Electric pressure washer

Advertisement

Assembly Instructions and Parts List
Please read and save these instructions. Read carefully before attempting to assem-
ble, install, operate or maintain the product described. Protect yourself and others by
observing all safety information. Failure to comply with instructions could result in
personal injury and/or property damage! Retain instructions for future reference.

Specifications

Cleaning
Model
Power
PW1380
2340

Assembly Instructions

1. Hook up chemical suction hose to
the tip on the bottom of the handle
(Figure 1).
2. Attach black handle with enclosed
screws and washers (Figure 2).
3. Assemble the wheels to the axle
(Figure 3).
4. Attach foot to front of pressure
washer and snap wheels into pres-
sure washer base. Push hubcaps
onto wheels (Figure 4).
© 2000 Campbell Hausfeld
Max Pressure
with
Standard
Maximum
Lance
Capacity
1300 psi
1.8 GPM 13 Amps
For parts, product & service information
visit www.chpower.com
Electric Pressure
Washer
NOTE: REFER TO PRODUCT MANUAL
FOR ALL SAFETY INSTRUCTIONS
Motor
Power
(Single
Phase)
Voltage
120V
Figure 1
Figure 3
PW1380
Maximum
Inlet
Water
Unit
Temp.
Weight
100˚F
25 lbs.
Figure 2
Figure 4
IN455701AV 10/00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PW1380 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Campbell Hausfeld PW1380

  • Page 1: Specifications

    4. Attach foot to front of pressure washer and snap wheels into pres- Figure 1 Figure 2 sure washer base. Push hubcaps onto wheels (Figure 4). Figure 3 Figure 4 For parts, product & service information © 2000 Campbell Hausfeld IN455701AV 10/00 visit www.chpower.com...
  • Page 2: Operation

    Assembly Instructions and Parts List PW1380 Garden Hose Connection ! IMPORTANT ! GARDEN HOSE CONNECTION This pressure washer is equipped with a INSTRUCTIONS microswitch sensitive to water flow. This 1. Attach nipple adapter to inlet fitting Instant Start/Stop switch (ISS) senses on the unit (this may already be water flow in the pump.
  • Page 3: System Connection

    Assembly Instructions and Parts List PW1380 System Connection 1. Insert lance into the gun and turn 4. Connect garden hose as explained clockwise to positive stop as shown in under Garden Hose Connection Figure 7. Instructions. 5. Plug the power cord into a grounded 120V outlet.
  • Page 4 Assembly Instructions and Parts List PW1380 Please provide following information: Replacement Parts List -Model number -Serial number (if any) For Replacement Parts, -Part description and number as shown in parts list Call 1-800-330-0712 Address parts correspondence to: The Campbell Group / Parts Dept.
  • Page 5: Spécifications

    Figure 2 Figure 1 pulvérisateur de lavage et fixer les roues à la base du pulvérisateur de lavage. Fixer les chapeaux de moyeu sur les roues (Figure 4). Figure 4 Figure 3 © 2000 Campbell Hausfeld IN455701AV 10/00 5 Fr...
  • Page 6 Instructions de Montage et Liste de Pièces de Rechange PW1380 Branchement du Tuyau ! IMPORTANT ! d’Arrosage Ce pulvérisateur de lavage est équipé d’un microrupteur sensible au débit INSTRUCTIONS DE BRANCHEMENT d’eau. Cet interrupteur de Marche/Arrêt DU TUYAU D’ARROSAGE Instantané (Instant Start/Stop - ISS) est 1.
  • Page 7 Instructions de Montage et Liste de Pièces de Rechange PW1380 3. Brancher le tuyau haute pression et Cordon (Suite) le montage de pistolet au modèle. 4. Brancher le tuyau d’arrosage selon 2. ON DOIT LE FAIRE CHAQUE FOIS les directives: Instructions de QU’ON BRANCHE L’UNITÉ...
  • Page 8 Instructions de Montage et Liste de Pièces de Rechange PW1380 S’il vous plaît fournir l’information suivante: Liste de Pièces de Rechange -Numéro de Modèle Pour Pièces de Rechange, -Numéro de Série (si applicable) Appelez 1-800-330-0712 -Description et numéro de la pièce indiqués sur la liste de pièces de rechange...
  • Page 9: Especificaciones

    4. Fije el soporte a la parte delantera de la lavadora a presión e inserte las ruedas en la base de la lavadora. Presione los tapacubos en las ruedas Figura 1 Figura 2 (Figura 4). Figura 4 Figura 3 9 Sp IN455701AV 10/00 © 2000 Campbell Hausfeld...
  • Page 10: Operación

    Instrucciones de montaje y lista de piezas PW1380 Conexión de la Manugera ¡ IMPORTANTE ! de Jardín Esta lavadora a presión está equipada con un microinterruptor sensible al flujo del INSTRUCCIONES DE CONEXIÓN DE agua. Este interruptor de arranque y para- LA MANGUERA DE JARDÍN...
  • Page 11 Instrucciones de montaje y lista de piezas PW1380 3. Conecte la manguera de alta presión Cable de Corriente Eléctrica y el conjunto de pistola en la unidad. Continuación 4. Conecte la manguera de jardín según se explica en Instrucciones de conex- 2.
  • Page 12 Instrucciones de montaje y lista de piezas PW1380 Sírvase proporcionar la siguiente información: Lista de Repuestos -Número de modelo Para ordenar repuestos, -Número de serie (si lo hubiera) sírvase llamer al -Descripción y número del repuesto, según se indica en la lista de repuestos.
