PW1350
36
Operating Instructions and Parts List
Please read and save these instructions. Read carefully before attempting to assemble,
install, operate or maintain the product described. Protect yourself and others by
observing all safety information. Failure to comply with instructions could result in
personal injury and/or property damage! Retain instructions for future reference.
BUILT TO LAST

Specifications

Cleaning
Maximum
Maximum
Model
Power
Pressure
Capacity
PW1350
1755
1350 psi
1.3 GPM
Figure 1

Safety Guidelines

This manual contains information that
is very important to know and
understand. This information is
provided for SAFETY and to PREVENT
EQUIPMENT PROBLEMS. To help
recognize this information, observe the
following symbols.
Warning indicates
a potentially
hazardous situation which, if not
avoided, COULD result in death or
serious injury.
© 2006 Campbell Hausfeld/Scott Fetzer
For parts, product & service information
visit www.chpower.com
PW1350
Electric Pressure
Washer
Maximum
Inlet
Water
Temp.
Voltage
Amperage Weight
100˚F
120V
11 Amps
Caution indicates a
potentially
hazardous situation which, if not
avoided, MAY result in minor or
moderate injury.
NOTE or NOTICE: Information that
requires special attention.
IN468000AV 12/06
Unit
15 lbs.
