Campbell Hausfeld RN164500 Operating Instructions Manual

Manual de Instrucciones
Notas
Modelo RN164500
8-Sp
Operating Instructions
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury, death
and/or property damage! Retain instructions for future reference.
BUILT TO LAST
EMPLOYER'S RESPONSIBILITY:
Table Of Contents
Distribute this instruction manual to all
General Safety . . . . . . . . . . . . . . . . .1-2
users before allowing use of the nailer.
Specifications . . . . . . . . . . . . . . . . . . . .2
Ensure all operators read, understand
Contact Trip Safety Mechanism . . . . .3
and follow all safety warnings, labels
Operating The Nailer . . . . . . . . . . . .3-5
and instructions outlined in this manual.
Troubleshooting . . . . . . . . . . . . . . . . .6
Warranty . . . . . . . . . . . . . . . . . . . . . . .7
Description an imminently hazardous situation
which, if not avoided, will result in
This nailer is designed for roofing
death or serious injury.
(asphalt and fiberglass shingles), reroof-
G Do not use any type of
ing, and sheathing installation. Features
flammable gases or
include: convenient top loading maga-
oxygen as a power
zine which holds up to 120 nails, an
source for the nailer.
adjustable shingle guide, a rubber han- Use filtered, lubricated,
regulated compressed air only. Use
dle grip, an adjustable depth of drive
of a compressed gas instead of
mechanism and adjustable exhaust.
compressed air may cause the nailer
General Safety Information
to explode which will cause death
or serious personal injury.
This manual contains safety, operational
G
Do not exceed maxi-
and maintenance information.
mum operating pressure
Read this manual and under-
of the nailer (120 psi).
stand all safety warnings and
The nailer will not func-
instructions before operating
MANUAL
tion properly. Do not
the nailer. Contact your
use a compressed air
Campbell Hausfeld represen-
source capable of more than 200 PSI.
tative if you have any questions.
The nailer could explode which will
cause death or serious personal injury.
CALIFORNIA PROPOSITION 65
G
Never use gasoline or
other flammable liquids
to clean the nailer.
You can create dust when you
Never use the nailer in
cut, sand, drill or grind materi-
the presence of flam-
als such as wood, paint,
metal, concrete, cement, or other mason- mable liquids or gases. Vapors could
ry. This dust often contains chemicals ignite by a spark and cause an
known to cause cancer, birth defects, or
explosion which will result in death
other reproductive harm. Wear protec-
or serious personal injury.
tive gear.
G Always remain in a
firmly balanced posi-
Excessive
tion when using or
exposure to vibration, working in awk-
handling the nailer.
ward positions and repetitive work
motions can cause injury to hands and
G
Do not modify or
arms. Stop using any tool if discomfort,
disable the Work
numbness, tingling or pain occur and
Contact Element
consult a physician.
(WCE). Do not tie or
OPERATOR'S RESPONSIBILITY:
tape the WCE or
trigger in a
Before operating the nailer, read and
depressed position.
understand all safety warnings and
Death or serious personal injury
labels. Follow the operating instruc-
could result.
tions outlined in this manual.
Campbell Hausfeld Nailers meet or exceed Industries' Standards as set forth by the American National
Standard Institute/International Staple, Nail and Tool Association in ANSI/ISANTA SNT-101-2007.
© 2007 Campbell Hausfeld
Model RN164500
Coil Roofing
Nailer
Danger
indicates
Model RN164500
O
CO
2
Locate model and serial number on
tool and record below:
Model No. ________________________
Serial No. _________________________
Retain these numbers for
future reference.
120 psi
G Do not touch the trig-
MAX.
ger unless driving nails.
Never attach air line to
nailer or carry nailer
while touching the
trigger. The tool could
eject a fastener which will result in
death or serious personal injury.
Warning
indicates
a potentially hazardous situation
which, if not avoided, COULD result in
death or serious injury.
G
Always discon-
nect nailer from
air line before
clearing jams,
adjusting or ser-
vicing the nailer, relocating the
nailer, or when the nailer is not in
use. Always reconnect the air line
BEFORE loading any fasteners. The
nailer could eject a fastener causing
death or serious personal injury.
G
Protect your eyes and
ears. Wear Z87 safety
glasses, with side
shields. Wear hearing
IN718600AV 3/07
