- Page 1 PRA518 GOOSENECK CONDENSER MICROPHONE Contact Marketing and sales Goang-Fann Co., Ltd. +886-2-26931323 sales@superlux.com.tw support@superlux.com.tw Manufacturing & logistics Superlux Enterprise Development ( Shanghai ) Co., Ltd. English...
- Page 2 CONDENSER MICROPHONE DESCRIPTION Mini back electret gooseneck condenser conference microphone PRA518 provides the frequency response and cardioid directivity for conference application. There are 5 versions to choose from: full bend, double bend or single bend, 30, 45 or 60 cm on length.
-
Page 3: Specifications
PRA518 FREQUENCY RESPONSE (CARDIOID) PRA518 SPECIFICATIONS Type Back electret, Ø6mm（Ø0.24"） Polar Pattern Cardioid Frequency Response 50-16,000Hz Sensitivity -39 dBV/Pa（11.2 mV/Pa） Output Impedance 200 Ω S/N Ratio 68 dB Min. Load Impedance 1,000 Ω Equivalent Output Noise 26 dB Max. SPL... - Page 4 DIMENSIONS PRA518AS PRA518AM PRA518AL...
- Page 5 PRA518BM PRA518BL Unit:mm / in.
- Page 6 ASSEMBLING DIAGRAM HM22 HM23 SHIELD RED(+) BLACK (-) BLAC K (-) BLAC K (- ) RED(+ ) RED(+) SHIELD SHIELD HM24 HM24C...
-
Page 7: Knowing Your Microphone
ASSEMBLE DIMENSIONS Ø74mm Ø20mm Ø20mm Ø50mm Ø74mm HM22 HM23 Unit:mm KNOWING YOUR MICROPHONE Type of transducer Condenser With an extremely light weight diaphragm, it is very sensitive to sound. Very small versions are available for hidden applications. High performance condenser microphones are regarded as standard equipment in recording studios for extreme detail capturing. -
Page 8: Supplied Accessories
SUPPLIED ACCESSORIES HM22 Windscreen Mounting Screw Foam Flange OPTINAL ACCESSORIES HM23 DS002 Shock Mount Gooseneck Flange Mic Base K3F2 GT6F XLR3F Socket XLR3F Flange HM24 HM24C XLR3F Flush Socket XLR3F Flush Socket With Open End Cable with XLR3M Connector... -
Page 9: Limited Warranty
Enterprise, request by distributor without authorized, or the serial number sticker on Superlux product is unidentified, modified, or removed. All repair of Superlux products can only accept from re- pair centre, distributor or agent which authorized by Superlux. Un- authorized repair, maintenance and modification will not receive relevant warranty and will be excluded in the warranty.
