Specifications
Write Multiple Holding Registers
Read Device Identification
Coils
Device Resource
Power/Output/eFuse
Discrete Inputs
Device Resource
DC Inputs
Stop Condition active
POE active
Status Power Sources
OVP active (Line-Ins)
eFuse Error
Status Power Sources
EPC 8221 / 8226
ENC 2111 / 2191
ESB 7213 / 7214
Input Registers
Device Resource
Info Bereich
CPU Sensor values
Externe Sensoren
Fan Level
Line Energy Sensors
Port Energy Sensors
Bank Energy Sensors
Power Source Sensors
Info Area
Address
0
1
2
3
4
5
Sensor Type Description
87
Expert Power Control 8021/8025
0x10
0x2B / 0x0E
Start End Device Function
0x000 0x3ff Coil represens Port State
Start End Function when set
0x400 0x7ff Input logically 1
0x800 0x800 Stop Input active
0x801 0x801 POE active
0x1000 0x100f Power Source active
0x1010 0x101f OVP active
0x1100 0x11ff eFuse Error
0 = Bank A, 1 = Bank B
0 = Pwr1, 1 = Pwr2
0 = Pwr1, 1 = Pwr2 (only 7214)
Start End Function
0x000 0x005 see table
0x080 0x083 see table
0x100 0x1ff see table
0x200 0x20f 0 (aus) bis 3 (maximal)
0x400 0x39ff see table
0x3a00 0x81ff see table
0x8200 0x823f see table
0x8240 0x827f see table
Width Information
16-bit Number of Ports (Relay)
16-bit Number of Ports (Outlets) with
Energy Measurement
16-bit Number of Banks
16-bit Number of Line-In
16-bit Phases per line
16-bit Number of Inputs
Offset
