Product description

4. Product description
4.1. Product description
MULTI SYSTEM TYP 1 is a two-stage, single unit amalgam separator with integrated, static air/water separation and place selection valve.
4.2.

Technical data / performance data

Height [H]
Width [W]
Depth [D]
Power supply
Frequency
Max. current consumption
Max. power consumption
Max. ambient temperature
Max. liquid fl ow rate
Negative pressure range
Separation rate
Collection container volume
Dimensions (H x W x D)
Dimensions with cover (H x W x D)
Class
DIBT approval number
Possible suction systems
4.3.

Type plate

8
MULTI SYSTEM TYP 1
24 V AC
50 / 60 Hz
2 A
46 VA
40 °C
3.0 l/min via the spittoon; 1.5 l/min via the suction side
80 mbar - 250 mbar
98.60 %
300 cm3
305 x 210 x 104 mm
340 x 280 x 185 mm
MD class 1
Z-64.1-4
Wet or dry suction systems
MULTI SYSTEM TYP 1 Built-in version:
The type plate is located on module 1 and is visible when module 2 is removed (to do this, tilt the locking bracket on
module 2 upwards and remove module 2).
MULTI SYSTEM TYP 1 with cover:
The type plate is located on the cover next to the external display (push the lid of the cover upwards) as well as on
module 1 and is visible when module 2 is removed (see built-in version).
