Operating manual | EN
ELX3152 and ELX3158
Two- and eight-channel analog input terminals, 0/4 ... 20 mA,
single ended, 16 Bit, Ex i
2020-10-08 | Version: 2.0.0

Advertisement

Table of Contents
loading

Summary of Contents for Beckhoff ELX3152

  • Page 1 Operating manual | EN ELX3152 and ELX3158 Two- and eight-channel analog input terminals, 0/4 … 20 mA, single ended, 16 Bit, Ex i 2020-10-08 | Version: 2.0.0...
  • Page 3: Table Of Contents

    Wiring.......................... 24 3.6.3 Proper line connection .....................  26 3.6.4 Shielding and potential separation...................  26 3.6.5 ELX3152 - Contact assignment .................. 27 3.6.6 ELX3158 - Contact assignment .................. 29 4 Appendix .............................. 31 EtherCAT AL Status Codes ...................... 31 UL notice ............................ 31 FM notice ............................ 32 Support and Service ........................ 33...
  • Page 4 Table of contents Version: 2.0.0 ELX3152 and ELX3158...
  • Page 5: Foreword

    EP1590927, EP1789857, EP1456722, EP2137893, DE102015105702 with corresponding applications or registrations in various other countries. ® EtherCAT is registered trademark and patented technology, licensed by Beckhoff Automation GmbH, Germany. Copyright © Beckhoff Automation GmbH & Co. KG, Germany. The reproduction, distribution and utilization of this document as well as the communication of its contents to others without express authorization are prohibited.
  • Page 6: Safety Instructions

    All the components are supplied in particular hardware and software configurations appropriate for the application. Modifications to hardware or software configurations other than those described in the documentation are not permitted, and nullify the liability of Beckhoff Automation GmbH & Co. KG. Personnel qualification This description is only intended for trained specialists in control, automation and drive engineering who are familiar with the applicable national standards.
  • Page 7: Documentation Issue Status

    • Chapter Marking of ELX-Terminals updated 1.0.0 • Chapter Intended use updated • Technical data updated • Mounting and wiring updated • Chapter Intended use added • Mounting and wiring updated • First preliminary version ELX3152 and ELX3158 Version: 2.0.0...
  • Page 8: Marking Of Elx Terminals

    • Beckhoff Traceability Number, or BTN for short (as a serial number it clearly identifies each terminal) Date code The date code is an eight-digit number given by Beckhoff and printed on the ELX terminal. The date code indicates the build version in the delivery state and thus identifies an entire production batch, but does not distinguish between the terminals in a batch.
  • Page 9: Fig. 1 Elx2008-0000 With Date Code 2519Hmhm, Btn 0001F6Hd And Ex Marking

    Foreword Beckhoff Traceability Number (BTN) In addition, each ELX terminal has a unique Beckhoff Traceability Number (BTN). Ex marking The Ex marking can be found at the top left on the terminal: II 3 (1) G Ex ec [ia Ga] IIC T4 Gc...
  • Page 10: Fig. 2 Elx9560-0000 With Date Code 12150000, Btn 000B000 And Ex Marking

    Foreword Fig. 2: ELX9560-0000 with date code 12150000, BTN 000b000 and Ex marking Version: 2.0.0 ELX3152 and ELX3158...
  • Page 11: Fig. 3 Elx9012 With Date Code 12174444, Btn 0000B0Si And Ex Marking

    Foreword Fig. 3: ELX9012 with date code 12174444, BTN 0000b0si and Ex marking ELX3152 and ELX3158 Version: 2.0.0...
  • Page 12: Product Overview

    Fig. 4: ELX3152 - Two channel, analog input terminal, 0/4 … 20 mA, single ended, 16 bit, Ex i The ELX3152 analog input terminal is suitable for operation in zone 2 and in not explosive areas. It allows the direct connection of intrinsically safe field devices located in hazardous areas classified Zone 0/20 or 1/21.
  • Page 13: Elx3158 - Introduction

    Zone 0/20 or 1/21. It supplies measuring transducers in the field and transmits their analog measuring signals, electrically isolated, to the automation device. Overload and wire breakage are indicated by the error LEDs. ELX3152 and ELX3158 Version: 2.0.0...
  • Page 14: Technical Data

    CE, UL, ATEX, IECEx, cFMus CE, ATEX, IECEx *) With a technical measuring range of 107% of the nominal range, the terminal also supports commissioning with sensor values in the limit range and an evaluation according to NAMUR NE43. Version: 2.0.0 ELX3152 and ELX3158...
  • Page 15: Intended Use

    The ELX components may only be used in accordance with the ATEX directive and the IECEx scheme! The ELX terminals extend the field of application of the Beckhoff bus terminal system with functions for integrating intrinsically safe field devices from hazardous areas. The intended field of application is data acquisition and control tasks in discrete and process engineering automation, taking into account explosion protection requirements.
  • Page 16: Mounting And Wiring

    Special conditions of use for ELX terminals WARNING Observe the special conditions of use for the intended use of Beckhoff ELX terminals in potentially explosive areas (ATEX directive 2014/34/EU)! • The certified components are to be installed in a suitable housing that guarantees an ingress protection of at least IP54 in accordance with EN 60079-0 and EN 60529! The prescribed environmental conditions...
  • Page 17 1 to 8 on the left above the respective terminal point as well as via the laser image. Observe any possible polarity dependency of connected intrinsically safe circuits! ELX3152 and ELX3158 Version: 2.0.0...
  • Page 18: Arrangement Of Elx Terminals Within A Bus Terminal Block

    • The last terminal of each ELX segment is to be covered by an ELX9012 bus end cover, unless two ELX9410 power supply terminals are installed in direct succession for continuing the same terminal seg- ment with standard Beckhoff EtherCAT terminals (e.g. EL/ES/EK)! Examples for the arrangement of ELX terminals Fig. 6: Valid arrangement of the ELX terminals (right terminal block).
  • Page 19: Fig. 9 Valid Arrangement - Elx9410 In Front Of An Elx9560 Power Supply Terminal

    Fig. 11: Invalid arrangement - terminal that does not belong to the ELX series within the ELX terminal segment. Fig. 12: Invalid arrangement - second ELX9560 power supply terminal within the ELX terminal segment without an upstream ELX9410. ELX3152 and ELX3158 Version: 2.0.0...
  • Page 20: Fig. 13 Invalid Arrangement - Missing Elx9012 Bus End Cover

    ELX9560 power supply terminal in accordance with the specified technical data. If required, an additional power supply terminal ELX9560 with an upstream ELX9410 connected (see mounting examples) must be installed or a completely new terminal block must be assembled. Version: 2.0.0 ELX3152 and ELX3158...
  • Page 21: Installation Position And Minimum Distances

    • besides the bus terminal block: 20 mm (recommended) Fig. 14: Installation position and minimum distances WARNING Observe the minimum separation distances according to IEC 60079-14! Observe the prescribed minimum separation distances between intrinsically safe and non-intrinsically safe circuits according to IEC 60079-14. ELX3152 and ELX3158 Version: 2.0.0...
  • Page 22: Installation Of Elx Terminals On Mounting Rails

    To mount the mounting rails with a height of 7.5 mm under the terminals and couplers, you should use flat mounting connections (e.g. countersunk screws or blind rivets). Version: 2.0.0 ELX3152 and ELX3158...
  • Page 23: Connection

    Bring the bus terminal system into a safe, powered down state before starting installation, disassembly or wiring of the bus terminals! The terminals of ELXxxxx series include electronics and connection level in a single enclosure. ELX3152 and ELX3158 Version: 2.0.0...
  • Page 24: Wiring

    3.6.2 Wiring WARNING Risk of electric shock and damage of device! Bring the bus terminal system into a safe, powered down state before starting installation, disassembly or wiring of the Bus Terminals! Version: 2.0.0 ELX3152 and ELX3158...
  • Page 25: Fig. 17 Standard Wiring

    The cables are released, as usual, using the contact release with the aid of a screwdriver. See the following table for the suitable wire size width. ELX3152 and ELX3158 Version: 2.0.0...
  • Page 26: Proper Line Connection

    In any case, make sure that the galvanic isolation made by the ELX9560 between the 24 V Ex busbar (power contacts +24 V Ex and 0 V Ex) and other system potentials (if applicable also functional or protec- tive earths) is not removed. Version: 2.0.0 ELX3152 and ELX3158...
  • Page 27: Elx3152 - Contact Assignment

    Mounting and wiring 3.6.5 ELX3152 - Contact assignment Fig. 20: ELX3152 - Contact assignment Terminal point Description Name Supply voltage for channel 1 Ground for channel 1 (for using a 3-wire connection) Input 1 Signal input channel 1 not implemented Supply voltage for channel 2...
  • Page 28 Fault indication in the event of broken wire or undershooting or overshooting of the measuring range for channel 1 Error Ch 2 red Fault indication in the event of broken wire or undershooting or overshooting of the measuring range for channel 2 Version: 2.0.0 ELX3152 and ELX3158...
  • Page 29: Elx3158 - Contact Assignment

    Supply voltage for channel 3 Supply voltage for channel 5 Supply voltage for channel 7 Supply voltage for channel 2 Supply voltage for channel 4 Supply voltage for channel 6 Supply voltage for channel 8 ELX3152 and ELX3158 Version: 2.0.0...
  • Page 30 Fault indication in the event of broken wire or undershooting or overshooting of the measuring range for channel 7 Error Ch 8 red Fault indication in the event of broken wire or undershooting or overshooting of the measuring range for channel 8 Version: 2.0.0 ELX3152 and ELX3158...
  • Page 31: Appendix

    Beckhoff EtherCAT modules are intended for use with Beckhoff’s UL Listed EtherCAT Sys- tem only. Examination For cULus examination, the Beckhoff I/O System has only been investigated for risk of fire and electrical shock (in accordance with UL508 and CSA C22.2 No. 142). For devices with Ethernet connectors Not for connection to telecommunication circuits.
  • Page 32: Fm Notice

    Group A, B, C, D or in non-explosive areas! WARNING Consider the Control Drawing ELX documentation! When installing the I/O modules of the ELX series, be sure to read the Control Drawing ELX documentation, which is available for download on https://www.beckhoff.de/english/ download/ethercat.htm! Version: 2.0.0 ELX3152 and ELX3158...
  • Page 33: Support And Service

    Beckhoff's branch offices and representatives Please contact your Beckhoff branch office or representative for local support and service on Beckhoff products! The addresses of Beckhoff's branch offices and representatives round the world can be found on her internet pages: http://www.beckhoff.com You will also find further documentation for Beckhoff components there.
