3.6

STORAGE TANK UNIT

The indoor unit is prepared for connection to a storage tank unit,

which must be connected to terminals 37 and 38 of the terminal

board (placed inside the connections compartment), eliminating

resistance R8.

3.7

The indoor unit has a filter on the system return cock to keep the

system in good operating conditions.

Periodically and when necessary, the filter can be cleaned as de-

scribed below (Fig. 64).

Close the tap (3) with a size 12 spanner and tap (5) by hand, drain

out the water contained in the indoor unit using the draining

valve (4).

Open the cap (1) and clean the filter (2).
