- Page 1 Operating manual | EN ELX2792 Two Channel Relais Output Terminal, Solid State, potential free, Ex i 2023-05-09 | Version: 1.0.0...
-
Page 3: Table Of Contents
Wiring .......................... 24 3.7.3 Proper line connection ..................... 25 3.7.4 Shielding and potential separation ................... 25 3.7.5 ELX2792 - Connection and LEDs .................. 26 4 Appendix .............................. 27 EtherCAT AL Status Codes ...................... 27 UL notice ............................ 27 Support and Service........................ 28 ELX2792... - Page 4 Table of contents Version: 1.0.0 ELX2792...
-
Page 5: Foreword
, XTS and XPlanar are registered trademarks of and licensed by Beckhoff Automation GmbH. Other designations used in this publication may be trademarks whose use by third parties for their own purposes could violate the rights of the owners. Patent Pending... -
Page 6: Safety Instructions
All the components are supplied in particular hardware and software configurations appropriate for the application. Modifications to hardware or software configurations other than those described in the documentation are not permitted, and nullify the liability of Beckhoff Automation GmbH & Co. KG. Personnel qualification This description is only intended for trained specialists in control, automation and drive engineering who are familiar with the applicable national standards. -
Page 7: Documentation Issue Status
Foreword Documentation Issue Status Version Comment 1.0.0 • Document structure updated • Corrections • First draft ELX2792 Version: 1.0.0... -
Page 8: Marking Of Elx Terminals
• Beckhoff Traceability Number, or BTN for short (as a serial number it clearly identifies each terminal) Date code The date code is an eight-digit number given by Beckhoff and printed on the ELX terminal. The date code indicates the build version in the delivery state and thus identifies an entire production batch but does not distinguish between the terminals in a batch. -
Page 9: Fig. 1 Elx2008-0000 With Date Code 2519Hmhm, Btn 0001F6Hd And Ex Marking
Foreword Beckhoff Traceability Number (BTN) In addition, each ELX terminal has a unique Beckhoff Traceability Number (BTN). Ex marking The Ex marking can be found at the top left on the terminal: II 3 (1) G Ex ec [ia Ga] IIC T4 Gc... -
Page 10: Fig. 2 Elx9560-0000 With Date Code 12150000, Btn 000B000 And Ex Marking
Foreword Fig. 2: ELX9560-0000 with date code 12150000, BTN 000b000 and Ex marking Version: 1.0.0 ELX2792... -
Page 11: Fig. 3 Elx9012 With Date Code 12174444, Btn 0000B0Si And Ex Marking
Foreword Fig. 3: ELX9012 with date code 12174444, BTN 0000b0si and Ex marking ELX2792 Version: 1.0.0... -
Page 12: Product Overview
Fig. 4: ELX2792 - 2-channel relay output terminal, solid state, potential-free, Ex i The ELX2792 output terminal has two solid state relays, each of which is a changeover contact. Intrinsically safe loads can thus be switched up to zone 0/20. These could be ohmic loads, solenoid valves, contactors or optical/acoustic signal devices. -
Page 13: Technical Data
Product overview Technical data Technical data ELX2792-0000 Technology Semiconductor output Number of outputs Connection technology 2-wire Switching voltage max. 30 V max. 30 V (taking into account IEC 60079-11) Ohmic switching current max. 0.5 A max. 1 A (taking into account IEC 60079-11) Power supply of the electronics from the E-bus (5 V... -
Page 14: Intended Use
The ELX components may only be used in accordance with the ATEX directive and the IECEx scheme! The ELX terminals extend the field of application of the Beckhoff bus terminal system with functions for integrating intrinsically safe field devices from hazardous areas. The intended field of application is data acquisition and control tasks in discrete and process engineering automation, taking into account explosion protection requirements. -
Page 15: Mounting And Wiring
Special conditions of use for ELX terminals WARNING Observe the special conditions of use for the intended use of Beckhoff ELX terminals in potentially explosive areas (ATEX directive 2014/34/EU)! • The certified components are to be installed in a suitable housing that guarantees an ingress protection of at least IP54 in accordance with EN 60079-0 and EN 60529! The prescribed environmental conditions... - Page 16 1 to 8 on the left above the respective terminal point as well as via the laser image. Observe any possible polarity dependency of connected intrinsically safe circuits! Version: 1.0.0 ELX2792...
-
Page 17: Arrangement Of Elx Terminals Within A Bus Terminal Block
• The last terminal of each ELX segment is to be covered by an ELX9012 bus end cover, unless two ELX9410 power supply terminals are installed in direct succession for continuing the same terminal segment with standard Beckhoff EtherCAT terminals (e.g. EL/ES/EK)! Examples for the arrangement of ELX terminals Fig. 5: Valid arrangement of the ELX terminals (right terminal block). -
Page 18: Fig. 8 Valid Arrangement - Elx9410 In Front Of An Elx9560 Power Supply Terminal
Fig. 9: Invalid arrangement - missing ELX9560 power supply terminal. Fig. 10: Invalid arrangement - terminal that does not belong to the ELX series within the ELX terminal segment. Fig. 11: Invalid arrangement - second ELX9560 power supply terminal within the ELX terminal segment without an upstream ELX9410. Version: 1.0.0 ELX2792... -
Page 19: Fig. 12 Invalid Arrangement - Missing Elx9012 Bus End Cover
ELX9560 power supply terminal in accordance with the specified technical data. If required, an additional power supply terminal ELX9560 with an upstream ELX9410 connected (see mounting examples) must be installed or a completely new terminal block must be assembled. ELX2792 Version: 1.0.0... -
Page 20: Installation Position And Minimum Distances
• besides the bus terminal block: 20 mm (recommended) Fig. 13: Installation position and minimum distances WARNING Observe the minimum separation distances according to IEC 60079-14! Observe the prescribed minimum separation distances between intrinsically safe and non-intrinsically safe circuits according to IEC 60079-14. Version: 1.0.0 ELX2792... -
Page 21: Installation Of Elx Terminals On Mounting Rails
To mount the mounting rails with a height of 7.5 mm under the terminals and couplers, you should use flat mounting connections (e.g. countersunk screws or blind rivets). ELX2792 Version: 1.0.0... -
Page 22: Disposal
Products marked with a crossed-out wheeled bin shall not be discarded with the normal waste stream. The device is considered as waste electrical and electronic equipment. The national regulations for the disposal of waste electrical and electronic equipment must be observed. Version: 1.0.0 ELX2792... -
Page 23: Connection
Ultrasonically "bonded" (ultrasonically welded) conductors Ultrasonically “bonded" conductors It is also possible to connect the Standard and High Density Terminals with ultrasonically "bonded" (ultrasonically welded) conductors. In this case, please note the tables concerning the wire-size width below! ELX2792 Version: 1.0.0... -
Page 24: Wiring
Wire stripping length 8 ... 9 mm 8 ... 9 mm NOTICE Maximum screwdriver width for ELX9560 Use a screwdriver with a maximum width of 2 mm to wire the ELX9560 power supply terminal. Wider screwdrivers can damage the terminal points. Version: 1.0.0 ELX2792... -
Page 25: Proper Line Connection
In any case, make sure that the galvanic isolation made by the ELX9560 between the 24 V Ex busbar (power contacts +24 V Ex and 0 V Ex) and other system potentials (if applicable also functional or protective earths) is not removed! ELX2792 Version: 1.0.0... -
Page 26: Elx2792 - Connection And Leds
Mounting and wiring 3.7.5 ELX2792 - Connection and LEDs Fig. 19: ELX2792 - Connection and LEDs Connection Terminal point Description Name Channel 1: NO contact Channel 1: Common contact Channel 1: NC contact not connected Channel 2: NO contact Channel 2: Common contact... -
Page 27: Appendix
The modules are intended for use with Beckhoff’s UL Listed EtherCAT System only. Examination For cULus examination, the Beckhoff I/O System has only been investigated for risk of fire and electrical shock (in accordance with UL508 and CSA C22.2 No. 142). For devices with Ethernet connectors Not for connection to telecommunication circuits. -
Page 28: Support And Service
Please contact your Beckhoff branch office or representative for local support and service on Beckhoff products! The addresses of Beckhoff's branch offices and representatives round the world can be found on her internet pages: www.beckhoff.com You will also find further documentation for Beckhoff components there. - Page 29 ELX9560-0000 with date code 12150000, BTN 000b000 and Ex marking........Fig. 3 ELX9012 with date code 12174444, BTN 0000b0si and Ex marking .......... Fig. 4 ELX2792 - 2-channel relay output terminal, solid state, potential-free, Ex i......... Fig. 5 Valid arrangement of the ELX terminals (right terminal block)............. Fig. 6 Valid arrangement - terminals that do not belong to the ELX series are set before and after the ELX terminal segment.
- Page 31 More Information: www.beckhoff.com/ELX2792 Beckhoff Automation GmbH & Co. KG Hülshorstweg 20 33415 Verl Germany Phone: +49 5246 9630 info@beckhoff.com www.beckhoff.com...
