table B.1.1-2 Emphasis Tab Main Item Secondary Item Tertiary Item Default Manual Setting Emphasis Standard/Preset USER De-Emphasis Preset0 Graph Total Amplitude 0.500 Vp-p Upper Eye 33.400% Lower Eye 33.400% Cursor2 0.000 dB Cursor1 0.000 dB Post Cursor1 0.000 dB Coefficient 0.000 000 0.000 000...
Page 170 Appendix B List of Default Settings Table B.1.1-3 Pattern Tab Main Item Secondary Item Tertiary Item Default Test Pattern All List PRBS Length 2^15–1 PRBS Inv MSB PRBS Inv LSB Gray Coder Pre Coder Logic MSB Logic LSB Bit Shift Data Length 4 bits...
Page 171 MU196020A Table B.1.1-3 Pattern Tab (Cont’d) Main Item Secondary Item Tertiary Item Default Test Pattern PRBS23Q, PRBS Inv MSB PRBS31Q, PRBS Inv LSB PRBS31Q (Infiniband), Gray Coder PRBS31Q Pre Coder (Fibre Channel) Logic MSB Logic LSB Bit Shift PRBS13Q, PRBS Inv MSB QPRBS13-CEI, PRBS Inv LSB QPRBS31-CEI,...
Page 172 Appendix B List of Default Settings Table B.1.1-4 Error Addition Tab Main Item Secondary Item Tertiary Item Default Error Addition Error Addition Mode Bit Error on MSB Bit Error on MSB Symbol/Burst Symbol Source Internal Variation Repeat Rate 1E–3 Burst Length 1 Symbols Table B.1.1-5 Misc1 Tab Main Item...
Page 173: Nrz
MU196020A B.1.2 NRZ Table B.1.2-1 Output Tab Main Item Secondary Item Tertiary Item Default Bitrate Variable Bitrate 12.500 000 Gbit/s Output Data Clock Level Guard Level Guard Setup Amplitude 0.800 V Offset Max(Voh) 3.300 V Offset Min(Vol) –2.800 V (NRZ pattern Amplitude 0.500 Vp-p settings)
Page 174 Appendix B List of Default Settings Table B.1.2-2 Emphasis Tab Main Item Secondary Item Tertiary Item Default Manual Setting Emphasis Function Standard/Preset USER De-Emphasis Preset0 Graph Amplitude 0.500 Vp-p Cursor2 0.000 dB Cursor1 0.000 dB Post Cursor1 0.000 dB Coefficient 0.000 000 0.000 000 1.000 000...
Page 175 MU196020A Table B.1.2-3 Pattern Tab Main Item Secondary Item Tertiary Item Default Test Pattern All List PRBS Length 2^15–1 Mark Ratio Logic Zero Substitution Length 2^15 Zero Substitution 1 bits Length Additional Bit Logic Data Length Logic Data Editor Data Length Format Hex(Byte) Edit Mode...
Page 176 Appendix B List of Default Settings Table B.1.2-5 Misc1 Tab Main Item Secondary Item Tertiary Item Default Pattern Sequence Repeat Gating Output Repeat Pulse Width 256 bits Delay 0 bits Burst Source Internal Data Sequence Restart Enable Period 128 000 bits Burst Cycle 128 000 000 bits Delay...
Page 177: Mu196040A
MU196040A B.2 MU196040A B.2.1 PAM4 Table B.2.1-1 Result Tab Main Item Secondary Item Tertiary Item Default Switch of setting Setting display format Gating items Input Upper Eye Threshold 0.095 V Middle Eye Threshold 0.000 V Lower Eye Threshold –0.095 V UL Threshold Delay 0 mUI...
Page 178 Appendix B List of Default Settings Table B.2.1-2 Measurement Tab Main Item Secondary Item Tertiary Item Default Gating Cycle Repeat Unit Time Time 0 day 00:00:01 Clock Count >E+10 Error Count >E+10 Current Calculation Progressive Interval 100 ms Auto Sync Auto Sync Threshold Sync Control...
Page 179 MU196040A Table B.1.2-3 Pattern Tab (Cont’d) Main Item Secondary Item Tertiary Item Default Test Pattern PRBS23Q, PRBS Inv MSB PRBS31Q, PRBS Inv LSB PRBS31Q Gray Coder (Infiniband), PRBS31Q Pre Coder (Fibre Channel) Logic MSB Logic LSB PRBS13Q, PRBS Inv MSB QPRBS13-CEI, PRBS Inv LSB QPRBS31-CEI,...
Page 180 Appendix B List of Default Settings Table B.2.1-4 Input Tab Main Item Secondary Item Tertiary Item Default Data Input Condition Single-Ended Single-Ended Data Differential 50Ohm Independent Differential 100Ohm Independent Termination Data Upper Eye Threshold 0.165 V Middle Eye Threshold 0.000 V Lower Eye Threshold –0.165 V XData...
Page 181 MU196040A Table B.2.1-6 Misc1 Tab Main Item Secondary Item Tertiary Item Default Pattern Sequence Repeat Source External -Enable AUX Input External Mask AUX Output 1/N Clock 1/N Clock (Divide ratio) 1/64 Clock Pattern Sync Position 1 symbols B-15...
Page 182: Nrz
Appendix B List of Default Settings B.2.2 NRZ Table B.2.2-1 Result Tab Main Item Secondary Item Tertiary Item Default Switch of setting Setting display format Gating items Input Data Threshold 0.000 V XData Threshold – Differential Selection Data-XData Threshold – Delay 0 mUI Gating...
Page 183 MU196040A Table B.2.2-2 Measurement Tab Main Item Secondary Item Tertiary Item Default Gating Cycle Repeat Unit Time Time 0 day 00:00:01 Clock Count >E+10 Error Count >E+10 Current Calculation Progressive Interval 100 ms Auto Sync Auto Sync Threshold Sync Control Frame Length 64 bits Frame Position...
Page 184 Appendix B List of Default Settings Table B.2.2-3 Pattern Tab Main Item Secondary Item Tertiary Item Default Test Pattern All List PRBS Length 2^15–1 Mark Ratio Logic Zero Substitution Length 2^15 Zero Substitution 1 bits Length Additional Bit Logic Data Length Logic Data Editor...
Page 185 MU196040A Table B.2.2-4 Input Tab Main Item Secondary Item Tertiary Item Default Data Input Condition Single-Ended Single-Ended Data Differential 50Ohm Independent Differential 100Ohm Independent Data Threshold 0.000 V Termination Variable 0.000 V XData Threshold 0.000 V Differential Selection Data-XData Threshold 0.000 V Clock Selection...
Page 186 Appendix B List of Default Settings Table B.2.2-6 Misc1 Tab Main Item Secondary Item Tertiary Item Default Pattern Sequence Repeat Burst Source External -Enable Delay 0 bits Enable Period 128 000 bits Burst Cycle 128 000 000 bits Auto/Manual Manual AUX Input External Mask AUX Output...
Page 187: Mu196040B
MU196040B B.3 MU196040B B.3.1 PAM4 Table B.3.1-1 Result Tab Main Item Secondary Item Tertiary Item Default Switch of setting Setting display format Gating items Input Upper Eye Threshold 0.095 V Middle Eye Threshold 0.000 V Lower Eye Threshold –0.095 V U/L Threshold Sync Low Frequency Equalizer...
Page 188 Appendix B List of Default Settings Table B.3.1-2 Measurement Tab Main Item Secondary Item Tertiary Item Default Gating Cycle Repeat Unit Time Time 0 day 00:00:01 Clock Count >E+10 Error Count >E+10 Current Calculation Progressive Interval 100 ms Auto Sync Auto Sync Threshold Sync Control...
Page 189 MU196040B Table B.3.1-3 Pattern Tab (Cont’d) Main Item Secondary Item Tertiary Item Default Test Pattern (Cont’d) Data Editor Data Length Format Hex(Byte) Edit Mode Overwrite Cursor Addr 0x00000000 PRBS23Q, PRBS Inv MSB PRBS31Q, PRBS Inv LSB PRBS31Q Gray Coder (Infiniband), PRBS31Q Pre Coder (Fibre Channel)
Page 190 Appendix B List of Default Settings Table B.3.1-3 Pattern Tab (Cont’d) Main Item Secondary Item Tertiary Item Default Test Pattern (Cont’d) RS-FEC Scrambled Gray Coder Idle 50G 1Lane, Pre Coder RS-FEC Scrambled Logic MSB Idle 100G 1Lanes, Logic LSB RS-FEC-Int Input Signal Decoder Scrambled Idle 100G Inverse Gray Coder...
Page 191 MU196040B Table B.3.1-4 Input Tab Main Item Secondary Item Tertiary Item Default Data Input Condition Single-Ended Single-Ended Data Differential 50Ohm Independent Differential 100Ohm Independent Termination Data Upper Eye Threshold 0.095 V Middle Eye Threshold 0.000 V Lower Eye Threshold –0.095 V XData Upper Eye Threshold 0.095 V...
Page 192 Appendix B List of Default Settings Table B.3.1-5 Capture Tab Main Item Secondary Item Tertiary Item Default Capture Mode Capture Mode Sync Mode Capture State ----- Capture Result Auto Launch Capture Data Display Condition Number of Blocks Capture Area After the Trigger Trigger Match Pattern Match Pattern Length...
Page 193 MU196040B Table B.3.1-7 Logging Tab Main Item Secondary Item Tertiary Item Default BER/SER Logging Logging Cycle 00:00:05 ER (Symbol) ER (Bit) ER (MSB) ER (LSB) EC (Symbol) EC (Bit) EC (MSB) EC (LSB) Clock Loss Sync Loss B-27...
Page 194: Nrz
Appendix B List of Default Settings B.3.2 NRZ Table B.3.2-1 Result Tab Main Item Secondary Item Tertiary Item Default Switch of setting Setting display format Gating items Input Data Threshold 0.000 V XData Threshold – Differential Selection Data-XData Threshold – Delay 0 mUI 0.000 dB...
Page 195 MU196040B Table B.3.2-2 Measurement Tab Main Item Secondary Item Tertiary Item Default Gating Cycle Repeat Unit Time Time 0 day 00:00:01 Clock Count >E+10 Error Count >E+10 Current Calculation Progressive Interval 100 ms Auto Sync Auto Sync Threshold Sync Control Frame Length 64 bits Frame Position...
Page 196 Appendix B List of Default Settings Table B.3.2-3 Pattern Tab Main Item Secondary Item Tertiary Item Default Test Pattern All List PRBS Length 2^15–1 Mark Ratio Logic Zero Substitution Length 2^15 Zero Substitution 1 bits Length Additional Bit Logic Data Length Logic Data Editor...
Page 197 MU196040B Table B.3.2-4 Input Tab Main Item Secondary Item Tertiary Item Default Data Input Condition Single-Ended Single-Ended Data Differential 50Ohm Independent Differential 100Ohm Independent Data Threshold 0.000 V Termination Variable 0.000 V XData Threshold 0.000 V Differential Selection Data-XData Threshold 0.000 V Equalizer Low Frequency Equalizer...
Page 198 Appendix B List of Default Settings Table B.3.2-5 Capture Tab Main Item Secondary Item Tertiary Item Default Capture Mode Capture Mode Sync Mode Capture State ----- Capture Result Auto Launch Capture Data Display Condition Number of Blocks Capture Area After The Trigger Trigger Match Pattern Match Pattern Length...
Page 199 MU196040B Table B.3.2-7 Logging Tab Main Item Secondary Item Tertiary Item Default BER/SER Logging Logging Cycle 00:00:05 ER (Total) ER (INS) ER (OMI) EC (Total) EC (INS) EC (OMI) Clock Loss Sync Loss B-33...
Page 200 Appendix B List of Default Settings B-34.
Page 201 Appendix C Performance Test Record Sheet C.1 Performance Test Result Sheet Document number: Test Location: Date: Test person in charge: Product name: Serial number: Software version: Option: Power voltage: Power frequency: Ambient temperature °C Relative humidity Model name Serial number Instruments used Model name Serial number...
Page 202 Appendix C Performance Test Record Sheet C.2 MU196020A C.2.1 MU196020A-001 Table C.2.1-1 Operating Frequency Range Results Specification Data Data No errors occur within the range from 2.4 to 32.1 Gbit/s.* No errors occur within the range from 2.4 to 32.1 Gbaud.* Pattern PRBS, 2^31–1 Table C.2.1-2 MU196020A-001 Waveform Evaluation Test- Amplitude (NRZ) Settings...
Page 203 MU196020A Table C.2.1-5 MU196020A-001 Waveform Evaluation Test- Offset (PAM4) Settings Specification Results Offset Lower Limit Upper Limit Baud rate Data Data (Vth) 32.1 Gbaud 3.265 2.817 3.713 –2.35 –2.590 –2.111 Table C.2.1-6 MU196020A-001 Waveform Evaluation Test-Cross point (NRZ) Settings Specification Results Lower Limit Upper Limit...
Page 204 Appendix C Performance Test Record Sheet C.2.2 MU196020A-002 Table C.2.2-1 Operating Frequency Range Results Specification Data Data No errors occur within the range from 2.4 to 32.1 Gbit/s.* No errors occur within the range from 2.4 to 32.1 Gbaud.* Pattern PRBS, 2^31–1 Table C.2.2-2 MU196020A-002 Waveform Evaluation Test- Amplitude (NRZ) Settings Specification...
Page 205 MU196020A Table C.2.2-5 MU196020A-002 Waveform Evaluation Test- Offset (PAM4) Settings Specification Results Offset Lower Limit Upper Limit Baud rate Data Data (Vth) 58.2 Gbaud 3.265 2.817 3.713 –2.30* –2.489 –2.112 –2.35* –2.590 –2.111 *1: When J1790A cables are used, Amplitude 0.60 Vp-p *2: When J1789A cables are used, Amplitude 0.70 Vp-p Table C.2.2-6 MU196020A-002 Waveform Evaluation Test- Cross point (NRZ) Settings...
Page 206 Appendix C Performance Test Record Sheet C.2.3 MU196020A-003 Table C.2.3-1 Operating Frequency Range Results Specification Data Data No errors occur within the range from 2.4 to 32.1 Gbit/s.* No errors occur within the range from 2.4 to 32.1 Gbaud.* Pattern PRBS, 2^31–1 Table C.2.3-2 MU196020A-003 Waveform Evaluation Test- Amplitude (NRZ) Settings Specification...
Page 207 MU196020A Table C.2.3-5 MU196020A-003 Waveform Evaluation Test- Offset (PAM4) Settings Specification Results Offset Lower Limit Upper Limit Baud rate Data Data (Vth) 64.2 Gbaud 3.265 2.817 3.713 –2.275* –2.438 –2.112 –2.35* –2.590 –2.111 *1: When J1790A cables are used, Amplitude 0.55 Vp-p *2: When J1789A cables are used, Amplitude 0.70 Vp-p Table C.2.3-6 MU196020A-003 Waveform Evaluation Test - Cross point (NRZ) Settings...
Page 208 Appendix C Performance Test Record Sheet C.3 MU196040A Table C.3-1 Input Level Range (NRZ) Settings Results MU196020A MU196040A Specification Termi Amplitude Offset Termi Threshold Data Data nation (Vp-p) (Vth) (V) nation Voltage (V) –2.35 –2.350 No errors occur. 0.05 –0.225 –0.225 +2.95 +2.950...
Page 209 MU196040A Table C.3-3 Test Pattern (PRBS-NRZ) Settings Results MU196020A MU196040A Specification Length Logic Length Logic Data Data 2^7–1 2^7–1 No errors occur. 2^9–1 2^9–1 2^11–1 2^11–1 2^13–1 2^13–1 2^15–1 2^15–1 2^20–1 2^20–1 2^23–1 2^23–1 2^31–1 2^31–1 2^31–1 2^31–1 Table C.3-4 Test Pattern (PRBS-PAM4) Settings Results MU196020A...
Page 210 Appendix C Performance Test Record Sheet Table C.3-5 Test Pattern (Zero Substitution-NRZ) Settings Results MU196020A MU196040A Specification Length Logic Length Logic Data Data No errors occur. 2^10 2^10 2^11 2^11 2^15 2^15 2^20 2^20 2^23 2^23 2^7–1 2^7–1 2^9–1 2^9–1 2^10–1 2^10–1 2^11–1...
Page 211 MU196040B C.4 MU196040B Table C.4-1 Input Level Range (NRZ ≤32.1 Gbit/s) Settings Results MU196020A MU196040B Specification Termi Amplitude Offset Termi Threshold Data Data nation (Vp-p) (Vth) (V) nation Voltage (V) –2.35 –2.350 No errors occur. 0.05 –0.225 –0.225 +2.95 +2.950 0.05 +0.305 +0.305...
Page 212 Appendix C Performance Test Record Sheet Table C.4-3 Input Level Range (PAM4 ≤32.1 Gbaud) Settings Results MU196020A MU196040B Specification Termi Amplitude Offset Termi Threshold Data Data nation (Vp-p) (Vth) (V) nation Voltage (V) –2.35 Upper: –2.117 No errors occur. Middle: –2.350 Lower: –2.583 –2.15 Upper: –2.050...
Page 213 MU196040B Table C.4-5 Test Pattern (PRBS-NRZ) Settings Results MU196020A MU196040B Specification Length Logic Length Logic Data Data 2^7–1 2^7–1 No errors occur. 2^9–1 2^9–1 2^11–1 2^11–1 2^13–1 2^13–1 2^15–1 2^15–1 2^20–1 2^20–1 2^23–1 2^23–1 2^31–1 2^31–1 2^31–1 2^31–1 Table C.4-6 Test Pattern (PRBS-PAM4) Settings Results MU196020A...
Page 214 Appendix C Performance Test Record Sheet Table C.4-7 Test Pattern (Zero Substitution -NRZ) Settings Results MU196020A MU196040B Specification Length Logic Length Logic Data Data No errors occur. 2^10 2^10 2^11 2^11 2^15 2^15 2^20 2^20 2^23 2^23 2^7–1 2^7–1 2^9–1 2^9–1 2^10–1 2^10–1...
Page 215 Index References are to page numbers. AUX In ..........3-2, 3-3, 3-4 TIA ..............4-2 AUX Out ...........3-2, 3-3, 3-4 TOSA ............. 4-2 Transportation ..........6-3 Bias-T ............2-5 WARNING ............ii Warranty ............iii Calibration............. 6-3 CAUTION ............ii CDR ............... 4-5 CE marking ............ix Clock Out ............
Page 216 Index Index-2.

This manual is also suitable for:

Mu196040a pam4 ed Mu196040b pam4 ed

Anritsu MU196020A PAM4 PPG Operation Manual

Chapter 1 Overview

Chapter 2 Before Use

Chapter 3 Panel Layout and Connectors

Chapter 4 Usage Examples

Chapter 5 Performance Test

Chapter 6 Maintenance

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Anritsu MU196020A PAM4 PPG

Summary of Contents for Anritsu MU196020A PAM4 PPG

This manual is also suitable for:

Table of Contents
