Horse Arena Harrow 2015 1
Operator's Manual for Attachment
Horse Arena Harrow
Product number
A21646
Please read this ma nual carefully before using the equipment ,
and follow all instructions.
Keep this ma nual for later reference.
www.avanttecno.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A21646 and is the answer not in the manual?

Questions and answers

Related Manuals for AVANT A21646

Summary of Contents for AVANT A21646

  • Page 1 Horse Arena Harrow 2015 1 Operator's Manual for Attachment Horse Arena Harrow Product number A21646 Please read this ma nual carefully before using the equipment , and follow all instructions. Keep this ma nual for later reference. www.avanttecno.com...
  • Page 2 Horse Arena Harrow 2015 1 1797 2219...

  • Page 3: Table Of Contents

    Horse Arena Harrow 2015 1 CONTENTS 1. Foreword ................................. 4 2. Designed purpose of use ..........................5 3. Safety instructions for using the harrow ....................... 6 4. Technical specifications ..........................8 4.1 Safety labels and main components of the attachment ......................8 5.

  • Page 4: Foreword

    If you sell or transfer the equipment, be sure to hand over this manual to the new owner. If the manual is lost or damaged, you can request a new one from your Avant dealer or from the manufacturer.

  • Page 5: Designed Purpose Of Use

    The Horse arena harrow A21646 does not require rear hydraulic outlet on the loader, and only rear tow hitch ball is needed. The harrow is intended for levelling all soft materials generally used at horse arenas or similar areas.

  • Page 6: Safety Instructions For Using The Harrow

    6 (14) 3. Safety instructions for using the harrow Please bear in mind that safety is the result of several factors. The loader-attachment combination is highly powerful and improper or careless use or maintenance may cause serious personal injury or property damage.
  • Page 7 7 (14) Safe parking of the attachment, before leaving the loader or the attachment unattended Always set the attachment to a safe position before going near the attachment. Safe position will prevent unintentional movements of the attachment. Safe position:  Lower the boom completely down (and lower any attachment possibly fitted on the loader boom on the ground).

  • Page 8: Technical Specifications

    Product number A21646 Working width: 1530 mm Other dimensions: See overview Weight: 166 kg Suitable AVANT loader: See Table 1 Options: A36593 Transport wheel kit: See chapter 5.3 A35957 31 kg each, max 4 pcs Additional weights: See chapter 5.4 4.1 Safety labels and main components of the attachment...
  • Page 9 9 (14) Table 3 – Decal warning messages and locations Label Warning message 1 A46771 Read instructions before use. 2 A46803 Crushing hazard, moving components. Keep clear of moving parts. Identification plate Table 4 - Main components of the Horse Arena Harrow Trailer coupling, 50 mm ball hitch Nose wheel Towbar adjustment...

  • Page 10: Using The Horse Arena Harrow

    10 (14) 5. Using the Horse Arena Harrow Check the attachment and the operating environment once more before starting to work, and that all obstacles have been removed from the operating area. Quick inspection of the equipment and the operating area before use are parts of ensuring safety and the best performance of the equipment.

  • Page 11: Support Wheels (Optional Extra)

    11 (14) 4. Adjust the leveller height: A: The leveller can be set to either locked position, by sliding the pin through the slot A. B: On some materials, a floating position for the leveller may work better (B). Place the pin above the slot.

  • Page 12: Extra Weights (Optional Extra)

    12 (14) 5.4 Extra weights (optional extra) Some materials may require more weigh on the harrow for the best result. Typically more dense or easily compacted materials mix better and with better finish when counterweights are added. The same counterweights (A35957) can also be used as counterweights on the loader. Fit the counterweights as a pair and secure them with bolts at both ends.

  • Page 13: Warranty Terms

    13 (14) 7. Warranty terms Avant Tecno Oy grants a warranty of one year (12 months) from the date of purchase for the attachment it manufactures. The warranty covers repair costs as follows:  Work costs are covered, if the repair is not performed at the factory.
