SET COMMUNICATION:

This section define the fundamental communication parameters of two buses, OPC UA and
DeviceNet.
By Pressing the "Set Communication" button from the main window for SW67B14 (Fig. 2)
the window "Set Communication" appears (Fig. 3).
The means of the fields for "OPC UA Client" are:
In the field "IP Address" the IP address for OPC UA side of the converter is defined;
In the field "SubNet
defined;
In the field "Gateway" the default gateway of the net is defined. This feature can be
enabled or disabled pressing the Check Box field. This feature is used for going out
of the net;
In the field "DNS" the IP Address of the DNS server is defined. This feature can be
enabled or disabled pressing the Check Box field.
The means of the fields for "DeviceNet Slave" are:
In the field "ID Device" the ID of DeviceNet side is defined;
In the field "Baudrate" the data rate of DeviceNet bus is defined;
In the field "Number Byte
(max 455 bytes);
In the field "Number Byte
defined (max 455 bytes).
The means of the fields for "NTP (Network Time Protocol)" are:
In the field "Server URL" the URL or the IP Address of the NTP Server is defined;
In the field "Poll Time
defined.
ADFweb.com Srl – IT31010 – Mareno – Treviso
Mask" the SubNet Mask for OPC UA side of the converter is
IN" the number input bytes of DeviceNet Slave is defined
OUT" the number output bytes of DeviceNet Slave is
(seconds)" the polling time for the time synchronization is
User Manual OPC UA Client / DeviceNet Slave
Document code: MN67B14_ENG Revision 1.000
Figure 3: "Set Communication" window
