Zephyr Milano Use, Care And Installation Manual page 12

Installation Instructions
Front of Hood
12-13/16"
8-3/8"
23-15/16"
35-5/16"
12
Top of Hood
AC In
Milano Use, Care, and Installation Guide
Side of Hood
13-5/8"
STANDARD
min. ducted - 26-
min. recirc. - 31"
max. - 50"
Z1C-01MI
min. ducted - 42"
min. recirc. - 46"
max. - 80"
20-1/2"
C O R E
M I L A N O
WA L L
"
1/2
