All the components are supplied in particular hardware and software configurations appropriate for the application. Modifications to hardware or software configurations other than those described in the documentation are not permitted, and nullify the liability of Beckhoff Automation GmbH & Co. KG. Personnel qualification This description is only intended for trained specialists in control, automation and drive engineering who are familiar with the applicable national standards.
Foreword Documentation Issue Status Version Comment 1.0.0 • Technical data and cover picture updated • Technical data updated • First preliminary version ELX3252 Version: 1.0.0...
• Beckhoff Traceability Number, or BTN for short (as a serial number it clearly identifies each terminal) Date code The date code is an eight-digit number given by Beckhoff and printed on the ELX terminal. The date code indicates the build version in the delivery state and thus identifies an entire production batch, but does not distinguish between the terminals in a batch.
Foreword Beckhoff Traceability Number (BTN) In addition, each ELX terminal has a unique Beckhoff Traceability Number (BTN). Ex marking The Ex marking can be found at the top left on the terminal: II 3 (1) G Ex ec [ia Ga] IIC T4 Gc...
Fig. 4: ELX3252 - Two channel analog intput terminal for potentiometers, 16 Bit, Ex i The ELX3252 analog input terminal is suitable for operation in zone 2 and in not explosive areas. It allows the direct connection of potentiometers located in hazardous areas classified Zone 0/20 or 1/21. A stabilized power supply via power contacts of the ELX9560 power supply terminal and the ratiometric measurement of the input voltage offer the preconditions for precise measurement.
Product overview Technical data Technical data ELX3252-0000 Technology ratiometric potentiometer evaluation, potentiometer supply by the terminal Number of inputs Connection technology 3-wire Supply voltage for potentiometer max. 4.94 V Measuring range potentiometer 300 Ω … 40 kΩ Resolution 16 bit (incl. sign) Measuring error <...
The ELX components may only be used in accordance with the ATEX directive and the IECEx scheme! The ELX terminals extend the field of application of the Beckhoff bus terminal system with functions for integrating intrinsically safe field devices from hazardous areas. The intended field of application is data acquisition and control tasks in discrete and process engineering automation, taking into account explosion protection requirements.
Special conditions of use for ELX terminals WARNING Observe the special conditions of use for the intended use of Beckhoff ELX terminals in potentially explosive areas (ATEX directive 2014/34/EU)! • The certified components are to be installed in a suitable housing that guarantees an ingress protection of at least IP54 in accordance with EN 60079-0 and EN 60529! The prescribed environmental conditions...
Page 16
1 to 8 on the left above the respective terminal point as well as via the laser image. Observe any possible polarity dependency of connected intrinsically safe circuits! Version: 1.0.0 ELX3252...
• The last terminal of each ELX segment is to be covered by an ELX9012 bus end cover, unless two ELX9410 power supply terminals are installed in direct succession for continuing the same terminal seg- ment with standard Beckhoff EtherCAT terminals (e.g. EL/ES/EK)! Examples for the arrangement of ELX terminals Fig. 5: Valid arrangement of the ELX terminals (right terminal block).
Fig. 9: Invalid arrangement - missing ELX9560 power supply terminal. Fig. 10: Invalid arrangement - terminal that does not belong to the ELX series within the ELX terminal segment. Fig. 11: Invalid arrangement - second ELX9560 power supply terminal within the ELX terminal segment without an upstream ELX9410. Version: 1.0.0 ELX3252...
ELX9560 power supply terminal in accordance with the specified technical data. If required, an additional power supply terminal ELX9560 with an upstream ELX9410 connected (see mounting examples) must be installed or a completely new terminal block must be assembled. ELX3252 Version: 1.0.0...
• besides the bus terminal block: 20 mm (recommended) Fig. 13: Installation position and minimum distances WARNING Observe the minimum separation distances according to IEC 60079-14! Observe the prescribed minimum separation distances between intrinsically safe and non-intrinsically safe circuits according to IEC 60079-14. Version: 1.0.0 ELX3252...
To mount the mounting rails with a height of 7.5 mm under the terminals and couplers, you should use flat mounting connections (e.g. countersunk screws or blind rivets). ELX3252 Version: 1.0.0...
During the design of a bus terminal block, the pin assignment of the individual Bus Terminals must be taken account of, since some types (e.g. analog Bus Terminals or digital 4-channel Bus Termi- nals) do not or not fully loop through the power contacts. Version: 1.0.0 ELX3252...
Ultrasonically "bonded" (ultrasonically welded) conductors Ultrasonically “bonded" conductors It is also possible to connect the Standard and High Density Terminals with ultrasonically "bonded" (ultrasonically welded) conductors. In this case, please note the tables concerning the wire-size width below! ELX3252 Version: 1.0.0...
Wire stripping length 8 ... 9 mm 8 ... 9 mm NOTE Maximum screwdriver width for ELX9560 Use a screwdriver with a maximum width of 2 mm to wire the ELX9560 power supply terminal. Wider screwdrivers can damage the terminal points. Version: 1.0.0 ELX3252...
In any case, make sure that the galvanic isolation made by the ELX9560 between the 24 V Ex busbar (power contacts +24 V Ex and 0 V Ex) and other system potentials (if applicable also functional or protec- tive earths) is not removed. ELX3252 Version: 1.0.0...
Mounting and wiring 3.6.5 Contact assignment Fig. 19: ELX3252 - Contact assignment Terminal point Description Name potentiometer 1, feed A potentiometer 1, tab potentiometer 2, tab potentiometer 2, feed A potentiometer 1, feed B not implemented not implemented potentiometer 2, feed B Version: 1.0.0...
Page 27
Fault indication in the event of broken wire or undershooting or overshooting of the measuring range for channel 1 Error LED2 red Fault indication in the event of broken wire or undershooting or overshooting of the measuring range for channel 2 ELX3252 Version: 1.0.0...
Beckhoff EtherCAT modules are intended for use with Beckhoff’s UL Listed EtherCAT Sys- tem only. Examination For cULus examination, the Beckhoff I/O System has only been investigated for risk of fire and electrical shock (in accordance with UL508 and CSA C22.2 No. 142). For devices with Ethernet connectors Not for connection to telecommunication circuits.
Group A, B, C, D or in non-explosive areas! WARNING Consider the Control Drawing ELX documentation! When installing the I/O modules of the ELX series, be sure to read the Control Drawing ELX documentation, which is available for download on https://www.beckhoff.de/english/ download/ethercat.htm! ELX3252 Version: 1.0.0...
Beckhoff's branch offices and representatives Please contact your Beckhoff branch office or representative for local support and service on Beckhoff products! The addresses of Beckhoff's branch offices and representatives round the world can be found on her internet pages: http://www.beckhoff.com You will also find further documentation for Beckhoff components there.
