Cutting bar S30 2018 1
Operator's Manual for Attachment
Cutting bar S30
Product number:
A430938
www.avanttecno.com
A436907 2018 1 EN 2018-

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CUTTING BAR S30 and is the answer not in the manual?

Questions and answers

Related Manuals for AVANT CUTTING BAR S30

Summary of Contents for AVANT CUTTING BAR S30

  • Page 1 English Cutting bar S30 2018 1 Operator's Manual for Attachment Cutting bar S30 Product number: A430938 www.avanttecno.com A436907 2018 1 EN 2018-...
  • Page 2 Cutting bar S30 2018 1...

  • Page 3: Table Of Contents

    Cutting bar S30 2018 1 CONTENTS 1. FOREWORD ............................4 Warning symbols used in this manual ..........................5 2. DESIGNED PURPOSE OF USE ......................6 3. SAFETY INSTRUCTIONS FOR USING THE ATTACHMENT ............7 4. TECHNICAL SPECIFICATIONS ......................11 Safety labels and main components of the attachment.................. 11 5.

  • Page 4: Foreword

    If you sell or transfer the equipment, be sure to hand over this manual to the new owner. If the manual is lost or damaged, you can request a new one from your Avant dealer or from the manufacturer.

  • Page 5: Warning Symbols Used In This Manual

    5 (30) Warning symbols used in this manual The following warning symbols are used throughout this manual. They indicate factors that must be taken into account to reduce the risk of personal injury or damage to property: WARNING: SAFETY ALERT SYMBOL This symbol means: “Warning, be alert! Your safety is involved!”...

  • Page 6: Designed Purpose Of Use

    The Cutting bar S30 is not designed for any other use than what is specified in this manual and must not be used for any other purposes than intended.

  • Page 7: Safety Instructions For Using The Attachment

    7 (30) 3. Safety instructions for using the attachment Please bear in mind that safety is the result of several factors. The loader-attachment combination is highly powerful and improper or careless use or maintenance may cause serious personal injury or property damage.
  • Page 8 8 (30)  Never leave the driver’s seat when the attachment is running or if the auxiliary hydraulics control lever is locked on. The blades move for a short period after the hydraulic supply has been shut off. Wait until the blades have stopped completely before going near the attachment.
  • Page 9 9 (30) Stuck blade can move and cut when removed blockage - Risk of cutting and severing. Never perform any cleaning, maintenance, service, or adjustment tasks if the loader engine is running or if the auxiliary hydraulics is locked on. Blade bar that has DANGER become stuck may move unexpectedly when removing a blockage because of residual pressure left in the hydraulic systems may cause cutting motion, creating severing...
  • Page 10 Prevent starting of the machine, remove ignition key. Observe the local regulations concerning the use of the equipment on public roads. The loader may need to be registered for road use. Contact your local Avant dealer or local authorities for more information.

  • Page 11: Technical Specifications

    11 (30) 4. Technical specifications Table 2 - Cutting bar S30 - Specifications Product number A430938 Working width: 1500 mm Total width, blade horizontal: 1600 mm Side reach (from middle of quick coupling plate): 1280 mm Height in transport position...
  • Page 12 Operate attachment only from the driver’s seat. A431012 Attachment identification plate Table 4 - Cutting bar S30 - Main components S30 Quick coupling for side arm Hydraulic motor Blade bar, 19 blades Blade cover Wear plate Adjusting disc...

  • Page 13: Assembling The Attachment

    1. Make sure the side arm or the hydraulic boom is connected and locked to the loader. The hydraulic and electric connectors must also be coupled. 2. Open the S30 coupling of the side arm with the Allen key that is stored at the Avant quick coupling plate of the side arm.
  • Page 14 If your loader is not listed in Table 1 on page 6, ask your Avant dealer before using this attachment.

  • Page 15: Connecting And Disconnecting Hydraulic Hoses

    Follow safe stopping procedure before disconnecting hydraulics. The hydraulic connectors of the Cutting bar S30 fit to the outlets of the mechanical A431070 or hydraulic A424552 side arm. All three couplings must be connected to prevent damage to the hydraulic motor.
  • Page 16 16 (30) Disconnecting hydraulic hoses: Before disconnecting the fittings, lower the attachment to safe position on solid and level surface. Turn the control lever of the auxiliary hydraulics to its neutral position. When uncoupling the attachment, always disconnect the hydraulic couplings before unlocking the quick coupling, to prevent hose damage and any oil spills.

  • Page 17: Instructions For Use

    17 (30) 6. Instructions for use Check the attachment and the operating environment once more before starting to work, and that all obstacles have been removed from the operating area. Quick inspection of the equipment and the operating area before use are parts of ensuring safety and the best performance of the equipment.

  • Page 18: Checks Before Use

    18 (30) 6.1 Checks before use Check that all obstacles, including any possibly hidden ones, have been removed from the working  area or marked visibly before operation. Check before each work shift that the bar and its blades are in full working condition. Never use if ...

  • Page 19: Using The Cutting Bar

    If you do not have the relevant manuals, do not use the cutting bar. Contact your Avant dealer or service point for another copy of the manual. Operate the controls of the loader and its attachment in a careful and smooth manner. Always avoid sharp turns and sudden changes in speed or direction whenever using the cutting bar for the best stability of the loader.
  • Page 20 20 (30) Recommended operating speed and maximum allowed oil flow: Adjust engine RPM so that the loader's auxiliary hydraulic flow is within the specified range for the  cutting bar. Too little flow will not move the blades fast enough for good cutting results. Correct flow makes sure that the blades move fast enough for a good finish.

  • Page 21: Working On Uneven Ground

    21 (30) 6.3 Working on uneven ground Extra caution is needed when using the equipment on inclined terrains and slopes. Drive slowly especially on inclined, uneven, or slippery surfaces, and avoid sudden changes in speed or direction. Operate the controls of the loader with careful and smooth movements.

  • Page 22: Transport Position

    22 (30) 6.5 Transport position When driving with the loader, keep the cutting bar lifted off the ground and tilted sideways, as shown in the adjacent figure. Also keep the hydraulic boom completely retracted during transport. For safety, it is recommended to disconnect the auxiliary hydraulics outlet during transport drive.

  • Page 23: Uncoupling And Storage

    23 (30) 6.6 Uncoupling and storage Uncouple and store the attachment on level ground. The best way to store the attachment is a place where it is protected from direct sunlight, rain, and extreme temperatures.  Avoid leaving the attachment laying directly on the ground for long periods of time. Place it on blocks of wood or on a pallet, for example.

  • Page 24: Storage Of Uncoupled Cutting Bar

    24 (30) 6.6.2 Storage of uncoupled cutting bar When storing the cutting bar for longer periods than temporary uncoupling from the loader, the cutting bar should be disconnected from the side arm and stored separately. Avoid leaving the attachment laying directly on the ground. Place it on blocks of wood or on a pallet, for example.

  • Page 25: Maintenance And Service

    Finding any fault means that the hydraulic hose or component must be replaced and the equipment must not be used until it is repaired. Spare parts are available from your nearest AVANT retailer or authorised service point. Leave the repair work to professional service technicians, if you don’t have adequate knowledge and experience about hydraulic assemblies and how to perform the repairing safely.

  • Page 26: Cleaning The Attachment

    26 (30) 7.2 Cleaning the attachment Clean the attachment regularly to prevent accumulation of dirt which is more difficult to remove. A pressure washer and mild detergent can be used for cleaning. Do not use strong solvents, and do not spray directly at the hydraulic components, or at the labels on the attachment.

  • Page 27: Mower Blades

    27 (30) 7.5 Mower blades There are a total of 19 blades, product number 65810. Their teethed edges help to retain good cutting properties over a long time. Damaged blades can be replaced, and also blade guides should be checked and replaced as necessary.

  • Page 28: Warranty Terms

    28 (30) 8. Warranty terms Avant Tecno Oy grants a warranty of one year (12 months) from the date of purchase for the attachment it manufactures. The warranty covers repair costs as follows:  Work costs are covered, if the repair is not performed at the factory.
  • Page 29 SFS-EN ISO 12100, SFS-EN ISO 4413 Mallit / Modeller / Models Avant Hydraulitoiminen palkkiniittokone; Avant-kuormaajan työlaite Hydraulisk slåtterbalk; arbetsredskap för Avant lastare A430938 Hydraulic cutting bar; attachment for Avant loaders 16.7.2019 Ylöjärvi, Finland Risto Käkelä, Toimitusjohtaja / Verkställande direktör / Managing Director...
