Codonics Horizon Ci Manual

Multi-media imager
Hide thumbs Also See for Horizon Ci:
Table of Contents

Advertisement

Available languages

Available languages

Quick Links

Download this manual

Table of Contents

EN - English ............................................................................................................................................................ 21
Documentation Notice......................................................................................................................................... 21
Overview ................................................................................................................................................................ 21
Specifications ........................................................................................................................................................ 21
Product Information ............................................................................................................................................. 25
Warnings and Limitations of Use .......................................................................................................................... 25
Location of Safety and Compliance Labels ....................................................................................................... 25
Voltage Warning ............................................................................................................................................... 26
Laser Warning .................................................................................................................................................. 27
Temperature Warning ...................................................................................................................................... 28
Compliance ....................................................................................................................................................... 28
Serial Number, Configuration, Date Code, and Modification Codes ................................................................ 28
ESD Caution ...................................................................................................................................................... 29
Potential for Radio Frequency Interference on Imager Operation ................................................................... 29
Potential for Radio and Television Interference ............................................................................................... 29
Guidance Regarding Electromagnetic Emissions and Immunity ....................................................................... 30
Safety Precautions ............................................................................................................................................ 32
Location Precautions ........................................................................................................................................ 33
Cleaning Precautions ........................................................................................................................................ 34
Media ............................................................................................................................................................... 34
Codonics Paper/White Film Media ................................................................................................................... 35
File Transfer via FTP and LPR ............................................................................................................................ 35
Color Management........................................................................................................................................... 35
Image Scaling .................................................................................................................................................... 35
Hardware Variations ......................................................................................................................................... 35
Disposal Requirements ..................................................................................................................................... 36
European Disposal Requirements .................................................................................................................... 36
Indications for Use............................................................................................................................................ 36
User Manual Warnings and Cautions ............................................................................................................... 37

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Horizon Ci and is the answer not in the manual?

Questions and answers

Related Manuals for Codonics Horizon Ci

Summary of Contents for Codonics Horizon Ci

  • Page 1: Table Of Contents

    Safety Precautions ............................32 Location Precautions ............................33 Cleaning Precautions ............................34 Media ................................34 Codonics Paper/White Film Media ........................35 File Transfer via FTP and LPR ..........................35 Color Management............................35 Image Scaling ..............................35 Hardware Variations ............................35 Disposal Requirements .............................
  • Page 2 Sigurtà Prekawzjonijiet ........................... 392 Post Prekawzjonijiet ............................393 Tindif Prekawzjonijiet ............................. 394 Midja ................................394 Codonics Karta / Abjad Film Midja........................395 Fajl Trasferiment permezz FTP u LPR ......................395 Kulur Ġestjoni ..............................395 Immaġni Skalar ............................... 395 Ħardwer Varjazzjonijiet ..........................396 Rimi Rekwiżiti ..............................

  • Page 3: En - English

    Setup IFU are available in simple translation Member State Languages; primary IFU are available in English. Overview Horizon Ci combines diagnostic film, color paper and grayscale paper printing to provide the world’s most versatile medical imager. Featuring color paper to show off your latest imaging techniques, room light viewable grayscale paper to cut your costs and a compact, counter-top design, Horizon obsoletes film-only imagers.
  • Page 4 Image Control: Gamma, Contrast, Saturation, Medical Color Matching (MCM™), Polarity,Rotation, Scaling, Antialiasing Sheet Control: Density Adjustment (Dmax), Look-Up Tables (LUT), Image Warnings,Captions, Sheet Coverage, Border Color, Border Fill, Crop Anchor Sheet Formatting: 1:1 - 1:81; Variable Multi-Formatting (VMF™), Fixed Multi-Formatting (FMF™) Control Panel: Large, backlit LCD display, Status lights include Online, Alert, Fault, Active Power and Menu navigation buttons Processor: Intel...
  • Page 5  The selector arrow moves up and down through the list. The bottom portion of the control panel display shows a message associated with the currently selected menu option. ation Control Panel Navig Menu paths are used in some procedures instead of documenting every step needed to navigate to a specific menu option.
  • Page 6 Monospaced type is used for the contents of an ASCII file or machine text displayed in a terminal command window. User Data Bold monospaced type is used to indicate specific characters or words that you enter at a host workstation when performing advanced imager operations. If the type is also italicized, it indicates variable text.

  • Page 7: Product Information

    (Catalog no. HORIZON MNLT). The Technical Manual serves as a companion document to this manual Product Information For technical assistance with the Horizon, call Codonics Technical Support at the following number: Phone: +1.440.243.1198 Toll Free: 800.444.1198 (USA only) Technical Support is available anytime. Technical Support is also available online via email and the Codonics web site: Email: support@codonics.com...

  • Page 8: Voltage Warning

    Voltage Warning The exclamation point within an equilateral triangle and person reading a manual symbol are intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying this device. NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

  • Page 9: Laser Warning

    Any person who connects external equipment to signal input, signal output, or other connectors has formed a system and is therefore responsible for the system to comply with the requirements of IEC 60601-1-1. If in doubt, contact a qualified technician or Codonics Technical Support for approved configurations.

  • Page 10: Temperature Warning

    The temperature warning label is shown below. Compliance Codonics is in compliance with various regulations. The Compliance label, which is affixed at the back of the imager, is shown below. Serial Number, Configuration, Date Code, and Modification Codes The Serial number label is placed onto the Compliance label.

  • Page 11: Esd Caution

    ESD Caution Connections to other pieces of equipment are made at the rear of the Horizon imager. These connectors are marked with a precautionary ESD warning symbol, as shown below. Do not touch any of the pins of these connectors. When making connections to the imager, it is best done while the imager is plugged in but not powered on.

  • Page 12: Guidance Regarding Electromagnetic Emissions And Immunity

    • Relocate the imager with respect to the receiver If necessary, you should consult Codonics technical support or an experienced radio/television technician for additional suggestions. You may find the following booklet prepared by the Federal Communications Commission helpful: How to Identify and Resolve Radio-TV Interference Problems.

  • Page 14: Safety Precautions

    Safety Precautions • Never connect this imager to any outlet or power supply that has a voltage or frequency different than that specified on the rear of the imager. • When servicing the imager, always power it off using the (power) key at the control panel, then turn the rocker switch in the back to the 0 (off) position, then unplug the imager.

  • Page 15: Location Precautions

    Damage to the power cord may cause fire or shock hazard. When unplugging the power cord, hold it by the plug only and remove the plug carefully. • If the power cord needs to be replaced, replace it only with another Codonics power cord manufactured specifically for your imager’s power configuration. •...

  • Page 16: Cleaning Precautions

    CAUTION Adequate ventilation is required for proper operation of the imager CAUTION When positioning the Horizon Imager, ensure there is adequate space to access the rear power switch. • Do not place imager in a high humidity or high dust area. Airborne dirt particles can cause image quality problems.

  • Page 17: Codonics Paper/White Film Media

    These variations most often occur in color ribbons and are characterized as a slight color hue in grayscale images. • Codonics film media is designed to be viewed using a light box suitable for viewing medical diagnostic images. •...

  • Page 18: Disposal Requirements

    European Disposal Requirements Codonics imagers and electronic accessory devices are not to be discarded or recycled; rather they are to be returned to the manufacturer. Contact Codonics directly or by the link provided for the latest information concerning: •...

  • Page 19: User Manual Warnings And Cautions

    For information about the approved Codonics media types and sizes, and how to order cassettes, refer to “Ordering Media”. CAUTION Do not refill a cassette. Do not tamper with or remove the barcode label. The cassette’s barcode information is essential for ensuring diagnostic image quality.
  • Page 20 CAUTION Do not remove or insert a cassette while a sheet is being printed, or you could affect the image quality of the printed sheet or cause a jam. Always pause the imager first. CAUTION Do not remove the printed cassette cover; it protects the media from dust and other contaminants.
  • Page 21 WARNING With the receive trays removed, touch only those internal components that are colored green. Remove rings, ties, jewelry, and other items, and tie back hair, so that they do not fall into or get caught in the imager. CAUTION Use only cleaning swabs from a Barcode Reader Cleaning Kit. CAUTION Do not scratch or nick the sheet metal.
  • Page 22 Gwida & Setup IFU huma disponibbli fi sempliċi traduzzjoni Membru Stat Lingwi; primarja IFU huma disponibbli fi Ingliż. Ħarsa ġenerali Horizon Ci tgħaqqad dijanjostiku film, kulur karta u skala tal-griż karta stampar għal jipprovdu il tad-dinja l-aktar versatili mediku immaġinatur. Jidhru kulur karta għal juru mitfi tiegħek l-aktar tard immaġini tekniki, kamra dawl viżibbli skala tal-griż...
  • Page 23 Immaġni Kwalità: Awtomatiku kalibrazzjoni bl-użu inkorporat densitometru Immaġni Kontroll: Gamma, Kuntrast, Saturazzjoni, Mediku Kulur Tqabbil (MCM ™), Polarità, Rotazzjoni, Skalar, Antialiasing Folja Kontroll: Densità Aġġustament (Dmax), Ħares il-fuq Tabelli (LUT), Immaġni Twissijiet, Captions, Folja Għattietà, Fruntiera Kulur, Fruntiera Imla, Ħsad Ankra Folja Ifformattjar: 1: 1 - 1:81;...
  • Page 24  Il selettur vleġġa jiċċaqlaq sa u isfel permezz il lista. Il qiegħ porzjon ta ' il kontroll panel wiri turi a messaġġ assoċjat ma ' il bħalissa magħżula menu għażla. azzjoni Kontroll Panel Navig Menu mogħdijiet huma użat fi xi wħud proċeduri minflok ta ' dokumentazzjoni kull pass meħtieġa għal tinnaviga għal a speċifiku menu għażla.
  • Page 25 Monospazjat tip huwa użat għal il kontenut ta ' an ASCII fajl jew magna test murija fi a terminali kmand tieqa. Utent Dejta Bold monospazjat tip huwa użat għal indika speċifiku karattri jew kliem dak int daħħal fi a ospitanti stazzjon tax-xogħol meta jwettaq avvanzat immaġinatur operazzjonijiet. Jekk il tip huwa ukoll korsiv, dan tindika varjabbli test.
  • Page 26 Manwal (Nru tal-Katalgu.HORIZONMNLT). Il Tekniku Manwal iservi kif a ħbieb dokument għal dan manwali Prodott Informazzjoni Għal tekniku għajnuna ma ' il Horizon, sejħa Codonics Tekniku Appoġġ fi il wara numru: Telefon:+1.440.243.1198 Pedaġġ Ħielsa: 800.444.1198 (L-ISTATI UNITI biss) Tekniku Appoġġ huwa disponibbli ghaċ. Tekniku Appoġġ huwa ukoll disponibbli online permezz email u il Codonics web sit: Email:appoġġ...
  • Page 27 vultaġġ Twissija Il exclamation punt ġewwa an ekwilaterali trijanglu u persuna qari a manwali simbolu huma maħsuba għal twissija il utent għal il preżenza ta ' importanti joperaw u manutenzjoni (manutenzjoni) istruzzjonijiet fi il letteratura akkumpanjament dan apparat. LE SERVIZZABBLI MINN UŻU PARTIJIET ĠEWWA. REFERENZA SERVIZZ LE KWALIFIKAT SERVIZZ PERSONAL.
  • Page 28 LE PREVENI NAR JEW XOKK PERIKLU, DO MHUX JESPONU DAN IMMAĠINATUR LE XITA JEW UMDITÀ. TAGĦMIR MA JINTUŻAX BĦALA KOMPONENT TA 'SISTEMA TA' SOSTENN TAL-ĦAJJA. Apparat jew sistemi ta 'appoġġ għall-ħajja huma apparat jew sistemi li jsostnu jew isostnu l-ħajja, u li n-nuqqas tagħhom li jwettaq jista' jkun raġonevolment mistenni li jirriżulta f'korriment sinifikanti jew mewt lil persuna.
  • Page 29 Il temperatura twissija tikketta huwa murija hawn taħt. Konformità Codonics huwa fi konformità ma ' varji regolamenti. Il Konformità tikketta, liema huwa imwaħħal fi il lura ta ' il immaġni, huwa murija hawn taħt. Serjali Numru, Konfigurazzjoni, Data Kodiċi, u Modifika Kodiċijiet Il Serjali numru tikketta huwa mqiegħda fuq il Konformità...
  • Page 30 ESD Attenzjoni Konnessjonijiet għal oħra biċċiet ta ' tagħmir huma magħmula fi il fuq wara ta ' il Horizon immaġinatur. Dawn konnetturi huma immarkat ma ' a prekawzjonarju ESD twissija simbolu, kif murija hawn taħt. Agħmel mhux tmiss kwalunkwe ta ' il labar ta ' dawn konnetturi. Meta jagħmlu konnessjonijiet għal il immaġni, dan huwa l-aħjar lest waqt il immaġinatur huwa imdaħħal fi iżda mhux imħaddem fuq.
  • Page 31 • Irriloka il immaġinatur ma ' rispett għal il riċevitur Jekk meħtieġ, int għandu ikkonsulta Codonics tekniku appoġġ jew an esperjenza radju / televiżjoni tekniku għal addizzjonali suġġerimenti. Int jista ' sib il wara ktejjeb ippreparat minn il Federali Komunikazzjonijiet Kummissjoni utli: Kif għal Identifika u Issolvi Radju-TV Interferenza Problemi. Dan ktejjeb huwa disponibbli minn il U.S.
  • Page 33 Sigurtà Prekawzjonijiet • Qatt qabbad dan immaġinatur għal kwalunkwe iżbokk jew qawwa provvista dak għandu a vultaġġ jew frekwenza differenti minn dak speċifikat fuq il fuq wara ta ' il immaġinatur.
  • Page 34 Ħsara għal il qawwa korda jista ' kawża nar jew xokk periklu. Meta qtugħ il qawwa korda, żomm dan minn il tapp biss u neħħi il tapp b'attenzjoni. • Jekk il qawwa korda bżonnijiet għal tkun mibdul, ibdel dan biss ma ' ieħor Codonics qawwa korda manifatturati speċifikament għal tiegħek tal-imager qawwa konfigurazzjoni. •...
  • Page 35 • Jekk l-immaġinatur jiġi mċaqlaq malajr minn post estremament kiesaħ għal wieħed iktar sħun, x'aktarx li tifforma l-kondensazzjoni. Tużax l-imager jekk tkun iffurmat il-kondensazzjoni. Stenna sakemm il-kondensazzjoni tevapora. Tista 'tħaffef il-ħin ta' l-evaporazzjoni billi tiċċaqlaq l-immaġinatur għal post li jnixxef. •...
  • Page 36 Dawn varjazzjonijiet l-aktar spiss iseħħu fi kulur żigarelli u huma ikkaratterizzat kif a żgħira kulur lewn fi skala tal-griż immaġini. • Codonics film midja huwa ddisinjat għal tkun meqjusa bl-użu a dawl kaxxa adattat għal wiri mediku dijanjostiku immaġini. •...
  • Page 37 Ewropew Rimi Rekwiżiti Codonics immaġini u elettroniku aċċessorju apparat huma mhux għal tkun mormi jew riċiklat; anzi huma huma għal tkun lura għal il manifattur. Kuntatt Codonics direttament jew minn il rabta ipprovdut għal il l-aktar tard informazzjoni dwar: •...
  • Page 38 MT 50419 simbolu Indikazzjonijiet għal Uża ATTENZJONI Approvat FDA Klassi 2 apparat - Federali liġi jirrestrinġi dan apparat għal tkun mibjugħa għal użu minn jew fuq il ordni ta ' a tabib. Il maħsuba użu ta ' il Horizon Serje Imagers hija immaġini b'kopja iebsa b'riżoluzzjoni għolja ta 'materjal ta' sors ta 'immaġni diġitali u permezz tal-konverżjoni ta' sinjali elettroniċi minn varjetà...
  • Page 39 ATTENZJONI Uża biss Codonics midja. Agħmel mhux użu sempliċi karta, uffiċċju trasparenzi, jew oħra mhux approvat midja kif ħsara, mhux xieraq operazzjoni, jew malfunzjoni jista ' riżultat. Għal informazzjoni madwar il approvat Codonics midja tipi u daqsijiet, u kif għal ordni kasetts, irreferi għal “Ordni Midja ”.
  • Page 40 TWISSIJA Ma ' il immaġinatur għata miftuħ, tmiss biss dawk intern komponenti dak huma ikkulurit aħdar. Neħħi ċrieki, rabtiet, dehbijiet, u oħra oġġetti, u tie lura xagħar, hekk dak huma agħmel mhux jaqgħu ġo jew ġib maqbuda fi il immaġinatur. TWISSIJA Il termali jistampa ras jista ' tkun jaħraq.
  • Page 41 ATTENZJONI Uża kura meta ġiri il Tnaddaf Stampa Impjiegi funzjoni. Dan funzjoni se tnaddaf oħra utenti jistampa impjiegi kif tajjeb kif tiegħek. ATTENZJONI Kollha fajls ttellgħet bl-użu anonimu FTP huma tinqara minn oħra FTP utenti. DO MHUX ittella ' sensittiv jew klassifikati informazzjoni.
