We open up New Horizons
COMBINED
The Wizard-C
SAFETY &
activation and safety for an automatic sliding door system. For activation, the unit provides digitally processed and sophisticated
ACTIVATION
motion tracking technology for unidirectional sensing when energy conservation is critical. For safety, the unit emits 2 rows of 24
SENSOR
beams of focused presence technology that provides extraordinary safety. The active infrared remains active even when the door
is closing. Serial numbers 52000 and greater provide the added ability for an "ALL RELAY" output, making it compatible with older
non-microprocessed control boxes.
TECHNICAL
DESCRIPTION
SPECIFICATIONS
Supply voltage
Power frequency
Power consumption
Mounting height
SMR data input
Delay of the output activation after stimulation
3-color LED
Temperature range
Degree of protection
Product conformity
Dimensions
Weight
Housing material
Color of Housing
Cable length
Technology
Detection field (standard)
Detection mode
Angle :
Output specification
Output hold-time
Manual adjustment
Remote control adjustments
75.5101 V1 Sep. 2003 [Rev. 9/22/2003]
USERS GUIDE
COMBINED ACTIVATION & SAFETY SENSOR
(PN:10WIZARDC) combines k-band microwave and focused active infrared technology to provide superior
PRELIMINARY
• Standard
• High
MOTION SENSOR
Microwave and microprocessor
Transmitter frequency :24.125 GHz
Transmitter radiated power : <20 dBm EIRP
Transmitter power density : < 5 mW/cm²
• Wide field
13'0" W x 6'6" D
• Narrow field
6'6" W x 8'2" D
Minimum detection speed
2 inches / sec. (measured in the sensor axis)
from 15° to 50° in elevation (adjustable)
Relay (free of potential change-over contact) :
• Max contact voltage : 42V AC/DC
• Max contact current : 1A (resistive)
• Max switching power : 30W (DC) / 60VA (AC)
0.5s to 9s (adjustable)
• orientation of sensing field (mechanically)
• shape of the sensing field (choice of antenna)
• multiple functions (using push buttons).
• Sensitivity.
• Hold time.
• Detection mode.
• Immunity
• Output configuration.
WIZARD-C
SPECIFICATION
12 to 24 VAC / VDC: -5% to +10%
50 / 60 Hz
< 3 W
5'9" to 8'2"
8'2" to 13"
10 to 30 V DC
transistor : < 1ms
• RED :
presence detection
• GREEN : motion detection
• ORANGE :monitoring process
-30°F to +131°F
NEMA 3S / (IP54)
R&TTE 1999/5/EC & EMC 89/336/EEC
BZT Germany, TÜV
10.4 " x 2.2 " x 1.9 "
.55 lbs / 250 g
ABS & LURAN S
Anthracite gray (standard), aluminum or white finish
8' of six-conductor cable
PRESENCE SENSOR
Focused active infrared and
Self-monitored microprocessor
Spot diameter (standard) : 4" max
Number of spots : 24 or 12 spots by
curtain
Number of curtains : 2
6'6" W x 13.75" D
3'3" W x 13.75" D
Response time : < 128ms
from - 4° to + 4° (adjustable)
Transistor (optocoupled transistor)
• Max output current : 100 mA
• Max switching power : 48 V DC
1s (fixed)
• orientation of sensing field
• shape of the sensing field (choice of
front lens)
• multiple functions (by push buttons).
• Sensitivity.
• Auto-learn time
• Monitoring mode
• Number of Curtains
• Relay / Transistor configuration
• Rain Mode
• Snow Mode
Page 1 of 16
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for BEA WIZARD-C
Summary of Contents for BEA WIZARD-C
- Page 1 COMBINED ACTIVATION & SAFETY SENSOR We open up New Horizons COMBINED The Wizard-C (PN:10WIZARDC) combines k-band microwave and focused active infrared technology to provide superior SAFETY & activation and safety for an automatic sliding door system. For activation, the unit provides digitally processed and sophisticated ACTIVATION motion tracking technology for unidirectional sensing when energy conservation is critical.
- Page 2 COMPONENT ID CABLE I.R. REMOTE RECEIVER COVER LED INDICATOR ANTENNA STORAGE MANUAL SET-UP MOUNTING SCREWS BUTTONS MOTION SENSOR PRESENCE SENSOR FRONT LENSES ESD PRECAUTION Circuit board components are vulnerable to damage by electrostatic discharge (ESD). ESD can cause (ELECTRO-STATIC immediate or subtle damage to sensitive electronic parts. An electrostatic charge can build up on the DISCHARGE) human body and then discharge when you touch a board.
-
Page 3: Electrical Installation - Wiring
ELECTRICAL With Wizard in place, locate the enclosed cable and feed the stripped end through the wire passage INSTALLATION hole in header from the Wizard side as shown in Picture (F). Leave enough slack to allow connection to the Wizard and proper routing of wire around the plastic posts (E). Please observe proper routing of the cable as shown –... -
Page 4: Mechanical Adjustments
MECHANICAL ADJUSTMENTS Insert the desired microwave planar antenna for a narrow or wide field of detection. Refer to the diagram below for approximation of field size for each pattern. WIDE NARROW 7’-0” height = [13’ (W) X 6’ 6” (D)] [6 6”... - Page 5 +4° to –4°. At the standard mounting height, one complete clockwise turn of the adjustment screw will move the pattern approximately 3 inches closer to the door. The precise location of the infrared beam may be found by using the BEA Spot-finder (PN: 10SPOT) after the Wizard has been powered up. DOOR HEADER -4°...
- Page 6 WIZARD SMR All program changes and inquiries can only be accomplished while the Wizard is unlocked. PROGRAMMING GUIDE – LOCKING & UNLOCKING USER’S ACTIONS DEFAULT LED STATUS UNLOCK Press the UNLOCK key once, then enter 0000 The red LED will flash quickly after your 4-digit code to unlock the Wizard.
- Page 7 SN 52000 and greater. SMR (Self-Monitoring Ready) mode is After pressing the SMR key, the red enabled for the use with BEA’s DCU (Door LED flashes quickly. After pressing a Control Unit). It is disabled for all other number button, the red LED flashes applications.
- Page 8 The Snow Mode is designed to minimize the effect of heavy snow on the Wizard’s auto-learn requirements. Snow Mode may only be enabled by performing the following: 1. Using the BEA remote control, Unlock the Wizard as described in the programming guide. + unlock code, if necessary.
-
Page 9: Manual Setup
The Snow Mode is designed to minimize the effect of heavy snow on the Wizard’s auto-learn requirements. CANADIAN Snow Mode may only be enabled by performing the following: Using the BEA remote control, Unlock the Wizard as described in the programming guide. + unlock code, if necessary. Set Infrared Sensitivity to LOW (1). - Page 10 MANUAL SET-UP PARAMETER NUMBER PARAMETER VALUES DEFAULT (without remote) (altered by the right button and (altered by the VALUE confirmed by GREEN LED) left button and confirmed by RED LED) Radar Sensitivity Relay hold time Output configuration Auto-learn presence sensing Detection mode Immunity IR sensitivity...
- Page 11 Red LED flashes for approx. 1. Infrared curtains are too close to 1. Adjust Infrared curtain as necessary. Use of BEA’s 10 seconds when attempting a the door and the sensor detects a Spotfinder during this process is recommended.
- Page 12 Adjust infrared curtain and launch a new set- Wizard will not respond to Improper SMR setting 1. If the Wizard is NOT being used with a BEA motion. DCU, set SMR to a value of 0. See page 8. ACCESSORIES •...
- Page 13 ADDENDUM 1 – The purpose of the addendum is to accommodate for the differences in the Standard Rocker Switch package and the WIZARD WITH Rotary Switch package. The standard wiring provided with the Rotary Switch Package is incompatible when using the STANLEY partial opening switch selection with the Wizard sensor system.
- Page 14 ADDENDUM 2 – WIZARD WITH BESAM AMD-II Page 14 of 16 75.5101 V1 Sep. 2003 [Rev. 9/22/2003]...
- Page 15 ADDENDUM 3 – WIZARD WITH BESAM UNI-SLIDE GREEN GREEN WHITE WHITE BLUE BLUE Page 15 of 16 75.5101 V1 Sep. 2003 [Rev. 9/22/2003]...
- Page 16 ADDENDUM 4 – WIZARD WITH DOR-O-MATIC 96K SLIDER GREEN WHITE BLUE GREEN WHITE BLUE Page 16 of 16 75.5101 V1 Sep. 2003 [Rev. 9/22/2003]...
