Sensor - Gude Expert Power Control 8021 Series Manual

Device Description
Category
Voltage
Current
Frequency
Phase
Active power
Reactive power 0 - 4000
Apparent power 0 - 4000
Power factor
Active Energy
(total)
Active Energy
(temporary)
1.7

Sensor

Two external sensors can be connected to the Expert Power Control 8021/8025.
The following sensors are currently available
Cable length
Connector
temperature range
air humidity range
(non-condensing))
11
Expert Power Control 8021/8025
Electrical Measurement Specification
Range Unit
90-265 V
0 - 16 A
45-65 Hz
-180 - +180 °
0 - 4000 W
Var
VA
0 - 1 -
Energy Counter
9.999.999,999 kWh
9.999.999,999 kWh
Humidity/Temperature Sensor 7102 (End-of-Life)
RJ45
-20°C to +80°C, ±0,5°C (maximum) and ±0,3°C (typical)
0-100%, ±3% (maximum) and ±2% (typical)
Resolu- Inaccuracy
tion (typical)
0.01 < 1%
0.001 < 1.5%
0.01 < 0.03%
0.1 < 1%
1 < 1.5%
1 < 1.5%
1 < 1.5%
0.01 < 3%
0.001 < 1.5%
0.001 < 1.5%
